BATTERY SAFETY WARNINGS
SPECIFICATIONS
Input: 18V
Battery Power: 1.5Ah Li-ion
Charge Times: 30min (Multi Battery Charger)
30min (Fast Charger)
60min (Standard Charger)
2Hr (Eco Charger)
Weight: 0.35kg
1. Battery
2. Battery Release Button
3. Charge Indicator Button
ozito-diy.co.uk
ORIGINAL INSTRUCTIONS
PXBP-150U
Art.-No.: 30.003.97
I.-No.: 11018
Information about the battery
1. The battery pack supplied with your cordless tool is not charged. The battery pack has to be charged before you use
the tool for the rst time.
2. For optimum battery performance avoid low discharge cycles. Charge the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 15°C and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural ageing process. The battery pack must be replaced at the latest when its
capacity falls to just 80% of its capacity when new. Weakened cells in an aged battery pack are no longer capable of
meeting the high power requirements and therefore pose a safety risk.
5. Do not throw battery packs into an open re. There is a risk of explosion!
6. Do not ignite the battery pack or expose it to re.
7. Do not exhaustively discharge batteries. Exhaustive discharge will damage the battery cells. The most
common cause of exhaustive discharge is lengthy storage or non-use of partly discharged batteries. Stop working as
soon as the performance of the battery falls noticeably or the electronic protection system triggers. Place the battery
pack in storage only after it has been fully charged.
8. Protect batteries and the tool from overloads. Overloads will quickly result in overheating and cell
damage inside the battery housing without this overheating actually being apparent externally.
9. Avoid damage and shocks. Replace batteries which have been dropped from a height of more than one
meter or which have been exposed to violent shocks without delay, even if the housing of the battery pack appears
to be undamaged. The battery cells inside the battery may have suffered serious damage. In this respect, please also
read the waste disposal information.
10. If the battery pack suffers overloading and overheating, the integrated protective cut-off will switch off the equipment
for safety reasons.
Important. Do not press the ON/OFF switch any more if the protective cut-off has actuated. This may damage the
battery pack.
11. Use only original battery packs. The use of other batteries may result in injuries, explosion and a re risk.
Information on chargers and the charging process
1. Please check the data marked on the rating plate of the battery charger. Be sure to connect the battery charger to a
power supply with the voltage marked on the rating plate. Never connect it to a different mains voltage.
2. Protect the battery charger and its cable from damage and sharp edges. Have damaged cables repaired without delay
by a qualied electrician.
3. Keep the battery charger, batteries and the cordless tool out of children’s reach.
4. Do not use damaged battery chargers.
5. Do not use the supplied battery charger to charge other cordless tools.
6. In heavy use the battery pack will become warm. Allow the battery pack to cool to room temperature before
commencing with the charging.
7. Do not exceed the maximum charging times. These charging times only apply Do not over-charge batteries.
to discharged batteries. Frequent insertion of a charged or partly charged battery pack will result in over-charging and cell
damage. Do not leave batteries in the charger for days on end.
8. Never use or charge batteries if you suspect that the last time they were charged
was more than 12 months previously. There is a high probability that the battery pack has already suffered
dangerous damage (exhaustive discharge).
9. Charging batteries at a temperature below 10°C will cause chemical damage to the cell and may cause a re.
10. Do not use batteries which have heated during the charging process, as the battery cells may have suffered dangerous
damage.
11. Do not use batteries which have suffered curvature or deformation during the charging process or which show other
non-typical symptoms (gassing, hissing, cracking,…)
12. Never fully discharge the battery pack (recommended depth of discharge max. 80%) A complete discharge of the
battery pack will lead to premature ageing of the battery cells.
13. Never charge the batteries unsupervised.
Protection from environmental influences
1. Wear suitable work clothes. Wear safety goggles.
2. Moisture and Protect your cordless tool and the battery charger from moisture and rain.
rain can cause dangerous cell damage.
3. Do not use the cordless tool or the battery charger near vapors and inammable liquids.
4. Use the battery charger and cordless tools only in dry conditions and an ambient temperature of 10-40°C.
5. Do not keep the battery charger in places where the temperature is liable to reach over 40°C. In particular, do not leave
the battery charger in a car that is parked in the sunshine.
6. Overloads, over-charging and exposure to direct sunlight will result Protect batteries from overheating.
in overheating and cell damage. Never charge or work with batteries which have been overheated – replace them
immediately if possible.
7. Store the charger and your cordless Storage of batteries, battery chargers and cordless tools.
tool only in dry places with an ambient temperature of 10-40°C. Store your lithium-ion battery pack in a cool, dry place at
a temperature of 10-20°C. Protect them from humidity and direct sunlight. Only place fully charged batteries in storage
(charged at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery packs which were stored below 0°C for more than 60
minutes must be disposed of.
9. When handling batteries beware of electrostatic charge: Electrostatic discharges cause damage of the electronic
protection system and the battery cells. Avoid electrostatic charging and never touch the battery poles.
Rechargeable batteries and cordless electric machines and tools contain materials that are potentially harmful to the
environment. Never place any cordless electric machines or tools in your household refuse. When cordless electric
machines or tools become defective or worn, remove the rechargeable batteries and return them to iSC GmbH (address:
Eschenstrasse 6, D-94405, Germany). If the rechargeable batteries cannot be removed, return the complete cordless
machine or tool.
You can then be sure that the equipment will be correctly disposed of by the manufacturer.
When shipping or disposing of batteries and cordless tools, always ensure that they are
packed individually in plastic bags to prevent short circuits and fires.
Do not lose these safety instructions
ELECTRICAL SAFETY
DESCRIPTION OF SYMBOLS
Danger! Read the operating instructions to reduce the risk of inquiry.
Store the battery only in dry rooms with an am bient temperature of +10°C to +40°C.
Place only charged batteries in storage (charged at least 40%).
This consignment contains lithium-ion batteries.
In accordance with special provision 188 this consignment is not subject to the ADR regula tions. Handle with care.
Danger of ignition in case of damage to the consignment package. If the consignment package is damaged: Check and if
necessary repackage. For further information contact: 0049 1807 10 20 20 66 (xed network 14 ct/min, mobile phone max.
42 ct/min) Outside Germany charges will apply instead for a regular call to a landline number in Germany.
The reprinting or reproduction by any other means, in whole or in part, of documentation and papers accompanying
products is permitted only with the express consent of the iSC GmbH.
Subject to technical changes
Danger!
The equipment and packaging material are not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of swallowing or suffocating!
WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of fire, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an emergency, before operating the tool.
Before you connect the charger to the mains supply make sure that the data on the rating plate are identical to the mains data.
This tools chargers are double insulated; therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this tool. The insulation system is for
added protection against injury resulting from a possible electrical insulation failure within the tool.
The power supply for this products charger should be protected by a residual current device (rated at 30mA or less). A residual current
device reduces the risk of electric shock.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Double insulated
2 31
1.5Ah BATTERY
