EN
Quick guide
THANK YOU FOR BUYING AN INDESIT PRODUCT
In order to receive a more complete assistance, please
register your product on www . indesit . com/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally lled
appliance. Position the antibacterial anti-odour lter in the fan as
demonstrated in the lter packaging (if available). If the audible signal
sounds, it means that the temperture alarm has intervened: press the
button to switch o the acoustic alarms.
CONTROL PANEL
1. Thermostat control reference
2. Freezer and refrigerator compartment
temperature knob
3. LED light bulb
1.
2.
3.
FREEZING FRESH FOOD
Place the fresh food to be frozen in the FREEZING ZONE in the freezer
compartment avoiding the direct contact with the food that is already
frozen. To optimize the freezing speed, the lower drawer can be
removed and the food can be placed directly on the bottom of the
compartment.
FAN*
You can turn the Fan on/o by pressing the button on the base (as
shown in the gure). If the ambient temperature
exceeds 27°C, or if drops of water are present on the
glass shelves, it is essential that the fan is on to ensure
the proper preservation of the food. Deactivation of the
fan allows energy consumption to be optimised.
FREEZER AND REFRIGERATOR COMPARTMENT TEMPERATURE
This Fridge/Freezer is switched on using the thermostat located inside
the refrigerator compartment. The temperature of both compartments
is adjusted by turning the thermostat knob.
Thermostat set to 1/2 : minimum refrigeration (less cold)
Thermostat set to 3-5 : medium refrigeration
Thermostat set to 6/7 : maximum refrigeration (colder)
Setting the Thermostat knob to • turns the whole appliance o (no
refrigeration, no light).
* Available only on certain models
