Nexa MYCR-3500 Manual


Læs nedenfor 📖 manual på dansk for Nexa MYCR-3500 (2 sider) i kategorien Ikke kategoriseret. Denne guide var nyttig for 8 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Side 1/2
Plug-in receiver with on/off button on the receiver. Works with
System Nexa remote controls, transmitters and the Nexa Bridge.
This is a self-training system, so installation is very easy and flexible.
INSTALLATION
Connect the load to the receiver. Ensure that the load does not
exceed 3500 W.
PROGRAMMING
1. Connect the receiver (plug-in) to a power socket. The receiver
goes into setup mode as soon as it is powered up.
2. Press the “ON” button for the selected channel on any System
Nexa remote control within 6 seconds.
PROGRAMMING CONFIRMATION
The LED indicator on the receiver flashes rapidly. If a light is
connected to the receiver, this flashes twice.
DELETING MEMORY
1. To delete a memory slot, remove the receiver (plug-in) from the
wall socket
2. Wait at least 6 seconds
3. Reconnect the receiver to a wall socket
4. Press the “OFF” button for the selected channel on the System
Nexa remote control within 6 seconds.
To delete all storage locations, repeat steps 1-3 above, then press
the “ALL OFF” button on the System Nexa control within 6 seconds.
CONFIRMATION OF DELETION
The LED indicator on the receiver flashes rapidly. If a light is
connected to the receiver, this flashes twice.
MEMORY SLOTS
Every MYCR-3500 plug-in receiver has 32 memory slots. When
memory slot 32 is occupied, slot 1 is overwritten during setup.
CONTROL
The plug-in receiver can be controlled in a number of ways.
1. With a System Nexa remote control
2. With other programmed System Nexa transmitters
3. With the On/Off button on the plug-in receiver
4. With a Nexa Bridge
ENGLISH Safety and information
Indoor range: up to 30 m (optimal conditions). The range is
strongly dependent on local conditions, such as the presence
of metals. For example, the thin metal coating in Low-emissivity
(Low-E) glass has a negative impact on the range of radio signals.
There may be restrictions on the use of this device outside the
EU. If applicable, check whether this device complies with local
directives.
Maximum load: Never connect lights or equipment that exceed
the maximum load of the receiver, as it can result in defects, a
short circuit or fire.
Life-support: Never use Nexa products for life-support systems
or other applications in which equipment malfunctions can have
life-threatening consequences.
Interference: All wireless devices may be subject to interference,
which could affect performance. The minimum distance between 2
receivers should be at least 50 cm.
Repairing: Do not attempt to repair this product. There are no
user-serviceable parts inside.
Water-resistance: This product is not water-resistant. Keep it dry.
Moisture will corrode the inner electronics and can result in a short
circuit, defects and shock hazard.
Cleaning: Use a dry cloth to clean this product. Do not use harsh
chemicals, cleaning solvents, or strong detergents.
Environment: Do not expose the product to excessive heat or
cold, as it can damage or shorten the life of electronic circuit
boards.
THIS PRODUCT SUPPORTS SMART MODE.
Devices that support Smart Mode can save up to 3 different
favourite scenarios, and these can be activated easily using a
Nexa Smart Mode transmitter.
PÅ/AV-knapp
och LED
ON/OFF button
and LED
NEXA AB, DATAVÄGEN 37B, 436 32 ASKIM, SWEDEN
info@nexa.se | www.nexa.se
MYCR-3500
PLUG-IN ON/OFF
MYCR-3500 – PLUG-IN ON/OFF
Switch type Relay
Power supply 220-240 V~50 Hz
Max. load 3500 W RL
Frequency System Nexa (433,92 MHz)
Range up to 30 m
Memory slots 32
Power consumption < 1 W (standby)
Pollution Degree 2
Built in protective device Temperature fuse
IP rating Inomhusbruk / Indoor use
Size (L X H X W) 53 x 53 x 58 mm
TECHNICAL DATA
Declaration of conformity finns tillgänglig på / is available at www.nexa.se


Produkt Specifikationer

Mærke: Nexa
Kategori: Ikke kategoriseret
Model: MYCR-3500
