Profile Intercom EN - 1
PAC-206
We thank you for the purchase of this Profile product.
Note: It is important that you read this manual carefully
before using the product. Then keep this manual in a
safe place.
Technical information Internal unit
Supply voltage adapter: 230VAC/15VDC 1A
Working current: 170 mA + 50mA
Operating temperature: -10°C to 60°C
Max relative humidity: 85%
Total dimensions: 265(L) x 94(B) x 45(H) mm
Technical information External unit
Working current: < 300mA
Temperature for use: -20°C / +50°C
Total dimensions: 120 (L) x 41 (B) x 45 (H) mm
Technical requirements for connections
Use either the cable supplied measuring 10 metres
or own wiring measuring 0.6 - 0.8mm² with a max.
length of 25 metres.
You need a plug socket that is max. 1.5m from the
internal unit.
Required wiring without door lock: 3
Required wiring with door lock: 5
Parts
Internal unit with receiver
External unit
Protective cover for external unit
Mounting bracket internal unit
Fixing screws
Connecting cable 10 m
Safety instructions
The internal/external unit may never be cleaned
with detergents. Only clean with soap and a damp
cloth.
The power wiring may never be cut through nor
extended; this renders the guarantee invalid!
The internal unit may not be placed close to
magnetic fields such as next to a TV or thick power
cables.
Water may never be poured over the internal and
external unit. The external unit is only splashproof.
Assembly instructions
1. If there is not yet any wiring:
The is determined as position of the internal unit
follows: the height amounts to approximately 165
cm, and is max. 150 cm from a plug socket where
the adapter will be plugged in. The connecting
cable between the internal unit and external unit
must therefore come out of the wall behind the
internal unit. Provide a tube so the cable can move
freely. If possible also provide a tube with a
sufficiently large diameter (20-25mm).
Determine the position of the external unit
outside at the door. The ideal installation height
is 155 to 165 cm.
Insert the cable from the external unit to the
internal unit from outside to inside; the cable is
moulded.
Connect the wiring according to the diagram
below. We again emphasise that the power supply
wiring may not be extended or cut through: this
causes the appliance to work poorly and
invalidates the guarantee.
Cut off the cables with 2 cores without door lock.
If a door lock is to be connected, its connection
must be from the outside unit as shown on the
diagram above. The lock may consume no more
than 300 mA and must have a memory function
(the lock remains free until just before the door is
pushed open). The 2 wires are already provided in
a moulded cable (4m)
2. If there is already wiring present (max. 25m):
The wire diameter must be between 0.6 and 0.8
mm². Only 3 wires have to be connected. The
yellow video connection is not used so does not
have to be connected.
Shorten the moulded cables to the desired length
and strip the wires approximately 1cm. If an
electrical door lock is used: also strip the 2-core
cable over a length of 1cm.
The door lock is connected from the external unit
with the moulded cable with two wires. The lock
may consume no more than 300 mA and must
have a memory function (the lock remains in a free
position as long as the door is not pushed open).
Provide a recess behind the external unit in the
wall or door frames, connect the wiring using the
connecting blocks and push this into the recess. If
you cannot do this the wires must be twisted
together and insulated with insulation tape.
Use:
A. Having a normal conversation
1. Ringing on the external unit
2. Take the receiver and speak to the visitor.
Outdoor
unit
