HANDLE AND BRAND BADGE INSTALLATION
Once the undercounter appliance has been completely installed, follow these instructions to
replace the factory installed handle and badge with the handle and badge in this kit.
Parts and Tools Included:
Tools Needed:
Replace Handle
NOTES:
■ To avoid scratching the door, place a soft cloth against the door while removing the
factory installed handle and installing the alternative handle.
■ Save the hex key and all instructions.
1. Remove the hex key wrench from the hardware bag.
2. While holding the handle, insert the short end of the hex key into a hole in the underside of
the handle. Using a right to left motion, loosen the setscrew. ❶
3. Repeat steps 1 and 2 to loosen the second setscrew. Pull the handle away from the door
or drawer.
4. With the setscrews facing down, place the new handle on the mounting studs so that the
base of the handle is flush against the front panel.
5. Insert the short end of the hex key into the handle to engage the setscrew. Using a left to
right motion, tighten the setscrew. ❷
6. Repeat steps 3 and 4 to fasten the second setscrew. When the screws feel tight, tighten
them an additional quarter-turn.
Replace Brand Badge
1. Using the tool (provided), lift up the right-hand side of the badge and peel it from right to
left away from the door.
NOTE: To avoid scratching the door, do not use a sharp or metallic object to pry the
brand badge from the door.
2. Rub a small amount of liquid dish soap over any adhesive residue with your fingers. Rinse
the door with warm water and dry with a soft cloth.
3. Cut the template along the dotted lines that match the shape of the brand badge.
4. Align the edges of the template with the bottom and right-hand side edges of the door.
Tape the template to the door. Remove the tape from the back of the brand badge. ❸
5.
Using the cutout as a guide, press the brand ba
dge onto the door making sure the hole is
completely covered. Remove the template.
A. Mounting stud
Perno de montaje
Goujon de montage
B. Door handle
Manija de la puerta
Poignée de porte
C. Setscrew (inside handle standoff)
Tornillo opresor (en el interior del soporte de la manija
Vis de blocage (à l'intérieur du pied de la poignée)
D. Hex key
Llave hexagonal
Clé à tête hexagonale
❷❶ ❸
W10586889A
■ Handle
■ Extra setscrew
■ Brand badge template (last page of
instructions)
■ Brand badge
■ Brand badge removal tool
■ Hex key wrench
■ ■Masking tape Scissors
