Side 1/86
P/NO : MFL67477511
FRENCH ARABICENGLISH
Copyright © 2018 LG Electronics. All rights reserved
2
Starting
Before Setting The Temperature
Door Alarm
Self Test
Controls For Freezer Compartment
Controls For Refrigerator Compartment
Express Freeze
Child Lock (Optional)
Wi-Fi
Door Cooling+
Vegetable Drawer
Defrosting
Deodorizer
Ice Making
Hygiene Fresh (Optional)
Water Dispenser (Optional)
Smart Diagnosis
Lamp Replacement
Vacation Time
G*-*4**/ G*-*5**
IMPORTANT SAFETY INFORMATION ............3
INSTALLATION...............................................10
INNER PARTS ................................................11
OPERATIONS.................................................13
SUGGESTIONS ON FOOD STORAGE .........23
CLEANING .....................................................24
GENERAL INFORMATION.............................25
IMPORTANT WARNINGS ..............................26
BEFORE CALLING FOR SERVICE ...............27
3
WARNING
Keep ventilation openings, in the appliance enclosure or in
the built-in-structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage
compartment, unless they are recommended by the
manufacturer.
The refrigerant and insulation blowing gas used in the
appliance requires special disposal procedures. When
disposal, please consult with services agent or a similarly
qualified person.
4
(*NOTE - 1,2,3 are applicable for Jordan Regulations and other countries as per applicability)
All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the government
or the local authorities.
The correct disposal of your old appliance will help prevent potential negative consensus for the
environment and human health.
For more detailed information about the disposal of your old appliances, please contact your city
office, waste disposal service or the shop where you purchased the product.
This appliance contains a small amount of isobutane refrigerant
(R600a), natural gas with high environmental compatibility, but it is
also combustible. When transporting and installing the appliance,
care should be taken to ensure that no parts of the refrigerating
circuit are damaged. Refrigerant squirting out of the pipes could
ignite or cause an eye injury. If a leak is detected, avoid any naked
flames or potential sources of ignition and air the room in which the
appliance is standing for several minutes.
Never startup an appliance showing any signs of damage. If in
doubt, consult your dealer.
If gas used is R600a
5
Do not use or store
inflammable materials like
ether, benzene, alcohol,
medicine, LP gas, spray or
cosmetics
near or in the
refrigerator.
It may cause
explosion or fire.
Install in places away from the fire
such as the place
where flammable
gas is leaked.
It may cause fire.
6
like gasket
7
Completely empty inside before taking
out the container from the door.
8
Do not place glass containers,
bottles or cans (especially
those containing carbonated
drinks) in the freezer
compartment, shelves or ice
bin that will be exposed to
temperatures below freezing.
9
Please do not use a dishwasher to clean the lower drawers; the high temperature may cause
damage to the baskets which make them unusable.
If the appliance is equipped with a lock (some countries only), keep the key out of reach of children.
This appliance is intended to be used in household and similar applications such as
- staff kitchen areas in shops, offices and other working environments;
- farm houses and by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
10
Inverter-On feature (Optional)
Minimum requirement: UPS/ Inverter should be in ON condition having minimum 600VA
capacity along with minimum 120Ah capacity battery connected with the refrigerator’s
power supply socket.
5. After installing the appliance, connect the
power plug into a socket outlet. Before
moving and discarding the appliance,
disconnect the plug from the socket outlet.
Dimensions and Clearances
Too small of a distance from adjacent items
may result in degradation of freezing capability
and increased electricity costs. Allow over
50mm clearance from each adjacent wall when
installing the appliance.
Ambient Temperature
The appliance is designed to operate within a
limited range of ambient temperatures,
depending on the climate zone. do not use the
appliance at a temperature exceeding the limit.
The internal temperatures could be affected by
the location of the appliance, the ambient
temperature, the frequency of door opening
and so on.
The climate class can be found on the rating
label.
Climate Class
0
Ambient Temperture Range C
SN (Extended Temperate)
+10 - +32
N (Temperate)
+16 - +32
ST (Subtropical)
+16 - +38
T (Tropical)
+16 - +43/+10 - +43*
*Australia, India, Kenya
NOTE
The appliances rated from SN to T are intended
to be used at an ambient temperature between
0 0
10 C and 43 C
Image for representation purpose only
-
G*-*5**
G*-*4**
A
700
700
B
1780
1680
C
730
730
D
15
15
E
660
660
F
715
715
G
1035
1035
H
1200
1200
11
- The automatic defrosting system in the appliance ensures that the compartment remains free of ice
build up under normal operating conditions
Smart Diagnosis
Freezer Door Rack
Water Tank
Refrigerator Door
Rack
Egg Tray
Levelling Screw
Vegetable Drawer
Hygiene Fresh
(Optional)
Shelves
Deodorizer
Fresh Room Drawer
/Pull Out Tray (Optional)
Lamp
REFRIGERATOR
COMPARTMENT
FREEZER
COMPARTMENT
Lamp
Shelf
Twisting Ice Serve
Type Ice Making
Water Dispenser Model
Freezer Temperature
Control Dial
12
- The automatic defrosting system in the appliance ensures that the compartment remains free of ice
build up under normal operating conditions
Vegetable Drawer
Hygiene Fresh
(Optional)
Shelves
Deodorizer
Fresh Room Drawer
/Pull Out Tray (Optional)
Lamp
REFRIGERATOR
COMPARTMENT
FREEZER
COMPARTMENT
Lamp
Shelf
Twisting Ice Serve
Type Ice Making
Non Water Dispenser Model
Smart Diagnosis
Freezer Door Rack
Refrigerator Door
Rack
Egg Tray
Levelling Screw
Freezer Temperature
Control Dial
Refrigerator Door
Rack
(Optional)
13
When the freezer compartment is not cold enough in winter, adjust the control for the freezer to
High (6~8).
‘5’.
‘3’ or ‘4’.
CONTROLS FOR REFRIGERATOR COMPARTMENT
14
COLD COLDEST
Ref. Temp Control Button
REF. TEMP CONTROL The default setting of the temperature control button
for the refrigerator compartment is NORMAL.
To control the refrigerator temperature, press the REF.
TEMP CONTROL button.
Whenever pressing the button, LED emitting the light.
The temperature is set in 7 steps, from to COLD
COLDEST COLD COLDEST cooling. ( = warmest, =
coldest temperature)
FOR INTERNAL CONTROLLER MODEL
FOR EXTERNAL CONTROLLER MODEL
Display graphic can be different, depend on the type of your refrigerator.
Press ‘Hygiene Fresh’ button to operate hygiene fresh motor (optional).
0
Press ‘FRIDGE’ button to control refrigerator temperature.
EXPRESS FREEZE*
When the refrigerator is first turned ON the EXPRESS FREEZE feature can be turn ON. The
compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator
temperature. It shuts off automatically.
For non-dual display
If warm food is placed into the refrigerator, FAST FREEZING can be started with the button on the control
panel. FAST FREEZING will shut off when the temperature reaches the proper level or it can be shut off
manually by pressing the FAST FREEZING button.
For non-dual display
For dual display
O
- Press a button, Fridge temperature will be down each 1 C
Whenever pressing the button, the LED emits light.
- Press b button, Hygiene Fresh motor will be on, power mode, off.
For dual display
15
CHILD LOCK (OPTIONAL)*
CHILD LOCK
Press and hold the child lock button for 3 seconds to lock the child lock. When it is locked, the Lock LED
will be on and the other button will not operate. To unlock, press and hold the CHILD LOCK button for 3
seconds again.
For non-dual display
For dual display
This sets the refrigerator to connect to your home's Wi-Fi network.
Wi-Fi*
For non-dual display
For dual display
Wireless function S/W version : V 1.0
* This feature will be OFF by itself, if the refrigerator is switched OFF.
Wireless LAN module Specifications
Model
LCW-004
Frequency Range
2412 Mhz - 2472 MHz
Output Power (Max)
IEEE 802.11b: 17.82 dBm
IEEE 802.11g: 17.72 dBm
IEEE 802.11n: 16.61 dBm
VEGETABLE DRAWER
How to use
Vegetable drawer can be used through the control of knob.
Check the position of knob prior to store the food.
Do not locate the knob on the middle point.
DOOR COOLING+
If water of foreign substances enter the cool air vent while
cleaning, efficiency will be lowered.
2
TABLE DES MATIÈRES
Demarrage
Avant Le Réglage De La Température
Alarme De La Porte
Test Automatique
Contrôles Du Compartiment Congélateur
Contrôle Du Compartiment Réfrigérateur
Express Freeze
Verrouillage De Sécurité Á L'égard Des Enfants
(en Option)
Wifi
Door Cooling+
Bac À Legumes
Dégivrage
Désodoriseur
Production De Glace
Fraicheur Hygiène (en Option)
Distributeur D'eau (en Option)
Smart Diagnosis
Remplacement De La Lampe
Période De Vacances
CONSEILS POUR LA CONSERVATION DES
ALIMENTS............................23
NETTOYAGE .........................24
CONSIGNES GÉNÉRALES. . . . . . . . . . . . . . . 25
AVIS IMPORTANTS.....................26
AVANT DE SOLLICITER UN ENTRETIEN . . . 27
G*-*4**/ G*-*5**
CONSIGNES DE SÉCURITÉ
IMPORTANTES.........................3
INSTALLATION ........................10
IDENTIFICATION DES PIÈCE . . . . . . . . . . . . . 11
FONCTIONNEMENT....................13
