Side 1/2
SAFETY INFORMATION
1. Please read these instructions carefully.
2. Keep all information and instructions in a safe place.
3. Follow the instructions.
4. Observe all safety warnings. Never remove safety warnings or other information from the equipment.
5. Use the equipment only in the intended manner and for the intended purpose.
6. Use only sufficiently stable and compatible stands and/or mounts (for fixed installations). Make cer-
tain that wall mounts are properly installed and secured. Make certain that the equipment is installed
securely and cannot fall down.
7. During installation, observe the applicable safety regulations for your country.
8. Never install and operate the equipment near radiators, heat registers, ovens or other sources of heat.
Make certain that the equipment is always installed so that is cooled sufficiently and cannot overheat.
9. Never place sources of ignition, e.g., burning candles, on the equipment.
10. Ventilation slits must not be blocked.
11. Do not use this equipment in the immediate vicinity of water (does not apply to special outdoor
equipment - in this case, observe the special instructions noted below. Do not expose this equipment
to flammable materials, fluids or gases.
12. Make certain that dripping or splashed water cannot enter the equipment. Do not place containers
filled with liquids, such as vases or drinking vessels, on the equipment.
13. Make certain that objects cannot fall into the device.
14. Use this equipment only with the accessories recommended and intended by the manufacturer.
15. Open the device for changing the battery, do not modify this equipment.
16. After connecting the equipment, check all cables in order to prevent damage or accidents, e.g., due
to tripping hazards.
17. During transport, make certain that the equipment cannot fall down and possibly cause property
damage and personal injuries.
18. If your equipment is no longer functioning properly, if fluids or objects have gotten inside the equip-
ment or if it has been damaged in another way, switch it off immediately and unplug it from the
mains outlet (if it is a powered device). This equipment may only be repaired by authorized, qualified
personnel.
19. Clean the equipment using a dry cloth.
20. Comply with all applicable disposal laws in your country. During disposal of packaging, please sep-
arate plastic and paper/cardboard.
21. Plastic bags must be kept out of reach of children.
22. If the equipment has been exposed to strong fluctuations in temperature (for example, after trans-
port), do not switch it on immediately. Moisture and condensation could damage the equipment. Do
not switch on the equipment until it has reached room temperature.
23. Do not step on the power cord. Make certain that the power cable does not become kinked, especially
at the mains outlet and/or power adapter and the equipment connector.
24. When connecting the equipment, make certain that the power cord or power adapter is always freely
accessible. Always disconnect the equipment from the power supply if the equipment is not in use
or if you want to clean the equipment. Always unplug the power cord and power adapter from the
power outlet at the plug or adapter and not by pulling on the cord. Never touch the power cord and
power adapter with wet hands.
25. To disconnect the equipment from the power mains completely, unplug the power cord or power
adapter from the power outlet.
26. Unplug the power cord and power adapter from the power outlet if there is a risk of a lightning strike
or before extended periods of disuse.
CAUT ION:
CAU TIO N
RIS K OF SELE CTRIC HOCK
DO N O NOT PE
There are no user serviceable parts inside. Have repairs carried out only by qualified service personnel.
CAUT ION – HIGH VOLUME LEVELS WITH AUDIO PRODUCTS!
This equipment is intended for professional use. Therefore, commercial use of this equipment is subject
to the respectively applicable national accident prevention rules and regulations. As a manufacturer, Adam
Hall is obligated to notify you formally about the existence of potential health risks. Hearing damage due to
high volume and prolonged exposure: When in use, this product is capable of producing high sound-pres-
sure levels (SPL) that can lead to irreversible hearing damage in performers, employees, and audience
members. For this reason, avoid prolonged exposure to volumes in excess of 90 dB.
MANUFACTURER’S WARRANTY & LIMITATION OF LIABILITY
You can find our current warranty conditions and limitation of liability at: http://www.adamhall.com/media/
shop/downloads/documents/manufacturersdeclarations.pdf
To request warranty service for a product, please contact Adam Hall GmbH, Daimler Straße 9, 61267 Neu
Anspach / Email Info@adamhall.com / 49 (0) 6081 / 9419-0
PROPER DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT)
(Valid in the European Union and other European countries with waste separation)
This symbol on the product, or the documents accompanying the product, indicates that this appliance
may not be treated as household waste. This is to avoid environmental damage or personal injury due
to uncontrolled waste disposal. Please dispose of this product separately from other waste and have it
recycled to promote sustainable economic activity.
SCOPE OF APPLICATION
The PLI-02 is a dual channel line transformer box which can be used to balance mixer outputs, effects
devices or amplifier inputs. Thanks to the utilized Neutrik combo sockets for the inputs you can connect
jacks (unbalanced inputs) or XLR connectors (balanced inputs). Should you want to use the XLR connectors
for unbalanced signals then a bridge must be soldered between the cold pin and pin 1 (pin 2 is generally
hot so pin 1 must be connected to pin 3).
Of course you can also “simply” use the PLI-02 as a line isolator between two mains powered devices to
prevent ground loop hum.
CAUTION:
All Audio transformers are quite sensitive to magnetic fields caused by mains transformers for example.
Before you permanently install the PLI-02 somewhere, make sure the location is suitable by temporarily
installing the device.
GLOSSARY
A galvanic isolation means that there is no electrically conducting connection between the two points. This
is the case with a transformer; the signal is transmitted between input and output by varying magnetic
fields. In digital electronics you can employ optocouplers in which case the signals are transmitted by
light impulses.
You can differentiate Hum caused by ground loops from other low frequency interferences simply by con-
necting the mass of the two devices (e.g. metallic parts of the chassis) to provoke the system to hum. The
reason for ground loops is that ground potentials are not always exactly the same. Due to different cable
lengths and other factors a slight displacement in the ground potential can take place. So if you connect
two devices with different ground potentials to each other, a current will flow between them over the
shielding of the audio cable. As a result a hum at mains frequency (50 or 60 Hz) including its harmonics
will overlay the signal. The more experienced users will be able to determine a ground loop by its sound
alone. Other humming caused by interferences, sounds brighter and has more harmonics compared to
the hum caused by a ground loop, which sounds sonorous and deeper.
TECHNICAL SPECIFICATIONS
Product Type: line isolator
Type: passive
Number of Channels: 2
Number of Inputs: 2
Input Connections: 6.3 mm Jack, XLR
Input Type: balanced / unbalanced (depending on TS / TRS connection)
Input Impedance: 0.6 k Ohm(s)
Max. Input Level: + 20 dBU
Outputs: 2
Output Connections: XLR
Output Type: balanced / unbalanced (depending on TS / TRS connection)
Output Impedance: 600 Ohm(s)
Max. Output Levels: + 20 dB
Transformer balanced: yes
Translation Ratio (Ratio): 1:1
Frequency response: 20 - 20,000 Hz
Controls: ground lift
Housing Material: die-cast aluminium
Housing Surface: powder coated
Width: 135 mm
Depth: 95 mm
Height: 35 mm
Weight: 0.53 kg
© Palmer Musical Instruments, Adam Hall GmbH, D-61267 Neu-Anspach, Daimlerstr. 9, Germany TEL: ++49 (0)6081 94190
FAX: ++49 (0)6081 43280 WEB: www.adamhall.com, www.palmer-germany.com EMAIL: info@palmer-germany.com
PLI- – LINE ISOLATION BOX – 2 CHANNEL 02
