OWNER'S MANUAL
Color Video Camera
Please read this manual carefully before operating
your set and retain it for future reference.
P/NO : MFL63745106(A)
MODEL
L320-BP/L320-BN/L321-BP/L321-BN
L320-CP/L321-CP
L320-DN/L321-DN
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A ground-
ing type plug has two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for replacement of the obso-
lete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-
over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Specication
ITEM L320-BP L320-CP L320-BN L320-DN
Signal System PAL NTSC
Total Pixels No. 470 000 Pixels 410 000 Pixels
Effective Pixels No. 440 000 Pixels 380 000 Pixels
Image Device 6 mm Super HAD II CCD
Signal Process XDI-S2
Lens CS Mount (C Mount using adaptor ring)
IRIS Control DC/ELC
Sync. System Internal
Scanning Frequency (H/V) 15.625 kHz / 50 Hz 15.734 kHz / 59.94 Hz
Horizontal Resolution 620 TV Lines
S/N Ratio 52 dB
Minimum
Illumination
(30 IRE)
Color
Mode
0.06 lx @ Sens-up OFF
0.0001 lx @ Sens-up Auto
B/W
Mode
0.03 lx @ Sens-up OFF
0.000 001 lx @ Sens-up x128
Video Output Signal 1 Vp-p Composite (75 Ω)
Day & Night Digital Day / Night / Auto
Backlight OFF/BLC/HSBLC
DNR 3D-DNR (Off/Low/Middle/High)
Auto Gain Control Off / Low / Middle / High
Electronic Shutter Speed 1/50 to 1/90 000 1/60 to 1/90 000
Electronic Sensitivity OFF/Auto
ITEM L320-BP L320-CP L320-BN L320-DN
White Balance ATW / AWC PUSH / Manual b
User Color Mode STANDARD/COOL/WARM/VIVID
Power Source AC 24 V,
DC 12 V AC 230 V AC 24 V,
DC 12 V DC 12 V
Power Consumption 2.9 W 4.4 W 2.9 W 2.4 W
Operation Temp. -10 ºC to 50 ºC
Storage Temp. -20 ºC to 60 ºC
Operation Humidity 0 %RH to 80 %RH
Storage Humidity 0 %RH to 85 %RH
Weight 321 g
Dimension (H x V x D) 67.4 mm x 61.5 mm x 134 mm
ITEM L321-BP L321-CP L321-BN L321-DN
Signal System PAL NTSC
Total Pixels No. 470 000 Pixels 410 000 Pixels
Effective Pixels No. 440 000 Pixels 380 000 Pixels
Image Device 6 mm Super HAD II CCD
Signal Process XDI-S2
Lens CS Mount (C Mount using adaptor ring)
IRIS Control DC/ELC
Sync. System Internal
Scanning Frequency (H/V) 15.625 kHz / 50 Hz 15.734 kHz / 59.94 Hz
Horizontal Resolution 620 TV Lines
S/N Ratio 52 dB
ITEM L321-BP L321-CP L321-BN L321-DN
Minimum
Illumination
(30 IRE)
Color
Mode
0.05 lx @ Sens-up OFF
0.0001 lx @ Sens-up Auto
B/W
Mode
0.005 lx @ Sens-up OFF
0.000 001 lx @ Sens-up x128
Video Output Signal 1 Vp-p Composite (75 Ω)
Day & Night Day / Night / Auto
Backlight OFF/BLC/HSBLC
DNR 3D-DNR (Off/Low/Middle/High)
Auto Gain Control Off / Low / Middle / High
Electronic Shutter Speed 1/50 to 1/90 000 1/60 to 1/90 000
Electronic Sensitivity OFF/Auto
White Balance ATW / AWC PUSH / Manual b
User Color Mode STANDARD/COOL/WARM/VIVID
Power Source AC 24 V,
DC 12 V AC 230 V AC 24 V,
DC 12 V DC 12 V
Power Consumption 4.4 W 4.4 W 4.4 W 2.9 W
Operation Temp. -10 ºC to 50 ºC
Storage Temp. -20 ºC to 60 ºC
Operation Humidity 0 %RH to 80 %RH
Storage Humidity 0 %RH to 85 %RH
Weight 376 g
Dimension (H x V x D) 67.4 mm x 61.5 mm x 134 mm
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning flash with arrowhead symbol within an equi-
lateral triangle is intended to alert the user to the presence
of uninsulated dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
FCC WARNING: This equipment may generate or use radio frequency energy.
Changes or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the equip-
ment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful inter-
ference in which case the user will be required to correct the interference at his
own expense.
A suitable conduit entries, knock-outs or glands shall be provided in the •
cable entries of this product in the end user.
Caution: Danger of explosion if battery is incorrectly replaced. Replaced •
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Holes in metal, through which insulated wires pass, shall have smooth well •
rounded surfaces or shall be provided with brushings.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du
Canada.
Warning: Do not install this equipment in a confined space such as a bookcase
or similar unit.
Warning: Wiring methods shall be in accordance with the National Electric
Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic environment this product
may cause radio interference in which case the user may be required to take
adequate measures.
Warning: To reduce a risk of fire or electric shock, do not expose this product to
rain or moisture.
Caution: This installation should be made by a qualified service person and
should conform to all local codes.
Caution: To avoid electrical shock, do not open the cabinet. Refer servicing to
qualified personnel only.
Caution: The apparatus shall not be exposed to water (dripping or splashing)
and no objects filled with liquids, such as vases, shall be placed on the appara-
tus.
To disconnect power from mains, pull out the mains cord plug. When install-
ing the product, ensure that the plug is easily accessible.
LG Electronics hereby declares that this/these product(s) is/are in
compliance with the essential requirements and other relevant pro-
visions of Directive 2004/108/EC, 2006/95/EC, and 2009/125/EC.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere,
The Netherlands (Tel : +31-(0)36-547-8888)
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to
a product it means the product is covered by the European
Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of
separately from the municipal waste stream via designated
collection facilities appointed by the government or the local
authorities.
3. The correct disposal of your old appliance will help prevent
potential negative consequences for the environment and
human health.
4. For more detailed information about disposal of your old
appliance, please contact your city office, waste disposal
service or the shop where you purchased the product.
<For Turkey only>
5. EEE Compliance with Directive.
(EEE Yönetmeliğine Uygundur.)
AB28
