OWNER’S MANUAL
Read this owners manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
GM-F223DLXQ
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
MFL67851614
Rev.00_210601
www.lg.com
BOTTOM FREEZER
REFRIGERATOR
3
TABLE OF CONTENTS
4 SAFETY INSTRUCTIONS
8 PRODUCT OVERVIEW
11 INSTALLATION
24 OPERATION
33 SMART FUNCTIONS
34 MAINTENANCE
39 PRODUCT FICHE
40 TROUBLESHOOTING
4 SAFETY INSTRUCTIONS
4 WARNING
7 CAUTION
8 Product Features
11 Before Installing
12 Choosing the Proper Location
14 Removing/Assembling the Handles
15 Removing/Assembling the Doors and Drawers
19 Connecting the Water Line
23 Leveling and Door Alignment
23 Turning on the Power
24
25
27
27
28
30
30
31
31
32
Before Use
Control Panel
Water Dispenser
Automatic Icemaker
Storing Food
Humidity Controlled Crispers
Glide‘N’Serve
Refrigerator Shelves
Door Bins
Durabase
33 Smart Functions (Smart Diagnosis)
34 Cleaning
35 Water Filter
39 Product Fiche
40 FAQs
41 Before Calling for Service
4SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
WARNING
Installation
WARNING
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what may happen if the instructions are not followed.
• To reduce the risk of explosion, re, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
• To reduce the risk of injury to persons, adhere to all industry recommended safety procedures including
the use of long-sleeved gloves and safety glasses.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has
missing or broken parts, including a damaged cord or plug.
Only connect this product to a dedicated grounded electrical outlet rated for use with this product (230
V, 50 Hz AC only). It is the user’s responsibility to replace a standard 2-prong wall outlet with a standard
3-prong wall outlet.
• Do not use an outlet that can be turned o with a switch. Do not use an extension cord.
• The appliance must be positioned for easy access to a power source.
• When moving the refrigerator, be careful not to roll over or damage the power cord.
• Contact an authorized service center when installing or relocating the refrigerator.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suocation.
• Do not install the refrigerator in a damp or dusty place where insulation on electrical parts may
deteriorate.
• Do not place the refrigerator in direct sunlight or expose it to the heat from heating appliances such as
stoves or heaters.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
WARNING
CAUTION
You may be killed or seriously injured if you do not follow instructions.
You may be injured or cause damage to the product if you do not follow instructions.
These words mean:
5SAFETY INSTRUCTIONS
ENGLISH
Operation
• This appliance is intended to be used in household and similar applications such as :
- sta kitchen areas in shops, oces and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
• This product is not to be used for special purposes such as the storage of medicine or test materials or
for use on ships, etc.
• DO NOT allow children to climb, stand, or hang on the refrigerator doors or on the shelves in the
refrigerator. They could damage the refrigerator and seriously injure themselves.
• Do not allow children to climb into the refrigerator. They could be trapped and suocated.
• Children should be supervised to ensure that they do not play with the refrigerator.
• Keep ngers out of pinch point areas; clearances between the doors and cabinets are necessarily small.
Be careful closing doors when children are nearby.
• Do not touch frozen food or the metal parts in the freezer compartment with wet or damp hands. Doing
so may cause frostbite.
• Do not refreeze frozen food that has thawed completely. Doing so may result in a serious health hazard.
• Do not use an adapter plug or plug the power plug into a multi-outlet extension cord.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly
qualied person in order to avoid a hazard.
• Do not operate the refrigerator or touch the power cord with wet hands.
• Do not modify or extend the power cord.
• Do not use an uncertied power outlet. Do not plug appliance into a damaged wall outlet.
• Do not put hands, feet or other objects into the air vents or bottom of the refrigerator. Doing so could
result in personal injury or electric shock.
• In the event of a gas leak (propane/LPG), ensure the area is adequately ventilated and contact an
authorized service center before resuming use. Do not touch the refrigerator or power cord of the
refrigerator.
• Disconnect the power cord immediately and contact an authorized service center if there is a strange
noise, odor, or smoke coming from the appliance.
• Do not use any fuse (such as copper, steel wire, etc.) other than a standard fuse.
• Do not place or use an electrical appliance inside the refrigerator, unless it is of a type recommended by
the manufacturer.
• Do not put animals inside the appliance.
• Do not place heavy or fragile objects, liquid lled containers, combustible substances, or ammable
objects (such as candles and lamps) on the appliance.
• Avoid contact with any moving parts of the ejector mechanism or with the heater that releases the ice
cubes.
• If connected to a circuit protected by fuses, use time delay fuse.
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not bend or pinch the power cord excessively or place heavy objects on it.
• When positioning the appliance, ensure the supply cord is not trapped or damaged.
• Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
6SAFETY INSTRUCTIONS
Maintenance
Disposal
Grounding Instructions
• Do not use a hair dryer to dry the inside of the refrigerator.
• Do not light a candle to remove odors in the refrigerator.
• In the event of a refrigerant leak, move ammable objects away from the refrigerator. Ensure the area is
adequately ventilated and contact an authorized service center.
• Keep ammable materials and vapors, such as gasoline, away from the refrigerator.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Unplug the power plug before cleaning or repairing the refrigerator.
• The refrigerator and freezer compartment lights are interior LED lighting, and service should be
performed by a qualied technician.
• Unplug the power plug immediately in the event of a blackout or thunderstorm.
• Turn the power o if water or dust penetrates into the refrigerator. Call a service agent.
• Do not store glass containers or soda in the freezer compartment. Contents may expand when frozen,
break the container and cause injury.
• Do not store, disassemble or repair the appliance yourself or allow unqualied personnel to do so.
• Do not bend or pinch the power cord excessively or place heavy objects on it.
• Junked or abandoned refrigerators are dangerous, even if they are sitting for only a few days. When
disposing of the refrigerator, remove the packing materials from the door or take o the doors but leave
the shelves in place so that children may not easily climb inside.
• If disposing of a refrigerator, make sure the refrigerant and insulation foam are removed for proper
disposal by a qualied servicer. If you release the refrigerant or throw away the insulation foam, you
may be ned or imprisoned in accordance with the relevant environmental law. Insulation foam contains
ammable blowing gas.
• When discarding the appliance, remove the door gasket while leaving the shelves and baskets in place,
and keep children away from the appliance.
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualied electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not t the outlet, have a proper
outlet installed by a qualied electrician.
• Have a certied electrician check the wall outlet and wiring for proper grounding.
• Never unplug the appliance by pulling on the power cord. Always grip the plug rmly and pull straight
out from the outlet. Failure to do so may damage the power cord, resulting in a risk of re and electric
shock.
• Do not use electrical appliances inside the food storage compartments of the appliance, unless they are
of the type recommended by the manufacturer.
• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.
• DO NOT place ngers in the automatic icemaker when the refrigerator is plugged in.
• When dispensing ice from the dispenser, do not use a fragile container.
7SAFETY INSTRUCTIONS
ENGLISH
Risk of Fire and Flammable Materials
This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible.
When transporting and installing the appliance, care should be taken to ensure that no parts
of the refrigerating circuit are damaged. Refrigerant squirting out of the pipes could ignite or
cause an eye injury. If a leak is detected, avoid any naked ames or potential sources of
ignition and air the room in which the appliance is standing for several minutes.
In order to avoid the creation of a ammable gas air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the appliance may be sited depends on the
amount of refrigerant used. The room must be 10.8 square feet (1 square meter) in size for
every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identication plate inside the appliance. Never start up an
appliance showing any signs of damage. If in doubt, consult your dealer.
CAUTION
CAUTION
• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
Installation
Operation
Maintenance
• Do not install the refrigerator where there may be a danger of the unit falling.
• The refrigerator must be properly installed in accordance with the Installation Instructions.
• Do not use aerosols near the refrigerator.
• This appliance is intended to be used only in domestic and similar applications.
• Do not strike or apply excessive force to any glass surface. Do not touch glass surfaces if they are
cracked or broken.
• Do not overll or pack items too tightly into door bins. Doing so may cause damage to the bin or
personal injury if items are removed with excessive force.
• Do not hang on to or place heavy objects on the refrigerators dispenser.
• Do not use strong detergents like wax or thinners for cleaning. Clean with a soft cloth.
• Remove foreign objects (such as dust and water) o the prongs of the power plug and contact areas. Do
not use a wet or damp cloth when cleaning the plug.
• Do not spray water directly on the inside or outside of the refrigerator.
• Do not clean glass shelves or covers with warm water when they are cold. They may break if exposed to
sudden temperature changes
SAVE THESE INSTRUCTIONS
8PRODUCT OVERVIEW
PRODUCT OVERVIEW
Product Features
Exterior
The images in this guide may be dierent from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
Control Panel
Sets the refrigerator temperature and freezer temperature, the water lter condition and the
dispenser mode.
Filtered Water
Dispenses puried water
Freezer Handle
Easily opens the freezer door.
Handle
Opens and closes the refrigerator door.
Refrigerator
Fresh food compartment
Freezer
Frozen food compartment
9PRODUCT OVERVIEW
ENGLISH
Interior
LED Interior Lighting
Lights up the inside of the refrigerator.
Fixed Door Bin
Stores chilled food or drinks.
Humidity Controlled Crisper
Helps vegetables and fruit to stay crisp and controls humidity.
Auto-Closing Hinge
The refrigerator doors and freezer drawers close automatically when pushed slightly. (The door only
closes automatically when it is open at an angle of less than 30°.)
Water Filter
Puries water.
Replace the water lter every six months. See the Replacing the Water Filter section in this manual for
details.
Folding Door Mullion
Blocks the cold air of the refrigerator from escaping when the doors are closed.
10 PRODUCT OVERVIEW
Pullout Drawer
Provides extra storage within the freezer compartment.
Durabase and Durabase Divider
Provides storage for large food items.
Product Specications
*The appearance and specications listed in this manual may vary due to constant product improvements.
Description
Net weight
Standard-depth, bottom freezer
246.9 lb (112 kg)
Electrical requirements: 230 V, 50 Hz
Min. / Max. water pressure: 20 - 120 psi (138 - 827 kPa)
Model GM-F223DLXQ
Adjustable Refrigerator Shelf
The refrigerator shelves are adjustable to meet individual storage needs.
Glide’N’Serve
Store food items at a dierent temperature than the regular refrigerator area.
11INSTALLATION
ENGLISH
INSTALLATION
Before Installing
Installation Overview
Please read the following installation instructions rst after purchasing this product or transporting it to
another location.
Unpacking the Refrigerator
Choosing the Proper Location
Disassembling/Assembling
Connecting the Water Line
Leveling and Door Alignment
WARNING
• Connect to potable water supply only.
12 INSTALLATION
Unpacking the Refrigerator
Water
Electricity
Flooring
Ambient Temperature
WARNING
WARNING
NOTE
NOTE
NOTE
• Use two or more people to move and install the
refrigerator. Failure to do so can result in back
injury or other injury.
• The refrigerator is heavy. Protect the oor when
moving the refrigerator for cleaning or service.
Always pull the refrigerator straight out when
moving it. Do not wiggle or walk the refrigerator
when trying to move it, as oor damage could
occur.
• Keep ammable materials and vapors, such as
gasoline, away from the refrigerator. Failure to
do so can result in re, explosion, or death.
• The water pressure must be 20 - 120 psi or 138 -
827 kPa or 1.4 - 8.4 kgf/cm2. If the refrigerator is
installed in an area with low water pressure
(below 20 psi or 138 kPa or 1.4 kgf/cm2), you can
install a booster pump to compensate for the
low pressure.
• Installing on carpeting, soft tile surfaces, a
platform or weakly supported structure is not
recommended.
• Do not overload house wiring and cause a re
hazard by plugging in multiple appliances in the
same outlet with the refrigerator.
• To reduce the risk of electric shock, do not install
the refrigerator in a wet or damp area.
Water supply must be easily connected for the
automatic icemaker.
Use an individual, grounded outlet: 230 Volts, 50
Hz, AC, 15 Amps minimum.
To avoid noise and vibration, the unit must be
installed and leveled on a solidly constructed oor.
If required, adjust the leveling legs to compensate
for the unevenness of the oor.
Install this appliance in an area where the
temperature is between 55 °F (13 °C) and 110 °F
(43 °C).
If the temperature around the appliance is too low
or high, cooling ability may be adversely aected.
• Remove tape and any temporary labels from
your refrigerator before using. Do not remove
any warning labels, the model and serial number
label
• To remove any remaining tape or glue, rub the
area briskly with your thumb. Tape or glue
residue can also be easily removed by rubbing a
small amount of liquid dish soap over the
adhesive with your ngers. Wipe with warm
water and dry.
• Do not use sharp instruments, rubbing alcohol,
ammable uids, or abrasive cleaners to remove
tape or glue. These products can damage the
surface of your refrigerator.
• Reinstall or adjust shelves as needed.
Refrigerator shelves are installed in the shipping
position. Reinstall shelves according to your
individual storage needs.
Choosing the Proper
Location
13INSTALLATION
ENGLISH
Dimensions and Clearances
• Check the dimensions of the appliance and the installation path to ensure there is sucient room to
move the refrigerator through doors or narrow openings.
• If an opening is too narrow to t the refrigerator through, remove the refrigerator doors. See Removing/
Assembling the Doors and Drawers in this manual.
• The installation location chosen for the refrigerator should allow space behind the unit for connections
and airow and space in front to open the doors and drawers.
• Too small of a distance from adjacent items may result in lowered freezing capability and increased
electricity consumption charges. Allow at least 27 inches (686 mm) in front of the refrigerator to open the
doors, and at least 2 inches (51 mm) between the back of the refrigerator and the wall.
Dimension/Clearance
Depth without Handle
Width
Height to Top of Case
Height to Top of Hinge
Back Clearance
Case Edge Clearance (Door Fully Open)
Width (Door Fully Open without Handle)
Depth without Door
Depth with Handle
Depth (Total with Freezer Drawer Open)
Depth (Total with Door Open 90°)
Front Clearance
31 1/2” (800 mm)
29 3/4” (756 mm)
67” (1 700 mm)
68 1/2” (1 740 mm)
2” (51 mm)
11 7/8” (301 mm)
48 1/4” (1 225 mm)
27 5/8” (700 mm)
35 1/2” (901 mm)
54 3/8” (1 380 mm)
43 3/8” (1 100 mm)
33 7/8” (860 mm)
-
A
B
C
D
E
F
G
H
I
J
K
L
GM-F223DLXQ
B
A
CD
H
G
K
J
E
L
I
FF
14 INSTALLATION
Removing/Assembling the
Handles
When moving the refrigerator through a narrow
opening, removing the doors is preferred.
The appearance of the handles may vary from
what is shown.
WARNING
• When assembling or disassembling the
refrigerator handles, grasp the handle rmly to
avoid dropping it.
• Do not swing the handle into nearby people or
animals.
• Make sure that the bracket hole of the handle
ts properly into the stopper bolt of the door.
Assemble the set screws to x the handle into
place.
• Make sure that there is not a gap between the
door and handle after assembling the handle.
Tools Needed
• 3/32 in. Allen wrench
• 1/8 in. Allen wrench
• 1/4 in. Allen wrench
Loosen the set screws with a 3/32 in. Allen
wrench and remove the handle.
Loosen the set screws located on the lower
side of the handle with a 1/8 in. Allen wrench
and remove the handle.
Assemble the mounting fasteners at both
ends of the handle with a 1/4 in. Allen wrench.
Assemble the mounting fasteners at both
ends of the handle with a 1/4 in. Allen wrench.
Loosen the mounting fasteners that
connect to the refrigerator door and handle
using a ¼ in. Allen wrench, and remove the
mounting fasteners.
Loosen the mounting fasteners with a 1/4
in. Allen wrench, and remove the mounting
fasteners.
Place the handle on the door by tting the
handle footprints over the mounting
fasteners and tightening the set screws
with a 1/8 in. Allen wrench.
Place the handle on the door by tting the
handle footprints over the mounting
Removing the Refrigerator Handles
Removing the Freezer Drawer
Handle
Assembling the Freezer Drawer
Handle
Assembling the Refrigerator
Handles
1
1
1
1
2
2
2
2
fasteners and tightening the set screws
with a 3/32 in. Allen wrench.
15INSTALLATION
ENGLISH
Removing/Assembling the
Doors and Drawers
If the entrance door is too narrow for the
refrigerator to pass through, remove the
refrigerator doors and move the refrigerator
sideways through the doorway.
CAUTION
CAUTION
NOTE
WARNING
• Use two or more people to remove and install
the refrigerator doors and freezer drawer.
• Disconnect the electrical supply to the
refrigerator before installing.
• Do not put hands, feet or other objects into the
air vents or bottom of the refrigerator.
• Be careful when handling the hinge and stopper.
• Remove food and bins before detaching the
doors and drawers.
• Do not hold the handle when removing or
replacing the doors and drawer as the handle
may come o.
• When lifting the hinge, be careful that the door
does not fall forward.
Place the door, inside facing up, on a
nonscratching surface.
Tools Needed
• 3/32 in. Allen wrench
• 1/8 in. Allen wrench
• 1/4 in. Allen wrench
• 10 mm Socket wrench
Collet Tube Insert line Clip
The water supply is connected to the upper
right part of the rear surface of the
refrigerator. Remove the ring in the joint area.
Hold the water supply connection and gently
push the collet to detach the water supply
line as shown
Remove the screw from the hinge cover at
the top of the refrigerator. Lift the hook (not
visible), located at the bottom of the front side
of the cover with a at-head screwdriver.
Remove the cover and pull out the tube .
Disconnect all wire harnesses . Unscrew the
ground wire .
Remove the three bolts using a 10mm
socket wrench. Lift o the top hinge .
Lift the door form the middle hinge pin and
remove the door.
Removing the Left Refrigerator
Door
1
2
3
4
5
• Disassembling/Assembling the Water Lines
16 INSTALLATION
Remove the top hinge cover screw . Lift up
the cover .
Remove the three bolts using a 10mm socket
wrench. Lift o the top hinge .
Lift the door from the middle hinge pin and
remove the door.
Removing the Right Refrigerator
Door
1
2
3
CAUTION
• When lifting the hinge, be careful that the door
does not fall forward.
CAUTION
Place the door, inside facing up, on a
nonscratching surface.
WARNING
• Use two or more people to remove and install
the refrigerator doors and freezer drawer.
• Be careful of sharp hinges on both sides of the
drawer.
• When you lay the drawer down, be careful not to
damage the oor.
• Do not sit or stand on the freezer drawer.
• To prevent accidents, keep children and pets
away from the drawer. Do not leave the drawer
open. If the Durabase® storage bin is removed
from the freezer drawer, there is sucient space
for a small child or pet to crawl inside.
Removing the Freezer Drawers
Pull the drawer open to full extension.
Gently lift and pull out the ice bin.
1
2
Lift the front of the drawer up, then pull it
straight out.
Remove the Durabase basket from the rails.
Remove the screws from the rails at both
ends.
3
4
17INSTALLATION
ENGLISH
Assembling the Freezer Drawer
Grip both sides of the drawer and pull it up to
remove it from the rails.
5
Hold both rails and push them insimultaneously.
6
CAUTION
• Do not hold the handle when removing or
replacing the drawer. The handle may come o,
causing personal injury. Grasp the drawer on each side and hook the
drawer supports into the rail tabs located on
both sides.
Pull out both rails simultaneously, until they
are fully extended.
2
1
CAUTION
• Do not hold the handle when removing or
replacing the drawer. The handle may come o,
causing personal injury.
Lower the door into its nal position and
insert the screws in the rails on both sides.
3
18 INSTALLATION
Replace the ice bin in the drawer. Insert the
Durabase basket in the rail assembly.
Insert the drawer into the frame, and push
the drawer back until it clicks into place.
Make sure that the plastic sleeve is inserted in
the bottom of the door. Lower the door onto
the middle hinge pin.
Make sure that the plastic sleeve is inserted in
the bottom of the door. Lower the door onto
the middle hinge pin.
Align the door with the cabinet.
Line up the holes in the top hinge with the
holes in the top of the refrigerator. Insert and
tighten the three Bolts in the hinge.
Line up the holes in the top hinge with the
holes in the top of the refrigerator. Insert and
tighten the three Bolts in the hinge.
Hook the tabs on right side of hinge cover
under the edge of the top hinge and posi-
tion the cover in place. Insert and tighten the
cover screw .
5
4
1
1
2
3
2
4
Assembling the Right Refrigerator
Door
Assembling the Left Refrigerator
Door
CAUTION
CAUTION
• Install the right-side door rst.
Install the left refrigerator door after the right
door is installed.
19INSTALLATION
ENGLISH
Install the grounding screw and connect the
two wire harnesses . Push the water tube ,
located at the top of the left door into the hole
beside the left hinge on the top of
the cabinet until it exits through the back.
Hold the water supply connection and gently
push in the collet to connect the water
supply line as shown. Insert the tube at least
5/8 inch (15 mm) into the connector. Insert
the clip on the joint to fasten the tube in place.
Place the cover in place. Insert and tighten
the cover screw .
3
4
4
NOTE
NOTE
Collet Tube Insert line Clip
• Disassembling/Assembling the Water Lines
• Gently press the collet and insert the tube until
only one line shows on the tube.
Connecting the Water Line
Before Beginning
This water line installation is not covered by the
refrigerator warranty. Follow these instructions
carefully to minimize the risk of expensive water
damage.
If necessary, call a qualied plumber to correct
water hammer before installing the water supply
line to the refrigerator. Water banging in the
pipes, or water hammer in residential plumbing
can cause damage to refrigerator parts and lead to
water leakage or ooding.
• Turn the icemaker OFF if the refrigerator will be
used before the water line is connected.
• Do not install the icemaker tubing in areas
where the ambient temperatures fall below
freezing.
WARNING
• Connect to potable water supply only.
CAUTION
• To prevent burns and product damage, only
connect the refrigerator water line to a cold
water supply.
• Wear eye protection during installation to
prevent injury.
20 INSTALLATION
• A self-piercing saddle type water valve should
not be used.
NOTE
Water Pressure
Supplies Needed
You will need a cold water supply.
If the water pressure from the reverse osmosis
system is less than 20 psi or 138 kPa or 1.4 kgf/
cm2 (takes more than 4 seconds to ll a cup of 7 oz
or 198 cc capacity):
• Check to see if the sediment lter in the reverse
osmosis system is blocked. Replace the lter if
necessary.
• Allow the storage tank on the reverse osmosis
system to rell after heavy usage.
• If the water pressure remains low, call a
licensed, qualied plumber.
• All installations must be in accordance with local
plumbing code requirements.
• Copper or PEX Tubing, ¼ in. outer diameter, to
connect the refrigerator to the water supply. Be
sure both ends of the tubing are cut square. To
determine how much tubing you need, measure
the distance from the water valve on the back of
the refrigerator to the water supply pipe. Then,
add 8 feet (2.4 m). Be sure there is sucient
extra tubing (about 8 feet [2.4 m] coiled into 3
turns of about 10 in. [25 cm] diameter) to allow
the refrigerator to move out from the wall after
installation.
• Power drill.
• ½ in. or adjustable wrench.
• Flat-blade and Phillips-head screwdrivers.
• Two ¼ in. outer diameter compression nuts
and 2 ferrules (sleeves) to connect the copper
tubing to the shuto valve and the refrigerator
water valve.
Water Pressure
models with water
lter
20 - 120 psi (138 - 827 kPa)
where reverse
osmosis water
ltration system is
connected to a cold
water supply
40 - 60 psi minimum to
reverse osmosis system (2.8
kgf/cm2 - 4.2 kgf/ cm2, or
less than 2 - 3 seconds to ll
a cup of 7 oz capacity)
• If your existing copper water line has a ared
tting at the end, purchase an adapter (available
at plumbing supply stores) to connect the water
line to the refrigerator OR cut o the ared
tting with a tube cutter and then use a
compression tting.
• Shuto valve to connect to the cold water line.
The shuto valve should have a water inlet with
a minimum inside diameter of 5/32 in. at the
point of connection to the COLD WATER LINE.
Saddle-type shuto valves are included in many
water supply kits. Before purchasing, make sure
a saddle-type valve complies with your local
plumbing codes.
Water Line Installation Instructions
Install the shuto valve on the nearest frequently
used drinking water line.
WARNING
• When using any electrical device (such as a
power drill) during installation, be sure the
device is battery-powered, double-insulated or
grounded in a manner that will prevent the
hazard of electric shock.
21INSTALLATION
ENGLISH
Shut o the main water supply.
• Turn on the nearest faucet to relieve the
pressure on the line.
Tighten the pipe clamp.
• Tighten the clamp screws until the sealing
washer begins to swell.
Pipe Clamp
Saddle-Type Shuto Valve
Vertical Cold Water Pipe
Pipe Clamp
Inlet End
Clamp Screw
Washer
Choose the valve location.
• Choose a location for the valve that is easily
accessible. It is best to connect into the side
of a vertical water pipe. When it is necessary
to connect into a horizontal water pipe,
make the connection to the top or side,
rather than at the bottom, to avoid drawing
o any sediment from the water pipe.
Drill the hole for the valve.
• Drill a ¼ in. hole in the water pipe using a
sharp bit. Remove any burrs resulting from
drilling the hole in the pipe. Be careful not
to allow water to drain into the drill. Failure
to drill a ¼ in. hole may result in reduced ice
production or smaller cubes.
1
5
2
3
• The hookup line cannot be white, plastic tubing.
Licensed plumbers must use only copper tubing
(NDA tubing #49595 or #49599) or Cross Link
Polyethylene (PEX) tubing.
• Do not over tighten clamp or you may crush the
tubing.
NOTE
NOTE
Fasten the shuto valve.
• Fasten the shuto valve to the cold water
pipe with the pipe clamp.
4
• Commonwealth of Massachusetts Plumbing
Codes 248CMR shall be adhered to. Saddle
valves are illegal and use is not permitted in
Massachusetts. Consult with your licensed
plumber.
NOTE
Route the tubing.
• Route the tubing between the cold water
line and the refrigerator. Route the tubing
through a hole drilled in the wall or oor
(behind the refrigerator or adjacent base
cabinet) as close to the wall as possible.
6
• Be sure there is sucient extra tubing (about 8
ft. coiled into three turns of about 10 in.
diameter) to allow the refrigerator to move out
from the wall after installation.
NOTE
22 INSTALLATION
CAUTION
• Check to see if leaks occur at the water line
connections.
Connect the tubing to the refrigerator.
Connect the tubing to the valve.
• Place the compression nut and ferrule
(sleeve) for copper tubing onto the end of
the tubing and connect it to the shuto
valve. Make sure the tubing is fully inserted
into the valve. Tighten the compression nut
securely.
Flush out the tubing.
• Turn the main water supply on and ush
out the tubing until the water is clear. Shut
the water o at the water valve after about
one quart of water has been ushed
through the tubing.
Saddle-Type Shuto Valve
Compression Nut
Packing Nut
Outlet Valve
Ferrule (sleeve)
Tubing Clamp
¼ in. Tubing
¼ in. Compression Nut
Ferrule (sleeve)
Refrigerator Connection
9
7
8
• Before making the connection to the
refrigerator, be sure that the refrigerator power
cord is not plugged into the wall outlet.
• Remove the plastic exible cap from the water
valve.
• Place the compression nut and ferrule (sleeve)
onto the end of the tubing as shown.
• Insert the end of the copper tubing into the
connection as far as possible. While holding the
tubing, tighten the tting.
NOTE
NOTE
Turn the water on at the shuto valve.
• Tighten any connections that leak.
10
23INSTALLATION
ENGLISH
Leveling and Door
Alignment
Turning on the Power
The refrigerator has two front leveling legs. Adjust
the legs to alter the tilt from front-to-back or side-to
side. If the refrigerator seems unsteady, or the
doors do not close easily, adjust the refrigerator’s
tilt using the instructions below:
If the space between the doors is uneven, follow
the instructions below to align the doors:
• After installing, plug the refrigerators power
cord into a 3-prong grounded outlet and push
the refrigerator into the nal position.
Turn the leveling leg to the left to raise that
side of the refrigerator or to the right to lower
it. It may take several turns of the leveling leg
to adjust the tilt of the refrigerator.
Open both doors and check to make sure that
they close easily. If the doors do not close
easily, tilt the refrigerator slightly more to the
rear by turning both leveling legs to the left. It
may take several more turns, and be sure to
turn both leveling legs the same amount.
1
2
• A are nut wrench works best, but an open-end
wrench will suce. Do not over-tighten.
NOTE
CAUTION
• Connect to a rated power outlet.
• Have a certied electrician check the wall outlet
and wiring for proper grounding.
• Do not damage or cut o the ground terminal of
the power plug.
Position the Refrigerator
Start the Icemaker *in some models
• Arrange the coil of tubing so that it does not
vibrate against the back of the refrigerator or
against the wall. Push the refrigerator back to
the wall.
• If the water line is connected, set the icemaker
power switch to the ON position.
• The icemaker will not begin to operate until it
reaches its operating temperature of 10 °F (–12
°C) or below. It will then begin operation
automatically if the icemaker power switch is in
the ON (I) position.
Leveling
Door Alignment
With one hand, lift up both the inner and
outer door sections of the right door to raise
them at the middle hinge. (It may be easier to
lift it with the doors open.)
With the other hand, use pliers to insert the
snap ring on the middle hinge of the inner
door section as shown. Do not insert the ring
on the hinge of the outer door section.
Insert additional snap rings until the right
door is aligned. (Two snap rings are provided
with the unit.)
1
2
3
24 OPERATION
CAUTION
CAUTION
• Do not scratch the refrigerator with a sharp object or use a detergent that
contains alcohol, a ammable liquid or an abrasive when removing any
tape or adhesive from the refrigerator. Remove adhesive residue by wiping
it o with your thumb or dish detergent.
• Do not peel o the model or serial number label or the technical
information on the rear surface of the refrigerator.
• Putting food in the refrigerator before it has cooled could cause the food to
spoil, or a bad odor to remain inside the refrigerator.
Clean the refrigerator.
Connect the power supply.
Turn o the icemaker.*
Wait for the refrigerator to cool.
The refrigerator makes a loud noise after initial operation.
Open refrigerator door and freezer drawer to ventilate the
interior.
Clean the refrigerator thoroughly and wipe o all dust that accumulated
during shipping.
Check if the power supply is connected before use.
Turn o the icemaker if the refrigerator is not yet connected to the water
supply.
NOTE
• The icemaker water valve may buzz if the icemaker is turned on while the
refrigerator is not connected to the water supply.
Allow the refrigerator to run for at least two to three hours before putting
food in it. Check the ow of cold air in the freezer compartment to ensure
proper cooling.
This is normal. The volume will decrease as the temperature decreases.
The inside of the refrigerator may smell like plastic at rst. Remove any
adhesive tape from inside the refrigerator and open the refrigerator door
and the freezer drawer for ventilation.
OPERATION
Before Use
Checklist
25OPERATION
ENGLISH
Control Panel
Control Panel Features
Depending on the model, some of the following functions may not be available.
The actual control panel may dier from model to model.
Freezer
Refrigerator
Express Freeze
Door Alarm
Light
Lock
Indicates the set temperature of the freezer compartment in Celsius C) or Fahrenheit (°F). The de-
fault freezer temperature is 0°F (-18 °C). Press the Freezer button repeatedly to select a new set
temperature from 5 °F to -7 °F (-23 °C to -15 °C).
Indicates the set temperature of the refrigerator compartment in Celsius (°C) or Fahrenheit (°F). The
default refrigerator temperature is 37 °F (3 °C). Press the button repeatedly to select aRefrigerator
new set temperature from 43 °F to 33 °F (7 °C to 1 °C).
This function increases both ice making and freezing capabilities.
Press the Express Freeze button to illuminate the icon and activate the function for 24 hours. The
function automatically shuts o after 24 hours. Stop the function manually by pressing the button
once more.
When power is connected to the refrigerator, the door alarm is initially set to ON. When you press the
Door Alarm button, the display will change to OFF and the Door Alarm function will deactivate.
When either the refrigerator or the freezer door is left open for more than 60 seconds, the alarm tone
will sound to let you know that the door is open. When you close the door, the door alarm will stop.
Press the Light button to turn the light on and o. When dispensing water, a light underneath the
water switch will illuminate.
If you want to activate the Lock function to lock other buttons, press and hold the button for Lock
three seconds or more. The Lock icon will display and the Lock function is now enabled. When the
Lock function is activated, no other buttons will work. The dispenser pad is also deactivated.
To disable the Lock function, press and hold the Lock button for approximately three seconds.
• To change the temperature mode from °F to °C (or vice versa) press and hold the Refrigerator and
Freezer buttons simultaneously for approximately ve seconds. The temperature indicator on the
display window switches between Celsius and Fahrenheit.
The displayed temperature is the target temperature, and not the actual temperature of the refrigerator.
The actual refrigerator temperature depends on the food inside the refrigerator.
NOTE
26 OPERATION
• When the refrigerator is in the Power Saving Mode, the display remains o until a door is opened or a
button is pressed. Once on, the display remains on for 20 seconds.
NOTE
CAUTION
Display Mode (For Store Use Only)
• The Display Mode disables all cooling in the refrigerator and freezer sections to conserve energy while
on display in a retail store. When activated, OFF is displayed on the control panel and the display remains
on for 20 seconds.
• To deactivate / activate:
- With either refrigerator door opened, press the Express Frz. button 3 times consecutively while
pressing the Refrigerator button. The control panel beeps and the temperature settings display to
conrm that Display Mode is deactivated. Use the same procedure to activate Display Mode.
Water Filter
Replace the water lter when the Water Filter indicator turns on. After replacing the water
lter, press and hold the Water Filter button for three seconds to turn the indicator light o. Replace
the water lter approximately every six months.
27OPERATION
ENGLISH
Water Dispenser
Before Use
Using the Water Dispenser
Water Tray
To dispense cold water, push on the dispenser
switch with a glass.
To remove the tray, press down on either of the
front corners and pull out.
To replace the tray, slightly tilt up the front of the
tray and snap the tabs into the holes.
CAUTION
• Keep children away from the dispenser. Children
may play with or damage the controls.
• If ice or water dispenses unexpectedly, turn o
the water supply and contact an LG Electronics
Customer Information Center.
• The rst ice water dispensed may include
particles or odor from the water supply line or
the water tank. Throw away the rst few batches
of water. This is also necessary if the refrigerator
has not been used for a long time.
• The dispenser will not operate when either of
the refrigerator doors is open.
• Some dripping may occur after dispensing. Hold
the cup beneath the dispenser for a few seconds
after dispensing to catch all of the drops.
• There is no drain beneath the tray. You may need
to empty the tray of any liquid that collects in it.
NOTE
NOTE
Automatic Icemaker
Freezer Icemaker
*on some models
This feature is only available on some models.
The feature may vary depending on model
purchased.
Auto Shuto (feeler arm)
Power Switch
• The icemaker produces ice once approximately
48 hours have passed after the appliance is
initially installed.
• Throw away the rst few batches of ice (about
140 - 160 cubes) after installation.This is also
NOTE
28 OPERATION
Turning the Automatic Icemaker
On
Normal Sounds You May Hear
Preparing for Vacation
To turn the automatic icemaker On/O, press the
power switch on the icemaker to the ON ( | ) or
OFF (O) position.
• Keeping the power turned on to the icemaker
before the water line is connected can damage
the icemaker.
• The icemaker water valve buzzes as the
icemaker lls with water. If the icemaker power
button is in the ON mode, it will buzz even if it
has not yet been hooked up to water. To stop the
buzzing, press the icemaker power button to
turn it o.
• You will hear the sound of cubes dropping into
the bin and water running in the pipes as the
icemaker rells.
Set the icemaker power button to OFF and shut o
the water supply to the refrigerator.
If the ambient temperature will drop below
freezing, have a qualied technician drain the
water supply system to prevent serious property
damage due to ooding caused by ruptured water
lines or connections
• The ice bin should be emptied any time the
icemaker power button is turned to the OFF
mode.
NOTE
Storing Food
Food Storage Tips
Wrap or store food in the refrigerator in airtight
and moisture-proof material unless otherwise
noted. This prevents food odor and taste transfer
throughout the refrigerator. For dated products,
check date code to ensure freshness.
CAUTION
• Do not overll or pack items too tightly into door
bins. Doing so may cause damage to the bin or
personal injury if items are removed with
excessive force.
CAUTION
• Do not store glass containers in the freezer.
Contents may expand when frozen, break the
container and cause injury.
Food
Butter or
Margarine
Cheese
Milk
Eggs
Fruit
Keep opened butter in covered dish
or closed compartment. When
storing an extra supply, wrap in
freezer packaging and freeze.
Store in original wrapping until used.
Once opened, rewrap tightly in
plastic wrap or aluminum foil.
Wipe milk cartons. For coldest milk,
place containers on an interior shelf.
Store in original carton on interior
shelf, not on door shelf.
Do not wash or hull fruit until it is
ready to be used. Sort and keep fruit
in original container in a crisper, or
store in completely closed paper bag
on refrigerator shelf.
How to Store
necessary if the refrigerator has not been used
for a longtime.
• The automatic freezer icemaker produces 12
cubes at a time, 50-110 pieces within a 24 hour
period if conditions are favorable. This amount
may vary according to the environment (ambient
temperature around the appliance, frequency of
the door being opened, amount of food stored
in the appliance, etc.).
• The amount and shape of ice may vary according
to the environment (ambient temperature
around the appliance, frequency of the door
being opened, amount of food stored in the
appliance, water pressure, etc.).
• The sound of ice dropping into the ice bin is
normal.
• If the ice bin is completely lled with ice, ice
production will stop.
• In the event of a power outage, throw away the
ice stored in the ice bin.
• Ice cubes which are stored in the ice bin for a
long time may clump together and be dicult to
separate. If this happens, empty the ice bin
completely and clean it before reinstalling it.
29OPERATION
ENGLISH
Storing Frozen Food
Freezing
Packaging
Check a freezer guide or a reliable cookbook for
further information about preparing food for
freezing or food storage times.
Your freezer will not quick-freeze a large quantity
of food. Do not put more unfrozen food into the
freezer than will freeze within 24 hours (no more
than 2 to 3 pounds of food per cubic foot of freezer
space). Leave enough space in the freezer for air to
circulate around packages. Be careful to leave
enough room at the front so the door can close
tightly.
Storage times will vary according to the quality
and type of food, the type of packaging or wrap
used (how airtight and moisture-proof) and the
storage temperature. Ice crystals inside a sealed
package are normal. This simply means that
moisture in the food and air inside the package
have condensed, creating ice crystals.
Successful freezing depends on correct packaging.
When you close and seal the package, it must not
allow air or moisture in or out. If it does, you could
• Allow hot foods to cool at room temperature for
30 minutes, and then package and freeze.
Cooling hot foods before freezing saves energy.
NOTE
Do not use
• Bread wrappers
• Non-polyethylene plastic containers
• Containers without tight lids
• Wax paper or wax-coated freezer wrap
• Thin, semi-permeable wrap
Follow package or container instructions for
proper freezing methods.
• If you are leaving home for a short period, like a
short vacation, the refrigerator should be left on.
Refrigerated foods that are able to be frozen will
stay preserved longer if stored in the freezer.
• If you are leaving the refrigerator turned o for
an extended period, remove all food and unplug
the power cord. Clean the interior, and leave the
door open to prevent fungi from growing in the
refrigerator.
• Do not store food with high moisture content
towards the top of the refrigerator. The moisture
could come in direct contact with the cold air and
freeze.
• Wash food before storing it in the refrigerator.
Vegetables should be washed, and food
packaging should be wiped down to prevent
adjacent foods from being contaminated.
• If the refrigerator is kept in a hot and humid
place, frequent opening of the door or storing a
lot of vegetables in the refrigerator may cause
condensation to form. Wipe o the
condensation with a clean cloth or a paper towel.
• If the refrigerator door or freezer drawer is
opened or closed too often, warm air may
penetrate the refrigerator and raise its
temperature. This can increase the running costs
of the unit.
NOTE
Food
Leafy
Vegetables
Vegetables
with skins
(carrots,
peppers)
Remove store wrapping, trim or tear
o bruised and discolored areas,
wash in cold water, and drain. Place
in plastic bag or plastic container and
store in crisper.
Place in plastic bags or plastic
container and store in crisper.
How to Store
Fish
Leftovers
Freeze fresh sh and shellsh if they
are not being eaten the same day
purchased. Eating fresh sh and
shellsh the same day purchased is
recommended.
Cover leftovers with plastic wrap or
aluminum foil, or store in plastic
containers with tight lids.
have food odor and taste transfer throughout the
refrigerator and could also dry out frozen food.
Packaging recommendations
• Rigid plastic containers with tight-tting lids
• Straight-sided canning/freezing jars
• Heavy-duty aluminum foil
• Plastic-coated paper
• Non-permeable plastic wraps
• Specied freezer-grade self-sealing plastic bags
30 OPERATION
• Vegetables keeps moist air in the crisper for
best storage of fresh, leafy vegetables.
• Fruit lets moist air out of the crisper for best
storage of fruit.
This feature is only available on some models.
The crispers provide fresher tasting fruit and
vegetables by letting you easily control humidity
inside the drawer.
You can control the amount of humidity in the
moisture-sealed crispers by adjusting the control
to any setting between Vegetables and Fruit.
Humidity Controlled
Crispers
Using the Humidity Controlled
Crispers
Removing/Assembling the
Humidity Controlled Crispers
Pull out the crisper to full extension, lift the
front up, and pull straight out.
Lift the front of the cover up with both hands
until it detaches from the back wall of the
cabinet, then pull it out.
To reassemble, insert the cover into the
refrigerator with both hands and lower it onto
the guides.
Slightly tilt up the front, insert the crisper into
the frame and push it back into place.
1
2
3
4
This drawer can be used for large party trays, deli
items and beverages. This drawer should not be
used to store vegetables that require high
humidity.
Glide‘N’Serve
Using the Glide‘N’Serve
Detaching/Assembling the
Glide‘N’Serve
CAUTION
• Do not place any items on the Glide‘N’Serve
cover.
To remove the Glide’N’Serve, pull out the
Glide’N’Serve to full extension, lift the front
up, and pull straight out.
1
31OPERATION
ENGLISH
Detaching/Assembling the Door
Bins
Detaching the Shelf
Assembling the Shelf
CAUTION
CAUTION
CAUTION
CAUTION
• Do not clean glass shelves with warm water
while they are cold. Shelves may break if
exposed to sudden temperature changes or
impact.
• Make sure that shelves are level from one side to
the other. Failure to do so may result in the shelf
falling or spilled food.
• Glass shelves are heavy. Use special care when
removing them.
• Regularly detach and wash the storage bins and
shelves; they can become easily contaminated
by food.
• Do not apply excessive force while detaching or
assembling the storage bins.
• Do not use the dishwasher to clean the storage
bins and shelves.
Tilt the front of the shelf up and guide the
shelf hooks into the slots at a desired height.
Tilt up the front of the shelf and lift the shelf
straight up.
Lower the front of the shelf so that the hooks
drop into the slots.
Pull the shelf out.
To remove the bin, simply lift the bin up and
pull straight out.
To assemble, slightly tilt up the front, insert
the Glide’N’Serve into the frame and push it
back into place.
1
1
2
2
1
2
Refrigerator Shelves
Door Bins
The shelves in the refrigerator are adjustable to
meet individual storage needs. Your model may
have full or split shelves.
Adjusting the shelves to t items of dierent
heights will make nding the exact item you want
easier.
The door bins are removable for easy cleaning and
adjustment.
32 OPERATION
Using the Durabase
CAUTION
• If the Durabase divider is removed, there is
enough open space for children or pets to crawl
inside. To prevent accidental child and pet
entrapment or suocation risk, DO NOT allow
children or pets to touch or go near the drawer.
To replace the bin, slide it in above the desired
support and push down until it snaps into
place.
2
Durabase
The divider allows you to organize the Durabase
Durabase area into 2 sections. It can be adjusted
from side to side to accommodate items of
dierent sizes.
33SMART FUNCTIONS
ENGLISH
SMART FUNCTIONS
Smart Diagnosis
LG ThinQ Application
This feature is only available on models with the
or logo.
Use this feature to help you diagnose and solve
problems with your appliance.
This feature is only available on models with the
or logo.
The application allows you toLG ThinQ
communicate with the appliance using a
smartphone.
Communicate with the appliance from a
smartphone using the convenient smart features.
Search for the LG ThinQ application from the
Google Play Store or Apple App Store on a smart
phone.
• Follow instructions to download and install the
application.
• Run the LG ThinQ application and follow the
instructions in the application to register the
appliance.
Smart Diagnosis
• If you experience a problem while using the
appliance, this smart diagnosis feature will help
you diagnose the problem.
Follow the instructions below to use the audible
diagnosis method.
• Launch the LG ThinQ application and select the
Smart Diagnosis feature in the menu. Follow the
instructions for audible diagnosis provided in the
LG ThinQ application.
• For best results, do not move the phone while
the tones are being transmitted.
• The application is subject to change for appliance
improvement purposes without notice to users.
• Functions may vary by model.
NOTE
NOTE
LG ThinQ Application Features
Installing the LG ThinQ
Application
Using Audible Diagnosis to
Diagnose Issues
Open the refrigerator door.
Press and hold the Freezer button for 3
seconds or longer.
• The control panel will be turned o, and
then ‘3’ will be displayed on the fridge
temperature display part.
Hold the phone on the upper right speaker
hole.
After the data transfer is complete, the
diagnosis will be displayed in the application.
1
2
3
4
• For reasons not attributable to LGE’s
negligence, the service may not operate due to
external factors such as, but not limited to, Wi-Fi
unavailability, Wi-Fi disconnection, local app
store policy, or app unavailability.
• The feature may be subject to change without
prior notice and may have a dierent form
depending on where you are located.
NOTE
34 MAINTENANCE
MAINTENANCE
Cleaning
• Both the refrigerator and freezer sections
defrost automatically; however, clean both
sections once a month to prevent odors.
• Wipe up spills immediately.
• Unplug the refrigerator or disconnect power
before cleaning.
• Remove all removable parts, such as shelves.
• Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use abrasive or
harsh cleaners.
• Hand wash, rinse and dry all surfaces
thoroughly.
• Allow freezer to warm up so the cloth will not
stick.
To help remove odors, wash the inside of the
refrigerator with a mixture of baking soda and
warm water. Mix 2 tablespoons of baking soda to 1
quart of water (26 g soda to 1 liter water.) Be sure
the baking soda is completely dissolved so it does
not scratch the surfaces of the refrigerator.
Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use cleaning
waxes, concentrated etergents, bleaches, or
cleaners containing petroleum on plastic
refrigerator parts.
Use a clean sponge or soft cloth and a mild
detergent in warm water. Do not use glass
cleaners, abrasive cleansers, or ammable uids.
These can scratch or damage the material.
Use a vacuum cleaner with a brush or crevice
attachment to clean the condenser cover and
vents. Do not remove the panel covering the
condenser coil area.
For products with black stainless steel exterior,
spray glass cleaner on a clean, microber cloth
and rub in direction of grain. Do not spray glass
cleaner directly at the display panel. Do not use
harsh or abrasive cleaners.
For products with a standard stainless steel
exterior, use a damp microber cloth and rub in
the direction of the grain. Dry with a paper towel
to avoid streaks. For stubborn stains and
ngerprints, use a few drops of liquid dish soap in
water, and rinse with hot water before drying. Do
not use abrasive or harsh cleaners.
General Cleaning Tips
Inside Walls
Door Liners and Gaskets
Plastic Parts (Covers and Panels)
Condenser Coils
Exterior
WARNING
CAUTION
• Use non-ammable cleaner. Failure to do so can
result in re, explosion, or death.
• Do not use an abrasive cloth or sponge when
cleaning the interior and exterior of the
refrigerator.
• Do not place your hand on the bottom surface of
the refrigerator when opening and closing the
doors.
• When lifting the hinge free of the latch, be
careful that the door does not fall forward.
35MAINTENANCE
ENGLISH
Water Filter
WARNING
CAUTION
• To reduce the risk associated with choking, do
not allow children under 3 years of age to have
access to small parts during the installation of
this product.
• To reduce the risk associated with the ingestion
of contaminants, do not use with water that is
microbiologicallyunsafe or of unknown quality
without adequate disinfection before or after the
system. Systems certied for cyst reduction may
be used on disinfected water that may contain
lterable cysts.
• Use of unauthorized water lters may result in
product malfunction, water leakage or water
quality issues, which will not be covered under
the product warranty.
• Read and follow Use Instructions before
installation and use of this system.
• Installation and use MUST comply with all state
and local plumbing codes.
• Do not install if water pressure exceeds 120 psi
(827 kPa). If your water pressure exceeds 80 psi,
you must install a pressure limiting valve.
Contact a plumber if uncertain how to check
your water pressure.
• Do not install where water hammer conditions
may occur. If water hammer conditions exist you
must install a water hammer arrester. Contact a
plumbing professional if you are uncertain how
to check for this condition.
• Do not install on hot water supply lines. The
maximum operating water temperature of this
lter system is 100 °F (37.8 °C).
• Protect lter from freezing. Drain lter when
temperatures drop below 40 °F (4.4 °C).
• The disposable lter cartridge MUST be replaced
every 6 months, at the rated capacity or if a
noticeable reduction in ow rate occurs.
• Protect from freezing, remove lter cartridge
when temperatures are expected to drop below
33° F.
• Do not install systems in areas where ambient
temperatures may go above 110° F (43.3° C).
• Where a backow prevention device is installed
on a water system, a device for controlling
pressure due to thermal expansion must be
installed.
Before Replacing the Water Filter
Replacing the Water Filter
• Ensure all tubing and ttings are secure and free
of leaks.
`Replace the water lter:
• Approximately every six months.
• When the Water Filter icon turns on.
• When the ice maker output decreases.
To purchase a replacement water lter:
• Visit your local dealer or distributor
• Search using “water lter”on lg.com
• Use replacement cartridge: ADQ36006101
If the top shelf, located below the water lter,
is in the highest position, it will need to be
removed prior to replacing the water lter.
• To remove any shelf, tilt up the front of the
shelf and lift it. Pull the shelf out.
Press the push button to open the water
lter cover.
Pull the water lter downward and pull out.
1
2
3
36 MAINTENANCE
Replace with a new water lter.
• Take the new water lter out of its packing
and remove the protective cover from the
o-rings.
With the water lter tabs in the
horizontal position, push the new water
lter into the manifold hole and turn it
clockwise until it stops.
Swing the lter up into place in the enclosure.
Close the cover until it clicks into place.
After the water lter is replaced, dispense 2.5
gallons of water (ush for approximately 5
minutes) to remove trapped air and
contaminants from the system.
After changing the lter, press and hold the
Water Filter button for three seconds to reset
the indicator light.
4
5
6
7
NOTE
• Replacing the water lter causes a small amount
of water (around 1 oz. or 25 cc) to drain.
• Wrap a cloth around the front end of the water
lter cover to collect any leaking water. Hold the
water lter upright, once it is removed, to
prevent any remaining water from spilling out of
the water lter.
NOTE
• Do not dispense the entire 2.5 gallon amount
continuously. Press and release the dispenser
pad for cycles of 30 seconds ON and 60 seconds
OFF.
37MAINTENANCE
ENGLISH
Before Replacing the Water Filter
Model: LT1000P, LT1000PC, LT1000PCS
NSF System Trade Name Code: MDJ64844601
The concentration of the indicated substances in water entering the system was reduced to a
concentration less than or equal to the permissible limit for water leaving the system as specied in NSF/
ANSI Standard 42, Standard 53 and Standard 401.
System tested and certied by NSF International against NSF/ANSI Standard 42, Standard 53 and
Standard 401 for the reduction of substances listed below.
Substance
Reduction
Chlorine Taste and
Odor
2.0 μg/L 0.050 μg/L>97.5% N/A 50.00%2.0 μg/L± 10%
Nominal Particulate
Class I, , 0.5 to <
1.0 μm
12,000,000
pts/mL
99.80% 24,000 pts/ml N/A 85.00%12,000,000
pts/mL
Asbestos 180 MFL >99.00% < 1 MFL N/A 99.00%
107 to 108 MFL; bers
greater than 10 μg/Lin
length
Atrazine >94.10% N/A8.5 μg/L 0.500 μg/L 3.0 μg/L9.0 μg/L ± 10%
Benzene >96.60% N/A15.0 μg/L 0.510 μg/L 5.0 μg/L15.0 μg/L ± 10%
Carbofuran 98.30% N/A74.0 μg/L 1.258 μg/L 40 μg/L80.0 μg/L ± 10%
Lindane >99.00% N/A1.9 μg/L 0.019 μg/L 0.2 μg/L2.0 μg/L ± 10%
P-Dichlorobenzene >99.80% N/A230.0 μg/L 0.460 μg/L 75.0 μg/L225.0 μg/L ± 10%
2,4-D >99.90% N/A210.0 μg/L 0.210 μg/L 70.0 μg/L210.0 μg/L ± 10%
Lead pH @6.5 99.60% N/A140.0 μg/L 0.560 μg/L 10.0 μg/L150.0 μg/L ± 10%
Lead pH @8.5 >99.70% N/A150.0 μg/L <0.500 μg/L 10.0 μg/L150.0 μg/L ± 10%
Mercury @ pH6.5 91.00% N/A5.9 μg/L 0.531 μg/L 2.0 μg/L6.0 μg/L ± 10%
Mercury @ pH8.5 92.5% N/A5.6 μg/L 0.420 μg/L 2.0 μg/L6.0 μg/L ± 10%
Cyst* 100,000
cysts/L
>99.99% 10 cysts/L N/A 99.95%Minimum 50,000
cysts/L
Atenolol 240 ng/L > 95.50% 10.80 ng/L 30 ng/L N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
200 ± 40% ng/L
Carbamazepine 1600 ng/L 98.40% 25.60 ng/L 200 ng/L1400 ± 40% ng/L
DEET 1600 ng/L 97.10% 46.40 ng/L 200 ng/L1400 ± 40% ng/L
Trimethoprim 170 ng/L >96.80% 5.44 ng/L 20 ng/L140 ± 40% ng/L
Linuron 160 ng/L >96.60% 5.44 ng/L 20 ng/L140 ± 40% ng/L
Phenytoin 200 ng/L >94.80% 10.40 ng/L 30 ng/L200 ± 40% ng/L
Ibuprofen 400 ng/L >94.50% 22.00 ng/L 60 ng/L400 ± 40% ng/L
Estrone 120 ng/L >96.10% 4.68 ng/L 20 ng/L140 ± 40% ng/L
Naproxen 140 ng/L >96.10% 5.46 ng/L 20 ng/L140 ± 40% ng/L
Bisphenol A 2000 ng/L >98.90% 22.00 ng/L 300 ng/L2000 ± 40% ng/L
Nonyl Phenol 1600 ng/L >97.10% 46.40 ng/L 200 ng/L1400 ± 40% ng/L
• Based on the use of Cryptosporidium parvum oocysts.
Average
Inuent
Challenge
Avg %
Reduction
NSF specied
Challenge
Concentration
Average
Product Water
Concentration
Max Permissible
Product Water
Concentration
NSF
Reduction
Requirements
38 MAINTENANCE
Guidelines for Application / Water Supply Parameters
Service Flow
Water Supply
Water Pressure
Water Temperature
Capacity
0.5 gpm (1.9 lpm)
Community or Private Well - Potable Water
20 – 120 psi (138 – 827 kPa)
33 °F – 100 °F (0.6 °C – 37.8°C)
200 gallons (757 liters)
It is essential that the manufacturer’s recommended installation, maintenance and lter replacement
requirements be carried out for the product to perform as advertised.
• While the testing was performed under standard laboratory conditions, actual performance may vary.
NOTE
For replacement lters, visit your local dealer or distributor or search under “water lters” on the lg.com
website.
Replacement Cartridge: LT1000P, LT1000PC or LT1000PCS
LG is a trademark of LG corp.
NSF is a trademark of NSF International.
Manufactured by LG Electronics, INC:
170, Sungsanpaechoungro, Seongsan-gu, Gyeongsangnam-do, THE REPUBLIC OF KOREA
39PRODUCT FICHE
ENGLISH
Trade Mark LG Electronics
GM-F223DLXQ
7 (Refrigerator-Freezer)
A+
411
122
None
Fresh Food, Frozen Food
17
6
42
Free standing
T
This appliance is intented to be
used at ambient temperature
between 16°C and 43°C
361
Model
Category
Energy eciency class
Fresh Food Storage Volume (L)
Frozen Food Storage Volume (L)
Design temperature of other compartments (>14°C)
Frost-Free Compartments
Temperature Rise time (h)
Freezing Capacity (kg/24h)
Airborne acoustical noise emissions [dB(A)]
Free standing / Built-in
Climate Class
Energy eciency class Actual energy consumption will
depend on how the appliance is
used and where it is located
EN
A
B
C
D
E
F
G
H
I
J
K
L
M
N
ENGLISH PRODUCT FICHE
40 TROUBLESHOOTING
What are the best temperature settings for my refrigerator and freezer?
The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the
freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired
temperatures. Milk should be cold when stored on the inner shelf of the refrigerator. Ice cream
should be rm and ice cubes should not melt in the freezer. To switch the display from Fahrenheit to
Celsius, press and hold the Freezer and Refrigerator buttons until you hear a beep and the settings
in the display change.
How do I set the refrigerator and freezer temperatures?
Continually press the Refrigerator or Freezer button on the control panel until the desired
temperature appears. The numbers will cycle from highest to lowest and then return to the highest
again with continuous pressing.
Why do I hear a buzzing noise from my refrigerator periodically?
This may happen if you do not have a water source attached to your refrigerator and the icemaker is
turned on. If you do not have a water source attached to the back of the refrigerator you should turn
the icemaker o.
Why does the icemaker tray look crooked?
This is a normal part of the icemaker cycle. The icemaker tray may appear level or with a slight tilt.
The change in position is to assist in the freezing process.
My refrigerator is powered on and the controls are working, but it’s not cooling and the display
shows “OFF” (see below). What is wrong?
The refrigerator is in Display Mode. The Display Mode disables all cooling in the refrigerator and
freezer sections to conserve energy while on display in a retail store. When activated, OFF is displayed
on the control panel and the display remains on for 20 seconds. With either refrigerator door opened,
press the Express Frz. button 3 times consecutively while pressing the Refrigerator button. The
control panel beeps and the temperature settings display to conrm that Display Mode is deactivated.
Use the same procedure to activate Display Mode.
Q:
A:
TROUBLESHOOTING
FAQs
Frequently Asked Questions
Q:
A:
Q:
A:
Q:
A:
Q:
A:
41TROUBLESHOOTING
ENGLISH
Before Calling for Service
Cooling
Refrigerator is in the defrost cycle.
• During the defrost cycle, the temperature of each compartment may rise slightly. Wait 30
minutes and conrm the proper temperature has been restored once the defrost cycle has
completed.
Refrigerator was recently installed.
• It may take up to 24 hours for each compartment to reach the desired temperature.
Refrigerator was recently relocated.
• If the refrigerator was stored for a long period of time or moved on its side, it is necessary
for the refrigerator to stand upright for 24 hours before connecting it to power.
Refrigerator is replacing an older model.
• Modern refrigerators require more operating time but use less energy due to more
ecient technology.
Refrigerator was recently plugged in or power restored.
• The refrigerator will take up to 24 hours to cool completely.
Doors are not closed completely.
• Firmly push the doors shut. If they will not shut all the way, the “Doors will not close
correctly or pop open” section in Troubleshooting
The door is opened often or a large amount of food / hot food was added.
• Adding food and opening the door warms the refrigerator, requiring the compressor to
run longer in order to cool the refrigerator back down. In order to conserve energy, try to
get everything you need out of the refrigerator at once, keep food organized so it is easy
to nd, and close the door as soon as the food is removed. (Refer to the Food Storage
Guide.)
Refrigerator is installed in a hot location.
• The compressor will run longer under warm conditions. At normal room temperatures (70
°F or 21 °C) expect your compressor to run about 40 % to 80 % of the time. Under warmer
conditions, expect it to run even more often. The refrigerator should not be operated
above 110 °F (43 °C).
Condenser / back cover is clogged.
• Use a vacuum cleaner with an attachment to clean the condenser cover and vents. Do not
remove the panel covering the condenser coil area.
Problem
Refrigerator and
Freezer section are
not cooling.
Cooling system runs
too much.
The refrigerator control is set to OFF (some models).
• Turn the control ON. Refer to the Setting the Controls section for proper temperature
settings.
Refrigerator is set to Demo Mode.
• Demo Mode allows the lights and control display to work normally while disabling cooling,
to save energy while the refrigerator is on the showroom oor. See the FAQs section of
this manual for instructions on how to disable Demo Mode.
Possible Cause & Solution
42 TROUBLESHOOTING
Interior moisture
buildup.
Food is freezing in
the refrigerator
compartment.
Refrigerator or
Freezer section is too
cold.
Frost or ice crystals
form on frozen food
(inside of sealed
package).
Frost or ice crystals
form on frozen food
(outside of package).
Problem Possible Cause & Solution
Doors are opened often or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment. To
lessen the eect, reduce the frequency and duration of door openings.
Food with high water content was placed near an air vent.
• Rearrange items with high water content away from air vents.
Refrigerator temperature control is set incorrectly.
• If the temperature is too cold, adjust the control one increment at a time and wait for the
temperature to stabilize. Refer to the Control Panel section for more information.
Refrigerator is installed in a cold location.
• When the refrigerator is operated in temperature below 41 °F (5 °C), food can freeze in the
refrigerator compartment. The refrigerator should not be operated in temperature below
55 °F (13 °C).
Incorrect temperature control settings.
• If the temperature is too cold, adjust the control one increment at a time and wait for the
temperature to stabilize. Refer to the Control Panel for more information.
Condensation from food with a high water content has frozen inside of the food
package.
• This is normal for food items with a high water content.
Food has been left in the freezer for a long period of time.
• Do not store food items with high water content in the freezer for a long period of time.
Door is not closing properly.
• Refer to the “Doors will not close correctly or pop open” section in the Troubleshooting.
Door is opened frequently or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment.
Increased moisture will lead to frost and condensation. To lessen the eect, reduce the
frequency and duration of door openings.
Doors are not closed correctly.
• See the “Doors will not close correctly or pop open” section.
Weather is humid.
• Humid weather allows additional moisture to enter the compartments when the doors are
opened leading to condensation or frost. Maintaining a reasonable level of humidity in the
home will help to control the amount of moisture that can enter the compartments.
Defrost cycle recently completed.
• During the defrost cycle, the temperature of each compartment may rise slightly and
condensation may form on the back wall. Wait 30 minutes and conrm that the proper
temperature has been restored once the defrost cycle has completed.
Food is not packaged correctly.
• Food stored uncovered or unwrapped, and damp containers can lead to moisture
accumulation within each compartment. Wipe all containers dry and store food in sealed
packaging to prevent condensation and frost.
43TROUBLESHOOTING
ENGLISH
Problem Possible Cause & Solution
Refrigerator or
Freezer section is too
warm.
Refrigerator was recently installed.
• It may take up to 24 hours for each compartment to reach the desired temperature.
The air vents are blocked. Cold air circulates from the freezer to the fresh food section
and back again through air vents in the wall dividing the two sections.
• Locate air vents by using your hand to sense airow and move all packages that block
vents and restrict airow. Rearrange items to allow air to ow throughout the
compartment.
Doors are opened often or for long periods of time.
• When the doors are opened often or for long periods of time, warm, humid air enters the
compartment. This raises the temperature and moisture level within the compartment. To
lessen the eect, reduce the frequency and duration of door openings.
Unit is installed in a hot location.
• The refrigerator should not be operated in temperatures above 110 °F (43 °C).
A large amount of food or hot food was added to either compartment.
• Adding food warms the compartment requiring the cooling system to run. Allowing hot
food to cool to room temperature before putting it in the refrigerator will reduce this
eect.
Doors are not closed correctly.
• See the “Doors will not close correctly or pop open” section in the Troubleshooting.
Temperature control is not set correctly.
• If the temperature is too warm, adjust the control one increment at a time and wait for the
temperature to stabilize.
Defrost cycle has recently completed.
• During the defrost cycle, the temperature of each compartment may rise slightly and
condensation may form on the back wall. Wait 30 minutes and conrm the proper
temperature has been restored once the defrost cycle has completed.
44 TROUBLESHOOTING
Icemaker is not
making enough ice.
Demand exceeds ice storage capacity.
• The icemaker will produce approximately 70-184 cubes in a 24 hour period.
House water supply is not connected, valve is not turned on fully, or valve is clogged.
• Connect the refrigerator to a cold water supply with adequate pressure and turn the water
shuto valve fully open. If the problem persists, it may be necessary to contact a plumber.
Low house water supply pressure.
• The water pressure must be between 20 and 120 psi on models without a water lter and
between 40 and 120 psi on models with a water lter. If the problem persists, it may be
necessary to contact a plumber.
Water lter has been exhausted.
• Replacing the water lter is recommended:
Approximately every six months.
When the water lter indicator turns on.
When the water dispenser output decreases.
When the ice cubes are smaller than normal
Reverse osmosis ltration system is used.
• Reverse osmosis ltration systems can reduce the water pressure below the minimum
amount and result in icemaker issues. (Refer to the Connecting the Water Line section.)
Tubing connecting refrigerator to house supply valve is kinked.
• The tubing can kink when the refrigerator is moved during installation or cleaning
resulting in reduced water ow. Straighten or repair the water supply line and arrange it to
prevent future kinks.
Doors are opened often or for long periods of time.
• If the doors of the unit are opened often, ambient air will warm the refrigerator which will
prevent the unit from maintaining the set temperature. Lowering the refrigerator
temperature can help, as well as not opening the doors as frequently.
Doors are not closed completely.
• If the doors are not properly closed, ice production will be aected. See the “Doors will not
close correctly or pop open” section in Parts & Features Troubleshooting for more
information.
The temperature setting for the freezer is too warm.
• The recommended temperature for the freezer compartment for normal ice production is
0°F. If the freezer temperature is warmer, ice production will be aected.
Ice & Water
Problem Possible Cause & Solution
45TROUBLESHOOTING
ENGLISH
Icemaker is not
making ice
Ice has bad taste or
odor.
Icemaker is making
too much ice.
Refrigerator was recently installed or icemaker recently connected.
• It may take up to 24 hours for each compartment to reach the desired temperature and
for the icemaker to begin making ice.
Icemaker is not turned on.
• Locate the icemaker ON/OFF and conrm that it is turned on.
The ice detecting sensor is obstructed.
• Foreign substances or frost on the ice-detecting sensor can interrupt ice production. Make
sure that the sensor area is clean at all times for proper operation.
The refrigerator is not connected to a water supply or the supply shuto valve is not
turned on.
• Connect the refrigerator to the water supply and turn the water shuto valve fully open.
Icemaker shuto (arm or sensor) obstructed.
• If your icemaker is equipped with an ice shuto arm, make sure that the arm moves freely.
Reverse osmosis water ltration system is connected to your cold water supply.
• Reverse osmosis ltration systems can reduce the water pressure below the minimum
amount and result in icemaker issues. (Refer to the Connecting the Water Line section).
Water supply contains minerals such as sulfur.
• A water lter may need to be installed to eliminate taste and odor problems. NOTE: In
some cases, a lter may not help. It may not be possible to remove all minerals/odor/taste
in all water supplies.
Icemaker was recently installed.
• Ice that has been stored for too long will shrink, become cloudy, and may develop a stale
taste. Throw away old ice and make a new supply.
The food has not been stored properly in either compartment.
• Rewrap the food. Odors may migrate to the ice if food is not wrapped properly.
The interior of the refrigerator needs to be cleaned.
• See the Maintenance section for more information.
The ice storage bin needs to be cleaned.
• Empty and wash the bin (discard old cubes). Make sure that the bin is completely dry
before reinstalling it.
Icemaker shuto (arm/ sensor) is obstructed.
• Empty the ice bin. If your icemaker is equipped with an ice shuto arm, make sure that the
arm moves freely. Reinstall the ice bin and wait 24 hours to conrm proper operation.
Problem Possible Cause & Solution
46 TROUBLESHOOTING
Parts & Features
Problem Possible Cause & Solution
Doors will not close
correctly or pop
open.
Doors are dicult to
open.
Refrigerator wobbles
or seems unstable
Lights do not work.
Refrigerator has an
unusual odor.
The interior of the
refrigerator is
covered with dust or
soot.
Clicking
Food packages are blocking the door open.
• Rearrange food containers to clear the door and door shelves.
The gaskets are dirty or sticky.
• Clean the gaskets and the surfaces that they touch. Rub a thin coat of appliance polish or
kitchen wax on the gaskets after cleaning.
Leveling legs are not adjusted properly.
• Refer to the Leveling and Door Alignment section.
LED interior lighting failure.
• The refrigerator compartment lamp is LED interior lighting, and service should be
performed by a qualied technician.
The Air Filter may need to be set to the MAX setting or replaced.
• Set the Air Filter to the MAX setting. If the odor does not go away within 24 hours, the lter
may need to be replaced. See the Replacing the Air Filter section for replacement
instructions.
The refrigerator is located near a re source, such as a replace, chimney, or candle.
• Make sure that the refrigerator is not located near a re source, such as a replace,
chimney or candle.
The defrost control will click when the automatic defrost cycle begins and ends. The
thermostat control (or refrigerator control on some models) will also click when cycling
on and o.
• Normal Operationchimney or candle.
Floor is not level.
• It may be necessary to add shims under the leveling legs or rollers to complete installation.
Ice bin, crisper cover, pans, shelves, door bins, or baskets are out of position.
• Push bins all the way in and put crisper cover, pans, shelves and baskets into their correct
positions. See the Operation section for more information.
The doors were removed during product installation and not properly replaced.
• Remove and replace the doors according to the Removing and Replacing Refrigerator
Handles and Doors section.
Refrigerator is not leveled properly.
• See Door Alignment in the Refrigeration Installation section to level refrigerator.
Door was recently closed.
• When you open the door, warmer air enters the refrigerator. As the warm air cools, it can
create a vacuum. If the door is hard to open, wait one minute to allow the air pressure to
equalize, then see if it opens more easily.
Noises
Problem Possible Cause & Solution
47TROUBLESHOOTING
ENGLISH
Problem Possible Cause & Solution
Rattling
Whooshing
Gurgling
Popping
Sizzling
Vibrating
Dripping
Pulsating or high-
pitched sound
Rattling noises may come from the ow of refrigerant, the water line on the back of
the unit, or items stored on top of or around the refrigerator.
• Normal Operation
Evaporator fan motor is circulating air through the refrigerator and freezer
compartments.
• Normal Operation
Air is being forced over the condenser by the condenser fan.
• Normal Operation
Refrigerant owing through the cooling system.
• Normal Operation
Contraction and expansion of the inside walls due to changes in temperature.
• Normal Operation
Water dripping on the defrost heater during a defrost cycle.
• Normal Operation
If the side or back of the refrigerator is touching a cabinet or wall, some of the normal
vibrations may make an audible sound.
• To eliminate the noise, make sure that the sides and back cannot vibrate against any wall
or cabinet.
Water running into the drain pan during the defrost cycle.
• Normal Operation
Your refrigerator is designed to run more eciently to keep your food items at the
desired temperature. The high eciency compressor may cause your new refrigerator
to run longer than your old one, but it is still more energy ecient than previous
models. While the refrigerator is running, it is normal to hear a pulsating or high-
pitched sound.
• Normal Operation
Refrigerator with linear compressor was jarred while running.
• Normal Operation
Refrigerator is not resting solidly on the oor.
• Floor is weak or uneven or leveling legs need to be adjusted. See the Leveling and Door
Alignment section.


Produkt Specifikationer

Mærke: LG
Kategori: Køleskab
Model: GM-F223DLXQ

Har du brug for hjælp?

Hvis du har brug for hjælp til LG GM-F223DLXQ stil et spørgsmål nedenfor, og andre brugere vil svare dig




Køleskab LG Manualer

LG

LG GTM744PZAZD Manual

2 Januar 2025
LG

LG GS-V600MBLC Manual

1 Januar 2025
LG

LG GS-N599PL Manual

1 Januar 2025
LG

LG GR4691LCWA Manual

1 Januar 2025
LG

LG GSLV51WBXM Manual

1 Januar 2025
LG

LG GTB574SEHZD Manual

1 Januar 2025
LG

LG GT5142SEBS1 Manual

1 Januar 2025
LG

LG GT5240AVFW Manual

1 Januar 2025
LG

LG GR-B218JUFA Manual

1 Januar 2025
LG

LG GSLC41EPPE Manual

1 Januar 2025

Køleskab Manualer

Nyeste Køleskab Manualer
