Side 1/20

Refrigerant R410A

KWH20CRC

KWH20HRC

KWH26CRC

KWH26HRC

KWH39CRC

KWH39HRC

KWH53CRC

KWH53HRC

KWH62CRC

KWH62HRC

Window Wall (Electronic)

Room Air Conditioner

User Manual

CONTENTS

1. SAFETY PRECAUTIONS.................................................................

2. UNIT PARTS IDENTIFICATION.......................................................

3. OPERATING INSTRUCTIONS ........................................................

4. INSTALLATION INSTRUCTIONS.....................................................

5. TROUBLESHOOTING .....................................................................

Inside you will find many helpful hints on how to use and maintain your air

conditioner properly. Just a little preventive care on your part can save you

a great deal of time and money over the life of your air conditioner. You'll find

many answers to common problems in the chart of troubleshooting tips.

If you review the chart of Troubleshooting Tips first, you may not need to

call for service at all.

Contact the authorised service technician for repair or maintenance of this unit.

Contact the installer for installation of this unit.

The air conditioner is not intended for use by young children or infirmed persons

without supervision.

Young children should be supervised to ensure that they do not play with the

air conditioner.

If the power cord is to be replaced, replacement work shall be performed by

authorised personnel only.

Installation work must be performed in accordance with the national wiring

standards by authorised personnel only. Wrong connection can cause overheating

!CAUTION

Read This Manual

This air conditioner should be installed in accordance with AS/NZS 3000:2000

and your electricity suppliers rules.

There are local council rules regarding maximum allowable noise levels emitted

by air conditioners.

or fire.

Conditions of use 

This appliance is intended to be used in household and similar applications such as:

Staff kitchen areas in shops, offices and other working environments.

Farm houses.

By clients in hotels, motels and other residential type environments.



CAUTION

When the air filter is to be

removed, do not touch the

metal parts of the unit.

It may cause an injury.

Do not clean unit when

power is on as it may cause

fire and electric shock, it may

cause an injury.

Operation with windows

opened may cause wetting

of indoor and soaking of

household furniture.

When the unit is to be

cleaned, switch off, and turn

off the circuit breaker.

Stop operation and close

the window in storm or

hurricane.

Use caution when unpacking and

installing.

Do not clean the air

conditioner with water.

Water may enter the unit and

degrade the insulation. It may

cause an electric shock.

This could injure the pet or

plant.

It may cause electric shock

and damage.

Do not put a pet or house

plant where it will be

exposed to direct air flow.

Hold the plug by the head

of the power plug when

taking it out.

Ventilate the room well when

used together with a stove,

etc.

An oxygen shortage may occur.

Do not use this air conditioner to

preserve precision devices, food,

pets, plants, and art objects.

It may cause deterioration of

quality, etc.

It may cause failure of product

or fire.

Do not use for special

purposes.

Turn off the main power

switch when not using the

unit for a long time.

If water enters the unit, turn the unit off at the power

outlet and switch off the circuit breaker. Isolate

supply by taking the power-plug out and contact a

qualified service technician.

It may cause failure of

appliance or accident.

Appearance may be

deteriorated due to change

of product color or

scratching of its surface.

Do not place obstacles

around air-inlets or inside

of air-outlet.

Do not use strong deter-

gent such as wax or

thinner but use a soft cloth.

If bracket is damaged, there

is concern of damage due to

falling of unit.

There is danger of fire or

electric shock.

Ensure that the installation bracket of

the outdoor appliance is not damaged

due to prolonged exposure.

Do not place heavy object on the

power cord and ensure that the cord

is not compressed.

Operation without filters may

cause failure.

It contains contaminants and

could make you sick.

Always insert the filters

securely. Clean filter once

every two weeks.

Do not drink water drained

from air conditioner.

Sharp edges could cause injury. It may cause electric shock and damage.

Safety

Precautions Prior to Operation

Preparing for operation

Usage

Cleaning and maintenance

Service

Operating Temperature

1. Contact an installation specialist for installation.

2. Plug in the power plug properly.

3. Do not use a damaged or non-standard power cord.

4. Do not share the same outlet with other appliances.

5. Do not use an extension cord.

6. Do not start/stop operation by plugging/unplugging the power cord.

1. Exposure to direct airflow for an extended period of time could be hazardous

to your health. Do not expose occupants, pets, or plants to direct airflow for

extended periods of time.

2. Due to the possibility of oxygen deficiency, ventilate the room when used

together with stoves or other heating devices.

3. Do not use this air conditioner for non-specified special purposes (e.g.

Preserving precision devices, food, pets, plants, and art objects). Usage in

such a manner could harm such property.

1. Do not touch the metal parts of the unit when removing the filter. Injuries can

occur when handling sharp metal edges.

2. Do not use water to clean inside the air conditioner. Exposure to water can

destroy the insulation, leading to possible electric shock.

3. When cleaning the unit, first make sure that the power and circuit breaker are

turned off.

For repair and maintenance, contact your authorised service dealer.

COOLING MODE

INDOOR OUTDOOR

HEATING MODE

MAX. MIN. MAX. MIN.

32 C 17 C OO

27 C 10 C

43 C 17 C OO

24 C 1 C

MAX. MIN. MAX. MIN.

Note: Performance may be reduced outside of these operating temperatures.

CLOCK SWING

TIMER ON TIMER OFF

ENERGY

SAVER SLEEP

LIGHT

FAN ON OFF MODE

This mode is used to decrease the humidity in the room.

O O

The temperature setting are adjustable between 16 C to 30 C . Cooling begins

automatically when the room temperature is 1 C above the set point, and stops

when the room temperature is 1 C below the set point. The fan will not stop running.

O O

The temperature settings are adjustable between 16 C to 30 C in heating mode.

the fan speed is optional.

When heating stops, there may be a slight delay of 30 seconds for the fan

For the cooling only models, after selecting "AUTO" by "MODE" keypad,the unit

will select the appropriate operating mode from "FAN", "COOL" or "DRY" based upon

the temperature difference between the actual and desired room temperature.

For the cooling and heating models,after selecting "AUTO" by "MODE" keypad,the

unit will select the appropriate operating mode for Cool, Heat or Dry based upon the

temperature difference between the actual and desired room temperature.The default

is 20oC,the default cooling temperature set point is 25oC.

motor to stop.

Note: This Function can only be activated by remote control, Please refer to remote

operating instruction for more detail information

heating temperature set point

FILTER:

This feature is a reminder to clean the Air Filter (See Air Filter) for more efficient

operation.The light will illuminate after 250 hours of operation.To reset after cleaning

the filter, press the "FILTER" button and the light will go off.

DEFROST:

Under heating mode, when there is "H1" on the LED display indicates the unit is under

defrost function. In this case, any set on main unit or remote controller will not be

carried out until the defrost is completed.

FAILURE INDICATOR DISPLAY:

Indicates a malfunction of the indoor room temperature sensor

Indicates a malfunction of the evaporator temperature sensor

Indicates a malfunction of the outdoor condenser temperature sensor

When one of the above malfunctions occurs, turn off the unit, and check for

any obstructions. Restart the unit, if the malfunction is still present, turn off

the unit and unplug the power cord. Contact the manufacturer or its service

agents or a similar qualified person for service.

F 1F 1

F 2F 2

F 4F 4

LIGHT:

Turn the unit LED light on or off only.

ENERGY SAVER:

Activate the "ENERGY SAVER" mode.

CLOCK:

Press this button to set clock.

CLOCK SWING

TIMER ON TIMER OFF

ENERGY

SAVER SLEEP

LIGHT

FAN ON OFF MODE

(23 ft)

TIMER OFF:(only available when unit on)

Press the "TIMER OFF" button to activate the auto stop timer function. The method

of setting is the same as above for "TIMER ON".

TIMER ON :(only available when unit off)

Press the "TIMER ON" button to activate the auto start timer function. Auto start

can be set from 1/2-24 hours. At unit off, press "TIMER ON" button,"HOUR ON"

on the display will blink and during 5 seconds blinking, the value can be adjusted by

pressing " + " or " - " button, every press of this button, 1/2 hours will be increased or

decreased within 0-10 hours,one hour will be increased or decreased within 10-24 hours,

if continuously press the " + " or " - " button, 2 seconds later, the value will be changed

quickly.During blinking, press the "TIMER ON" button to confirm the time. After "TIMER ON"

set up, when repressing the "TIMER ON" button, the "TIMER ON" setting will be canceled.

In this mode, the fan will continue to run for 1 minute after compressor shuts off.

ENERGY SAVER:(only available in "COOLING" and "DRY" mode)

Press “ENERGY SAVER” to activate or disactivate the "ENERGY SAVER" Function.

Press +and - buttons simultaneously to lock or unlock the keypad. If the remote controller

is locked, the icon will be displayed on it, in that case, press any button, the mark will

flicker for three times. Repress the combination to unlock.

About switch between Fahrenheit and Centigrade

Under status of unit off, press "MODE" and " - " buttons simultaneously to switch ℃ and ℉.

INTRODUCTION FOR SPECIAL FUNCTION

ABOUT LOCK

Press this button at unit On, the light on the main unit will be turned on or off. Light On is

defaulted when power on.

LIGHT:

Press this button, the clock can be set up, icon blinks. Within 5 seconds, the value

can be adjusted by pressing " + " or " - " button, if continuously press this button for 2

seconds above, in every 1/2 seconds, one minute will be increased or decreased, if you

are still pressing the button after ten minutes increased or decreased, ten minutes will be

increased or decreased every 1/2 seconds. Druing blinking, repress the Clock button,

icon will be constantly displayed and it denotes the setting succeeded.

CLOCK

1. To avoid vibration and noise, make sure the unit is installed securely and firmly.

2. Install the unit where the sunlight does not shine directly on the unit.

If the unit receives direct sunlight, build an awning to shade the cabinet.

3. There should be no obstacle, such as a fence or wall, within 50cm from the back of the

cabinet because it will prevent heat radiation of the condenser.

Restriction of outside air will greatly reduce the cooling and heating (reverse cycle models

only) efficiency of the air conditioner.

4. Install the unit with a slight angle down towards the rear to allow condensate to run to the

(about 10mm or 1/4 bubble with level).

5. Install the unit with its bottom portion 75~150cm above the floor level.

6. The power cord must be connected to an independent circuit. The yellow/green wire must

be earthed.

7. In some light construction walls there may be a requirement for the addition of a foam or

rubber strip between the air conditioner housing and the wall cavity. The addition of a foam

or rubber strip will assist in isolating transmission of normal operation vibration into the wall.

rear of the air conditioner

Over 50cm

About 10mm

FENCE

AWNING

75-150cm

Over 50cm

About 10mm

FENCE

AWNING

75-150cm

All side louvres of the cabinet must not be obstructed and must be positioned outside of

the structure.

CAUTION

Select the best location

INSTALLATION INSTRUCTIONS

Installations of the unit into the wall

AIR IN

AIR OUT

100mm minimum

OPTION A

AIR IN

LOUVRE

BRICK

WALL

45 BRICK CUT AWAY

TO CLEAR LOUVRES

FRONT

AIR OUT

AIR INAIR IN

TOP

VIEW

45 BRICK CUT AWAY

TO CLEAR LOUVRES

100mm

BRICK

WALL

100mm

OPTION B

Installation of the unit into the Housing

1. Remove the front panel as per the installation instruction

and slide the unit into the housing until it is firmly against

the rear of the housing. Care is required to ensure the foam

sealing strips on the inside of the housing remain in position.

2. Connect the air conditioner to the power and position

excess cord length beneath the air conditioner base.

3. Engage the chassis fixing brackets into the bottom housing

rail and secure to the base with the screw provided.

4. Re-install the front panel as per the installation instruction.

5. Switch the unit on. Check for operation of the unit and

check for vibration in the installation.

6. Fit the drain pan to the housing and run a drain line to a

suitable location if required.

Alternative method of installation if external

support cannot be provided.

FLASH OR SEAL AROUND EXTERNAL

WALL FRAME OR ARCHITRAVE

STURDY TIMBER

FRAME

TIMBER FRAMED

WALL OR PARTITION

SOLID TIMBER SUPPORT

STEADYING BRACKET

(ONE PER SIDE)

DRAIN PAN

ENSURE LOUVRES

ARE ENTIRELY

OUTSIDE THE WALL

Hole in the wall

Unit housing

Foam strip

Step 1

Remove the air conditioner from it's packaging, remove fixing

screws and slide the air conditioner out of it's housing (Refer

to Installation Steps).

Step 2

Prepare the hole in the wall so that the bottom of the housing

is well supported, the top has minimum clearance and the air

inlet louvres have clearance as shown in options A and B.

Holes from the outside through to the cavity should be sealed.

The housing should slope down towards the rear by about

10mm to allow water formed during operation to drain.

Step 3

Install the housing into the wall and secure. Ensure the

foam seals are not damaged. Flash, seal or fill gaps

around the inside and outside to provide satisfactory

appearance and protection against the weather, insects

and rodents.

Note: To assist in isolating transmission of normal operation

vibration into the wall, use the foam strip.

Fit the foam strip between the air conditioner housing and

the wall cavity.

Installation of the Housing

NOTE: UNIT MAY BE SUPPORTED BY A

SOLID FRAME FROM BELOW OR

BY A HANGER FROM A SOLID

OVERHEAD SUPPORT.

Preferred method of installation into a timber

framed wall, partition or window.

FLASH OR SEAL AROUND EXTERNAL

WALL FRAME OR ARCHITRAVE

STURDY TIMBER

FRAME ALL

AROUND UNIT

TIMBER FRAMED

WALL OR PARTITION

EXTERNAL SUPPORT

FRAME AT BALANCE

POINT OF A/C

ALTERNATIVELY, BRACKETS

AS ILLUSTRATED IN FOLLOWING

DIAGRAM MAY BE USED.

DRAIN PAN

1. Remove the one fixing screws from the frame (See Fig.5).

2. Grasp the left corner of the frame's underside, then loosen the frame and carefully disconnect

the connector (See Fig.6).

1. Hold the slot under the front panel, then uplift it outwards, and remove the front panel (See Fig.3).

2. Pinch the handle under the air filter and make the air filter arched, remove it from the slot from

underside to upside (See Fig.4).

Fig. 3 Fig. 4 Fig. 5

Fig. 6 Fig. 7 Fig. 8

In-line Connector

1. Remove the fixing screws on the chassis fixing brackets and remove the two screws on the

back of cabinet (If fitted. These screws are not needed to install in later installation), then

remove the chassis fixing brackets (See Fig.7).

2. Grasp the handle on the chassis and carefully slide the air conditioner out of the cabinet

(See Fig.8).

3. Push the unit chassis into the cabinet (See Fig.9).

4. Fix the chassis with the screws previously removed as they were prior to removal.

1. Install the frame making sure not to interfere with the

temperature sensor (See Fig.10).

2. Fix the screws on the frame (See Fig.5). For ≥ 3.5kW/h

models, the screws are supplied with the unit.

1. Install the air filter into the frame's slot from upside to

underside (See Fig.4).

2. Hang the front panel on the frame's buckle, then press the

front panel into the frame's slot until you hear a click (See Fig11).

Fig. 9 Fig. 10 Fig. 11

Abnormal Operation

TROUBLESHOOTING

Normal Operation

Air conditioner

does not cool or

heat as it should

Air conditioner

does not start

Air conditioner

freezing up

Problem Possible Causes What To Do

The air conditioner is

unplugged.

Make sure the air conditioner plug is

pushed completely into the outlet and

switched on.

Troubleshooting Tips

Save time and money! Review the chart below first and you may not need to call for service.

You may hear a pinging noise caused by water being picked up and thrown against the

condenser on rainy days or when the humidity is high. This design feature helps remove

moisture and improve cooling efficiency.

Water will collect in the base pan during high humidity or on rainy days. The water may

overflow and drip from the outdoor side of the unit.

The fan may continue to operate when the compressor has cycled off.

The fuse is blown/circuit

breaker is tripped.

Check the house fuse/circuit breaker box

and replace the fuse or reset the breaker.

Power failure.

If power failure occurs, switch off and

disconnect /unplug the power cord. When

power is restored, reconnect (plug in) the

power cord, switch on the power and wait

3 minutes to restart the air conditioner to

prevent tripping of the compressor overload.

Airflow is restricted .

Make sure there are no curtains, blinds,

or furniture blocking the front of the air

conditioner.

Clean the filter at least every 2 weeks.

See the operating instructions section.

When the air conditioner is first turned on you

need to allow time for the room to cool down.

Check for open furnace floor registers and

cold or hot air returns.

Set the air conditioner's vent to the closed

position.

See Air Conditioner Freezing Up below.

The air filter is dirty.

The room may have been

hot.

Cold/hot air is escaping.

Coils have iced up.

Ice blocks the air flow and

stops the air conditioner

from cooling the room.

Set the fan at MED or HIGH until the

ice melts.

Produkt Specifikationer

Mærke:	Kelvinator
Kategori:	Klimaanlæg - Luftkøler
Model:	KWH20CRC

Har du brug for hjælp?

Hvis du har brug for hjælp til Kelvinator KWH20CRC stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Klimaanlæg - Luftkøler Kelvinator Manualer

Kelvinator KWH53CRC Manual

26 August 2024

Kelvinator KWH26CRC Manual

26 August 2024

Kelvinator KSE53HRC Manual

26 August 2024

Kelvinator KSE88HRC Manual

26 August 2024

Kelvinator KWH20HRC Manual

26 August 2024

Kelvinator KWH62HRC Manual

26 August 2024

Kelvinator KSV53HRC Manual

26 August 2024

Kelvinator KSE26CRC Manual

26 August 2024

Kelvinator KSE70HRC Manual

26 August 2024

Kelvinator KSV80HRC Manual

26 August 2024

Klimaanlæg - Luftkøler Manualer

Nyeste Klimaanlæg - Luftkøler Manualer

Sencor SAC MT9021C Manual

11 Januar 2025

Daikin FTXM42M2V1B Manual

10 Januar 2025

Daikin FTXM20M2V1B Manual

10 Januar 2025

Bomann CL 6045 QC CB Manual

30 August 2024

Bomann CL 6046 QC CB Manual

30 August 2024

General Electric AS-24 Manual

27 August 2024

General Electric AS-22 Manual

27 August 2024

General Electric AS-16 Manual

27 August 2024

General Electric AS-12 Manual

27 August 2024

General Electric AS-18 Manual

27 August 2024
