Privileg PWF X 873 A Manual

Privileg Vaskemaskine PWF X 873 A

Læs nedenfor 📖 manual på dansk for Privileg PWF X 873 A (4 sider) i kategorien Vaskemaskine. Denne guide var nyttig for 8 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Download PDF

Side 1/4

Quick Guide

CONTROL PANEL

1. ON/OFF button

2. START/PAUSE button and indicator light

3. TEMPERATURE button

4. DISPLAY

5. buttonCHILD LOCK

6. OPTION button

7. button DELAYED START

8. SPIN button

9. WASH CYCLE SELECTOR KNOB

10. PUSH & GO button

WASH CYCLE TABLE

PRODUCT DESCRIPTION

1. Top

2. Detergent dispenser drawer

3. Control panel

4. Handle

5. Porthole door

6. Drain pump (behind the plinth)

7. Plinth (removable)

8. Adjustable feet (2)

DETERGENT DISPENSER DRAWER

2 3 5

678

THANK YOU FOR CHOOSING OUR PRODUCT. Before using the appliance carefully read the Safety Instruction.

Before using the machine, it is imperative that the transport bolts are removed.

For more detailed instructions on how to remove them, see the Installation Guide.

Compartment 1:

Do not insert detergent in this compartment.

Compartment 2: Washing detergent (powder

or liquid)

If liquid detergent is used, the removable plastic

partition A (supplied) should be used for proper

dosage.

If powder detergent is used, insert the partition

into slot .B

Compartment 3: Additives (fabric softener, etc.)

The fabric softener must never exceed the “max”

level indicated on the central pin.

! Use powder detergent for white cotton garments, for pre-washing, and

for washing at temperatures over 60°C.

! Follow the instructions given on the detergent packaging.

! To remove the drawer, press lever and pull the drawer outwards.C

* By selecting the 16 cycle and excluding the spin cycle, the washing machine will drain only.

** The duration of the wash cycles can be checked on the display.

*** After programme end and spinning with maximum selectable spin speed, in default

programme setting.

**** The display will show the suggested spin speed as default value.

The cycle duration indicated on the display or instruction manual is an estimate based on

standard conditions. The actual duration may vary in relation to several factors, such as the

temperature and pressure of the incoming water, ambient temperature, amount of detergent,

load quantity and type, load balancing and any additional options selected. The values given

for programmes other than the Eco 40-60 programme are indicative only.

1) Eco 40-60

Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.

The most ecient programme in terms of energy and water consumption for washing

normally soiled cotton laundry.

Note: spin speed values shown on the display can slightly diers from the values stated in the table.

For all testing institutes:

2) Long cotton cycle: set cycle 6 at a temperature of 40°C.

3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.

Maximum load 8 kg

Power input in o mode 0.5 W / in left-on mode 8 W

Detergents and

Additives

Recommended

detergent

Residual

dampness %

(***)

Energy

consumption

kWh

Total water l

Laundry

temperature °C

Wash cycle Temperature Maxim

spin

(r.p.m.)

Max.

load

(kg)

Duration

(h : m)

Wash Fabric

softener

Powder

Liquid

Setting Range 2 3

1 Cotton 30°C – 30°C 1200 4 **   –– – – –

2 Synthetics 30°C – 30°C 1000 4 **   –– – – –

3 Colours 30°C – 30°C 1000 4 **   –– – – –

4 Delicates 30°C – 30°C 600 (****) 1 **   –– – – –

5 Rapid 30min 30°C – 30°C 1200 (****) 4 0:30   –71 0,18 37 27

6 Cotton (2) 40°C – 60°C 1400 8 3:55     49 451,10 97

7 Synthetics (3) 40°C – 60°C 1200 4 2:55     35 0,8 55 43

8 Mixed 40°C – 40°C 1400 8 **   –- - - –

40°C9Eco 40-60 (1) 40°C

1351 8 3:38     53 0,68 54 33

1351 4 2:48     53 0,43 53 28

1351 2 2:40     53 0,28 37,5 21

10 White 60°C – 90°C 1400 8 2:35     55 1,79 89 55

11 Rapid 20°C – 20°C 800 3.5 **   –– – – –

11 Rapid 40°C – 40°C 1200 4 **   –– – – –

11 Rapid 60°C – 60°C 1000 8 **     – – – –

12 Duvet 30°C – 30°C 1000 3.5 **   –– – – –

13 Wool 40°C – 40°C 800 2 **   –– – – –

14 20°C 20°C – 20°C 1400 8 1:50   –55 0,14 78 22

15 Rinse + Spin – – 1400 8 ** – – – – – – –

16 Spin + Drain * – – 1400 8 ** – – – – – – – –

 Required dosage Optional dosage
