NAC3MPX & NAC3MPX-WOT
powerCON TRUE1 - APPLIANCE INLET
R
OPERATING INSTRUCTION
ASSEMBLY INSTRUCTION
≥ Ø 23.8 [.937]
±0.1 ±0.003
19.0 [.748 ]
≥ Ø 3.2 [.126]
±0.1 ±0.003
24.0 [.945 ]
®
Flat tabs for FASTON
6.35 mm x 0.8 mm
(1/4” x 0.03”)
Panel Cutout (Rear Side)
OPERAT ING & ASS EMBLY INSTRU CTION
Application:
The power TRUE1 system is certified as connector with breaking capacity according IEC 60320, CON
VDE 0625. It is intended for use as appliance couplers and interconnection couplers. It serves to
supply power to an appliance and from an appliance to another equipment. To be installed by qualified
person only.
Connector Assignment: APPLIANCE
APPLIANCE INLET APPLIANCE OUTLET INLET OUTLET
COMBINATION
NAC3PXNAC3MPX
NAC3MPX-WOT
NAC3FPX
NAC3FPX-ST
20
250
P S
EJET
20
250 P S
EJET
16
250
20
250
NAC 3MX-W
20
250
P S
EJET
16
250
20
250
NAC 3
MX-W
20
250 P S
EJET
Power IN
Power OUT
Power IN
Power OUT
NAC3MX-W
(Plug connector)
NAC3FX-W
(Connector)
NAC3FX-W
(Connector)
NAC3MX-W
(Plug connector)
Find more details of power TRUE1 on www.neutrik.com.CON
Draft. Nr.: BDA 330 Update: 08.07.2015 Data subject to change without prior notice. 2015 NEUTRIK . ALL RIGHTS RESERVE D. NEUTRIK are regi stered trademark.
I I ® ®
©
www.neutrik.com
NEUTRIK AG LI T: F: +423 / 237 24 24 +423 /232 53 93
NEUTRIK USA Inc. USA T: F: +1 704 / 972 3050 +1 704/438 9202
( )
NEUTRIK UK Ltd. UK T: +44 1983 / 811 441 +44 1983 /811 439 F:
NEUTRIK Vertriebs GmbH T: F: DE / NL / AT/DK +49 8131 / 280 890 +49 8131 /280 830
NEUTRIK France FR T: F: +33 1/4131 6750 +33 1 /4131 0511
NEUTRIK Tokyo Ltd. JP T: F: +81 3 /3663 4733 +81 3/3663 4796
NEUTRIK Hong Kong Ltd. HK T: F: +852/2687 6055 +852/2687 6052
NEUTRIK India Pvt. Ltd. IND T: F: +91/982 05 43 424 +91 /22 26163 540
R
L N
Attention:
Maximum allowable
torque 0.4 Nm.
