RouterBOARD hAP ac

Quick Setup Guide and Warranty Information

The hAP is a simple home wireless access point. It is configured out of the box, you can simply plug in your internet

cable and start using wireless internet. We recommend you to set up a password to secure your device, follow

these steps

Connecting

1. Connect your Internet cable to port 1, and local network PCs to ports 2-5

2. Set your computer IP configuration to automatic (DHCP)

3. Wireless “access point” mode is enabled by default, connect to the wireless network “MikroTik”. Log into

your router and configure a the Wireless password and router password to secure your wireless network

and access to the router

4. Default IP address from the local network is 192.168.88.1, open this address in your web browser to start

configuration. The username is and there is admin no password

5. The Ether5 port suports PoE output for powering other RouterBOARD devices. The port has auto detection

feature, so you can connect Laptops and other non-PoE devices without damaging them. The PoE on

Ether5 outputs approximately 2V below input voltage, and supports up to 0.7A (So provided 24V PSU will

provide 22V/0.7A output to the Ether5 PoE port).

Powering

The board accepts powering from the power jack or from the first Ethernet port (Passive PoE):

direct-input power jack (5.5mm outside and 2mm inside, female, pin positive plug)

accepts 11-57V DC

first Ethernet port accepts passive Power over Ethernet accepts 11-57V DC (compensate for loss on cable,

so more than 12V recommended)

The power consumption under maximum load can reach 5W

Booting process

Initial connection has to be done via the Ethernet cable. Open 192.168.88.1 in your web browser. The username is

admin and there is no password. In case IP connection is not available, Winbox can be used to connect to the

MAC address of the device. More information here: http://wiki.mikrotik.com/wiki/First_time_startup In case you

wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of the device

when starting it until the LED light turns off, and unit will start to look for Netinstall servers.

Extension Slots and Ports

Five individual 10/100/1000 Gigabit Ethernet ports, supporting automatic cross/straight cable correction

(Auto MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.

Integrated Wireless 2.4GHz and 5GHz 802.11a/b/g/n/ac, simultaneous triple band radio with onboard

antennas, max gain 2dBi

Third chain of each band can have the antenna changed to a different one, there are two uFL connectors

inside the case, each has a small antenna connected. You can unplug these antennas, and change the

third chain to your own antenna. In most situations this is not required, so the connector is not easily

accessible or marked.

See www.routerboard.com for more information. Contact 9-Dec-15support@mikrotik.com

Buttons and Jumpers

RouterBOOT reset button (RESET, front panel) has three functions:

oHold this button during boot time until LED light starts flashing, release the button to reset

RouterOS configuration (total 5 seconds)

oKeep holding for 5 more seconds, LED turns solid, release now to turn on CAPs mode (total 10

seconds)

oOr Keep holding the button for 5 more seconds until until LED turns off, then release it to make the

RouterBOARD look for Netinstall servers (total 15 seconds)

Operating System Support

Currently tested operating system is MikroTik RouterOS starting from version v6.28

reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD,

RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks

appearing in this document are the property of their respective holders.

Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the

shipping date to be free of defects in materials and workmanship under normal use and service, except in case of

damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due

to wind, rain, fire or other acts of nature.

To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization)

procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA

process.

1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company

regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your

equipment directly from MikroTik in Latvia.

2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for:

CCR1016-12G, CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200,

RB600, RB600A and RB800 as a paid service (fees apply).

3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender

at sender's cost. If the customer has not organized return of such rejected devices within 12 months from

the day of arrival, MikroTik has the right to discard them.

RMA Instructions are located on our webpage here: http://rma.mikrotik.com

This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to,

the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every

effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical

inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor

for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including,

but not limited to, loss of data or profits. Please report any inaccuracies found to support@mikrotik.com

See www.routerboard.com for more information. Contact 9-Dec-15support@mikrotik.com
