Network Camera

Model No. WV-S6131 / WV-S6111

Installation Guide

Included Installation Instructions

Important safety instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9) Only use attachments/accessories specified by the manufacturer.

10) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the

apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury

from tip-over.

S3125A

11) Unplug this apparatus during lightning storms or when unused for long periods of time.

12) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been dam-

aged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have

fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

Troubleshooting

Open Source Software

• This product contains open source software licensed under GPL (GNU General Public License),

LGPL (GNU Lesser General Public License), etc.

• Customers can duplicate, distribute and modify the source code of the software under license of

GPL and/or LGPL.

• Refer to the “readme.txt” file on the provided CD-ROM for further information about open source

software licenses and the source code.

• Please note that Panasonic shall not respond to any inquiries regarding the contents of the source

code.

The model number and serial number of this

product may be found on the surface of the unit.

You should note the model number and serial

number of this unit in the space provided and

retain this book as a permanent record of your

purchase to aid identification in the event of

theft.

Model No.

Serial No.

NOTE: This equipment has been tested and found

to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when the

equipment is operated in a commercial environ-

ment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed

and used in accordance with the instruction man-

ual, may cause harmful interference to radio com-

munications.

Operation of this equipment in a residential area is

likely to cause harmful interference in which case

the user will be required to correct the interfer-

ence at his own expense.

FCC Caution: To assure continued compliance,

(example - use only shielded interface cables

when connecting to computer or peripheral devic-

es). Any changes or modifications not expressly

approved by the party responsible for compliance

could void the user’s authority to operate this

equipment.

For U.S.A.

CAN ICES-3(A)/NMB-3(A)

For Canada

WARNING:

• To prevent injury, this apparatus must be secure-

ly attached to the wall/ceiling in accordance with

the installation instructions.

• To prevent fire or electric shock hazard, do not

expose this apparatus to rain or moisture.

• The apparatus should not be exposed to drip-

ping or splashing.

• All work related to the installation of this product

should be made by qualified service personnel

or system installers.

• The installation shall be carried out in accor-

dance with all applicable installation rules.

• The connections should comply with local elec-

trical code.

• Batteries (battery pack or batteries installed)

shall not be exposed to excessive heat such as

sunlight, fire or the like.

CAUTION:

• Any changes or modifications not expressly

approved by the party responsible for compli-

ance could void the user’s authority to operate

the equipment.

• The network camera is only intended for a con-

nection to an ethernet or PoE network without

routing to the outside plant.

Disposal of Old Equipment and Batteries

Only for European Union and countries with recycling systems

These symbols on the products, packaging, and/or accompanying documents mean that used

electrical and electronic products and batteries must not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used batteries, please take them

to applicable collection points in accordance with your national legislation.

By disposing of them correctly, you will help to save valuable resources and prevent any potential

negative effects on human health and the environment.

For more information about collection and recycling, please contact your local municipality.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national

legislation.

Note for the battery symbol (bottom symbol)

This symbol might be used in combination with a chemical symbol. In this case it complies with the

requirement set by the Directive for the chemical involved.

About the user manuals

Product documentation is composed of the following documents.

• Installation Guide (this document): Explains installation, cable connections, mounting and removal. This

manual uses the WV-S6131 as an example in the explanations.

• Important Information (included in the CD-ROM):

Provides basic information about the product.

• Operating Instructions (included in the CD-ROM): Explains how to perform the settings and how to oper-

ate this camera.

Adobe® Reader® is required to read these operating instructions on the provided CD-ROM.

When the Adobe Reader is not installed on the PC, download the latest Adobe Reader from the Adobe web site

and install it.

The external appearance and other parts shown in this manual may differ from the actual product within the

scope that will not interfere with normal use due to improvement of the product.

Standard accessories

Installation Guide (this document) 1 set ........................
