Side 1/7
GB
User Manual
CONTROL PANEL
1. ON/OFF button
2. START/PAUSE button and indicator light
3. TEMPERATURE button
4. DISPLAY
5. OPTIONS button
6. DRYING ONLY button
7. buttonDRYING
8. DELAYED START button
9. SPIN button
10. WASH CYCLE SELECTOR KNOB
11. PUSH & GO button
WASH CYCLE TABLE
Prior to using the appliance, carefully read the .Safety and installation instructions
Prior to using the appliance, the bolts used for transport must be removed. For detailed
instructions on the removal procedure, consult the safety and installation instructions.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
1
10
2 3
5
89
11
4
6
7
For all testing institutes:
2) Long cotton cycle: set programme 6 at temperature 40°C.
3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.
* By selecting the cycle and excluding the spin cycle, the washer-dryer will drain only.
** The duration of the wash cycles can be checked on the display.
*** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60 (Wash) - Test wash cycle in compliance with EU Ecodesign regulation
2019/2014. The most ecient programme in terms of energy and water consumption for
washing normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in
the table.
5) Eco 40-60 (Wash & Drying)-
Test
wash and
drying cycle in compliance with EU
Ecodesign regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash
programme and set option level to
“ ”.
The most ecient programme in terms of energy
and water consumption for washing and drying normally soiled cotton laundry. At the end of
cycle the garments can be immediately stored to the cupboard.
DETERGENT DISPENSER DRAWER
Compartment 1:
Do not insert detergent in this compartment.
Compartment 2: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, insert the partition
into slot .B
Compartment 3: Additives (fabric softener, etc.)
The fabric softener must never exceed the “max”
level indicated on the central pin.
! The detergent drawer is suitable only for Liquid
and Powder detergent. No Capsule detergent allowed.
The Capsule detergent have to be placed into the drum before the load.
Make sure to use the correct Capsule detergent dosage amount
recommended by Manufacturer.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
! To remove the drawer, press lever and pull the drawer outwards.C
C
Maximum load 9 kg
Power input in o mode 0.5 W / in left-on mode 8 W Detergents and
Additives Recommended
detergent
Residual
dampness %
(***)
Energy
consumption
kWh
Total water lt
Laundry
temperature °C
Wash cycle Temperature Max.
spin speed
(rpm)
Max.
load for
washing
(kg)
Duration
(h : m)
Drying
Max.
load for
drying
(kg)
Wash Fabric
softener
Powder
Liquid
Capsule
(4)
Setting Range 2 3
1Mixed 30 °C 1200 3.530 °C ** – – –– – – – –
2Shirt 40 °C - 40 °C 600 2 ** – – – – – – –
3ARIEL PODS 30 °C 1000 4.530 °C ** – – – – – – – – –
4 Wool 40 °C - 40 °C 800 2 ** 2 ––– – – –
5 20°C 20 °C - 20 °C 1400 9 1:50 6 ––49 0.160 90 22
6 Cotton (2) 40 °C - 60 °C 1400 9 3:55 6 49 1.400 105 45
7 Synthetics (3) 40 °C - 60 °C 1200 4 2:55 4 35 0.800 55 43
8 Mixed 40 °C - 40 °C 1000 9 ** 6 –– – – –
9Eco 40-60 (1)
(Wash) 40 °C 40°C
1351 9 3:48
6
53 0.730 59 35
1351 4.5 2:54 53 0.515 57 32
1351 2.5 2:15 53 0.280 38 23
10 White 60 °C - 90 °C 1400 9 2:45 6 49 0.900 90 55
11 Rapid 15min 20 °C - 20 °C 1200 (****) 1.5 ** – – –– – – – –
12 Rapid 45min Full Load 40°C - 40°C 1200 9 ** – – ––– – – –
13 Wash & Dry 45min 30 °C 1400 1 **30 °C 1 –– – – – –
14 Delicates 30°C 30 °C - 30 °C 600 (****) 1 ** 1 –– – – – –
Rinse + Spin – – 1400 9 ** 6 – – – – – – – –
Spin + Drain * – – 1400 9 ** 6 – – – – – – – – –
Required dosage Optional dosage - 4) Minimum 30°C recommended for usage of Capsule detergent.
9Eco 40-60 (5)
(Wash&Drying) 40 °C 40 °C 1351 6 9:20 6 – 0 3.800 75 33
1351 3 5:10 3 – 0 1.980 47 32
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
