2English
6English
3English
7English
4English
8English
Safety Information
5English
Auto clean function
Use the Auto clean function if the indoor unit produces odors.
Activating Auto clean
To activate Auto clean, press the (Options) button for at least 3 seconds.
The indoor unit display shows:
Canceling Auto clean
To cancel Auto clean while it is running, follow the procedure below:
▶Press and hold for 3 or more seconds.
or
▶ ▶ ▶Select Clean.
Deactivating Auto clean
To deactivate Auto clean, follow the procedure below while the air conditioner is in operation:
▶Press and hold for 3 or more seconds.
or
▶ ▶ ▶Select Clean.
Functions and Buttons
02
01
Function Button and Selection Display
Power On/Off
AI Auto ▶ ▶ Select Auto.
Auto ▶ ▶ Select Auto.
Cool ▶ ▶ Select Cool.
Dry ▶ ▶ Select Dry.
Fan ▶ ▶ Select Fan.
Fast In Cool mode ▶
5 Step Cooling In Cool mode ▶
Quiet In Cool mode ▶ ▶ ▶
Select Quiet. ▶
Beep ▶ ▶ Select Beep. ▶
Display lighting
▶ ▶ Select Display. ▶
Wi-Fi
(SmartThings)
▶ Press and hold for 5 or more
seconds.
Wi-Fi (On/Off) and ▶ Press and hold for 5
or more seconds.
Timed on/off ▶ Select On or Off ▶
(Set the duration.) ▶
good'sleep In Cool mode ▶ (Select .) ▶
(Set the duration.) ▶
01 Display
02 Button
NOTE
• Although appears Usage
on the remote control
display, it is not available
on this model.
• Features may differ
depending on models.
Operating the Air Conditioner Cleaning
CAUTION
When the air conditioner does not operate properly for cooling or heating, there is a possibility of refrigerant leakage. If
any leakage, stop operation, ventilate the room, and consult your dealer immediately for recharging refrigerant.
The refrigerant is not harmful. However, if it comes in contact with fire, it may generate harmful gases and there is
risk of fire.
During transportation of the indoor unit, the pipe lines shall be covered with brackets for protection. Do not move
the product with holding the pipe lines.
• It may cause gas leakage.
Do not cut or burn the refrigerant container or pipings.
Do not point the air direction to the fireplace or heater.
FOR USING
WARNING
If the product has been immersed in water or shows any abnormal sign, please contact the Customer
Service Centre. Do NOT arbitrarily disassemble, repair or modify it.
In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching
the power line. Do not touch the appliance or power line.
• Do not use a ventilating fan.
Do not touch the circuit breaker with wet hands.
After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as
packaging materials can be dangerous to children.
• If a child places a bag over its head, it may result in suffocation.
Do not touch the air-flow blade with your hands or fingers during heating.
Do not insert your fingers or foreign substances into the air inlet/outlet of the air conditioner.
Do not place an object near the outdoor unit that allows children to climb onto the machine.
• This may result in children seriously injuring themselves.
If any foreign substance such as water has entered the appliance, cut off the power supply and contact
the nearest service centre.
CAUTION
Check that the installation frame of the outdoor unit is not broken at least once a year.
Do not install the product in a ship or a vehicle (such as a campervan).
Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.
Do not spray volatile material such as insecticide onto the surface of the appliance.
When replacing the remote control batteries, keep them out of the reach of infants.
• If an infant eats batteries, contact a doctor immediately.
Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or
for any other unusual purposes.
FOR CLEANING
WARNING
Before cleaning, servicing, or performing maintenance, make sure to disconnect the product from its
power source and wait until the fan stops.
CAUTION
Take care when cleaning the surface of the heat exchanger of the outdoor unit since it has sharp edges.
• This should be done by a qualified technician. Please contact your installer or service centre.
FOR R-32 REFRIGERANT
WARNING
If the air conditioner malfunctions or requires repair, immediately stop its operation and disconnect the entire power
system. Then consult the authorized service personnel.
Do not use means to accelerate the defrost operation or to clean, other than those recommended by Samsung.
Do not pierce or burn.
Be aware that refrigerants may not contain an odour.
The product shall be stored in a room with no ignition sources (e.g. open flames, gas appliance, electric heater, etc.).
• Note that the refrigerant has no odour.
Failure to follow the instructions may result in electric shock,
injury, fire, breakdown or explosion.
FOR GENERAL
This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
FOR INSTALLATION
WARNING
Use a power cord with this product's power specifications or higher and use the power cord for this
appliance only. In addition, do not use an extension cord.
• Do not use it together with a power strip or other device.
Do not extend the power cord.
• Connect power matching to voltage / frequency / rated current conditions.
The installation of this appliance must be performed by a qualified technician or service company.
Do not attempt to install the air conditioner yourself.
Install an Isolation Switch next to the Air Conditioner (but not on the panels of the Air Conditioner) and circuit
breaker dedicated to the air conditioner.
Do not install this appliance near a heater, or flammable material. Do not install this appliance in a humid, oily or
dusty location, in a location exposed to direct sunlight and water (or rain). Do not install this appliance in a location
where gas may leak.
This appliance must be properly grounded. Do not ground the appliance to a gas pipe, plastic, water pipe, or telephone line.
• Make sure to use a socket-outlet with ground.
CAUTION
When installing the outdoor unit, make sure to connect the drain hose so that draining is performed correctly.
• The water generated during heating by the outdoor unit may overflow and result in property damage.
In particular, in winter, if a block of ice falls, it may result in injury, death or property damage.
Do not install the product in a place where thermo-hygrostat is needed (such as server room,
machinery room, computer room, etc.)
• Those places do not provide guaranteed operation condition of the product therefore performance
can be poor in these places.
FOR POWER SUPPLY
WARNING
Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a
metal object, place a heavy object on the power line, insert the power line between objects, or push the power line
into the space behind the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
WARNING: Read This Manual
Read and follow all safety information and instructions before installation, use, or maintenance of this
appliance. Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or
property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest
version, visit www.samsung.com.
Because the instructions in this manual cover various models, the characteristics of your air conditioner may
differ slightly from those described. If you have any questions, please contact your service provider or visit
www.samsung.com.
Notices and notes
To make you aware of safety messages and highlighted information, we use the following notices and notes
throughout this manual:
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property damage.
IMPORTANT
Information of special interest
NOTE
Supplementary information that may be useful
WARNING: Low burning velocity material
(This appliance is filled with R-32.)
The user and installer guides should be read carefully.
The user and installer guides should be read carefully.
The service guide should be read carefully.
Safety Information
DB68-09629T-02
Air conditioner
User manual
AR**CY*Y**** / AR**CY*Z****
• Thank you for purchasing this Samsung air conditioner.
• Before operating this unit, please read this manual carefully and retain it for future reference.
Indoor Unit Overview
The appearance of the actual product may differ slightly from the image below.
01
03
02
04
05
06
08
07
Connecting SmartThings
Registering the product / Reading the
manual / Connecting to Services
1 Launch a QR code reader app and scan the QR
code image on the product.
2 Try connecting the SmartThings app to the
product.
1 Launch a QR code reader app and scan the QR
code image on the product.
2 Choose the desired menu from the Product
Registration, Manual, Customer Support. If you
choose 'Manual' you can read the manual of the
product you purchased.
NOTE
• We provide online manuals that can be accessed via your smartphone or our website to contribute in
reducing the usage of manuals in paper format, as part of efforts to save the Earth.
Preparation
01 Air intake
02 Air filter
03 Front panel
04 Airflow blade (up and down)
05 Airflow blade (left and right)
06 Power button/Remote control receiver
07 Room temperature sensor
08 Display
Display
01
02 03 04
01 Temperature indicator (numeric)
Filter reset indicator ( )
Auto clean indicator ( )
02 AI Auto indicator
03 Timer indicator
good’sleep indicator
04 Wi-Fi indicator
NOTE
• When the Wi-Fi is turned on, the indicator blinks
three times and then turn on.
DB68-09629T-02_IB_23Y AR9500T SIEL GEO Wind 4way Wi-Fi_TL_EN_.indd 1
DB68-09629T-02_IB_23Y AR9500T SIEL GEO Wind 4way Wi-Fi_TL_EN_.indd 1
DB68-09629T-02_IB_23Y AR9500T SIEL GEO Wind 4way Wi-Fi_TL_EN_.indd 1
DB68-09629T-02_IB_23Y AR9500T SIEL GEO Wind 4way Wi-Fi_TL_EN_.indd 1DB68-09629T-02_IB_23Y AR9500T SIEL GEO Wind 4way Wi-Fi_TL_EN_.indd 1 2022-12-19 오전 9:51:50
2022-12-19 오전 9:51:50
2022-12-19 오전 9:51:50
2022-12-19 오전 9:51:502022-12-19 오전 9:51:50
