AX-MAZCAM-6V AX-MAZCAM-6V
REV. 8/28/18 REV. 8/28/18© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
INSTALLATION INSTRUCTIONSINSTALLATION INSTRUCTIONS
INTERFACE FEATURES
• Retains the factory backup camera to an aftermarket radio
• Allows an aftermarket camera to be added to the factory screen
• Includes the AX-CAM6V 12-volt to 6-volt converter
INTERFACE COMPONENTS
• AX-MAZCAM-6V harness • AX-CAM6V 12-volt to 6-volt converter
Mazda Backup Camera Retain/Add-On
2007-2015
MAZDA
CX-5 2013-2015
CX-7 2007-2012
CX-9 2007-2015
Mazda6 2011-2015
• Wire cutter • Crimping tool • Solder gun • Tape
• Connectors (example: butt connectors, bell caps, etc.)
APPLICATIONS
TOOLS REQUIRED
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator lights must
be connected before cycling the ignition. Also, do not remove the factory radio with the key in the on
position, or while the vehicle is running.
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and spected re
mobile elect nics school in our industry.ro
Log onto www.installerinstitute.com or call
800-354-6782 for mo information and take steps re
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
Connections to be made
The AX-MAZCAM-6V can be connected two different ways
To retain the factory backup camera to an aftermarket radio:
Connect the wire to chassis ground, and also to the wire of the AX-CAM6V.Black Black
Connect the Yellow Blue/Red wire to the wire of the AX-CAM6V.
Connect the reverse wire from the aftermarket radio, to the reverse signal in the vehicle,
and also to the wire of the AX-CAM6V.Blue/White
Connect the
male
Yellow RCA jack to the rear camera input of the aftermarket radio.
To allow an aftermarket camera to be added to the OEM screen:
Connect the
female
Yellow RCA jack to the aftermarket camera.
The AX-CAM6V 12-volt to 6-volt converter will not be used in this application.
Tape off and disregard the following (2) wires, they will not be used in this application;
Black Yellow,
IMPORTANT
If you are having difficulties with the installation of this product, please call our Tech Support
line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make
sure the installation was performed exactly as the instructions are stated. Please have the
vehicle apart and ready to perform troubleshooting steps before calling.
