Side 1/39
Online Reference
© 2024 Microchip Technology Inc. and its subsidiaries
DS50003666A - 1
CLB Synthesizer
The PIC16F13145 family of microcontrollers introduce a new peripheral, the Logic Block (CLB).Congurable
The CLB peripheral, comprised of 32 Basic Logic Elements (BLE), allows the users to incorporate hardware-
based custom logic into their applications. Each logic element’s Look-up Table (LUT) based design oers
vast customization options, and the CPU-independent operation improves the response time and power
consumption.
The user must elements as matrix multiplexers, LUTs, and to achieve a given logic function,congure ip-ops
which is similar to the Logic Cell (CLC) on PICCongurable ® MCUs or the Custom Logic (CCL) on theCongurable
AVR® MCUs. However, the matrix is much larger and is interconnected to a higher degree - which enables users
to make more complex logic functions. To help users focus on the intended functionality of their logic design
without having to understand the inner workings of the peripheral, Microchip provides a GUI (CLB Synthesizer)
used for Logic Block Congurable conguration.
Tool Versions: MCC-Integrated and Stand-Alone-Online
The available tool has two versions: One integrated into MCC Melody and one online, stand-aloneconguration
version.
CLB Synthesizer - MCC Melody: The version of the tool integrated into MPLAB® Code (MCC)Congurator
Melody allows one to create a logic design from scratch or to import a logic design from the online version of
the tool. It enables the user to develop a complete application using the CLB in MCC Melody and a highoers
level of integration with other peripherals also congured using MCC Melody.
CLB Synthesizer - Online: The tool's online version allows one to create a logic design, synthesize it, and
download it as a (bitstream). In addition to the bitstream, a template source code is provided for le conguring
the CLB, but integrating it into the embedded project is left up to the user.
The logic experience is common to both versions of the tool, so the tool's online version can beconguration
used to start a logic design using the CLB before moving to MCC Melody for further development.
Congurable Logic Block Synthesizer User Guide
CLB Synthesizer
