1. Slide the boot onto the cable.
2. Put chuck onto the cable.
Insert wires into the terminals and solder them.
Position the ground-shells over the conductors as
shown.
Pay attention to inserting coding-rib of ground shell
, into dedicated recess of pcb.
Lay cable-shield over ground shell. Distribute wires
circumferentially.
Slide chuck over cable-shield and ground shells
towards end-position aligning the slots of the
chuck to the ribs of the ground shells.
Slide insert into the housing.
Finish the installation by turning the bushing onto
the connector.
In Case of cable with foil shield only:
Solder drain wire to the ground shell (E1).
Keep drain wire as short as practical, proceed with step
(G).
(E2)
Prepare cable as shown.
Fold back the cable-shield as shown.
A
B
C
E
F
D
A
BC
D
F
G H
E
15
15
15
1515
3
3
3
33
5
5
5
55
G
H
End-
position
Soldering
2
1
Groundshell
E2
Shield contact area
Max. Shield length PCB
E1
NEUTRIK AG
NEUTRIK Zürich AG
NEUTRIK USA Inc.
NEUTRIK UK Ltd.
( )
LI
CH
USA
UK
T: F:
T: F:
T: F:
T: F:
+423 / 237 24 24 +423 / 232 53 93
+41 44 / 736 5010 +41 44 / 736 5011
+1 732 / 901 9488 +1 732 / 901 9608
+44 1983 / 811441 +44 1983 / 811 439
Draft. Nr.: BDA 136 Update: 28.09.2009/ 3102M1411 I I Data subject to change without prior notice. 2009 NEUTRIK . ALL RIGHTS RESERVED.© ®
NEUTRIK
NEUTRIK France
NEUTRIK Tokyo Ltd.
NEUTRIK
Vertriebs GmbH
Ltd.Hong Kong
DE / NL / AT
FR
JP
HK
T: F:
T: F:
T: F:
T: F:
+49 8131 / 280 890 +49 8131 / 280 830
+33 1 / 4131 6750 +33 1 / 4131 0511
+81 3 / 3663 4733 +81 3 / 3663 4796
+852 / 2687 6055 +852 / 2687 6052
ASSEMB LY INSTRUCTION
www.neutrik.com
NC3FXX-EMC & NC3MXX-EMC XLR Cable Connector
|
