© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
axxessinterfaces.com • metraonline.com axxessinterfaces.com • metraonline.com
Axxess Integrate
®Axxess Integrate
®
REV. 4/14/17 © COPYRIGHT 2017 METRA ELECTRONICS CORPORATION REV. 4/14/17
Installation Instructions for AX-HYKIACAM2-6VInstallation Instructions for AX-HYKIACAM2-6V
INTERFACE FEATURES
• Retains the factory back-up camera to an aftermarket radio
Allows an aftermarket camera to be added to the factory screen
• Includes the AX-CAM6V 12-volt to 6-volt converter
INTERFACE COMPONENTS
AX-HYKIACAM2-6V harness • AX-CAM6V 12-volt to 6-volt converter
AX-HYKIACAM2-6V
Hyundai / Kia (without NAV)
2014-2017
Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights
must be connected before cycling the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
HYUNDAI
Elantra * 2017
Elantra 2014-2016
Santa Fe 2013-2016
Santa Fe Sport * 2017
Santa Fe Sport 2013-2016
HYUNDAI (CONT)
Sonata 2015-2016
Tucson 2014-2017
KIA
Forte * 2017
Optima * 2017
KIA (CONT)
Optima 2016
Sedona ** 2015-2016
Sorento * 2017
Sportage * 2017
* Without 7-inch touchscreen radio
** Without UVO radio
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connections to be made
The AX-HYKIACAM2-6V can be connected two different ways
To retain the factory back-up camera to an aftermarket radio:
Connect the Black wire to chassis ground, and also to the wire of the AX-CAM6V.Black
Connect the Red Blue/Red wire to the wire of the AX-CAM6V.
Connect the reverse wire of the aftermarket radio, and the wire of the Blue/White
AX-CAM6V, to a reverse wire.
Connect the male Yellow RCA jack to the rear camera input of the aftermarket radio.
To allow an aftermarket camera to be added to the OEM screen:
Connect the Black wire to the aftermarket cameras ground wire.
Connect the power wire of the aftermarket camera to accessory power.
Connect the female Yellow RCA jack to the aftermarket camera.
Tape off and disregard the following (1) wire, it will not be used in this application: Red.
Disregard the AX-CAM6V, it will not be used in this application.
Note: If the wire is not populated on the factory side, a reverse wire will need to Blue/Red
be sourced from the vehicle. A 48-inch loose wire is included for this purposeGreen/Purple
.
