EN ENGLISH
*MFL72002120*
Copyright © 2023 LG Electronics Inc. All Rights Reserved
MFL72002120
Rev.02_112123
AIR CONDITIONER
Read this owner’s manual thoroughly before operating the appliance
and keep it handy for reference at all times.
OWNER’S MANUAL
TYPE : WINDOW
LW1217ERSM1
LW1521ERSM1
LW1223ERSM
LW1523ERSM
LW1224RSMX
Scan to see the online manual.
TABLE OF CONTENTS
SAFETY INSTRUCTIONS 3 ..............................................................
IMPORTANT SAFETY INSTRUCTIONS 4 ..........................................................
PRODUCT OVERVIEW 8 ..................................................................
Exterior Parts 8 ....................................................................................................
Interior Parts......................................................................................................8
INSTALLATION 9 ...............................................................................
Electrical Data 9 ...................................................................................................
Parts Included (Appearance May Vary) 10 ..........................................................
Tools Needed 10 ..................................................................................................
How to Install the Unit ..................................................................................... 11
Window Requirements .................................................................................... 11
Storm Window Requirements .........................................................................11
Preparation of the Cabinet 12 ..............................................................................
Cabinet Installation..........................................................................................13
Unit Installation................................................................................................14
OPERATION 16 .................................................................................
Control Panel and Remote Control 16 .................................................................
Using the Light Off Function 17 ............................................................................
Using the Mute Function 17 .................................................................................
Wireless Remote Control 18 ................................................................................
Air Direction 19 .....................................................................................................
Additional Features 19 ........................................................................................
SMART FUNCTIONS 20 ....................................................................
LG ThinQ Application ......................................................................................20
Smart DiagnosisTM 22 ..........................................................................................
Demand Response Function...........................................................................22
MAINTENANCE 23 ............................................................................
Cleaning 23 ..........................................................................................................
TROUBLESHOOTING 24 ..................................................................
Before Calling for Service 24 ...............................................................................
Normal Sounds You May Hear 24 ........................................................................
WARRANTY 28 ..................................................................................
13
EN
Cabinet Installation
Inside Sill
Inside Sill
Inside Sill
Inside SillInside Sill
Center Hole
Center Hole
Center Hole
Center HoleCenter Hole
Outside Sill
Outside Sill
Outside Sill
Outside SillOutside Sill
1 Open the window. Mark a line on the center of
the inside sill.
Carefully place the cabinet in the window and
align the center hole on the cabinet bottom
front with the center line on the sill.
Inside Sill
Inside Sill
Inside Sill
Inside SillInside Sill
Center Hole
Center Hole
Center Hole
Center HoleCenter Hole
2 Pull the bottom window sash down behind the
upper guide until It meets the cabinet.
Window Sash
Window Sash
Window Sash
Window SashWindow Sash
Upper Panel
Upper Panel
Upper Panel
Upper Panel Upper Panel
Guide
Guide
Guide
GuideGuide
NOTE
•Do not pull the window sash down so tightly
that the movement of the curtain panels is
restricted.
3 Loosely assemble each sill support.
Sill Support
Sill Support
Sill Support
Sill SupportSill Support
Nut
Nut
Nut
NutNut
Bolt
Bolt
Bolt
BoltBolt
NOTE
•If the distance to the outer window sill is not
that deep, you may not need the bolt and nut.
4 Use 2 type A screws to attach a sill support
to the cabinet track holes on one side. Use
the cabinet track holes that will place the sill
support nearest to the outer edge of the sill.
The longer side of the sill support should be
facing outside the window.
Repeat with the second sill support on the
opposite side of the cabinet.
Screws
Screws
Screws
Screws (T
(T
(T
(Type A)
ype A)
ype A)
ype A)Screws (Type A)
Indoor
Indoor
Indoor
IndoorIndoor
Cabinet T
Cabinet T
Cabinet T
Cabinet Track
rack
rack
rack Holes
Holes
Holes
HolesCabinet Track Holes
Outdoor
Outdoor
Outdoor
OutdoorOutdoor
5 Install the cabinet with a slight tilt (about 1/2”)
downward on the outside.
Use the bolt and nut to adjust the tilt of the
cabinet.
about 1/2”
about 1/2”
about 1/2”
about 1/2”about 1/2”
Cabinet
Cabinet
Cabinet
CabinetCabinet
CAUTION
•Do not drill a hole in the bottom pan.
The product is designed to operate with
approximately 1/2” of water in the bottom pan.
There is no need to add water if the pan is dry.
15
EN
3 To prevent broken glass or damage
to windows, on vinyl or other similarly
constructed windows, attach the window
locking bracket with a type C screw.
Screw
Screw
Screw
Screw Screw
(T
(T
(T
(Type C)
ype C)
ype C)
ype C)(Type C)
Window Locking Bracket
Window Locking Bracket
Window Locking Bracket
Window Locking BracketWindow Locking Bracket
Vinyl
Vinyl
Vinyl
VinylVinyl
Screw
Screw
Screw
Screw Screw
(T
(T
(T
(Type C)
ype C)
ype C)
ype C)(Type C)
Wood
Wood
Wood
WoodWood
4 Connect the wire harness before assembling
the front grille.
5 Attach the front grille to the cabinet by
inserting the tabs on the grille into the slots on
the front top of the cabinet.
Push the grille in until it snaps into place.
NOTE
•The feature may be changed according to the
type of model.
6 Remove air filter from the front grille by pulling
the filter forward and then up slightly. Secure it
with 2 type A screws through the front grille.
NOTE
•The feature may be changed according to the
type of model.
