GC-61 GSM communicator 1 / 1 MHZ51105
The GC-61 GSM communicator
Installation manual
The GC-61 communicator is designed for communication with an
alarm receiving centre via a GSM network. The communicator receives
data from a control panel via a simulated telephone line. Report codes
are transmitted from a control panel to the GC-61 in Contact ID format.
A SIM card determines the GSM network used. This manual is valid for
version HZ61008.
The GSM module, when installed in the alarm control panel, enables:
• Data transfer to one or two Alarm Receiving Centres (ARC)
• Remote control and programming of the communicator via SMS
instruction messages from a mobile phone or from Jablotron’s SMS
website
• Programming of the communicator via Jablotron’s website
www.GSMlink.cz
• Phone calls using a telephone set attached to the communicator
(via the GSM network)
• An SMS terminal can be used for the easy and convenient
receiving and sending of SMS messages
1. Installation
The communicator can be installed into an alarm control panel or into
a metallic box with a TAMPER switch.
a) Disconnect the control panel’s power supply (both AC and
backup battery). If the control panel has been previously used
before this installation, enter programming mode before
disconnecting the power supply.
b) We recommend you to disable the SIM card PIN code protection
before you insert it into the dialler. Use a mobile phone to perform
this task (if you have a NOKIA phone, select: Menu, Settings,
Security settings, PIN code request, Off). If you insist on using a
PIN, enter PIN 1234.
c) Open the SIM card holder (by sliding it in the direction shown in
the figure 1 below and insert the SIM card into the holder and
close it by sliding it back.
d) Attach the communicator into the control panel case or metallic box
e) Connect the GSM antenna (never switch the power supply on
without a proper antenna)
f) Connect a telephone set to the PHONE connector (or to the
PHONE terminals) together with the SMS terminal if desired. Only
one telephone set can be attached to the dialler. The PHONE
output of the dialler should never be connected to any other
telephone network.
GC-61
connector
K1
GSM network
failure monitoring
telephone dialer
+12V
GND
INP
GSM ANTENNA
Figure. 1
g) The AUX output is switched on if the GSM network is not available
for 15 minutes. AUX can be used as an alarm terminal. (normally
open dry contact, max. 100mA / 60V) – see the figure 1
h) It is possible to connect an external device (tamper, alarm output
etc.) to the INP input. When activated (by disconnection from
GND), then an activation event will be sent to the ARC (in CID
protocol “1”) and a deactivation event will be sent after
reconnecting INP to the GND.
i) Connect the control panel’s power supply. The LED will start
flashing once every 2 seconds when it has successfully registered
to the GSM network (within 1 minute).
If the LED starts flashing quickly, the module was not able to connect
to the GSM network. In this case, switch off the control panel power.
Remove the SIM card and insert it into a mobile phone to confirm
whether it is possible to connect to the network at this location. You
can also select a desired network manually if this option is available.
Ensure that the SIM card does not request a PIN code (or the PIN
code is set to 1234) Once the SIM card works in the mobile phone,
insert it back into the GSM dialler and repeat step i). If the GSM signal
is weak in this area, change the location of the GSM antenna before
you try to re-establish the connection. The level of GSM signal can be
checked by the SMS command “DINFO”.
j) After connection to the GSM network you can call directly from the
attached telephone.
k) Set all the parameters for Alarm Receiving Centre communication.
l) Programming of the GSM dialler is possible by entering
programming sequences via a mobile phone or an attached SMS
terminal. The most convenient programming method however is via
the www.GSMlink.cz website.
2. Alarm Receiving Centre communication
setting:
The dialler can report events to two different Alarm Receiving
Centres (ARCs). Each ARC has its own setting sequences that differ in
parameter p (p=1 for ARC1 and p=2 for ARC2). Primary and backup
telephone or IP numbers can be set for each ARC. The dialler uses
Ademco Contact ID format and it is also equipped for the future use of
GPRS data transfers. The product is ready to report events to an ARC
based on either landline or GSM data transfer.
The GC-61 re-sends original report codes – the content is not modified
except the Account ID. The communicator forwards original CID
protocol report codes with separator constants 18 and 98 to the ARC
(the constants are converted to 18 during forwarding). Otherwise, their
contents are not altered except for the installation number, which is set
according to communicator settings. The time of a sent event is
generated by the GC-61. The system time is set when the first SMS is
received by GC-61.
Every SMS command must begin with a service access code.
Several setting sequences can be sent within a single SMS.
Sequences must be separated by a comma or space.
2.1. Digital dialler setting
The digital dialler must be set to:
format : Contact ID
ARC telephone number (DTMF): 002
2.2. GPRS setting
GPRS data communication can be used for transmitting events to an
ARC or for connection to the web page www.gsmlink.cz (see section
3). GPRS must be activated on the SIM card. It is also necessary to
set the name and APN in the communicator (for detailed information
ask your GSM provider).
GPRS xxx,yyy,zzz,
where:
xxx is the APN
yyy is a the user name (when not used, insert a space)
zzz is a password (when not used, insert a space)
Example: If the name and password are not required and the APN is
“internet”, then the sequence is: 0000 GPRS internet, , ,
2.3. Setting the service remote access code
PG0 xxxxxxxx
Where:
xxxxxxxx is a numerical code of 1 to 8 figures
Default setting: 0000 (4 zeros)
2.4. Entering ARC phone numbers (IP addresses)
Primary and back up telephone numbers can be entered for each
ARC:
Primary number: PG1p xx....x
Back up number: PG2p xx....x
where:
