Side 1/3

To listen to internet radio or to stream music, your radio must rst be connected to your network.

1 Choose ‘YES’ to keep the radio connected to the network when

in Standby. This will allow remote control software to switch on

your radio when needed.

2 A list of the available WiFi networks will then be displayed. If

no networks are found then your radio may be too far from your

router.

3 Rotate the Tuning control to navigate the list of available

networks and highlight your own Network Name. If your Network

Name is not found, then you may have to get your wireless router

working or your radio may be too far from the router.

4 If your Network Name (sometimes called SSID) is displayed with

“[WPS]” (WiFi Protected Setup), then press the Tuning control

and a WPS menu will be displayed, otherwise press the Tuning

control and proceed to step 6.

5 Choose one of the WPS menu options as required for your router

(WPS may be via push button, or using an identication number):

‘Push Button’ - the display prompts you to press the WPS button

on your router and then the Tuning control on the radio. The two

devices should then connect automatically. Proceed to step 9.

‘PIN’ - the display shows an identication number which you must

enter into your router using a web browser (refer to your router’s

user documentation). You should then press the Tuning control

on the radio. Proceed to step 9.

‘Skip WPS’ – if you wish to enter your password or if your

password was previously entered.

6 If you are prompted to enter a password (or key), enter each

character by rotating the control to highlight it, then Tuning

pressing the control. If you are not prompted for a Tuning

password then proceed to step 9.

7 The three controls on the right-hand side of the password key

screen have special functions. You can quickly access these by

pressing the button and then using the Info Tuning control as

needed.

Select ‘OK’ - When the complete password has been entered.

Select ‘BKSP’ - Select to erase a character (long press to clear).

Select ‘CANCEL’ - To cancel and re-run the Network Wizard.

8 After the nal character of the password has been entered,

highlight the symbol and press the control. ‘OK’ Tuning

9 The screen will show ‘Connecting..’ and then ‘Setup wizard

completed’. Press the control to exit the setup wizard. Tuning

The radio should now be able to connect to the network. Your

radio will display the Main mode menu.

10 For details on navigation and operation of your smart radio,

please see overleaf.

Smart radio, mains adaptor, quick start guide, safety/warranty and streaming service leaet. Please visit

www.robertsradio.com if you wish to download the full user guide.

Features

Controls

continued overleaf...

STEP 1 - Connect to the mains & setup your smart radioWhat is in the Box?

E - Connect to your network

F - Use the UNDOK app to setup your radio

• DAB / DAB+ / FM and WiFi internet radio with colour display and built-in battery charging

• Stream using Spotify Connect, Deezer and Amazon Prime music

(Third-party streaming services may require a subscription)

• Bluetooth audio streaming from iPhone or Smartphone

• MP3 playback via USB

• Full control via the UNDOK smartphone app (for Apple iOS and Android)

• 60 presets (40 x Internet Radio/Podcast, 10 x DAB, 10 x FM)

• Wireless connection (Dual-band WiFi, 802.11b/g/n/a)

• 6 equaliser proles and separate bass and treble

• 2 alarm timers (DAB/FM/Internet or buzzer)

• USB charging of smartphone, tablet or similar devices

• AC adaptor included / Batteries 6 x LR6/AA size or rechargeable equivalent (not included)

• Stereo auxiliary input, line out and headphone sockets

A - Connect to the mains

Please read the safety leaet provided before connecting your radio to the mains.

1 Place your radio on a at surface.

2 Plug the cable from the mains adaptor into the .DC input socket

3 Plug the mains adaptor into a wall socket and switch on the socket.

4 The display on the radio will show a start up screen for a few seconds.

If this is the rst time that you use your radio (or after a Factory Reset)

the display will show the language menu.

Line

Out

1 If you wish to setup your radio using the UNDOK app download

and install the UNDOK app on to your Android or iOS device.

2 Follow the on-screen instructions or see the full user guide

on-line.

• If you already have the UNDOK app installed on your device

ensure that you have the latest version.

1 Charge / Low battery indicator

2 On/Off / Volume control

3 Headphone socket

4 Auxiliary input socket

5 USB playback / Charge socket

6 Mode / Bluetooth pair button

7 Menu button

8 Info button

9 LCD display

10 Preset / Play / Pause button

11 Previous button

12 Next button

13 Alarm / Sleep button

14 Telescopic aerial

15 Tuning / Select / Snooze control

16 Bluetooth indicator

17 Loudspeaker

18 WiFi antenna (internal)

19 DC input socket

20 Line output socket

21 Battery compartment

22 Battery charge switch (inside compartment)

Before you can use your smart radio you must have the following:

• A broadband internet connection (not required for DAB, FM or music player functions).

• A router (or wireless access point) providing a WiFi signal, connected to your broadband internet

service provider.

• A Smartphone or tablet which uses the Android operating system (version 4.0.3 or later) or Apple

iOS (version 9 or later).

• If your wireless network requires a security password, then you will need to have this available during

setup. The radios WiFi system is compatible with 802.11b, g, n or a networks and can use 2.4GHz or

5 GHz WiFi frequency bands.

IMPORTANT: Before you continue, make sure your router is powered up and working with your

broadband internet service provider.

D - Select clock and time settings

1 The radio will show a setup wizard. With highlighted press ‘YES’

the Tuning/Select control to begin setting up your radio.

• Note: If you wish to go back within a menu or if you make an error

at any time, please use the button.Menu

2 Choose either the or12 24 hour clock display.

3 A menu allowing you to specify the auto-update option for the clock

will be shown. Update from network will be the best for most users.

4 Choose the timezone for your region.

5 Choose a daylight saving option. This is also known as Summer/

Winter time (or BST/GMT in the UK).

C - Select language

By default your radio will display all menus and messages in English.

1 Rotate the Tuning/Select control to highlight the desired language.

2 Press the control to enter the selection.Tuning/Select

• Your radio will display a privacy policy. Please read the privacy policy

and then press the control to accept the policy.Tuning/Select

Jones family

[WPS] Paul’s network

Smith

Brown

[Rescan]

[Manual config]

SSID

Network settings

Keep network connected?

Network settings

Network wizard

Scanning...

Push Button

Skip WPS

WPS Menu

Key:

0 1 2 3 4 5 6

7 8 9 . _ - @

, a b c d e

f g h i j k l

m n o p q r s

123-jones

Setup wizard

completed

Press ‘SELECT’ to exit

Network settings

Please wait

Connecting...

English

Dansk

Nederlands

Français

Deutsch

Italiano

Language

Your radio may be congured using either the display and buttons on

the radio or using the UNDOK app. First-time users are recommended

to use the radio’s controls.

1 If you wish to use to setup your radio, UNDOK skip to step F now.

2 If you would like to setup your radio using the radio’s controls follow

the setup procedure below and choose the desired language.

B - Setup using the radio or the UNDOK app

Setup wizard

Start now?

Date/Time

12/24 hour format

Auto update

Update from DAB

Update from FM

Update from Network

No update *

Line

Out

Internet/DAB / DAB+ / FM RDS / Bluetooth

USB Smart Radio

WiFi: 2.4GHz / 5GHz

FM: 87.5-108MHz

DAB/DAB+ (BAND III): 5A-13F

DC In: 12V 1.5A

USB Output: 5V 1A

Battery: 6x 1.5V AA

Designed & Engineered in the UK, Made in China

Roberts Radio Ltd,

Stoney Lane, Whiston,

Prescot, L35 2XW, UK

Glen Dimplex Europe Ltd,

Airport Road, Cloghran,

Co. Dublin, K67 VE08, Ireland

READ SAFETY GUIDE

iStream3L

Mode

Aux In

Preset

Sleep

Snooze

Low Battery

Charge/

Low Battery

19 20

Snooze
