Please read these instructions carefully before using this product, and save this
manual for future use.
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products on the market today.
Used properly, we’re sure it will bring you and your family years of enjoyment. Please take time
to fill in the information below. The serial number is on the tag located on the underside of your
camera. Be sure to as your convenient camera information source.retain this manual
Please note that the actual controls and components, menu items, etc. of your Digital Camera
may look somewhat different from those shown in the illustrations in this Owner’s Manual.
Information for Your Safety
∫Product identification marking
∫THE FOLLOWING APPLIES ONLY IN THE U.S.A.
∫About the battery pack
0Do not heat or expose to flame.
0Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with
doors and windows closed.
0Do not expose to low air pressure at high altitudes.
0Do not expose to extremely low air pressure, as this may result in explosions or leakage of
flammable liquids and gases.
∫About the AC adaptor (supplied)
0Do not use any other USB connection cables except the one supplied with the camera or the
Battery Charger (DMW-BTC15: optional).
0Always use a genuine Panasonic Shutter Remote Control (DMW-RS2: optional).
0Always use a genuine Panasonic Tripod Grip (DMW-SHGR1: optional).
0Use a Premium High Speed HDMI cable (Type A– Type A plug, up to 1.5 m (4.9 feet) long).
0Do not use the headphone cables with the length of 3 m (9.8 feet) or more.
0Do not use the stereo microphone cables with the length of 3 m (9.8 feet) or more.
0Keep the hot shoe cover out of reach of children to prevent swallowing.
0Keep the cover for the battery grip connector out of reach of children to prevent swallowing.
0Keep the memory card out of reach of children to prevent swallowing.
0Excessive sound pressure from earphones and headphones can cause hearing loss.
0When using an AC adaptor, ensure that the Panasonic DC Coupler (DMW-DCC17: optional)
and AC Adaptor (DMW-AC10PP: optional) are used.
0Always use a genuine Panasonic AC Adaptor (DMW-AC10PP: optional).
Standard Accessories
Product numbers correct as of September 2023.
Digital camera body
*1 This is attached to the camera at the time of purchase.
*2 This is supplied with Lens Kit DC-G9M2L.
*3 This is attached to the lens at the time of purchase.
*4 This is supplied with Lens Kit DC-G9M2M.
0If accessories are lost, customers can visit us at http://shop.panasonic.com/support for
further information about obtaining replacement parts.
0To order optional accessories please visit http://shop.panasonic.com or your local Photo
Specialty Dealer.
Names of Important Parts
Attaching a Shoulder Strap
Attach a shoulder strap to the camera with the following procedure to prevent it
from dropping.
Charging the Battery
1Set the camera on/off switch to [OFF].
2Insert the battery into the camera.
3Connect the camera USB port and the AC adaptor using the
USB connection cable.
4Connect the AC adaptor to an electrical outlet.
0The charging light turns red and charging begins.
The charging light turns off when charging is complete.
0Using the camera body and the supplied AC adaptor.
Inserting Cards (Optional)
You can use SD memory cards with this camera.
0Match the orientation of the cards as shown in the figure and then insert them firmly until
they click.
0To remove a card, confirm that the corresponding card access light has turned off, push the
card until it clicks, then pull the card out straight.
0Format the cards with the camera before use.
[ ] [ ] Select [Card Format]
Owner’s Manual <Complete Guide>
Refer to “Owner’s Manual <Complete Guide>” (HTML format/
PDF format) for details about how to use the camera and
notes on use.
https://panasonic.jp/support/dsc/oi/G9M2/index.html
U.S. customers only
Register online at http://shop.panasonic.com/support/register
to receive these benefits:
Safety Notification
Owner Verification
Efficient Warranty Service
Special Offers and Promotions from Panasonic
WARNING:
To reduce the risk of fire, electric shock or product damage,
0
0
0
00 Do not expose this unit to rain, moisture, dripping or splashing.
0
0
0
00 Use the recommended accessories.
0
0
0
00 Do not remove covers.
0
0
0
00 Do not repair this unit by yourself. Refer servicing to qualified service personnel.
The socket outlet shall be installed near the equipment and shall be easily
accessible.
Product Location
Digital camera Bottom
If you have any questions, visit:
USA : http://shop.panasonic.com/support
© Panasonic Entertainment & Communication Co., Ltd. 2023
Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
http://shop.panasonic.com
Printed in China
P
Date of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
0Reorient or relocate the receiving antenna.
0Increase the separation between the equipment and receiver.
0Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
0Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
0Any unauthorized changes or modifications to this equipment would void the user’s
authority to operate this device.
0To assure continued compliance, follow the attached installation instructions and use
only shielded interface cables with ferrite core when connecting to computer or
peripheral devices.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Supplier’s Declaration of Conformity
Trade Name: Panasonic
Model No.: DC-G9M2
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://shop.panasonic.com/support
How to Display Certification and Compliance Information
Certification and compliance information for this camera can be viewed on the menu
screen.
1Select the [Others] tab of the [Setup] menu.
2Select [Approved Regulations] and confirm your selection.
Contains FCC ID: VPYLBEE5ZZ1PJ
This transmitter must not be co-located or operated in conjunction with any other antenna
or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines as this
equipment has very low levels of RF energy.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the
MAC, through the digital and analog baseband, and finally to the RF chip. Several special
packets are initiated by the MAC. These are the only ways the digital baseband portion will
turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the
transmitter will be on only while one of the aforementioned packets is being transmitted. In
other words, this device automatically discontinue transmission in case of either absence
of information to transmit or operational failure.
Frequency Tolerance: n 20ppm
CAUTION
Battery pack (Lithium ion battery pack)
0Use the specified unit to recharge the battery pack.
0Do not use the battery pack with equipment other than the specified unit.
0Do not get dirt, sand, liquids, or other foreign matter on the terminals.
0Do not touch the plug terminals (i j and ) with metal objects.
0Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes, wash it off
thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the eyes. Rinse eyes
thoroughly with water, and then consult a doctor.
CAUTION
0Danger of explosion if battery is incorrectly replaced. Replace only with the type
recommended by the manufacturer.
0When disposing of the batteries, please contact your local authorities or dealer and ask
for the correct method of disposal.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 oC
(140 oF) or incinerate.
CAUTION!
To reduce the risk of fire, electric shock or product damage,
0
0
0
00 Do not install or place this unit in a bookcase, built-in cabinet or in another
confined space. Ensure this unit is well ventilated.
AC adaptor
This AC adaptor operates on AC between 110 V and 240 V.
But
0In the U.S.A. and Canada, the AC adaptor must be connected to a 120 V AC power
supply only.
0When connecting to an AC supply outside of the U.S.A. or Canada, use a plug adaptor to
suit the AC outlet configuration.
Battery pack
DMW-BLK22
Body cap*1
VKF4971
AC adaptor
VSK0815F
Hot shoe cover*1
4HR1MC5229Z
USB connection cable
K1HY24YY0026
Cover for the battery grip connector*1
SKF0145K
Shoulder strap
DVPW1030Z
Interchangeable lens “LEICA DG VARIO-ELMARIT 12-60mm/F2.8-4.0 ASPH./POWER
O.I.S.”*2
H-ES12060
Lens hood
1ZE4Z260Z
Lens rear cap*3
1GE1Z136Z
Lens cap *3
SYF0083
Interchangeable lens “LUMIX G VARIO 12-60mm/F3.5-5.6 ASPH./POWER O.I.S.”*4
H-FS12060
Lens hood
SYA0066
Lens rear cap*3
1GE1Z136Z
Lens cap *3
DVZE1047Z
(1) Mode dial
(2) Camera on/off switch
(3) Rear dial
(4) Charging light/Network connection light
(5) Video rec. button
(6) [WB] (White balance) button
[ISO] (ISO sensitivity) button
[ ] (Exposure compensation) button
(7) Front dial
(8) Shutter button
(9) AF-Point Scope button
(10) Lens fitting mark
(11) Preview button
(12) Hot shoe (hot shoe cover)
(13) Drive mode dial
(14) Shoulder strap eyelet
(15) Self-timer light/AF assist light
(16) Lens lock pin
(17) Lens release button
(18) [MIC] socket
(19) Headphone socket
(20) HDMI socket
(21) USB port
(22) Viewfinder
(23) [LVF] button
(24) [ ] (Playback) button
(25) [ ] (AF mode) button
(26) Monitor/Touch screen
(27) Battery grip connector (cover for the
battery grip connector)
(28) Focus mode lever
(29) Joystick
(30) [AF ON] button
(31) [Q] (Quick menu) button
(32) Control dial ( )
Cursor buttons (3421)
[MENU/SET] button ( )
(33) Card door
(34) [DISP.] button
(35) [ ] (Cancel) button/
[ ] (Delete) button
(36) DC coupler cover
(37) Battery door
(38) Battery door release lever
(39) [REMOTE] socket
(40) Card slot 1
(41) Card access light 1
(42) Card slot 2
(43) Card access light 2
(2)
(5)
(6)
(13)
(12)
(14)
(1)
(9)
(7)
(8)
(4)
(10)
(11)
(3)
(15)
(17)
(16)
(18)
(19)
(20)
(21)
(32)
(33)
(34)
(35)
(36)
(37)
(22)
(28) (29) (30) (31) (14)
(23)
(24)
(25)
(26)
(27)
(38)
(40)
(41)
(42)
(43)
(39)
1 2
3 4
Charging time Approx. 220 min
Cautions
0The battery that can be used with the camera is DMW-BLK22. (As of September 2023)
0
0
0
00 Always use genuine Panasonic batteries (DMW-BLK22).
0
0
0
00 If you use other batteries, we cannot guarantee the quality of this product.
0This battery may present a risk of fire or chemical burn if mistreated.
0
0
0
00 For charging, use this camera or the Battery Charger (DMW-BTC15: optional) and
the items supplied with them. Charging with a non-specified charger may cause
liquid leakage, overheating, fire, explosion, etc., resulting in injury.
0Do not use any other AC adaptors except the one supplied with the camera or the
Battery Charger (DMW-BTC15: optional).
0Place the removed battery in a plastic bag, and store or keep away from metallic objects
(clips, etc.).
0Even when the camera on/off switch is set to [OFF] thus turning the camera off, it
consumes power.
When the camera will not be used for a long time, remove the power plug from the
electrical outlet in order to save power.
0When disposing of the batteries, please contact your local authorities or dealer and ask
for the correct method of disposal.
0
0
0
00 For information on memory cards with confirmed operation, check the
following support site:
https://panasonic.jp/support/global/cs/dsc/connect/index.html
(English only)
3
4
1
2
1 2 3
DVQX2400ZA
F0823KN0
Owner’s Manual
<Quick Start Guide>
Digital Camera
Model No. DC-G9M2
Produkt Specifikationer
| Mærke: | Panasonic |
| Kategori: | Kamera |
| Model: | Lumix DC-G9M2 |
Har du brug for hjælp?
Hvis du har brug for hjælp til Panasonic Lumix DC-G9M2 stil et spørgsmål nedenfor, og andre brugere vil svare dig
Kamera Panasonic Manualer
15 Oktober 2024
10 September 2024
3 September 2024
1 September 2024
29 August 2024
27 August 2024
27 August 2024
27 August 2024
26 August 2024
20 August 2024
Kamera Manualer
- Kamera Bosch
- Kamera SilverCrest
- Kamera Acer
- Kamera Ozito
- Kamera Denver
- Kamera Sony
- Kamera Canon
- Kamera Samsung
- Kamera GE
- Kamera TP-Link
- Kamera Philips
- Kamera Lenco
- Kamera Gigaset
- Kamera Braun
- Kamera Logitech
- Kamera Epson
- Kamera Daewoo
- Kamera Technaxx
- Kamera HP
- Kamera Sanyo
- Kamera Easypix
- Kamera Grundig
- Kamera Arlo
- Kamera Bushnell
- Kamera Pyle
- Kamera Fujifilm
- Kamera Nikon
- Kamera Kodak
- Kamera Lenovo
- Kamera Olympus
- Kamera Nedis
- Kamera Zorki
- Kamera Optoma
- Kamera Creative
- Kamera Azden
- Kamera Casio
- Kamera Trevi
- Kamera Trust
- Kamera Laserliner
- Kamera Blaupunkt
- Kamera JVC
- Kamera Leica
- Kamera Hitachi
- Kamera Medion
- Kamera Exakta
- Kamera EZVIZ
- Kamera König
- Kamera Gembird
- Kamera Powerfix
- Kamera Alpine
- Kamera Netgear
- Kamera Maginon
- Kamera Avaya
- Kamera Nest
- Kamera Vtech
- Kamera BenQ
- Kamera Bresser
- Kamera Sigma
- Kamera Pentax
- Kamera Rollei
- Kamera Xiaomi
- Kamera Moultrie
- Kamera Viewsonic
- Kamera Imou
- Kamera Polaroid
- Kamera Ricoh
- Kamera Aida
- Kamera Konica-Minolta
- Kamera Foscam
- Kamera Kyocera
- Kamera GoPro
- Kamera Lorex
- Kamera Cobra
- Kamera Velleman
- Kamera FLIR
- Kamera Swann
- Kamera Eufy
- Kamera Celestron
- Kamera Ring
- Kamera Fluke
- Kamera Hikvision
- Kamera AVerMedia
- Kamera Reolink
- Kamera EVE
- Kamera Prixton
- Kamera Marshall Electronics
- Kamera General Electric
- Kamera SPC
- Kamera Hanwha
- Kamera ARRI
- Kamera BirdDog
- Kamera MuxLab
- Kamera Spypoint
- Kamera Vivitar
- Kamera Ansco
- Kamera Vimar
- Kamera Oregon Scientific
- Kamera Dahua Technology
- Kamera SereneLife
- Kamera Lexibook
- Kamera Intel
- Kamera SJCAM
- Kamera Scosche
- Kamera Speco Technologies
- Kamera Joy-It
- Kamera Kogan
- Kamera Levenhuk
- Kamera Emerson
- Kamera Minox
- Kamera Burris
- Kamera Silvergear
- Kamera Elmo
- Kamera AViPAS
- Kamera UniView
- Kamera AquaTech
- Kamera Alfatron
- Kamera BZBGear
- Kamera PTZ Optics
- Kamera Daitsu
- Kamera Agfa
- Kamera AgfaPhoto
- Kamera Argus
- Kamera Lumens
- Kamera Yashica
- Kamera Sygonix
- Kamera Mamiya
- Kamera Zenit
- Kamera Fuji
- Kamera Minolta
- Kamera EverFocus
- Kamera RunCam
- Kamera SeaLife
- Kamera Aplic
- Kamera FIMI
- Kamera Meade
- Kamera Contax
- Kamera Sinji
- Kamera Traveler
- Kamera Digital Watchdog
- Kamera Getac
- Kamera Ikegami
- Kamera Pelco
- Kamera ZeissIkon
- Kamera Dorr
- Kamera HOLGA
- Kamera Praktica
- Kamera Hasselblad
- Kamera Moto Mods (Motorola)
- Kamera Fantasea Line
- Kamera Brinno
- Kamera Z CAM
- Kamera General
- Kamera Ergoguys
- Kamera Strex
- Kamera Leitz Focomat IIc
- Kamera Cosina
- Kamera Videology
- Kamera InfiRay
- Kamera Videotec
- Kamera GoXtreme
- Kamera IOptron
- Kamera Cambo
- Kamera Kobian
- Kamera Kyocera Yashica
- Kamera Red Digital Cinema
- Kamera Konica
- Kamera Akaso
- Kamera Seek Thermal
- Kamera Ikelite
- Kamera Adeunis
- Kamera Hoppstar
- Kamera PatrolEyes
- Kamera Camouflage
- Kamera HuddleCamHD
- Kamera Linhof
Nyeste Kamera Manualer
15 Oktober 2024
15 Oktober 2024
8 Oktober 2024
4 Oktober 2024
4 Oktober 2024
4 Oktober 2024
3 Oktober 2024
2 Oktober 2024
1 Oktober 2024
1 Oktober 2024
