Proclip 539676 Manual


Læs nedenfor 📖 manual på dansk for Proclip 539676 (2 sider) i kategorien Ikke kategoriseret. Denne guide var nyttig for 6 personer og blev bedømt med 4.5 stjerner i gennemsnit af 2 brugere

Side 1/2
Item No. 539676 - Holder with Tilt Swivel and Key
Lock
Compatible with:
Samsung Galaxy Tab Active
Important:
Self-installation instructions and advice are provided for your
convenience. It is your responsibility to determine if you have the
knowledge, skills, and physical ability required to properly perform an
installation. ProClip USA, Inc. shall have no liability for damage or
injury resulting from the installation or use of any ProClip or third
party products. It is your responsibility to ensure that all products are
installed in adherence with local laws and regulations and in such a
manner as to allow a vehicle to be operated safely and without
distraction. ProClip USA, Inc. product warranties do not cover the
installation, removal or re-installation of any product.
Attention:
Carefully read all instructions and review the images before installing this product.
1. Unscrew the screw in the center of the holder so you can remove the tilt
swivel base plate on the back. Place the tilt swivel base plate over the matching
holes in the face plate of your mounting bracket (ProClip demo mount shown in
picture) Attach the base plate by using the self-tapping screws enclosed. Place
the Holder onto the tilt swivel base plate and attach it with the center screw.
This screw also controls the pivot, tighter for a rm hold and loose for more
(easier) angling/rotation of the Holder.
3. To remove the tablet from the holder: Use the enclosed key to open the lock.
Remove the lock by sliding it away from the holder. Slide the tablet carefully out
of the holder.
2. o place the device in the holder: Hold the device in an angled position, screen
facing downwards. Place the lower part of the device into the holder where the
opening between the sidewalls is widest. Flip the upper part of the device forward so
the device goes at into the holder. Slide the device straight downward into the holder.
Press the block with the lock downward onto the upper part of the holder and press
the button to lock it.
4. The holder and tablet is in place. Switch between portrait and landscape view by
rotating the holder to desired position.


Produkt Specifikationer

Mærke: Proclip
Kategori: Ikke kategoriseret
Model: 539676
