Side 1/2
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the
equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make
certain that wall mounts are properly installed and secured. Make certain that the equipment is
installed securely and cannot fall down.
7. During installation, observe the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources
of heat. Make certain that the equipment is always installed so that is cooled sufficiently and
cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor
equipment - in this case, observe the special instructions noted below. Do not expose this
equipment to flammable materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place contain-
ers filled with liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Do not open or modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g.,
due to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property
damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the
equipment or if it has been damaged in another way, switch it off immediately and unplug it from
the mains outlet (if it is a powered device). This equipment may only be repaired by authorized,
qualified personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please
separate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
FOR EquIpMENT ThAT cONNEcTS TO ThE pOwER MAINS:
22. CAUTION: If the power cord of the device is equipped with an earthing contact, then it must be
connected to an outlet with a protective ground. Never deactivate the protective ground of a
power cord.
23. If the equipment has been exposed to strong fluctuations in temperature (for example, after
transport), do not switch it on immediately. Moisture and condensation could damage the equip-
ment. Do not switch on the equipment until it has reached room temperature.
24. Before connecting the equipment to the power outlet, first verify that the mains voltage and
frequency match the values specified on the equipment. If the equipment has a voltage selection
switch, connect the equipment to the power outlet only if the equipment values and the mains
power values match. If the included power cord or power adapter does not fit in your wall outlet,
contact your electrician.
25. Do not step on the power cord. Make certain that the power cable does not become kinked,
especially at the mains outlet and/or power adapter and the equipment connector.
26. When connecting the equipment, make certain that the power cord or power adapter is always
freely accessible. Always disconnect the equipment from the power supply if the equipment
is not in use or if you want to clean the equipment. Always unplug the power cord and power
adapter from the power outlet at the plug or adapter and not by pulling on the cord. Never touch
the power cord and power adapter with wet hands.
27. Whenever possible, avoid switching the equipment on and off in quick succession because
otherwise this can shorten the useful life of the equipment.
28. IMPORTANT INFORMATION: Replace fuses only with fuses of the same type and rating. If a fuse
blows repeatedly, please contact an authorised service centre.
29. To disconnect the equipment from the power mains completely, unplug the power cord or power
adapter from the power outlet.
30. If your device is equipped with a Volex power connector, the mating Volex equipment connector
must be unlocked before it can be removed. However, this also means that the equipment can
slide and fall down if the power cable is pulled, which can lead to personal injuries and/or other
damage. For this reason, always be careful when laying cables.
31. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning
strike or before extended periods of disuse.
cAuTION:
CAUT ION
RI SK OF SEL EC T RI C HO C K
DO N O NO T PE
Never remove the cover, because otherwise there may be a risk of electric shock. There are no user
serviceable parts inside. Have repairs carried out only by qualified service personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electrical shock.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance instructions.
cAuTION – hIGh VOLuME LEVELS wITh AuDIO pRODucTS!
This equipment is intended for professional use. Therefore, commercial use of this equipment is subject
to the respectively applicable national accident prevention rules and regulations. As a manufacturer,
Adam Hall is obligated to notify you formally about the existence of potential health risks. Hearing
damage due to high volume and prolonged exposure: When in use, this product is capable of producing
high sound-pressure levels (SPL) that can lead to irreversible hearing damage in performers, employees,
and audience members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.
cAuTION! IMpORTANT INFORMATION ABOuT LIGhTING pRODucTS
Do not look into the beam from a distance of less than 40 cm.
Do not stare into the beam for extended periods at short-to-medium distances.
Do not view the beam directly with optical instruments such as magnifiers.
Under some circumstances, stroboscopic effects may trigger epileptic seizures in sensitive individuals!
For this reason, persons who suffer from epilepsy should always avoid places where strobe lights are
used.
MANuFAcTuRER’S wARRANTY
This warranty extends to the Palmer branded product you purchased from Adam Hall. The statutory warranty
rights against the vendor shall not be affected by this warranty. Rather, this warranty gives you addition-
al independent claims against Adam Hall. With this warranty, Adam Hall ensures that products you have
purchased from Adam Hall or Adam Hall partners, under normal use, are free of defects in material or
workmanship for a period of 5 years from the date of purchase, or 2 years from the date of purchase for tube
amplifiers and guitar cabinets. The warranty period begins on the date of purchase. In order to assert a claim
for warranty service, the proof of date of purchase is provided by the receipt bearing the date of purchase
or the date of purchase on the delivery note. You are entitled to warranty service under the conditions and
provisions set out in this document, if a repair within the warranty period is required. This warranty applies
only to the original purchaser of the products supplied by Adam Hall and is not transferable to any person to
whom the property is transferred by the original purchaser. Within the warranty period, the defective parts or
the product from Adam Hall will be repaired or replaced. Under the terms of this warranty, all the replaced or
removed components become the property of Adam Hall. In the unlikely event that a product acquired from
Adam Hall, repeatedly exhibits a defect, Adam Hall may decide, at its discretion, to replace this product with
a comparable product of at least the same performance. Adam Hall does not guarantee that the operation of
this product will be uninterrupted or error-free. Adam Hall accepts no responsibility for any damage due to
incorrect compliance with the instructions received in the delivery.
This warranty does not extend to:
• wearing parts (eg battery, tubes).
• devices that have had their serial number removed or damaged, or failed as a result of an accident
• inapropriate or abusive use or other external causes
• devices that were not used in accordance with the operating parameters defined in the user docu-
menta
tion shipped with the product
• devices that have been repaired using parts not made or distributed by Adam Hall
• devices that have been serviced, modified or repaired by someone other than Adam Hall or an autho-
rised service partner.
These terms and conditions constitute the complete and exclusive warranty agreement between you and
Adam Hall regarding the Adam Hall branded product you have purchased. This warranty is valid only within
Europe. Outside of Europe please contact our official distributors.
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive
remedy shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly
limited to the lesser of the price you have paid for the product or the cost of repair or replacement of any com-
ponents that malfunction under conditions of normal use. Adam Hall is not liable for any damages caused by
the product or the failure of the product, including any lost profits or savings or special, incidental, or conse-
quential damages. Adam Hall is not liable for any claim made by a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited War-
ranty or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim,
and cannot be rescinded or changed by anyone. This limitation of liability will be effective even if you have
advised Adam Hall or an authorized representative of Adam Hall of the possibility of any such damages, but
not, however, in the event of claims for damages in connection with personal injuries. This manufacturer’s
warranty grants you specific rights; depending on jurisdiction (nation or state), you may be be entitled to
additional claims. You are advised to consult applicable state or national laws for a full determination of
your rights.
REquESTING wARRANTY SERVIcE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from
which you purchased the product.
Ec DEcLARATION OF cONFORMITY
The equipment marketed by Adam Hall complies (where applicable) with the essential requirements and
other relevant specifications of Directives 1999/5/EC (R&TTE), 2004/108/EC (EMC) und 2006/95/EC (LVD).
Additional information can be found at www.adamhall.com.
pROpER DISpOSAL OF ThIS pRODucT (wASTE ELEcTRIcAL AND ELEcTRONIc EquIpMENT)
(Valid in the European Union and other European countries with waste separation) This symbol on the
product, or the documents accompanying the product, indicates that this appliance may not be treated as
household waste. This is to avoid environmental damage or personal injury due to uncontrolled waste dispos-
al. Please dispose of this product separately from other waste and have it recycled to promote sustainable
economic activity. Household users should contact either the retailer where they purchased this product, or
their local government office, for details on where and how they can recycle this item in an environmentally
friendly manner. Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product should not be mixed with other commercial wastes for disposal.
ENVIRONMENTAL pROTEcTION AND ENERGY cONSERVATION
Energy conservation is an active contribution to environmental protection. Please turn off all unneeded elec-
trical devices. To prevent unneeded devices from consuming power in standby mode, disconnect the mains
plug.
ScOpE OF AppLIcATION
A DI box (DI stands for direct injection) is used to feed the electronic signal of a musical instrument
directly into the microphone input of a mixing console or into a stagebox, thus avoiding any detours
due to acoustic conversion (speaker/microphone). In addition to adjusting the volume level, the DI
box ensures that the input signal is converted and balanced at low impedance. Thus, the signal is
less susceptible to noise interference and cable losses. All Palmer DI boxes also allow for galvanic
isolation between input and output, since they use an audio transmitter. However, you should not use
a passive DI box to electrically isolated line signals, because considerable losses in signal level will
occur for technical reasons. For this application, it is better to use a line isolation box (e.g., Palmer
PLI01, PLI 02, PLI03, PLI05, PLI06 etc.).
uSER INTERFAcE
cONNEcTORS
Using shielded mono jack cables, connect the unbalanced output of the musical instrument to the input
of the PAN01. The second jack socket, labelled Thru, permits looping of the original signal, e.g.in order
to connect to an amplifier on stage. Using a shielded microphone cable, connect the stagebox/micro-
phone input of the mixer to the XLR/m socket, labelled Balanced Out.
ATTENuATOR
This switch permits attenuation of high input signals by 30 dB. For all signals up to +6 dBu (line level),
use the 0 db position of the attenuator. If you want to send a speaker signal, i.e. position the DI box
between the amplifier and the speaker box, use the -30 db switch position. Generally speaking, you
should set the attenuator so that a reasonable level results at the microphone input.
GROuND LIFT SwITch
As mentioned above, the design of the PAN01 effects a galvanic isolation between input and output.
(Galvanic separation means that there is no electrically conductive connection. The coupling of the
signals in the transmitter is based on magnetic induction). The galvanic isolation suppresses ground
loop hum that results due to double grounding (e.g., instrument grounded via the power plug and mixer
grounded). In the simplest case, the ground lift switch should be operated by ear. As a rule of thumb, for
devices that are grounded via their power supply, the switch should be placed in the LIFT position and
for battery powered instruments, the GND position should be used.
© Palmer Musical Instruments, Adam Hall GmbH, D-61267 Neu-Anspach, Daimlerstr. 9, Germany TEL: ++49 (0)6081 94190
FAX: ++49 (0)6081 43280 WEB: www.adamhall.com, www.palmer-germany.com EMAIL: info@palmer-germany.com
PAN PASSIVE DI BOX01 –

Produkt Specifikationer

Mærke: Palmer
Kategori: Ikke kategoriseret
Model: PAN 01

Har du brug for hjælp?

Hvis du har brug for hjælp til Palmer PAN 01 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Palmer Manualer

Palmer

Palmer PAN 02 Manual

16 December 2024
Palmer

Palmer PLI-03 Manual

16 December 2024
Palmer

Palmer PLI04USB Manual

16 December 2024
Palmer

Palmer PLI-01 Manual

6 September 2024
Palmer

Palmer PLI-05 Manual

5 September 2024
Palmer

Palmer AoC Box XLRf Manual

5 September 2024
Palmer

Palmer RIVER ilm Manual

5 September 2024
Palmer

Palmer RIVER naab Manual

5 September 2024
Palmer

Palmer PAN 48 Manual

5 September 2024
Palmer

Palmer PAN 01 Manual

5 September 2024

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Zipper

Zipper ED500FW Manual

22 December 2024
Roland

Roland PDQ-8 Manual

22 December 2024
Panasonic

Panasonic DMW-LMCH62E Manual

21 December 2024
Philips

Philips VisaPure SC6026 Manual

21 December 2024
Philips

Philips DLP2015 Manual

21 December 2024
Philips

Philips SWV3034S Manual

21 December 2024
Philips

Philips CDR24D24H Manual

21 December 2024
Philips

Philips DVDRW1S04 Manual

21 December 2024
Philips

Philips CD74R Manual

21 December 2024
Philips

Philips EasyShine BHN368 Manual

21 December 2024
