OPERATION

PREPARING THE LAUNDRY/SELECTING A PROGRAM

ADDING LAUNDRY

Damage from incorrect installation

and connection.

Installing and connecting the washing ma-

chine incorrectly will cause serious dam-

age to property.

See “Installation”.

Damage resulting from failure to re-

move the shipping struts.

Failure to remove the shipping struts can

result in damage to the washing machine

and to adjacent cabinetry or appliances.

Remove the shipping struts as described

in “Installation and connection”.

Switching on the washing machine

Turn the program selector to the Normal

program.

The welcome tone will sound and the wel-

come screen will light up.

The display will now guide you through the

initial commissioning process, which is di-

vided into 5steps.

For additional information, please refer to

the separate operating instructions sup-

plied.















   

  

Operating the sensor buttons

The sensor buttons react to fingertip con-

tact. If a sensor button is illuminated, it can

be selected.

If a sensor button is brightly lit, this means:

currently selected

If a sensor button is dimly lit, this means:

selection possible

aControl field

The control field consists of a display

and various sensor buttons.

bDisplay

Various values are displayed and/or se-

lected on the display.

c sensor buttons

The values in the display can be

changed with the sensor buttons.

dOKsensor button

Confirm the selected values with the

OKsensor button.

eTwinDos sensor button with the ad-

ditional Whites and Colors sensor

buttons

Deactivate or activate automatic deter-

gent dispensing via the TwinDos sensor

button.

fOptical interface

This is used by the Service department

as a transmission point.

gSensor buttons for options

You can supplement the wash pro-

grams with options.

h sensor button

You can view information about the en-

ergy and water consumption of your

washing machine with the sensor

button.

i sensor button

The sensor button starts the Delay

Start function.

jsensor button

You can specify the degree of soiling of

the load in 3settings. This sensor but-

ton is only active when the TwinDos op-

tion is activated.

kStart Add laundry/ sensor button

Touching the /Start Add laun-

drysensor button starts the se-

lected program. The sensor but-

ton lights up constantly.

Once the program has been

started, the /Start Add laun-

drysensor button allows you to

add laundry.

lsensor button

Activates CapDosing via the detergent

drawer.

mProgram selector

For selecting programs and for switch-

ing the machine off. The washing ma-

chine is switched on when you select a

program, and switched off by turning

the program selector to the position.

Environmentally friendly washing

- Make use of the maximum load that the

wash program can accommodate. This

will keep energy and water consumption

to a minimum in relation to the size of the

load.

- Use the program for small, lightlyExpress

soiled loads.

- Modern detergents make it possible to

wash at lower temperatures (e.g.,

70°F/20°C). Using the corresponding

temperature settings will save energy.

- Washing at low temperatures and/or us-

ing liquid detergents can cause bacteria

and odors to build up in the washing ma-

chine. Miele therefore recommends

cleaning the washing machine once ev-

ery month.

The washing machine provides you with

a reminder with the message Sanitize

info: Run the “Sanitize” or “Clean Ma-

chine” program in the display.

1. Preparing the laundry

Empty all pockets.

Damage due to foreign ob-

jects.

Nails, coins, paper clips, and so on

can cause damage to garments

and components in the machine.

Check the laundry before wash-

ing and remove any such foreign

objects.

Sort the laundry by color and by care label. Most gar-

ments have a textile care label in the collar or side

seam.

Pre-treat stains and badly soiled areas.

2. Selecting a program

There are three possible ways to select a program.

1. Selecting the standard programs with the program

selector dial

Turn the program selector to the required program. The

selected program will be shown in the display. This will

then be replaced by the standard display.

2. Selecting additional programs by setting the

program selector to “Additional programs/ ” and

using the display.

Turn the program selector to the /Additional programs

position. The following appears in the display:Table

Linens/Drapes

Touch the sensor buttons until the program you

want appears in the display.

Confirm the program with the OK sensor button.

3. Selecting additional programs by setting the

program selector to MobileStart and using the

Miele app

Turn the program selector to the  posi-MobileStart 

tion.

The following appears in the display:

Load laundry, close the door and press “Start”. Appliance

can be remotely controlled

Follow the instructions in the display and start the pro-

gram.

The following appears in the display:

MobileStart 

The washing machine can now be operated with the Miele

app.

3 5

1 2

1Detergent drawer

2Control panel

3Drain filter

4Door

5TwinDos dispensing

3. Loading the washing machine

Opening the door

Take hold of the door and pull it

open.

Unfold the laundry and load

loosely into the drum.

Closing the door

Make sure that no items are

caught between the door and

the seal.

Shut the door gently.

4. Selecting program settings

Selecting a temperature/spin speed

Touch the sensor buttons above or below the tem-

perature or spin speed value in the display until the tem-

perature/spin speed you want appears in the display.

Selecting options

There are 2 ways of selecting options.

1. Directly via the sensor buttons

Touch the sensor button for the required option. It will

then light up brightly.

2. Via the Options sensor button and the display

Touch the Options sensor button. The following ap-

pears in the display: No Options

Touch the sensor buttons until the option you want

appears in the display and confirm this with the OK sen-

sor button.

Degree of soiling

The sensor button is only active when

the TwinDossensor button is activated.

- Light

No visible soiling or stains

- Normal

Visibly soiled and/or just a few slight

stains

- Heavy

Heavily soiled and/or stains clearly visible

 Delay Start/SmartStart

Delay Start

With the Delay Start function, you can delay

the start of the program. The start of the

program can be delayed from 15minutes

up to a maximum of 24hours.

SmartStart

The SmartStart function lets you define a

time period during which your washing ma-

chine will start automatically. The washing

machine is started via a signal, e.g., from

your energy supplier, that indicates that the

electricity rate is particularly economical.

5. Add detergent

There are several options for adding deter-

gent to the washing machine.

TwinDos

TwinDos dispensing is automatically acti-

vated for all programs in which dispensing

is possible.

Changing TwinDos dispensing

You can change the suggested color com-

position of the laundry.

Touch the or sensor but-Whites Colors

ton.

Deactivating TwinDos dispensing

Touch the TwinDossensor button. The

sensor button is only dimly lit and dis-

pensing is deactivated.

Filling with detergent

This washing machine requires particularly

efficient detergent. Add detergent in accor-

dance with the value in the pull-down

dosage display.

Ensure that TwinDos dispensing is deacti-

vated.

Pull out the deter-

gent drawer and

add detergent to

the compart-

ments.





Chlorine bleach for removing

stains or liquid detergent for the

pre-wash

Detergent for the main wash,

including Soak if selected





Fabric softener, liquid starch, or

caps

CapDosing

If you selected CapDosing when setting the

program, detergent will be dispensed via

the capsule for this wash program.

Using powder detergent

The detergent drawer contains an insert for

liquid detergent in the compartment.

This insert must be removed to use powder

detergent. It is not possible to use powder

detergent in the compartment.

Using chlorine bleach

Damage due to chlorine bleach.

Textiles may be discolored or their fibers

damaged.

Only use chlorine bleach on suitable tex-

tiles.

Chlorination must be activated in the set-

tings before chlorine bleach is first used.

The option must not be se-Pre-wash

lected.

Pour of bleachmax. 1/4 cup (60ml)

into the chamber.

The chlorine bleach is added automatically

10minutes before the end of the main

wash.

6. Start the program

Touch the flashing /Start Add laundry

sensor button.

The door will lock and the wash program

will start.

The program status will appear in the dis-

play.

Adding laundry during a program

sequence

Laundry can be added or removed at any

time, provided that the symbol is not illu-

minated in the display.

Touch the / sensor but-Start Add laundry

ton.

The following appears in the display:

Please wait

Wait until the following display lights up:

Door can be opened

Open the door and add or remove laun-

dry.

Close the door.

Touch the / sensor but-Start Add laundry

ton.

The wash program will continue.

7. Program end

The door is locked in the Anti-crease

phase. The display alternates between:

End/Anti-Crease Press Start button and 

Unlock the door either by touching the

Start Add laundry/ sensor button or by

turning the program selector to the

position.

The door will unlock.

Tip: After the Anti-crease phase, the door

will unlock automatically.

Take hold of the

door and pull it

open.

Remove the laun-

dry.

Items left in the drum could discolor other

items in the next wash or become discol-

ored themselves.

Remove all items from the drum.

Check the folds in

the door seal for

any foreign ob-

jects.

Tip: Leave the door slightly open.

If you used a capsule, remove it from the

detergent drawer.

Tip: Leave the detergent drawer slightly

open.

Options

You can supplement the wash programs

with options.

SoftSteam

In order to reduce creasing, the laundry

undergoes a smoothing process at the

end of the program. Reducing the maxi-

mum load by 50% will give a better result.

Please note the load information in the

display. Small loads achieve a better re-

sult.

without

SoftSteam

with

SoftSteam

Full load Half load

Half load Small load

Small load Very small load

The garments must be suitable for drying

in a tumble dryer and suitable for 

ironing . 

Pre-wash

For laundry with large amounts of dirt,

e.g., dust and sand.

Pre-wash and the use of bleach are not

possible.

The chlorine bleach is added too early.

Only liquid detergent may be added to

the chamber of the detergent

drawer.

Powder detergent clogs up the 

chamber and water can escape from the

detergent drawer.

Buzzer

A buzzer sounds at the end of the pro-

gram. The buzzer sounds until the wash-

ing machine is switched off.

Gentle

Drum rotation and wash duration is re-

duced. Lightly soiled items are washed

more gently.

ExtraRinse

An extra rinse can be activated to achieve

a more thorough wash result.

Soak

For heavily soiled and stained items with

protein stains. A duration of between

30minutes and 6hours can be selected

for the soak process. See “Settings” for

more information.

The factory default setting is 30minutes.

AllergyWash

This option should be used where high

standards of hygiene are required. Energy

consumption is increased to lengthen

temperature holding times and water con-

sumption is increased to improve rinsing

efficiency. The items must be suitable for

drying in a tumble dryer and suitable 

for ironing . 

Before the first use Operation Preparing the laundry Selecting a program Starting a program Options

 fold here  fold here  fold here  fold here  fold here  fold here

en-US M.-Nr. 11 622 870WWF 660, WXF 660

Produkt Specifikationer

Mærke:	Miele
Kategori:	Vaskemaskine
Model:	WXF 660 WCS

Har du brug for hjælp?

Hvis du har brug for hjælp til Miele WXF 660 WCS stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

Vaskemaskine Miele Manualer

Miele V 5869 WPS Manual

6 December 2024

Miele W1724 Manual

6 December 2024

Miele WED 325 WCS PWash Manual

19 Oktober 2024

Miele Top Electronic W720 Manual

1 Oktober 2024

Miele WS 5141 Manual

30 September 2024

Miele W 151 F Manual

27 September 2024

Miele W 3825 WPS Manual

12 September 2024

Miele G 7114 SC AutoDos Manual

9 September 2024

Miele WDB030 Eco Manual

9 September 2024

Miele W 852 Manual

7 September 2024

Vaskemaskine Manualer

Nyeste Vaskemaskine Manualer

Bosch WGE0240F Manual

21 December 2024

Bosch WGG244ZECO Manual

21 December 2024

Bosch WNC254A90 Manual

21 December 2024

Electrolux EW6F4943CP Manual

21 December 2024

Bosch WGH244M90 Manual

21 December 2024

Bosch WGA242Z0TR Manual

21 December 2024

Electrolux MEW6F348XP Manual

21 December 2024

Electrolux EW2FN727WP Manual

21 December 2024

Electrolux EW6F384YQ Manual

21 December 2024

Electrolux EW6T634W Manual

21 December 2024
