https://www.phoenixcontact.com/gb/products/3240084
06/29/2016Page1/3
Ring cable lug-C-RC 6/M5 DIN-3240084
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Ring cable lug, non-insulated, 2.6 ... 6 mm², M5
Why buy this product
The CRIMPFOX-RC... tools from our CRIMPFOX range of crimping pliers are available for optimum crimping
The ring cable lugs without plastic sleeve are made from high-quality tin-plated electrolytic copper for maximum protection against corrosion
The hard-soldered press zone enables maximum conductor pull-out values to be achieved
Key Commercial Data
Packing unit 50 STK
Minimum order quantity 50 STK
GTIN
Weight per Piece (excluding packing) 1.55 g
Country of origin China
Technical data
Dimensions
Length (b) 20 mm
Width (a) 10 mm
Maximum stripping length 9 mm
Length of insulation sleeve (c) 6 mm
Inner dimension of the insulating collar (d) 3.6 mm
Distance between the center and the insulation sleeve (e) 9 mm
Inner diameter (f) 5.3 mm
Material thickness (g) 1 mm
Ambient conditions
Ambient temperature (operation) 110 °C
