Stacking Kit Installation Guide (SKK-9MC*)

CAUTION

• Risk of personal injury. The dryer is large and heavy. Have at least two people move the dryer. Otherwise, it

may result in personal injury or death.

• Risk of product damage during installation. The dryer must be firmly installed on top of the washer. Do not

install the washer on top of the dryer. Otherwise, it may result in personal injury, death, or property damage.

• Risk of electric shock. You must disconnect the power cord before installing the product. Otherwise, it may

result in severe personal injury or death.

• When installing the dryer on top of the washer, make sure the drain hose in the rear is connected directly to

a drain and not to a water tank.

NOTE

This Stacking Kit is compatible with Samsung BESPOKE front-load washers and dryers released after 2022.

Check the compatibility of the stacking kit before installing it. You can check the compatible washer and dryer

models at the Samsung website (www.samsung.com).

Accessories

Hex-head screws (4)

6002-001431 (M5, L16)

Washers (4)

DC60-00044A (ID5, OD10)

Phillips-pan head

screws (8)

6002-000213 (M4, L12)

Phillips-pan head

screws (2)

6002-000215 (M4, L16)



:9($Ꮬ

:;($

Ꮪ



4.5cf

21kg

5.0cf23kg

Installation guide Left side top cover bracket Right side top cover

bracket (with multi-

connection cable

attached)

Front cover

Bracket guide Stacking guide (L/R)

Installation

STEP 1

Tighten the four leveling feet of the dryer all the way.

• Level the dryer using a level.

STEP 2

Slightly pull out the installed washer to gain access to

its rear.

Unfasten the two screws attached at the back of the

washer.

=H8 #

:;($

<H> #

:9($

STEP 3

Check the capacity of your washer (5.0 cf and over or

4.6 cf and less) and locate the correct assembly holes on

the top cover bracket (L/R).



<H= #

:9($

=H8 #

:;($

=H8 #

:;($

<H> #

:9($

Top cover bracket

Stacking guide

STEP 4

Fasten the top cover brackets (L/R) to their

corresponding stacking guides (L/R) using four M4 x L12

Phillips-Pan head screws.

• Check and make sure each top cover brackets are on

the correct sides (left/right) of the stacking guides

before fastening them.

4.5 cf21k g

5.0 cf23 k g

4.5 cf21k g

5.0 cf23 k g

4.5cf

21kg

5.0

23kg

STEP 5

Position the assembled stacking guides (L/R) on the

curved edges of the washer’s top cover. Fasten the

assembled stacking guides (L/R) using four washers and

M5 x L16 hex-head screws.

:9(

$Ꮭ

:;($

Ꮫ



($Ꮬ

:;($

Ꮪ



STEP 6

Assemble the bracket guide to the stacking guides at

the front end and check the alignment. Remove the

release liner from the double-sided tape attached

to the bottom of the stacking guides and attach the

stacking guides to the washer as shown in the figure.

Then, disassemble the bracket guide from the stacking

guides.

CAUTION

• Make sure the bottom curvature of the stacking

guide is aligned with the curvature of the washer’s

top cover.

• Attach the stacking guides after making sure they

are perfectly parallel with the washer’s top cover.

• After attaching the stacking guides, reattach the

bracket guide and double-check to make sure the

stacking guides are parallel.

STEP 7

Have at least two people lift the dryer and place it on

the stacking guide, and then push the dryer until the

rear two legs are properly locked into the stacking

guides’ U-shaped slot.

STEP 8

If installed correctly, the front edges of the stacking

guides should be perfectly aligned with the front edges

of the dryer’s side frames.

• Check to make sure the front edges of the dryer’s

side frame are not sticking out past the stacking

guides.

STEP 9

Attach the bracket guide to the stacking guides and

secure it in place using the M4 x L16 Phillips-Pan head

screws, as shown in the figure.

STEP 10

Hold the front cover with the letter ‘UP’ facing upward.

Align the hooks on the front cover with the holes on

the stacking guides as shown in the figure. Then, fully

insert the hooks to attach the front cover to the staking

guides.



<H= #:9(

<H= #:9($



<H= #:9($

STEP 11

Open the connector port covers on the dryer and the

washer. Then, connect the multi-connection cable on

both ports and close both connector port covers.

Attach each wire holder to the designated slots on the

dryer and the washer.

DC68-03859G-00

SKK-9MC_StackingKit_IG_DC68-03859G-00_EN+CFR+MES.indd 1 2022-04-11  9:02:13
