care & use/installation

MaKe tHe Most oF Your

siDe Burner accessorY

warning

READ THIS MANUAL CAREFULLY and completely before using your grill accessory to reduce the

risk of:

1) Fire

2) Burn hazard, personal injury or property damage

3) Ruined steaks or other unpleasant cooking experiences

4) Unapproved installation or servicing

THIS PRODUCT IS DESIGNED FOR OUTDOOR USE ONLY. Improper installation, adjustment,

alteration, service or maintenance can cause property damage, injury or death.

Read this manual thoroughly before installation, use, or servicing of this product.

DangEr

If you smell gas:

1) Shut off all gas supply lines to the grill

accessory.

2) Extinguish any open ames.

3) Carefully open lid. Remember, it may be

extremely hot!

4) If odor continues, keep everyone away

from the grill accessory and immediately

call your gas supplier or your re depart-

ment.

warning

►DO NOT store or use gasoline or other

ammable vapors and liquids in the

vicinity of this or any other appliance.

►An LP cylinder not connected for use shall

not be stored in the vicinity of this or any

other appliance.

DangEr

s’Il y a une odeur de gaz:

1) Coupez l’admission de gaz de l’appariel.

2) Éteindre toute amme nue.

3) Ouvrir le couvercle.

4) Si l’odeur persiste, éloignez-vous de

l’appareil et appelez immédiatement

le fournisseur de gaz ou le service

d’incendie.

avErtissmEnt

►Ne pas entreposer ni utiliser de l’essence

ni d’autres vap -eurs ou liquides inam

mables dans le voisinage de l’appareil, ni

de tout autre appareil.

►Une bouteille de propane qui n’est pas

raccordée en vue de son utilisation,

ne doit pas être entreposée dans le

voisinage de cet appareil ou de tout autre

appareil.

WARNING! CALIFORNIA PROPOSITION 65

►The burning of gas cooking fuel generates some by-products which are on the list of sub-

stances which are known by the State of California to cause cancer or reproductive harm.

►California law requires businesses to warn customers of potential exposure to such substanc-

es. To minimize exposure to the substances, always operate this unit according to the use

and care instructions found in this manual. Be certain to provide adequate ventilation when

cooking.

►California Proposition 65 lists “Silica, crystalline” which is used in one of the components of

the IR burner, as an agent known to the state of California to cause cancer.

how to light Your grill accessorY

1) Before each use, complete the checklist below.

2) Make sure all burner control knobs are in the “OFF” position.

3) Push and hold the control knob for 2-5 seconds, allowing the igniter to heat up

4) Turn the knob to the “LITE” position

5) After ignition set the knob to the desired setting

►Do you smell gas? If yes, shut off everything and call the gas company or a qualied

plumber to check for leaks, if Not please continue

►Are you prepared to stay with the side burner during the entire cooking process?

If not, gather what you need before starting the lighting process. If yes, please

continue.

►Is your cooking area free and clear of any combustibles, besides your food, that

might ignite? If no, clear the area before starting the lighting process, If yes, please

continue

►Do all control knobs turn freely? If not, call for service; if yes, please continue.

►If you are using a portable propane cylinder, is it connected and leak tested? If not,

check the connection before continuing. If yes please continue.

►Do you know where your side burner’s main gas supply shut-off valve is located? If

not, locate it before continuing. If yes, please continue.

►Are all burners properly seated in the side burner? If not, seat the burners properly

before continuing. If yes please continue.

►Is the wind blowing just lightly and not blowing on the side burner? If not, wait until

the wind subsides or turn your free-standing grill so the wind goes into the front of

the grill. If yes, please continue with the lighting process.

checklist before each use (for Your safetY)

33487 03/2011

This product complies with ANSI standard Z21.58/CSA 1.6 latest edition and has been tested and

approved by Intertek.

To obtain replacement parts or service contact:

Lynx Professional Grills

5895 Rickenbacker

Commerce, CA 90040

888-289-5969

WARNING

►Never use dented, rusty or damaged propane cylinders. NEVER store additional or empty

propane cylinders in the cabinet or in the vicinity of this or any other appliance. Do not store

propane cylinders indoors or on their sides.

►Children should NEVER BE LEFT ALONE or unattended in an area where an accessory is

located. Place your accessory well away from areas where children play. Do not store items

that may interest children in or around the area of your accessory, in your accessory cart, or in

the masonry enclosure.

►NEVER move the accessory when hot. When in use, portions of the accessory are hot enough

to cause severe burns.

►Always maintain the required clearances from combustibles as detailed. Accessories are

designed for outdoor use only. NEVER use in a garage, building, shed, breezeway, or other

enclosed area. Do not use this equipment under any overhead combustible construction.

►Grill accessories are not designed or certied for and are not to be installed in or on recre-

ational vehicles, portable trailers, boats or any other moving installation.

►ALWAYS have an ABC Fire Extinguisher accessible — never attempt to extinguish a grease re

with water or other liquids.

►STORING YOUR ACCESSORY: Store your accessory in a well-ventilated area. If stored

indoors, detach and leave LP cylinder outdoors in a well-ventilated area away from heat and

away from where children may tamper with it.

►Keep any electrical supply cord and the fuel supply hose away from any heated surfaces. Elec-

trical cords should be placed away from walkways to avoid tripping hazard.

►Do not repair or replace any part of the accessory unless specically recommended in this

manual. Other service should be performed by a qualied technician.

►If the accessory is installed by a professional installer or technician, be sure that he/she shows

you where your gas supply shut-off is located. All gas lines must have a shut-off that is readily

and easily accessible. If you smell gas, check for gas leaks immediately. Check only with a

soap and water solution. (See INDEX: “Leak Testing” for further details.) Never check for gas leaks

with an open ame.

►Inspect the LP gas supply hose prior to each use of the accessory. If there is evidence of

excessive abrasion or wear, or the hose is cut, it must be replaced before using the accessory.

►Never remove the grounding prong from the plug or use this product with an ungrounded,

2-prong adapter.

►THIS MANUAL MUST REMAIN WITH THE PRODUCT OWNER FOR FUTURE REFERENCE.

You’ve just joined the world of Lynx cooks … a

discriminating collection of amateur and pro-

fessional chefs that take outdoor cooking to a

new level.

Lynx manufactures many accessory cooking

appliances to compliment your Lynx grill and

your desire for truly superior cooking results.

Your appliance has been designed and built

with meticulous attention to detail and it offers

some unique and powerful features. You can

achieve maximum performance and enjoyment of these

features only by carefully reading this manual ... before

your rst cook-out.

This manual includes important safety tips and great

hints for better grilling. You should keep it handy for easy

reference.

Also, at Lynx, we enjoy hearing from our customers. We

like to hear about your successes but also about any

difculties you are having. Please feel free to contact us

with any questions or problems, or just to share a new

recipe. Please include the model number of your

appliance in your correspondence.

With the proper use and care this product will provide

years of trouble-free service.

Should your Lynx appliance change

ownership, please make sure that the new

owner receives this manual.

Thanks again for your purchase. Enjoy!

a Message to our custoMers…

STATE OF MASSACHUSETTS:

1) Massachusetts requires all gas be installed using a plumber or gas tter carrying the appro-

priate Massachusetts license.

2) All permanently-installed natural gas or propane installations require a “T” handle type

manual gas valve be installed in the gas supply line to this appliance.

3) This does not apply to portable propane installations using a 20 pound cylinder.

warning

1) The outdoor cooking gas appliance and its individual shutoff valve must be disconnected

from the gas supply piping system during any pressure testing of that system at test pres-

sures in excess of 0.5 psi (3.5 kPa).

2) The outdoor cooking gas appliance must be isolated from the gas supply piping system by

closing its individual manual shutoff valve during any pressure testing of the gas supply pip-

ing system at test pressures equal to or less than 1/2 psi (3.5 kPa).

warning - eleCtrICal groundIng

►Product installation must meet local electric codes or, in the absence of local codes, the latest

edition of the National Electrical Code ANSI/NFPA No. 70 or the Canadian Electrical Code

CGA 1.6b2005.

►Use only a Ground Fault Interrupter (GFI) protected circuit with this outdoor cooking gas ap-

pliance.

►This accessory is equipped with a three prong (grounding) electric plug for your protection

against shock hazard and must be plugged directly into a properly grounded three prong

outlet. NEVER cut or remove the grounding prong from this plug.

►Use only extension cords with a 3 prong grounding plug, rated for the power of the equip-

ment, and approved for outdoor use with a “W-A” marking.

►To protect against electric shock, do not immerse any part of the power cord, an extension

cord or any plugs in water or other liquid.

►Unplug the product from the outlet when not in use and before cleaning. Allow it to cool

before putting on or taking off parts.

►Do not let the cord hang over the edge of a table or touch hot surfaces.

►Do not operate any outdoor cooking gas appliance with a damaged cord, plug, or after the

appliance malfunctions or has been damaged in any manner. Contact the manufacturer for

repair.

Please revIew these ImPortant safety PreCautIons

before you use your grIll aCCessory.

1) never leave the grIll aCCessory unattended whIle CooKIng.

2) Ensure all tie-down wires have been removed from the burners.

3) Always use caution when operating the grill accessory in a windy area. (See INDEX: “Grilling in

Windy Conditions” for further details.)

4) Avoid wearing loose-tting garments or long sleeves while grilling. They could ignite.

5) Never touch the grill accessory racks or immediate surrounding metal surfaces with your bare

hands while grilling.

6) Use an insulated glove or mitt when opening and operating the grill accessory.

7) The grill accessory covers must be fully removed or opened while lighting the grill accessory.

Releasing fuel into a closed grill accessory before lighting will not make it light sooner or more

efciently. It will only risk explosion and personal injury or death. Never lean over hot grill ac-

cessory surface or look directly into the grill accessory when attempting to light.

8) Do not heat unopened food containers as pressure build-up will cause the container to ex-

plode.

9) Do not use aluminum foil to line grill accessory racks or drip pans. This will alter the airow or

trap excessive heat in the control area and can melt knobs and ignition modules. Such damage

is specically excluded from your warranty.

10) Never use charcoal or any other solid fuel in the grill accessory.

11) Cooking excessively fatty meats and oils will cause are ups. Internal res or damage caused by

them or by the grill accessory being left unattended while cooking are not covered under the

terms and conditions of our warranty.

12) Never grill without a drip pan in place if your accessory utilizes a built-in drip pan. Always en-

sure the drip pan is pushed all the way to the back of the grill accessory. When not correctly in

place, hot grease can leak downward and produce a re or explosion.

13) Grease is extremely ammable. Let hot grease cool down before attempting to handle or dis-

pose of it. The drip tray should be cleaned of grease on a regular basis.

14) Do not use the grill accessory unless a leak check has been performed on all gas connections.

(See INDEX: “Leak Testing” for further details.)

15) Never operate the grill accessory while under the inuence of alcohol or drugs.

16) Do not lean on side shelves and never place a load weighing more than 25 pounds on a side

shelf.

17) If any burner does not light or goes out during operation, turn off all gas control knobs and wait

ve (5) minutes before attempting to re-light.

iMportant safetY precautions

table of contents

a Message to our custoMers… ......................................................................5

iMportant safetY precautions .....................................................................7

using Your lYnX accessorY ..............................................................................9

Accessories Covered in this Manual ...............................................................................9

Using The LYNX Power Burner (LPB) ...........................................................................10

Smell of Gas While Cooking 10 .....................................................................................

Yellow Flames 10 ............................................................................................................

Lighting Instructions for All Accessories ......................................................................11

Safety Practices and Precautions ...............................................................................11

At Each New Season 11 .................................................................................................

Purging the Gas Lines ...............................................................................................11

Match Lighting 11 ..........................................................................................................

Low Heat Flame Adjustment 12 .....................................................................................

How To Obtain Service From Lynx ...............................................................................13

installing Your lYnX accessorY ...............................................................14

before You start ....................................................................................................15

If Shipment Arrives Damaged .....................................................................................15

Important Notes ............................................................................................................15

Where’s the Wind? 15 .....................................................................................................

How Long is Your Run? 15 ..............................................................................................

Are You “On-the-Level”? 15 ..........................................................................................

Built-in Installations 16 ...................................................................................................

Clearance to Combustible Materials 16 .........................................................................

gas & electric connections ..........................................................................17

gas Plumbing ................................................................................................................17

Natural Gas 17 ...............................................................................................................

LP Gas 18 .......................................................................................................................

Converting for Fuel Type 18 ...........................................................................................

LP Connections 18 .........................................................................................................

Propane Hook Up ..........................................................................................................19

Natural Gas Hook Up ....................................................................................................19

Maximum Runs for all appliances on supply line 19 ......................................................

Electrical Connections ...................................................................................................20

Optional Electrical Kits 20 ..............................................................................................

Connecting the Wiring 20 ..............................................................................................

Testing the Installation ..................................................................................................21

Leak Testing 21 ..............................................................................................................

Fixing a Gas Leak 21 ......................................................................................................

Schematics .....................................................................................................................22

Cut-out Dimensions for Built-in Grills & Accessories ..................................................23

lYnX liMited warrantY .......................................................................................24

lYnX residential plus warrantY .................................................................25

Side Burner Exploded Parts View ...............................................................................26

Index ..............................................................................................................................27

The Lynx Power

Burner (LPB) is a

dual-ring com-

mercial style

burner with a

range of 3,000

to 47,000 BTU’s.

This manual covers several Lynx accessory appliances and optional

accessories for those appliances.

Except where noted, the assembly, installation and use of these Lynx

accessories is identical.

using Your accessorY

The LSBPC-1

Prep Center

Features two

15,000 BTU

burners and

an integral

bamboo

cutting board

for food prep.

Accessories covered in this MAnuAl

The LCB1-2 & LCB2-2, LSB1-2 & LSB2-2 (Lynx

Side Burner 1 & 2) features either one or two

15,000 BTU burners for cooking smaller food

items. The LCB1-2 & LCB2-2 can be mounted

directly to most Lynx grills. For the 27” and

36” Lynx grills with smaller depths, a LCB-BKT

adapter is available. The LSB1-2 and LSB2-2

are designed for installation in a non-combus-

tible, built-in enclosure.

The Lynx Power Burner incorpo-

rates a cast brass, dual-ring,

burner.

Each ring can be independently

operated for maximum heat

control. Used together they can

generate up to 47,000 BTU’s.

The knob on the left controls

the outer burner ring and the

knob on the right controls the

inner burner ring.

The Hot Surface ignition system

provides reliable ignition.

The main grate can easily

handle oversized stock pots and

removing the center grate ac-

commodates a commercial style

round-bottom wok base. (12

inch minimum)

The Lynx Power Burner also

features a fully extendable

stainless steel drip pan.

smell of gas

whIle CooKIng

IF YOU SMELL GAS WHILE

THE GRILL ACCESSORY

IS OPERATING, IMMEDIATELY

TURN OFF ALL BURNERS AND

SHUT OFF THE MAIN FUEL

SUPPLY.

• PERFORM A LEAK TEST

(See INDEX: “Leak Testing” for

further details.)

• CHECK FOR BLOCKAGES

yellow flames

A yellow ame on the main

burners indicates a lack of air.

But, if the air around the grill

is dusty or if heavy grease is

present, some orange tips on

the burner ame are normal.

►ADJUST THE AIR SHUTTER

ONLY DO THIS WHEN THE

ACCESSORY HAS COOLED

DOWN COMPLETELY!

1. Remove the cooking

grates.

2. Reach under the drip

guard and rotate the air

shutters to adjust.

3. Ensure that the burner is

seated correctly on the

frame, with the brass peg

seated inside the

positioning hole.

4. Re-light and check the

ame.

Using The LYnX Power BUrner (LPB)

safety PraCtICes

and PreCautIons:

WARNING

Read the ‘User Manual/Instal-

lation Instructions’ carefully

and completely before using

your grill or grill accessory to

reduce the risk of re, burn

hazard or other injury.

Ensure that burner ties and all

packing materials are removed

before lighting any new

accessory.

at eaCh new season

At the start of each new grilling

season you should remove the

cooking grates and check the

burners, venturis, orices and

valves for obstructions.

Spiders and insects often nest

in these areas of the accessory

and can disrupt air ow, causing

damage to the accessory and

personal injury.

Also, check all hoses and

ttings for damage, abrasion,

wear and tear and repair, if

necessary, before turning the

gas on.

Replacement pressure regula-

tors and hose assemblies, must

be the type specied by Lynx.

The pressure regulator and

hose assembly supplied with

the unit must be used.

If the unit is LP, screw the

regulator into the tank and leak

check the hose and regulator

connections with a soap and

water solution before operating

the burner. Turn all knobs to

OFF then SLOWLY turn on the

gas supply valve.

Do not use any grill accessory if

you smell gas.

PurgIng the gas lInes

You should purge the gas line

of air before attempting to light

the grill accessory.

1. Make sure all grill controls

are in the “OFF” position.

2. Slowly turn on the main

gas supply.

3. Push in the control knob

for the burner furthest

from the fuel source. Using

the burner furthest from

the fuel source will com-

pletely purge the lines. It

will take several seconds

for the burner to light.

4. Hold the knob ON for

about 20 seconds to allow

the air in the system to

purge and the burner to

light

5. Wait at least 5 minutes

after shutting off the

control before attempting

to light the burners.

matCh lIghtIng

If a burner fails to light after

several attempts, it can

be match lit. If you’ve just

attempted to light the burner

with the igniter, allow 5 minutes

for any accumulated gas to

dissipate before match lighting.

Make sure all knobs are in the

OFF position. Keep your face

as far away from the burner as

possible.

Using the manual lighting rod,

pass a lit match over the ports

of the burner. The LYNX Power

Burner features a lighting rod as

shown above.

Push and turn the control

knob of the burner to ‘Lite”. If

the burner does not light in 4

seconds, turn the knob off and

wait 5 minutes before attempt-

ing again.

Lighting instructions for ALL Accessories

LOW HEAT FLAME

ADJUSTMENT

The burners on your Lynx

accessory feature an adjustable

low setting.

Fluctuations in gas pressure,

gas conversion and even in the

quality of the gas itself may

affect burner performance at

the “LOW” setting. It could be

either too high or too low.

To adjust the burner

for low setting:

►Make sure the grill

accessory is cool.

►Remove the grates so that

you can see the ame while

adjusting the burner.

►Light the burner and set

it to “LOW”. (all the way

counter- clockwise).

►Pull off the control knob.

►While holding the valve

shaft with pliers, insert a

thin at-blade screwdriver

into the shaft and, while

watching the ame, adjust

it to a minimum stable

setting.

Use a small screwdriver for low

setting burner adjustment.

Before calling for service,

please make sure you have the

following information:

Model number

Date of purchase

Proof of purchase by the

original owner

Serial number

The serial number can be

located on the rating plate

sticker. You may have a sticker

on the back page of this

manual. If not, you will nd one

located either on the underside

of the drip tray (if you have

one), on the heat shield behind

the front panel, or on the inside

left panel wall.

For warranty service, contact

the Lynx Customer Service

Department for an authorized

service agent near you at:

• (888) Buy-Lynx

• (888-289-5969)

• www.LynxGrills.com

Your satisfaction is of the

utmost importance to us. If a

problem cannot be resolved to

your satisfaction, please write,

fax or email us:

Lynx Professional Grills

5895 Rickenbacker

Commerce, CA 90040

Service: (888) Buy-Lynx

(888-289-5969)

Tel: (323) 838-1770

Fax: (323) 838-1778

www.lynxgrills.com

Contact Lynx for replacement

parts. Parts are shipped F.O.B.

Commerce, CA.

How To obTain Service From Lynx

installing Your accessorY

installing Your lYnX accessorY ................................................................14

before You start ....................................................................................................15

If Shipment Arrives Damaged .....................................................................................15

Important Notes ............................................................................................................15

Where’s the Wind? 15 .....................................................................................................

How Long is Your Run? 15 ..............................................................................................

Are You “On-the-Level”? 15 ...........................................................................................

Built-in Installations 16 ...................................................................................................

Clearance to Combustible Materials 16 .........................................................................

gas & electric connections ..........................................................................17

gas Plumbing .................................................................................................................17

Natural Gas 17 ................................................................................................................

LP Gas 18 ........................................................................................................................

Converting for Fuel Type 18 ...........................................................................................

LP Connections 18 .........................................................................................................

Propane Hook Up ..........................................................................................................19

Natural Gas Hook Up ....................................................................................................19

Maximum Runs for all appliances on supply line 19 .......................................................

Electrical Connections ...................................................................................................20

Optional Electrical Kits 20 ..............................................................................................

Connecting the Wiring 20 ..............................................................................................

Testing the Installation ..................................................................................................21

Leak Testing 21 ..............................................................................................................

Fixing a Gas Leak 21 ......................................................................................................

Schematics .....................................................................................................................22

Cut-Out Dimensions for Built-in Grills & Accessories .................................................23

lYnX liMited warrantY .......................................................................................24

lYnX residential plus warrantY .................................................................25

Side Burner Exploded Parts View ...............................................................................26

Index ..............................................................................................................................27

table of contents

how long

Is your run?

Keep all gas supply lines as

short as possible because

gas lines lose pressure over

distance and with each elbow

and tee that is added. This drop

in pressure affects accessory

performance. (See INDEX: “Gas

Supply Line Runs” for further details.)

if shipMent arrives daMaged

vIsIble loss or damage:

Be certain any visible damage to the carton is noted on freight bill or express receipt and signed by

the person making delivery.

FILE CLAIM FOR DAMAGES IMMEDIATELY, regardless of extent of damage.

ConCealed loss or damage:

If damage is unnoticed until the accessory is unpacked, notify the transportation company or carrier

immediately and le a “concealed damage” claim with them. This should be done within (15) days

of the date delivery is made to you. Be sure to hold on to the container for inspection. We cannot

assume responsibility for damage or loss incurred in transit. (See INDEX: “Obtaining Service from Lynx” for

further details.)

warning

►Never install this product into a combustible enclosure. Doing so could result in re, property

damage and personal injury.

►Never locate the accessory under a roof or overhang, in a building, garage, shed or other

such enclosed area.

►Always maintain the required clearances from combustibles as detailed. Accessories are

designed for outdoor use only. NEVER use in a garage, building, shed, breezeway, or other

enclosed area. Do not use this equipment under any overhead combustible construction.

►Installation must conform with local codes or, in the absence of local codes, with either the

National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas and propane Installation

Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, in Canada.

where’s the wInd?

When selecting a suitable

location, consider important

factors such as exposure to the

wind and foot-trafc patterns.

If you have a freestanding

grill, position it so the prevail-

ing wind blows into the front

control panel (at your back

when grilling), supporting the

proper front-to-rear airow.

Built-in accessories located

in areas with prevailing winds

should be protected by a wind

barrier.

are you “on-the-level”?

Proper leveling during instal-

lation is critical. An accessory

that is out of level will cause

erratic burner combustion and

inefcient, uneven heating. A

carpenter’s spirit level should be

used to level the accessory both

front-to-back and side-to-side.

If the oor is uneven or has

a decided slope, re-leveling

may be required each time you

move a freestanding unit.

before You start

iMportant notes

BUILT-IN INSTALLATIONS:

Lynx built-in accessories are

intended for installation in a

built-in enclosure constructed

of non-combustible materials.

The accessory drops into the

opening shown in the cutout

detail drawing and hangs from

its counter-top trim. A deck is

not required to support it from

the bottom.

Pay special attention to the

provisions shown for gas line

hook-up. (See INDEX: “Cut-out

Dimensions for Built-in Grills &

Accessories”)

Installation provisions may be

made for the Power Burner

installation. The Power Burner

cooking height may be reduced

to better accommodate large

cooking pots. Clearances to

combustible material must be

maintained as outlined below.

No combustible material shall

be used in the construction of

a counter top using a recessed

application.

The enclosure should have

ventilation holes to prevent gas

build-up in the event of a leak.

The deck ledges and counter

should be at and level. (Refer

to ANSI Z21.58 Standard for

Outdoor Cooking Gas Appli-

ances, Section 1.7 Enclosures

For Self Contained LP-Gas

Supply Systems or local codes

for additional information.)

The grill accessory may be

powered from either a 120 volt,

60 hertz, 15 amp GFI certied

outlet installed by a qualied

electrician OR it may be

powered directly

from your Lynx

Grill transformer power supply.

When a Lynx grill is not

available or if the grill is

not located close enough

to the grill a Lynx LASK

(Lynx Accessory Switch Kit)

is available as an optional

purchase.

CLEARANCE TO COM-

BUSTIBLE MATERIALS:

Minimum clearance from

the sides and back of the

accessory to adjacent combus-

tible construction below the

top of unit are 12” from the

sides and back.

Dégagement minimal entre

les parois latérales et l’arrière

de l’appariel et la construc-

tion combustible au-dessous

du panneau supérieur de

l’appareil (30 cm à partir des

parois latérales et 30 cm à

partir de l’arrière).

Minimum clearance from sides

and back of unit to adjacent

combustible construction

extending above the unit is

18” from the sides and back.

Dégagement horizontal

minimal entre les parois

latérales et l’arrière de

l’appariel et la construction

verticale combustible au-

dessus de l’appareil (45.7 cm

à partir des parois latérales et

45.7 cm à partir de l’arrière).

Do not use this appliance

under overhead combustible

surfaces.

Ne pas utiliser cet appareil

sous une surface combustible.

gas & electric connections

warning

Never coNNect a gas liNe directly to the accessory. a pressure regulator must

be iNstalled oN all gas equipmeNt. all local codes require it aNd lyNx supplies

the correct regulator with your accessory. removiNg or failiNg to iNstall the

pressure regulator caN result iN fire aNd serious persoNal iNjury aNd will void

the warraNty.

The accessory is factory set to

use either propane (LP) or

natural gas (NAT). It is critical

that the gas you use matches

that which the accessory was

set up for. You can verify that by

checking the rating plate.

The rating plate is located on

the heat

shield

behind

the front

panel.

Ensure that the gas supplied

meets with the minimum

pressure requirements.

Do not operate the accessory on

any gas other than that for which

the accessory has been set.

Fuel WC Max

Inlet

WC Min

Under Full

Load

Nat Gas 7 in 4 in

LP 14 in 10 in

Water Column Requirements

Both the regulator and the

manifold orices have been

tuned for the type of gas

specied on the rating plate.

Converting to a different type

of gas requires a conversion

kit which is included with your

side burner accessory and

must be installed by a qualied

technician.

All installation and all instal-

lation parts must conform to

local codes with the National

Electrical Code, ANSI/NFPA

70-1990 and the National

Fuel Gas Code, ANSI Z223.1/

NFPA 54 in the U.S. and CGA-

B149.1/.2 in Canada.

Canadian installations must

conform to CGA-B149.1/.2

natural gas/propane installation

code. (Canada)

natural gas

Lynx recommends that only

qualied professionals perform

the required plumbing on this

product.

The gas supply line must be

sized to accommodate the total

BTU requirements of all the

gas-red equipment that will be

connected to that line.

In no case should pipe less

than 3/4” inside diameter or 1”

outside diameter be used.

►Calculate the total BTU

output of all equipment

and refer to “INDEX: Gas

Supply Line Runs” for

allowable run distances.

Failure to meet these

minimum requirements may

reduce performance of the

accessory and any other

appliances running on that

supply line.

►Always keep supply line

runs as short as possible.

(See INDEX: “Gas Supply line

runs”)

►A gas shut-off valve must

be installed in an easily

accessible location by a

qualied plumber.

Gas PlumbinG

►Keep any threading

compound off of the rst

two pipe threads to avoid

having any small pieces of

compound break loose and

clog a burner valve or

orice. Do not put sealant

on any male end of are

ttings..

►

For built-in installations, it is

recommended that any exible

pipe used be kept as short as

possible. (See INDEX: “Gas Connec-

tions” for typical permanent hook up.)

lP gas

Accessories set up for LP gas

come equipped with an LP

hose/ regulator assembly for

connection to a standard 20 lb.

LP cylinder. (Type 1).

All ttings necessary to attach

the assembly to the accessory

are included.

Keep

last two

threads

clean

LP cylinder with type 1 valve

connection

Permanently plumbed LP con-

nections, such as those in line

with a bulk cylinder, require

a 4/11 regulator. (Lynx P/N

30781)

ConvertIng

for fuel tyPe

After changing all of the orices

in the conversion kit you must

make sure the correct regulator

is used. If you are using a 4/11

Convertible regulator, ensure

that it is set for the correct fuel.

The correct fuel type will be

abbreviated at the end of the

plunger. Remove the cap and

check the plunger. If, needed,

pull the plunger from the cap,

ip it over and re-attach it to

the cap. Then re-insert the cap

into the regulator and tighten it

using a 7/8 inch wrench.

Never connect an unregulated

gas line to the grill.

When exchanging your cylinder

for a rell, exchange only for

a Type 1 20lb cylinder with an

over-ll protection device.

Never use a cylinder with a

damaged valve.

A dented or rusty LP cylinder

may be hazardous and should

be avoided. If in doubt, have it

checked by your LP supplier.

Always check for leaks after

every LP cylinder change. (See

INDEX: “Leak Testing” for further

details.)

Always shut off the LP-gas

supply at the cylinder when the

accessory is not in use.

Cylinders must be stored

outdoors in a well-ventilat-

ed area out of the reach of

children. If your accessory is

stored indoors, the LP cylinder

must be stored outside.

lP ConneCtIons

Make sure the LP cylinder valve

is fully closed. It is possible for

the valve to be open without

releasing gas but, as soon

as you start connecting the

regulator, gas will leak from the

connection.

Insert the regulator inlet into

the cylinder valve and turn the

black coupler clockwise until

the coupler is hand tight. Do

not over-tighten this connec-

tion.

To disconnect the coupler, rst

make sure the main cylinder

valve is turned off. Grasp

the coupler and turn counter

clockwise. Always leak-test the

connection after relling or

exchanging LP cylinders. (See

INDEX: “Leak Testing” for further

details.)

propane hook up natural gas hook up

maXImum runs for all

aPPlIanCes on suPPly

lIne

Run Length

3/4” Pipe

(in feet)

Max BTU for all

Appliances on

line

10 360,000

20 245,000

30 198,000

40 169,000

50 150,000

60 135.000

70 123,000

80 115,000

COLD WEATHER

WARNING: PROPANE

Extremely cold temperatures may

cause your burner to light

inside

the

burner instead of

outside

. Once lit, if

you hear a ‘whooshing’ sound, im-

mediately turn the burner knob off to

extinguish the ame and then imme-

diately re-light the burner.

Installation requires an outdoor

120VAC 15A GFI (Ground Fault

Interrupter) electrical outlet

adjacent to the accessory.

The GFI outlet features an

internal breaker that reduces

shock hazard. This type of

outlet should be installed by

a qualied electrician either

inside the island enclosure

for built-in units, or near the

location where a free-standing

unit will be used.

For built-in accessories, the

supplied 12V transformer is

connected to the accessory

during installation.

If the electrical system fails to

operate, a connection may have

come loose in shipping or the

GFI may have tripped, requiring

a reset. See the Troubleshoot-

ing section for more details.

ConneCtIng the wIrIng

The accessory electrical

harnesses are designed to

provide power for both ignition

and lighting. While ignition is

controlled at the accessory,

lighting is controlled at the grill.

You can control lighting at the

accessory by installing the Lynx

Accessory Light Switch (LASK).

Disconnect the 4-pin connector

on the grill and connect those

plugs to the mating plugs on

your accessory. (See Index “Electri-

cal Connections)

Important note: If using

multiple Lynx accessories

with the Control Illumina-

tion/Blue LED’S, a connector

for this purpose is built into

the accessory wiring. This will

allow you to use the light switch

on your Lynx grill to actuate

the power on more than one

accessory.

ElEctrical connEctions

oPtIonal eleCtrICal KIts

In addition to the accessory burner kits, Lynx also manufactures 3 specialized electrical kits that you

may purchase for your accessory, depending upon how it will be installed. Each electrical kit ships

with an instructional sheet for assembly. Assembly instructions and schematics/drawings can also be

found on our website at WWW.LYNXGRILLS.COM.

►LASK: Lynx Accessory

Switch Kit

►LAK Lynx Electrical

Adapter Kit

►LPEK Lynx Power

Extension Kit

This switch and transformer kit allows independent control of

a Lynx accessory burner without connection to a grill. The kit

contains a transformer and mounting bracket as well as a switch

assembly with a mounting plate. The kit also contains a wiring

harness to adapt an L series accessory to an M series switch and

transformer.

M series Lynx grills and accessories feature a new wiring harness

design that simplies accessory installation. The LAK Lynx Electrical

Adapter Kit is needed only when installing a grill and accessory that

are not manufactured under the same series (M or L series & prior).

This one kit connects both an M series Lynx Grill to an earlier Lynx

accessory as well as an earlier Lynx Grill to an M series accessory.

Each kit contains two wire harnesses. Only one harness will be

used depending on the units being installed

The Lynx Power Extension Kit provides 12 feet of additional wire

between your Lynx Grill and accessory burner.
