Control® SB2210
Professional Series – Dual 10” Compact Subwoofer
S P E C S H E E T
Key Features:
• 2 x 250 mm (10 in) woven fiberglass cone LF drivers
• 500 Watts power handling
• Frequency response down to 38 Hz
• 13 x M6 insert points including inserts for optional U-Bracket
• Compact, low-profile design
Description:
The Control SB2210 provides low frequency reinforcement for a wide variety of
sound system applications. Its compact size, high output and outdoor capable
design makes it one of the most versatile subwoofers in the installation market.
The internal angled baffle allows for a large port opening and compact front
dimensions without compromising driver size. The Control SB2210 produces warm,
punchy low-end sound.
The 250 mm (10 inch) diameter low-frequency drivers feature a long-excursion design and extended low-frequency performance. The driver’s woven fiberglass
cone delivers robust performance and the highly damped butyl rubber surround and linear suspension spider design provide clean sound quality with lower
distortion. The driver’s high temperature anodized aluminum voice coil former, voice coil wire, and adhesive ensure stable performance under long time high
power working condition. An FEA optimized motor construction reduces harmonic distortion while an aluminum conductive ring coupled to the outside of the pole
post reduces harmonic distortion.
Included with the Control SB2210 are four feet for floor and shelf placement. Thirteen M6 insert points allow for installation using forged shoulder eyebolts (with
included bevel washers) for suspending the subwoofer, or for mounting to a wall or ceiling via the optional MTC-210UB U-Bracket. The cabinet is available in
black or white (Control SB2210-WH) and is paintable. The thermoset composite-coated grille stands up to UV as well as humidity and direct exposure to water.
The grille is backed with a combination of materials that, while acoustically transparent, prevent the intrusion of water into the cabinet.
Specifications:
System
Frequency Range (-10 dB)138 Hz – 500 Hz
Frequency Response (-3 dB)148 Hz – 95 Hz
Power Rating2500W (2000W peak) Continuous Pink Noise (2 hrs)
1000W Continuous Program (2 hrs)
400W (1600W peak) Continuous Pink Noise (100 hrs)
Maximum Input Voltage 60.0VRMS (2 hrs), 120V peak
Sensitivity195 dB, 1W @ 1m in half-space (2pi loading, average
50 – 90 Hz)
Max SPL3122 dB in half-space (2pi loading)
Nominal Impedance 8Ω
Minimum Impedance 7.2 at 160 HzΩ
Recommended Filter 45 Hz, 24 dB/oct high-pass filter
Transducers
Low Frequency Two 250 mm (10 inch) diameter LF drivers, long-
excursion design, woven fiberglass cone, highly damped
butyl rubber surround, linear suspension spider , high
temperature anodized aluminum voice coil former, high-
temp voice coil wire and coil adhesive, FEA optimized
motor construction, aluminum conductive ring.
Physical
Enclosure Material High Impact Polystyrene (HIPS) w/ 10% glass fill and
internal 8 mm polyurethane co-mold, painted with
highly-UV-resistant paint on white (-WH) model for
maximum UV fade resistance.
Grille Thermoset composite coated steel, zinc-plated, 3-layer
foam backing.
Environmental IP-45 rating per IEC529 when installed with included
MTC-PC2 terminal panel cover. Exceeds MilSpec 810
for humidity, salt spray, temperature & UV. Passes Mil-
STd-202F for salt spray.
Terminals Screw-down terminal strip, zinc plated copper base,
nickel-plated metal screws/washers. Accepts up to 9
mm outside, 4 mm inside open lug (#6, #8 or #10 lug),
plus bare wire (up to 12 AWG/2.5mm2). Included MTC-
PC2 and optional MTC-PC3 protective covers available
to provide sealed entrance for additional weather
protection.
Agency Rating ROHS-compliant. Optional MTC-SBT300 transformer is
UL recognized per UL1876.
Colors Black or white (-WH)
Dimensions (H x W x D) 355 x 590 x 570 mm (14 x 23.3 x 22.5 in.)
Net Weight 23.31 kg (51.4 lb)
Shipping Weight 25.85 kg (57.0 lb)
Included Accessories »1 pc MTC-PC2 input panel cover, 4 pcs floor standing
feet 4 pcs beveled washers
Optional Accessories »MTC-210UB (&-WH) U-Bracket
»
MTC-SBT300 70V/100V Transformer, 300W multi-tap,
installs onto inside of back input panel using included
4 studs
Transformer Taps 70V: 300W, 150W, 75W, 38W
100V: 300W, 150W, 75W
1 Continuous Pink Noise rating is IEC-shaped pink noise with a 6 dB crest factor.
Continuous Program Power is defined as 3 dB above the Continuous Pink Noise Rating.
2 Half-space, (2pi, as when on the floor)
3 Calculated from sensitivity and power handling, exclusive of power compression
JBL continually engages in research related to product improvement. Some materials,
production methods and design refinements are introduced into existing products
without notice as a routine expression of that philosophy. For this reason, any current
JBL product may differ in some respect from its published description, but will always
equal or exceed the original design specifications unless otherwise stated.
