www.lg.com
2
4. WATER DISPENSER
Your refrigerator has a mechanism that dispatches cool water
without open the door.
NOTE: Use only water (do not add sugar). Any other kind of liquid
can cause damage on the mechanism.
To obtain water, push upward the dispenser lever with a glass
until water start flows (Figure 14). After dispensing water, remove
slowly the glass from the lever in order to avoid dripping.
Tray
• The tray can be removed easily by holding and sliding it out,
see Figure 15.
• To reinstall the tray, just slide it in (Figure 16).
• Keep fresh food in the refrigerator.
• Freeze only small amounts of food.
• After you freeze some food, once you thaw it do not freeze them again, they loose their taste and nutritional value;
after thawing them, you might keep them in the refrigerator up to 48 hours.
• Do not store food that might get decomposed under low temperatures (like pineapple, bananas and cantaloupe).
• Do not store garlic in the refrigerator.
• When storing food in the refrigerator use closed containers to avoid odor mixing and loosing of humidity.
• Always clean the food before placing them in the refrigerator. Wash and dry the fruits and vegetables.
• It is recommendable to store onion in plastic bags to avoid other food odor to get mixed with it odor.
• If your are going to store ice cream for a long period of time, place it on the freezer grid and not on the freezer door.
• When storing eggs always place them in the highest shelf or in the first compartment in order to keep them fresh for
a longer period of time.
• Throw away any food that is being decomposed; it may contaminate other foods.
• Store cold cuts, cheese and sausages in bags or plastic sealed containers.
• Do not store glass bottles in the freezer because they can break when they freeze.
• Do not store hot food inside the refrigerator they might decrease the refrigerator’s efficiency.
• In the models with water dispenser it is recommended that you change the water at least every 7 days.
In order to avoid bad or unwanted odors, is important to keep the refrigerator clean. Any spilled food must be cleaned immediately; they
can stain and/or acidify the plastic parts of the refrigerator if they are let to get dry.
WARNING. Unplug the power plug always before cleaning around the electrical parts (lamps, switches, etc.) Clean any humidity to
avoid any liquid might get into any electrical part. Do not touch the frozen part with wet hands, humid or wet object stick to frozen
surfaces.
Exterior
Use a warm mixture of mild detergent or soap to clean the refrigerator’s surface. Clean with a damp cloth and dry immediately.
Interior
It is recommended to clean the interior often. Wash all the baskets and compartments with a mixture of bicarbonate or mild detergent
with water. Clean and dry. Using other kinds of products might damage your refrigerator.
After Cleaning
Verify that ground connection is not damaged or overheated, also check that is properly connected.
Ice Tray Kit “Indoor Ice Maker”
• Remove the ice tray from the kit, see Figure 17.
• Clean the inside and the outside of the tray with a mild soap, rinse with tap water (Figure 18).
• Pass a damp piece of cloth and then dry (Figure 19).
CAUTION. Do not immerse the ice tray in water. If done, completely dry the tray.
Door lining and gaskets
Use only a mild detergent (such as dish soap).
Plastic Parts
Do not use abrasive, paper or rough products. These could damage the product.
Back Cover
In order to get an efficient performance of your refrigerator, clean the rear part of it at least twice a year.
Water Container
1. Remove the water container, see Figure 20 (it is no necessary to empty it before remove).
2. Remove the container lid, opening the snaps and wash it with dish washing detergent.
3. Rinse thoroughly under water (Figure 21).
4. Wipe it with a clean cloth, Figure 22.
The refrigerator does
not work
• Check if any fuse is broken in the electric facility.
• Check if the power cord is correctly plugged.
• Check if the power outlet is not damaged.
• Identify if there are any high consume electrical appliances working at the same time, unplug the one
that are not necessary.
There is a power
interruption
• Check that no fuse is burned.
• Check if the power cord is plugged.
• Check that the outlet is not damaged.
• Identify weather you have different high consumption equipment plugged at the same time, unplug the
one you do not use.
In case of a black out, call your electric company and ask how long it will last.
• In case of a 24 hour or less black out, do not open the refrigerator; this will keep the food fresh.
• In case of a longer black out, do one of the following options:
1. 1. Pull out all of the frozen food and keep them in an ice chest.
2. Put 2 lbs (0, 907 Kg) of frozen ice (make sure you use gloves) for each square foot (28 L) inside the
freezer. This task will preserve the food for 2 to 4 days. While handling dry ice (CO
2), wear gloves to
protect your hands from frostbite.
3. In case you do not possess neither ice chest or dry ice (CO
2), consume your food as soon as possible.
The temperature of
the refrigerator or the
freezer is too warm
or hot
• Check that the temperature control is in the right position.
• Place the refrigerator away from any heat sources or direct sunlight.
• Open the doors only when necessary.
• There are too many food that block the air vents.
• Don’t let the doors open for too long.
I can hear some weird
or abnormal sounds
• Check that the refrigerator is placed over an even leveled surface, if not, adjust the refrigerator using the
leveling height adjusting screws.
• Remove the unnecessary object from the back or top of the refrigerator.
• Check that the voltage is the correct one, if not call your electric company.
There are some odors
in the refrigerator • Store all food in sealed containers.
• Frequently clean the refrigerator inside.
Some humidity
is formed in the
cabinet’s surface
• When the weather is humid is normal.
• The door might be opened, check that is properly closed.
The front part of the
refrigerator is getting
warm
• Do not worry, is part of the normal functioning of the refrigerator, and this happens in order to avoid
condensation or “sweat”.
• If this comes to happen, just clean with a dry piece of cloth.
The compressor
works too frequently
and for extended
periods of time
• Check if the temperature controls are place in the maximum, if so, place then in the middle.
• Check that the doors are properly closed.
• Do not store over heated products.
• Do not let the doors open for too long.
• Move away from any heat sources the refrigerator.
REMEMBER: In a power failure, a full freezer stays cold longer than a partially filled one. A freezer full of meat stays cold longer than a
freezer full of baked goods. If you see that food contains ice crystals, it may be safely refrozen, although the quality and flavor may be
affected. If the condition of the food is poor or if you feel it unsafe, dispose of it.
1. THE OVERALL PERFORMANCE OR EFFICIENCY OF YOUR REFRIGERATOR MIGHT BE AFFECTED IF:
• It is place near a heat source or humid area.
• You open the door frequently.
• If you introduce water or any object in the cold air vents.
2. DURING VACATIONS WE RECOMMENDED YOU THE FOLLOWING:
•Ifthevacationsareforashortperiodoftimeplacethefreezablefoodintherefrigerator.
•Ifyouaregoingtobeoutsideorawayforalongerperiodoftime,dothefollowing:
1. Take out all food.
2. Unplug the power cord.
3. Leave the doors open to avoid bad odors.
4. Thoroughly clean the refrigerator.
3. IF YOU ARE PLANNING TO MOVE OR TO CHANGE YOUR REFRIGERATOR
FROM ITS CURRENT POSITION:
• Remove and secure all attachments inside the refrigerator.
• To avoid any damage to the leveling height adjusting screws, turn then completely until
the base.
• Place the power cord in the hook located in the upper left side.
• Clean and empty the water container and do not forget to purge the system (turning on
the switch).
• After these procedures, you will be able to move your refrigerator.
• When you move your refrigerator, place a protection sheet, such as packing cartoon under
the refrigerator to avoid floor damage.
• Always pull your refrigerator straight out. Do not shift from side to side or “walk” the
refrigerator when you are moving it.
• Use the assistance of two or more persons to move or install the refrigerator. Not following
these instructions may cause injury to the back and other parts of the body.
4. LAMP REPLACEMENT
Your refrigerator has a LED Lamp, for replace or change it, you must call your Service Center,
this change only must be done by qualified technician.
WARNING. In case of replacement, the new lamp must be the same size and wattage as the
original.
5. THE FRONT AREA WARMS UP
The front wall of the cabinet of the refrigerator might warm up sometimes specially during installation.
DO NOT ALARM! It’s normal due to avoid humidity or “sweat”.
6. THE BACK OF THE REFRIGERATOR WARMS UP (some models)
The warming up is normal because from behind passes the cooling coil.
3
Figure 8. Refrigerator Internal Temperature
Control
(certain models)
Figure 7. Freezer Internal Temperature Control.
Turning knob (all models)
NOTE: Be careful of not blocking or moving with
food packages the temperature controls, you might
change or not recognize the temperature in which your
refrigerator is set.
MANUAL DE USUARIO
REFRIGERADOR CON
CONGELADOR SUPERIOR
Lea detenidamente este manual antes de empezar a utilizar el refrigerador
y guárdelo como referencia para el futuro.
ENGLISH
USING YOUR REFRIGERATOR
4
1
THIS MANUAL CONTAINS SEVERAL IMPORTANT SAFETY NOTICES. ALWAYS READ AND OBEY ALL OF THE
FOLLOWING SAFETY MESSAGES.
DANGER If you fail to follow these instructions you will be killed or seriously injured.
WARNING Misuses of the product will cause you physical damage or personal wounds.
CAUTION Inadequate use and installation will cause damage to your property.
All safety labels will inform you of potential danger, ways to reduce chance of injury and what can happen if instructions are not followed.
WARNINGS AND IMPORTANT SAFETY MEASURES
All safety labels will inform you of potential danger, ways to reduce chance of injury and what can happen if instructions are not followed.
CAUTION. This appliance is not intended for being used by children, persons with physical or mental
disabilities, persons with reduced sensory or mental capacity, or persons with lack of experience or know-how,
unless they have supervision or instruction in relation to the use of the appliance by the person responsible for
their safety. Children should be supervised to assure that they do not play with the appliance.
NEVER USE EXTENSION CORDS. Never connect multiple machines in the same socket, this can cause
wiring to overcharge, warming, voltage vibrations and bad functioning.
ELECTRICAL CORD REPLACEMENT. If electrical cord gets damaged it must be replaced by the manufacturer, our service
center or qualified LG Electronics personnel to minimize risks.
GROUND CONNECTION. In case of electrical surge, connection to ground will reduce risks of
electric shock hazard. This unit must be grounded. Consult a qualified electrician. When moving
your refrigerator, be careful not to step on the electrical cord with the machine’s rollers.
¡¡¡NEVER KEEP EXPLOSIVES INSIDE!!!. Never store explosive substances or chemicals in
your refrigerator such as benzene, alcohol, etc. It is DANGEROUS!!
DANGEROUS FUN. An empty refrigerator can be very dangerous for children. Remove doors or magnetic packaging
when not be in use or secure it in a way to make it impossible to open and allow a child to go in as this can lead to
suffocation. Never allow a child to climb, hang or play with the refrigerator compartments. They can get hurt themselves
and damage the refrigerator.
PLUG ACCESS. The refrigerator-freezer must be placed in a way that the electrical cord can be pulled easily in case of
emergency.
WHAT TO DO WITH YOUR OLD REFRIGERATOR. Your refrigerator contains liquids (refrigerant, lubricant) made of
recyclable materials. All these materials must be sent to a recycling waste disposal site as they can be reused after a specific
recycling process. Contact local authorities.
WHEN CLOSING REFRIGERATOR DOOR. Never place your thumb or fingers on the superior part of the
handle, as it can be pressed against the lower part of the freezer handle. Keep away all fingers from injury areas
such as where doors close cabinets and hinges, etc. Be careful when closing doors if children are nearby.
NEVER USE MECHANICAL DEVICES. Never use mechanical devices or any other means to
accelerate the thawing process, use only those which are approved by the manufacturer.
NEVER STORE ELECTRONIC DEVICES. Never use electronic equipment to store food unless they
are specific models approved by the manufacturer.
WARNING. The maintenance of the lower area from the refrigerator’s back side (see image) only must
be done by qualified personal, do it by non qualified technician can produce risk of electric shock.
NOTE: This guide covers different models. Your refrigerator could have some or all of the features and parts listed below. The location of
some of the parts may not correspond with your model.
Freezer Lamp (LED) *
Freezer Shelf (Plastic or Glass)
Temperature Control (Freezer)
Refrigerator Top Lamp (LED) *
External Temperature Control (Refrigerator) *
Internal Temperature Control (Refrigerator) *
Refrigerator Lamp (LED)
Refrigerator Shelf (Glass)
Cover for Vegetables & Fruits Compartment
Vegetables & Fruits Compartment
(“2 in 1 Box” or “1 Box”) *
Magic Crisper (Plastic)
Cover for vegetable drawer, it controls humidity
Vegetable Drawer
Keeps fruits and vegetables fresh
Vita Light *
Base Grille *
Freezer Big Basket
Ice @ Door (Ice Maker)
Home Bar (Ice Container)
Freezer Small Basket
Water Tank
Refrigerator Small Basket
Multi Flow Air Duct
Distributes air to all refrigerator compartments
Egg Tray
Refrigerator Big Basket
Leveling Screws
Water Dispenser
*Certain Models
Ice Tray
Freezer Shelf (Plastic)
Temperature Control (Freezer)
Temperature Control (Refrigerator)
Multi Flow Air Duct
Distributes air to all refrigerator compartments
Refrigerator Lamp (LED)
Refrigerator Shelf (Glass)
Magic Crisper
Cover for vegetable drawer, it controls humidity
Vegetable Drawer
Keeps fruits and vegetables fresh
Freezer Basket
Egg Tray
Refrigerator Basket
Leveling Screws
1. UNPACKING
Before installing your refrigerator, remove any tape or temporary stickers. Do not remove any stickers that feature warnings, the model
serial number or the technical label of the product located on the back of the refrigerator. To remove adhesive tape residue, rub it
well with your fingers and a little liquid detergent. Clean with warm water and let dry. Do not use sharp instruments, rubbing alcohol,
flammable liquids or abrasive cleaning products to remove the adhesive tape or glue. These products can damage the surface of your
refrigerator. The shelves come already installed in their factory position. Remove the shelves and replace
them according to your spacing needs.
2. INSTALL IT AWAY FROM HEAT SOURCES AND HUMID AREAS
In places with high temperatures, freezing capacity can be affected and cause high consumption of
electrical energy. Never install in places with high humidity as this can cause oxidation and electric shock
hazard.
SAFETY MEASURES
IDENTIFICATION OF PARTS
3. THOUGH AND EVEN FLOOR
Your refrigerator must be leveled and placed on a strong floor. An unstable installation can
produce noise and vibrations. If the floor is uneven, level the unit by twisting the height adjusting
screw, this will eliminate unwanted sounds and vibrations.
NOTE: Leveling screws can easily be turned by slightly tilting the front of the refrigerator, turn the
leveling screws clockwise ( ) to raise it and counter-clockwise ( ) to lower it.
4. AMBIENT TEMPERATURE
The refrigerator will work efficiently if room temperature is between 10 °C and 43 °C (50 °F and
109,4 °F).
5. A PROPER DISTANCE FROM ADJACENT ITEMS
Adequate air flow is needed for an efficient operation. Keep your refrigerator at a relative distance
from other objects. Reduced distances between the unit and other nearby objects can diminish
freezing capacity and rise consumption of electrical energy.
NOTE: Be careful when you open the doors, one of them can be opened more than the other one.
Avoid hit the doors with items around the refrigerator area.
6. WAITING PERIOD
Wait at least one hour before connecting, after installation was completed.
7. CONNECTION
DANGER. FOR YOUR PERSONAL SAFETY, this device must be properly grounded.
Connect to a single undamaged socket. Not having proper installation will require you to
call qualified personnel to achieve it.
Do not, under any circumstance, cut or extract the third prong from the plug. It is your
responsibility and obligation to replace two-prong outlets with that of an adequately
grounded three-prong outlet.
WARNING. REPLACING ELECTRICAL CABLE; if the power cord is damaged, it must
be replaced by our service center or qualified LG technician to avoid any risk. NEVER
disconnect the refrigerator by pulling the power cord, always grip the plug firmly and
disconnect it directly from the outlet.
8. BEFORE STORING FOOD
Leave it working from 2 h to 3 h before storing food. If operation is interrupted wait 5 min before trying again.
9. INSTALLATION OF BASE GRILLE (in some models)
Installing or Replacing the Base Grille:
1. Remove the 2 screws from the bottom front part of your refrigerator (in front).
2. Place base grille into position and insert and tighten screws, see Figure 1.
To remove the Base Grille:
1. Open the refrigerator’s door.
2. Once the door is open, remove screws from base grille and remove.
3. Remove the base grille.
4. Reattach screws to the base of refrigerator.
10. IN CASE OF UNINSTALLING
If you wish to dispose of your refrigerator, keep in mind the following WARNING.
WARNING. If the use of this unit is no longer needed, please contact local
authorities to dispose of this product in a safe way; as is Pentane-cycle or pentane like gas for insulation. Insulation gases require a
special elimination process. This product contains flammable insulation.
1. CONNECTION
Remember that your refrigerator must be grounded.
CAUTION. If operation is interrupted, wait 5 minutes before restarting it.
2. ICE MAKER OPERATION
“Ice @ Door”
• To make ice cubes, pull out the ice container and pour water on the shelves (Figure 1.) Then place in their original position until you
hear a “click” sound.
WARNING. Fill only with potable water.
WARNING. Make sure the level of water in the shelf is even on the entire surface, guiding yourself with pointing arrows on Figure
2. Water must not surpass this level as it can get spilled when opening or closing door.
• The ice maker takes around 4 hours to produce ice cubes. Check the ice status through the transparent panel.
• To remove ice cubes, carefully pull the drawer lever (Figure 3). The ice cubes will fall into the ice container (Figure 4).
WARNING. Refrain from pulling the lever before ice cubes have been completely made, as this can cause water to spill, freeze,
and cause the container to stick to the Ice maker (Figure 5). If water spills, immediately wipe it off with a cloth. Avoid heavy ice
accumulation in the container as this can cause problems to move the lever and/or container.
3. THAWING
Thawing occurs automatically, you do not need to worry about this. Thawed water will flow into the evaporation shelf at the back of the
refrigerator.
4. AUTO CHECK
Your refrigerator has the capacity of auto checking. If any failure comes to happen
a code will be displayed to help the technician for its repairing. While this code is
on display, the rest of the functions of control a visualizing will not be functioning.
NOTE: In the temperature controls, the code is represented with a no consecutive
blinking of the LED (left to right/down to up) as would be in the normal mode.
Example:
5. TEMPERATURE CONTROL SETTINGS
• Refrigerator temperature will always be the same, despite ambient temperature changes.
• We recommend not to change the temperature adjustments after they have been set unless it is necessary.
• This refrigerator contains a button which controls the refrigerator’s temperature and a knob to control the freezer’s temperature.
• The correct temperature configuration for the refrigerator compartment should be 37,4 °F (3 °C).
• The correct temperature configuration for the freezer compartment should be -2,2 °F (-19 °C).
• The refrigerator compartment contains a temperature sensor which will automatically start and stop the compressor functions as
needed.
5.1 External Temperature Control (in some models)
•Refrigerator: Monitors the refrigerator temperature. External temperature control, Figure 6, (certain models).
ENERGY SAVE: By pressing this button the refrigerator will work with minimal power, reducing the time it is spent used and energy
consumption. This feature will not activate if “EXPRESS FREEZING” is on.
DOOR ALARM: You will hear an alarm when the refrigerator or freezer door stays open for over a minute. The alarm will continue
with this sound every 30 seconds. NOTE: Freezer alarm is only available for 16 cubic feet capacity models. Alarm will stop once both
doors have been shut. By pressing the button, the alarm can be deactivated.
REFRIGERATOR: This feature allows you to adjust the refrigerator temperature. The number appearing on the screen will match the
degrees of the inside of the refrigerator. You can choose from 5 different settings, from 0 °C to 6 °C (32 °F to 42,8 °F).
EXPRESS FRZ: Once this button is pressed, the refrigerator will begin to cool at full power to a maximum of two 2 hours. Pressing
the button a second time will deactivate the mechanism. This feature will not be available if “ENERGY SAVE” is on.
Temperature Configuration
HOW TO ADJUST
COLDER RECOMMENDED COLD
Press the “REFRIGERATOR” button until
the bars reach the maximum limit and the
temperature indicator reads 32 °F (0 °C).
Press the “REFRIGERATOR” button
until the indicator reads 37,4 °F (3 °C).
This is the desired temperature for best
performance of this unit (Up to the third
bar will be lighted).
Press the “REFRIGERATOR” button until
the bars reach the minimum level. The
indicator will reads 42,8 °F (6 °C).
• Freezer: Controls the flow of cold air that goes from the freezer into the refrigerator.
NOTE: To check functions of the freezer temperature control, please look for Internal Temperature Control Function.
5.2 Internal Temperature Control
• Freezer: Controls the air flow from the freezer to the refrigerator, Figure 7.
HOW TO ADJUST COLDER RECOMMENDED COLD
To adjust the position knob turn to either
side to make it turn. The arrow will set the
temperature in your freezer.
OPERATIONS AND FUNCTIONS
Ice Container Ice Shelves
Water Level
Indicators
Water Level
must be even
Figure 2Figure 1
Shelves
Figure 9
Holder
Figure 10
Shelf
Figure 11
STORING FOOD SUGGESTIONS
Absorb Moisture
Too much humidity
Release Moisture
Low Humidity
Figure 12
Shelf
Bracket
Holder
Figure 13 WHAT TO DO WHEN...
Lattice
Vita Light
1
2
3
4
CONTROL DE TEMPERATURA REFRIGERADOR
( )
MENOS FRIO
( )
MAS FRIO
( )
The error is represented with letters
The first LED is off
WHAT YOU HAVE TO KNOW ABOUT YOUR REFRIGERATOR
2
3
4
1
• Refrigerator: Controls the temperature of the refrigerator. Internal Temperature Control, Figure 8 (according to every model).
HOW TO ADJUST
COLDER RECOMMENDED LESS COLD
Press the button until the maximum level
lights are on.
Press the button until the third light is on. This
temperature is the recommended one for the
optimum refrigerator performance.
Press the button until the first light in
on. The temperature is the minimum.
1. SHELVES
The shelves of your refrigerator can be adjusted to comply with your storage necessities; depending on the model you have it can include
glass shelves or plastic shelves. Storing your foods together and adjusting the shelves to different heights will help you to locate what you
need in an easier way. This also helps your refrigerator to stay shut longer which will save you energy.
IMPORTANT: While your refrigerator glass shelves are cold do not clean with hot or warm water. The glass shelves may break if they’re
exposed to rapid temperature changes or hard impacts. For your safety the glass shelves are made out of tempered glass so when at
breaking they will fracture into tiny fragments.
NOTE: Be careful while moving or relocating the shelves, they are heavy. If moving the shelves is required keep in mind to locate them
in a safe environment to prevent them from breaking.
Shelf Refrigerator
In order to remove the refrigerator shelves follow the next instructions.
NOTE: Be careful when you remove the shelves from the refrigerator, because they are secured to the refrigerator walls.
1. Take the shelf from the back.
2. Lift it from the bottom by using the necessary strength, see
Figure 9.
3. Release the holders, Figure 10.
4. Slide it towards outside, Figure 11.
Shelf Freezer
If you need to remove the shelf of the freezer, follow the instructions for not damaging it:
NOTE: Be careful when you remove the shelves from the refrigerator, because they are secured to the refrigerator walls.
1. Hold the shelf by the front part, see Figure 12.
2. Pull the shelf outwards lifting it slightly until it leaves the holder from the bracket, Figure 13.
2. COMPARTMENTS
• Door Baskets
Door baskets can be taken off in order to clean them better.
1. To remove the basket, raise it and pull it out.
2. To replace the basket again slide it on the desirable guide and
push it down until it is tighten (You will listen a “tick”).
WARNING. Someone could get hurt if the baskets are not
well assembled. DO NOT allow children play with baskets.
Sharp corners on basket could cause injury.
NOTE: Empty the food charge before you move the door basket.
• Compartment “2 in 1 box” / Vegetables and Fruits Compartment
(in some models)
Even with the door open, warm air can not affect the freshness
zone, so you can keep in it the store food more fresh.
The compartment should be correctly closed, because having
the door open could affect the refrigerator’s performance. The
compartment can be opened pulling the tray.
NOTE: Check the position before storing the food because it can
clog if it is not closed properly.
• Vegetable Drawer (Magic Crisper)
The magic crisper allows a better preservation of your fruits and vegetables allowing to easily control the level if humidity inside. It has a
vent located in the inner wall of the lid to let humidity in or out.
• Vita Light (in some models)
LED lamp automatically operates during all day allowing the photosynthesis of the vegetables.
• Compartment “Ice Home Bar” (certain models)
In order to obtain the ice without opening the door, open the
‘Home Bar’ door only by pressing the “PUSH” button (located at
the door of the “Home Bar”).
WARNING. When the door of the “Home Bar” is open,
children might harm themselves when walking around; to
avoid any damage, avoid children to play with or near the
“Home Bar”.
NOTE: If the water container is not well placed, water could spill or
drain and no water will come out from the dispenser in the door.
3. WATER CONTAINER (some models)
3.1 Filling the Water Container
To supply water, open the cover as it is shown in the picture. You
can fill it with a jar or a glass.
NOTE: The container’s capacity can vary from model to model.
3.2 If you need to empty the water container:
• Remove the water container.
• Lift up the lid’s holder and remove the lid.
• Throw the water away.
CLEANING
ESPAÑOL
MFL65001505
OWNER’S MANUAL
TOP MOUNT
REFRIGERATOR
Please read this manual carefully before operating your set and retain it for
future reference.
Lever
Ice
Maker
Figure 3
Ice
Container
Figure 4 Figure 5
FREEZER TEMPERATURE CONTROL
COLD / MENOS FRIO
(CONTROL DE TEMPERATURA CONGELADOR)
RECOMMENDED / NORMAL
COLDER / MAS FRIO
1
5
9 COLDER / MAS FRIO
11
5
9
5
9
5
9
FREEZER TEMPERATURE CONTROL
COLD / MENOS FRIO
(CONTROL DE TEMPERATURA CONGELADOR)
FREEZER TEMPERATURE CONTROL
COLD / MENOS FRIO
(CONTROL DE TEMPERATURA CONGELADOR)
RECOMMENDED / NORMAL RECOMMENDED / NORMAL
COLDER / MAS FRIO
REFRIGERATOR TEMPERATURE CONTROL
(CONTROL DE TEMPERATURA REFRIGERADOR)
COLD
(MENOS FRIO)
COLDER
(MAS FRIO)
REFRIGERATOR TEMPERATURE CONTROL
(CONTROL DE TEMPERATURA REFRIGERADOR)
COLD
(MENOS FRIO)
COLDER
(MAS FRIO)
REFRIGERATOR TEMPERATURE CONTROL
(CONTROL DE TEMPERATURA REFRIGERADOR)
COLD
(MENOS FRIO)
COLDER
(MAS FRIO)
“2 in 1“ Box
Vegetable and Fruit
Compartment
Lattice
Ice Maker
Figure 17 Figure 18 Figure 19
Ice Tray
Water Container
Figure 20 Figure 21
Lid
Figure 22
Lower Area
(Back of
Refrigerator)
1
2
3
4
Figure 6. External Temperature Control (in some models)
P
US
H
“Home
Bar”“Home
Bar” Door
Ice Box
5
1
2
3
4
1
2
3
4
1
2
3
4
Lift up
Lid’s holder
3.3 How to install the Water Container
To install the container in its original position, make sure the valve
fits correctly in the door’s hole; you can do that by pressing the
container down when it is already placed in the door (as it is shown
in the image). Make sure that container is placed under the ribs
of the door.
NOTE: If the water container is not well placed, water could spill or
drain and no water will come out from the dispenser in the door.
NOTE: For removing
the container, not it’s
necessary empty its
content.
WARNING. Fill only
with potable water.
Ribs of the Door
Press
down
Figure 14 Figure 15 Figure 16
FRONT
Turn the leveling screws to
adjust height
Front
Back
A
B
C
D
E
F
G
H
I
P
A
B
C
D
E
F
H
I
J
K
L
N
Q
R
S
T
M
External Temperature
Control at front of
door
Home Bar at freezer
door
Water Dispenser at
front of Refrigerator
Door
U
G
Frontal View of your Refrigerator
(It may vary according to the
model you purchased)
O
REFRIGERATOR INSTALLATION
FRONT
Turn the leveling screws
to adjust height
Three
terminal
plug
Duplex
Outlet
Make sure the
connection is
grounded
10 cm
10 cm 3 cm
Figure 1
A
B
C
D
F
I
J
K
G
L
M
H
E
E
J
K
L
V
W
X
M
Frontal View of your Refrigerator
(It may vary according to the
model you purchased)
REFRIGERATOR TEMPERATURE CONTROL
(CONTROL DE TEMPERATURA REFRIGERADOR)
FREEZER TEMPERATURE CONTROL
COLD / MENOS FRIO
RECOMMENDED / NORMAL
COLDER / MAS FRIO
1
5
9
55
4
3
6
7
E R / C EL A ROF RE ZE
ONG D
M C N
TE P O T RO L
COLD / M ENOS F RIO
RECOMMENDED / NORMAL
OLDER / MAS FRI O
C
1
5
9
(CONTROL DE TEMPERATURA CONGELADOR)
COLD
(MENOS FRIO)
COLDER
(MAS FRIO)
Y
Q
Y
5
Produkt Specifikationer
| Mærke: | LG |
| Kategori: | Køleskab |
| Model: | MR462UWT |
Har du brug for hjælp?
Hvis du har brug for hjælp til LG MR462UWT stil et spørgsmål nedenfor, og andre brugere vil svare dig
Køleskab LG Manualer
13 November 2024
13 November 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
14 Oktober 2024
Køleskab Manualer
- Køleskab DeLonghi
- Køleskab Ikea
- Køleskab Bosch
- Køleskab SilverCrest
- Køleskab PKM
- Køleskab Gram
- Køleskab TCL
- Køleskab Wolkenstein
- Køleskab Siemens
- Køleskab Samsung
- Køleskab Scandomestic
- Køleskab GE
- Køleskab Daikin
- Køleskab Zanussi
- Køleskab Cylinda
- Køleskab Panasonic
- Køleskab Candy
- Køleskab Fisher & Paykel
- Køleskab Gorenje
- Køleskab Husqvarna
- Køleskab VOX
- Køleskab Miele
- Køleskab Silverline
- Køleskab Blomberg
- Køleskab Caso
- Køleskab Concept
- Køleskab Teka
- Køleskab OK
- Køleskab AEG
- Køleskab Electrolux
- Køleskab Thetford
- Køleskab Bauknecht
- Køleskab Elica
- Køleskab Whirlpool
- Køleskab Vestfrost
- Køleskab Mitsubishi
- Køleskab Sharp
- Køleskab Hotpoint
- Køleskab Dacor
- Køleskab Melissa
- Køleskab Atag
- Køleskab Kenwood
- Køleskab Mobicool
- Køleskab Omega
- Køleskab Hoover
- Køleskab Daewoo
- Køleskab Arçelik
- Køleskab Junker
- Køleskab JennAir
- Køleskab Waeco
- Køleskab Garmin
- Køleskab Sanyo
- Køleskab Grundig
- Køleskab Worx
- Køleskab Progress
- Køleskab De Dietrich
- Køleskab Indesit
- Køleskab GYS
- Køleskab Hotpoint Ariston
- Køleskab Livoo
- Køleskab Toshiba
- Køleskab Pyle
- Køleskab Klarstein
- Køleskab Ardo
- Køleskab Furrion
- Køleskab Etna
- Køleskab Yamaha
- Køleskab Infiniton
- Køleskab Trisa
- Køleskab Princess
- Køleskab Matsui
- Køleskab Nedis
- Køleskab Emerio
- Køleskab Severin
- Køleskab Scholtès
- Køleskab Hansa
- Køleskab Logik
- Køleskab Bartscher
- Køleskab Polar
- Køleskab Moulinex
- Køleskab Sauber
- Køleskab Westinghouse
- Køleskab Ilve
- Køleskab Element
- Køleskab Thomson
- Køleskab Constructa
- Køleskab Hyundai
- Køleskab AKAI
- Køleskab Hisense
- Køleskab TriStar
- Køleskab Porkka
- Køleskab Brandt
- Køleskab Adler
- Køleskab Camry
- Køleskab Crivit
- Køleskab Dometic
- Køleskab Mestic
- Køleskab Blaupunkt
- Køleskab Tomado
- Køleskab AEG-Electrolux
- Køleskab Asko
- Køleskab Atlas
- Køleskab Becken
- Køleskab BEKO
- Køleskab Elvita
- Køleskab Gaggenau
- Køleskab Iberna
- Køleskab Ignis
- Køleskab Küppersbusch
- Køleskab Leonard
- Køleskab Neff
- Køleskab Privileg
- Køleskab Smeg
- Køleskab Viva
- Køleskab Costway
- Køleskab Honeywell
- Køleskab Quigg
- Køleskab Hitachi
- Køleskab Proficook
- Køleskab Medion
- Køleskab Liebherr
- Køleskab Ariston Thermo
- Køleskab Fagor
- Køleskab Haier
- Køleskab Bifinett
- Køleskab Bomann
- Køleskab Russell Hobbs
- Køleskab KitchenAid
- Køleskab United
- Køleskab Luxor
- Køleskab Rosieres
- Køleskab Boretti
- Køleskab Vivax
- Køleskab Mora
- Køleskab Crosley
- Køleskab UPO
- Køleskab Zanker
- Køleskab Galanz
- Køleskab Amana
- Køleskab Amica
- Køleskab Arthur Martin-Electrolux
- Køleskab Euromaid
- Køleskab Comfee
- Køleskab Sunny
- Køleskab Dimplex
- Køleskab Finlux
- Køleskab Telefunken
- Køleskab CaterCool
- Køleskab Kernau
- Køleskab Bertazzoni
- Køleskab Caple
- Køleskab SIBIR
- Køleskab Zerowatt
- Køleskab Cuisinart
- Køleskab Mercury
- Køleskab Primo
- Køleskab Orbegozo
- Køleskab Viking
- Køleskab Franke
- Køleskab Optimum
- Køleskab Veripart
- Køleskab Zenith
- Køleskab Balay
- Køleskab Cata
- Køleskab Exquisit
- Køleskab Hoover-Grepa
- Køleskab Pelgrim
- Køleskab Elba
- Køleskab Elektra Bregenz
- Køleskab Faure
- Køleskab Juno
- Køleskab Nodor
- Køleskab Respekta
- Køleskab Rommer
- Køleskab Stoves
- Køleskab Juno-Electrolux
- Køleskab Schneider
- Køleskab MPM
- Køleskab Profilo
- Køleskab Hanseatic
- Køleskab G3 Ferrari
- Køleskab Frigor
- Køleskab Thor
- Køleskab V-Zug
- Køleskab Maytag
- Køleskab Gourmetmaxx
- Køleskab Domo
- Køleskab Perel
- Køleskab Saro
- Køleskab Bush
- Køleskab Unold
- Køleskab Aspes
- Køleskab Bellini
- Køleskab Salora
- Køleskab Scancool
- Køleskab Nevir
- Køleskab Techwood
- Køleskab Inventum
- Køleskab Thorens
- Køleskab Swan
- Køleskab White Knight
- Køleskab Khind
- Køleskab Dunavox
- Køleskab Midea
- Køleskab Napoleon
- Køleskab CDA
- Køleskab Frigidaire
- Køleskab Frilec
- Køleskab Fridgemaster
- Køleskab Ardes
- Køleskab Husky
- Køleskab Esatto
- Køleskab SVAN
- Køleskab Everglades
- Køleskab Danby
- Køleskab Sogo
- Køleskab RCA
- Køleskab Koenic
- Køleskab Currys Essentials
- Køleskab ECG
- Køleskab General Electric
- Køleskab H.Koenig
- Køleskab Proline
- Køleskab Stirling
- Køleskab Gladiator
- Køleskab Eta
- Køleskab Lynx
- Køleskab Lavorwash
- Køleskab Kalorik
- Køleskab Cecotec
- Køleskab Osprey
- Køleskab Onyx
- Køleskab Royal Catering
- Køleskab Friac
- Køleskab Seiki
- Køleskab Baumatic
- Køleskab Cool Head
- Køleskab Chefman
- Køleskab Meireles
- Køleskab Marvel
- Køleskab Kenmore
- Køleskab Avanti
- Køleskab Vestel
- Køleskab U-Line
- Køleskab Continental Edison
- Køleskab Cookology
- Køleskab Corbero
- Køleskab Zephyr
- Køleskab CHiQ
- Køleskab MBM
- Køleskab Artusi
- Køleskab La Germania
- Køleskab Orima
- Køleskab Whynter
- Køleskab Magic Chef
- Køleskab True
- Køleskab Lamona
- Køleskab Philco
- Køleskab Zanussi-Electrolux
- Køleskab Benavent
- Køleskab Sôlt
- Køleskab Novy
- Køleskab Rex
- Køleskab Kunft
- Køleskab Climadiff
- Køleskab Euro Appliances
- Køleskab Summit
- Køleskab LeCavist
- Køleskab Kogan
- Køleskab LERAN
- Køleskab DCG
- Køleskab Coyote
- Køleskab New Pol
- Køleskab Ravanson
- Køleskab Matrix
- Køleskab Fulgor Milano
- Køleskab Hoshizaki
- Køleskab Airlux
- Køleskab Foster
- Køleskab NEO Tools
- Køleskab Avintage
- Køleskab Insignia
- Køleskab Sam Cook
- Køleskab Consul
- Køleskab Jocel
- Køleskab Heller
- Køleskab Signature
- Køleskab InAlto
- Køleskab Manta
- Køleskab FrigeluX
- Køleskab SanGiorgio
- Køleskab Electra
- Køleskab La Sommelière
- Køleskab Orava
- Køleskab NewAir
- Køleskab IFB
- Køleskab Haeger
- Køleskab Linarie
- Køleskab Create
- Køleskab Glem Gas
- Køleskab Premium Levella
- Køleskab Schaub Lorenz
- Køleskab Fhiaba
- Køleskab Lemair
- Køleskab Arktic
- Køleskab Beverage-Air
- Køleskab Thermador
- Køleskab Yolco
- Køleskab Kuhla
- Køleskab Atosa
- Køleskab Cooluli
- Køleskab Hestan
- Køleskab Aconatic
- Køleskab Wisberg
- Køleskab Aldi
- Køleskab Kluge
- Køleskab Leisure
- Køleskab Vintec
- Køleskab AYA
- Køleskab Vedette
- Køleskab Salton
- Køleskab Tricity Bendix
- Køleskab Palsonic
- Køleskab Arthur Martin
- Køleskab Nordland
- Køleskab Saba
- Køleskab BlueStar
- Køleskab John Lewis
- Køleskab Mabe
- Køleskab Monogram
- Køleskab Valberg
- Køleskab Accucold
- Køleskab Castor
- Køleskab Heinner
- Køleskab Nabo
- Køleskab Guzzanti
- Køleskab Defy
- Køleskab Igloo
- Køleskab Nordmende
- Køleskab Rangemaster
- Køleskab GOTIE
- Køleskab Kubo
- Køleskab WLA
- Køleskab Kelvinator
- Køleskab Steel Cucine
- Køleskab Jenn-Air
- Køleskab Limit
- Køleskab Freggia
- Køleskab Carpigiani
- Køleskab Listo
- Køleskab Edesa
- Køleskab Milectric
- Køleskab New World
- Køleskab WhiteLine
- Køleskab Bompani
- Køleskab Blaze
- Køleskab M-System
- Køleskab Changhong
- Køleskab Godrej
- Køleskab Belling
- Køleskab BeefEater
- Køleskab Essentiel B
- Køleskab Edy
- Køleskab Altus
- Køleskab Edgestar
- Køleskab Parmco
- Køleskab Eurotech
- Køleskab Café
- Køleskab Equator
- Køleskab Electrolux-Rex
- Køleskab Brandy Best
- Køleskab Sub-Zero
- Køleskab Flavel
- Køleskab Bluesky
- Køleskab Tecnolux
- Køleskab Icecool
- Køleskab Cobal
- Køleskab Marynen
- Køleskab Gardenline
- Køleskab Lec
- Køleskab Oranier
- Køleskab Turbo Air
- Køleskab DAYA
- Køleskab CombiSteel
- Køleskab DCS
- Køleskab Perlick
- Køleskab Tisira
- Køleskab Unic Line
- Køleskab Gastro-Cool
- Køleskab Hiberg
- Køleskab Maxx Cold
- Køleskab Wells
- Køleskab Paulmann
- Køleskab Kucht
- Køleskab Avantco
- Køleskab Norlake
- Køleskab Arctic Air
- Køleskab Snaigė
- Køleskab Romo
- Køleskab Merax
- Køleskab Koolatron
- Køleskab Coca-Cola
- Køleskab Blucher
- Køleskab Silhouette
- Køleskab ColdTech
- Køleskab Magic Cool
- Køleskab Rhino
- Køleskab Le Chai
- Køleskab Gamko
- Køleskab IOMABE
- Køleskab APW Wyott
- Køleskab SPT
- Køleskab Kolpak
- Køleskab Hatco
- Køleskab High One
- Køleskab Les Petits Champs
- Køleskab Airflo
- Køleskab Moa
- Køleskab Master-Bilt
- Køleskab Hydra Kool
- Køleskab XO
- Køleskab Curtiss
- Køleskab Nemco
- Køleskab Winia
- Køleskab Delfield
- Køleskab Traulsen
- Køleskab Alto-Shaam
- Køleskab Simfer
- Køleskab Federal
- Køleskab Structural Concepts
- Køleskab Vinata
- Køleskab Acros
- Køleskab Adventure Kings
- Køleskab Emperor's Select
- Køleskab Fisher Paykel
- Køleskab Cosmo
- Køleskab Wine Klima
- Køleskab Marbor
- Køleskab Engel
- Køleskab Americana
- Køleskab EvaKool
- Køleskab Coldtainer
- Køleskab Orien
- Køleskab Enofrigo
- Køleskab BSK
- Køleskab Techfrost
- Køleskab Irinox
- Køleskab Azure
- Køleskab Gecko
- Køleskab Bromic
- Køleskab MSW
- Køleskab Adora
- Køleskab Newpol
- Køleskab Brastemp
- Køleskab Haden
- Køleskab Sedona
- Køleskab Vinotemp
- Køleskab Norpole
- Køleskab Gasmate
- Køleskab Triomph
- Køleskab Schmick
- Køleskab Dellware
- Køleskab HABAU
- Køleskab Electroline
- Køleskab Tuscany
- Køleskab TESLA Electronics
- Køleskab Pando
- Køleskab Smart Brand
- Køleskab Brass Monkey
- Køleskab Waltham
- Køleskab Lec Medical
- Køleskab Kalamazoo
- Køleskab Koldfront
- Køleskab HomeCraft
- Køleskab Coors
- Køleskab Eqtemp
- Køleskab Uniprodo
- Køleskab Landmark
- Køleskab PITSOS
Nyeste Køleskab Manualer
21 November 2024
21 November 2024
21 November 2024
21 November 2024
21 November 2024
21 November 2024
20 November 2024
20 November 2024
20 November 2024
20 November 2024
