Side 1/3
Installation Instructions for CHRYSAV
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION © COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION REV. 7/17/15 REV. 7/17/15
Installation Instructions for CHRYSAV
axxessinterfaces.com metraonline.com axxessinterfaces.com metraonline.com
Axxess Integrate Axxess Integrate
Introduction
The CHRYSAV is designed to provide an audio/video input to the OEM
overhead video screen from the aftermarket radio, and provide the audio/
video input from the rear seat control panel to the aftermarket radio.
Note:
The CHRYSAV is designed to work with the overhead video monitors that
do not have the DVD player built in.
This harness must be used along with an Axxess interface.
Please visit axxessinterfaces.com for more information.
CHRYSAV
APPLICATIONS
INTERFACE COMPONENTS
• CHRYSAV harness
TOOLS REQUIRED
• Cutting Tool • Tape • Crimping Tool
• Connectors (i.e. butt-connectors, bell caps, etc.)
INSTALLATION INSTRUCTIONS
Important: Before beginning any of the following, disconnect the negative
battery terminal to prevent an accidental short circuit.
From the 22-pin harness
Connect the “A/V 1” RCAs to the aftermarket radios audio/video
input. Plug Yellow Redin to video-in, to right audio-in, and to White
left audio-in.
Connect the “A/V 2” RCAs to the aftermarket radios audio/video
output. Plug Yellow in to video-out, to right audio-out, and Red White
to left audio-out.
Connect the Yellow RCA to the aftermarket radios backup camera
input of the aftermarket radio.
Connect the loose wire to ground.Black
CHRYSLER
Town & Country 2008-up
DODGE
Durango 2008-2013
Grand Caravan 2008-up
Journey 2009-2010
Ram 1500 2009-2011
Ram 2500/3500 2010-2011
JEEP
Grand Cherokee 2008-2013
RAM
1500/2500/3500 2012
VOLKSWAGEN
Routan 2009-2013
