Profile Videophone EN - 1
PAC-108
We thank you for the purchase of this Profile product.
Note: It is important that you read this manual carefully
before using the product. Then keep this manual in a
safe place.
Technical data Monitor
Supply voltage adapter: 230VAC/15VDC 1A
Working current: +/- 300 / 700 mA
Operating temperature: -10°C to 50°C
Max relative humidity: 85%
Number of pixels: 480 x 3 (RGB) x 240 vertical
Screen size: 7 Inches (diagonal)
Video system: PAL/NTSC
Total dimensions: 283(L) x 143(B) x 43(H) mm
Technical data Camera
Working current: < 300mA
Temperature for use: -20°C / +50°C
Type: pinhole camera
Focus/picture angle: 50°
Total dimensions: 122 (L) x 73 (B) x 44 (H) mm
Technical requirements for connections
Use either the cable supplied measuring 10 metres
or own wiring measuring 0.6 - 0.8mm² with a max.
length of 25 metres.
You need a plug socket that is max. 1.5 m from the
monitor.
Required wiring without door lock: 4
Required wiring with door lock: 6
Parts
Hands-free monitor
Camera
Protective cover for external unit
Mounting bracket for monitor
Fixing screws
Connecting cable 10 m
Safety instructions
The monitor or camera may never be cleaned with
detergents. Only use soap and a damp cloth.
The power wiring may never be cut through nor
extended; this renders the guarantee invalid!
The monitor may not be placed close to magnetic
fields such as next to a TV or thick power cables.
Water may never be poured over the camera or
monitor. The camera is only splashproof.
Assembly instructions
1. If there is not yet any wiring:
The is determined as position of the monitor
follows: the height amounts to approximately 165
cm, and is max. 150 cm from a plug socket where
the adapter will be plugged in. The connecting
cable between monitor and outside camera must
therefore come from the wall behind the monitor.
Provide a tube so the cable can move freely. If
possible also provide a tube with a sufficiently
large diameter (20-25mm).
Determine the position of the camera outside at
the door. The ideal installation height is 155 to
165 cm. Shorter and taller persons then also
remain in picture.
Bring the camera cable to the monitor from outside
to inside; the cable is moulded.
Connect the wiring according to the diagram
below. We again emphasise that the power supply
wiring may not be extended or cut through: this
causes the appliance to work poorly and
invalidates the guarantee.
Cut off the cables with 2 cores without door lock.
If a door lock is to be connected, its connection
must be from the camera unit as shown on the
diagram above. The lock may consume no more
than 300 mA and must have a memory function
(the lock remains free until just before the door is
pushed open). The 2 wires are already provided in
a moulded cable (4m).
2. if there is already existing wiring (max. 25m):
The wire diameter must be between 0.6 and 0.8
mm².
Shorten the moulded cables to the desired length
and strip the wires approximately 1cm. If an
electrical door lock is used: also strip the 2-core
cable over a length of 1cm.
The door lock is connected from the camera with
the moulded cable with two wires. The lock may
consume no more than 300 mA and must have a
memory function (the lock remains in a free
position as long as the door is not pushed open).
Provide a recess behind the camera in the wall or
door frames, connect the wiring using the
connecting blocks and push this into the recess. If
you cannot do this the wires must be twisted
together and insulated with insulation tape.
Use:
A. Having a normal conversation
1. Ringing on the external unit
