INSTXSVI-1788-NAV
1-800-221-0932 metraonline.com
INSTXSVI-1788-NAV
1-800-221-0932 metraonline.com
REV. 6/23/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION REV. 6/23/16 © COPYRIGHT 2004-2016 METRA ELECTRONICS CORPORATION
K PNOWLEDGE IS OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP
certified technicians
Connect the Gray/Black wire to the right front negative speaker output of
the aftermarket radio.
Connect the Green wire to the radio’s left rear positive speaker output.
Connect the Green/Black wire to the radio’s left rear negative speaker output.
Connect the Purple wire to the radio’s right rear positive speaker output.
Connect the Purple/Black wire to the radio’s right rear negative speaker output.
The following (3) wires are for the aftermarket radios that have navigation built in.
Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio (if applicable).
Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio (if applicable).
Connect the Green/Purple wire to the reverse wire of the aftermarket navigation
radio (if applicable).
INITIALIZING THE XSVI-1788-NAV
Attention! If the interface loses power for any reason, the following steps will need to
be performed again. Also, if installing an ASWC-1 connect it after you initialize and test
the interface/radio, with the key in the off position.
Turn the key (or push-to-start button) to the ignition position and wait until the radio
comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the off
position, disconnect the interface, check all connections, reconnect the interface,
and then try again.
Turn the key to the off position, and then to the accessory position. Test all functions
of the installation for proper operation, before reassembling the dash.
FEATURES
Provides accessory power (12-volt 10-amp)
Retains R.A.P. (retained accessory power)
Provides NAV outputs (parking brake, reverse, and speed sense)
Prewired ASWC-1 harness (ASWC-1 sold separately)
Retains balance and fade
USB updatable
XSVI-1788-NAV
Dodge Sprinter 2008-2009 /
Freightliner Sprinter 2008-up
Accessory and NAV Output CAN Interface
Connections to be made
Connect the Yellow wire to the radio’s 12 volt battery or memory wire.
Connect the Black wire to the radio’s ground wire.
Connect the Red wire to the ignition wire of the aftermarket radio.
Connect the Orange wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire, tape off the wire.Orange
Connect the Blue wire to the antenna turn on wire of the aftermarket radio.
Connect the wire to the left front positive speaker output of the aftermarket radioWhite
.
Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
Connect the wire to the right front positive speaker output of the aftermarket radio.Gray
CAUTION!
All accessories, switches, climate controls panels, and especially air bag indicator
lights must be connected before cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
