© 2014 Samsung Electronics Co., Ltd. All rights reserved. BN68-06547K-LPR
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model______________ Serial No.______________
E-MANUAL
LED TV
User Manual
Contact SAMSUNG WORLD WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
Comuníquese con SAMSUNG WORLD WIDE
Si desea hacernos alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con nuestro centro de
atención al cliente de SAMSUNG.
Country Customer Care Center Web Site
ARGENTINE 0800-333-3733 www.samsung.com/ar/support
URUGUAY 000-405-437-33 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PARAGUAY 009-800-542-0001 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
BRAZIL 0800-124-421 (Demais cidades e regiões)
4004-0000 (Capitais e grandes centros)
www.samsung.com/br/support
CHILE 800-SAMSUNG(726-7864)
[HHP] 02-24828200
www.samsung.com/cl/support
BOLIVIA 800-10-7260 www.samsung.com/cl/support
COLOMBIA Bogotá 600 12 72
Gratis desde cualquier parte del país 01 8000 112
112 ó desde su celular #SAM(726)
www.samsung.com/co/support
COSTA RICA 0-800-507-7267
00-800-1-SAMSUNG (726-7864)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
DOMINICA 1-800-751-2676 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
ECUADOR 1-800-10-7267
1-800-SAMSUNG (72-6786)
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
EL SALVADOR 800-6225 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
GUATEMALA 1-800-299-0013
1-800-299-0033
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
HONDURAS 800-27919267
800-2791-9111
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
JAMAICA 1-800-234-7267
1-800-SAMSUNG (726-7864)
www.samsung.com/latin/support
NICARAGUA 001-800-5077267 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PANAMA 800-7267
800-0101
www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
PERU 0-800-777-08
Desde celulares por favor llamar al número 336
8686
www.samsung.com/pe/support
PUERTO RICO 1-800-682-3180 www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) www.samsung.com/latin/support (Spanish)
www.samsung.com/latin_en/support (English)
VENEZUELA 0-800-SAMSUNG (726-7864) www.samsung.com/ve/support
[UH5100-PAZL]BN68-06547K-LPRL02.indb 1 2014-07-22 �� 3:52:25
Viewing the Control Panel
The TV’s Controller, a small joy stick like button on the rear right side of the TV, lets you control the TV without the remote control.
Remote control sensor
TV Controller
The image is drawn by facing
the front side of the TV.
Function menu
Return
Selecting the Media Play
Selecting a Source
Power off
Selecting the Menu
✎
The product color and shape may vary depending on the model.
✎
Exits the menu when pressing the controller more than 1 second.
✎
When selecting the function by moving the controller to the up/down/left/right directions, be sure not to press the controller. If you
press it first, you cannot operate it to move the up/down/left/right directions.
Standby mode
Your TV enters Standby mode when you turn it off and continues to consume a small amount of electric power. To be safe and to
decrease power consumption, do not leave your TV in standby mode for long periods of time (when you are away on vacation, for
example). It is best to unplug the power cord.
Setup (Initial Setup)
When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWER
P
button. Set the initial setup following instructions that the TV guides.
✎
Setup is available only when the Source is set to TV.
✎
To start the Setup, enter the password using the remote control. The default password is 0-0-0-0.
✎
Select the proper county. The setup process and TV menu will differ depending on selecting country.
If You Want to Reset This Feature...
O
MENU
m
→ System → Setup → ENTER
E
English - 6
[UH5100-PAZL]BN68-06547K-LPRL02.indb 6 2014-07-22 �� 3:52:26
Making Connections
Connect your TV to an antenna or cable connection, and then connect your peripherals. When done, connect the power cord to the TV,
and then connect the power cord to an AC wall outlet. If you are connecting your TV to a cable or satellite box using HDMI, Component,
or Composite connections, you do not need to connect the ANT IN jack to an antenna or a cable connection.
• For the best picture and audio quality, connect digital devices using an HDMI cable.
• If you connect an external device to the TV that uses an older version of HDMI, the video and audio may not work. If this occurs, ask the manufacturer of the
device about the HDMI version and, if it is out of date, request an upgrade.
• Be sure to purchase a certified HDMI cable. Otherwise, the picture may not display or a connection error may occur.
• PC/DVI AUDIO IN input is not supported.
• For set-top box connection using HDMI cable, we highly recommend you to connect the port.HDMI IN 1(STB)
• For an HDMI to DVI cable connection, you must use the jack. HDMI IN 2(DVI)
• If an HDMI to DVI cable is connected to the port, the audio does not work. HDMI IN 2(DVI)
• For PCs with DVI video out jacks, use an HDMI to DVI cable to connect the DVI out on the PC to the jack on the TV. Use the PC's speakers for HDMI IN 2(DVI)
audio.
• The HDD (Hard Disk Drive) connected to USB is not supported.
VHF/UHF Antenna
Cable
USB
PC connection
(Using a HDMI (to DVI) Cable)
Set-top box / Blu-ray player
HDMI connection
Blu-ray player / DVD
Component connection
VCR
AV connection
TV Rear Panel
✎
The position of port may differ
depending on the model.
or
Digital Audio System
Audio connection
English - 7
[UH5100-PAZL]BN68-06547K-LPRL02.indb 7 2014-07-22 �� 3:52:27
Display Modes (HDMI/DVI Input)
Optimal resolution is 1920 x 1080@60Hz.
Mode Resolution Horizontal Frequency
(KHz)
Vertical Frequency
(Hz)
Pixel Clock Frequency
(MHz)
Sync Polarity
(H / V)
IBM 31.469 70.087 28.322 -/+ 720 x 400
MAC
640 x 480 35.000 66.667 30.240 -/-
832 x 624 49.726 74.551 57.284 -/-
1152 x 870 68.681 75.062 100.000 -/-
VESA DMT
640 x 480 31.469 59.940 25.175 -/-
640 x 480 37.861 72.809 31.500 -/-
640 x 480 37.500 75.000 31.500 -/-
800 x 600 37.879 60.317 40.000 +/+
800 x 600 48.077 72.188 50.000 +/+
800 x 600 46.875 75.000 49.500 +/+
1024 x 768 48.363 60.004 65.000 -/-
1024 x 768 56.476 70.069 75.000 -/-
1024 x 768 60.023 75.029 78.750 +/+
1152 x 864 67.500 75.000 108.000 +/+
1280 x 720 45.000 60.000 74.250 +/+
1280 x 800 49.702 59.810 83.500 -/+
1280 x 1024 63.981 60.020 108.000 +/+
1280 x 1024 79.976 75.025 135.000 +/+
1366 x 768 47.712 59.790 85.500 +/+
1440 x 900 55.935 59.887 106.500 -/+
1600 x 900RB 60.000 60.000 108.000 +/+
1680 x 1050 65.290 59.954 146.250 -/+
1920 x 1080 67.500 60.000 148.500 +/+
✎
NOTE
• The interlace mode is not supported.
• The set might operate abnormally if a non-standard video format is selected.
English - 8
[UH5100-PAZL]BN68-06547K-LPRL02.indb 8 2014-07-22 �� 3:52:27
Changing the Input Source
Source
Use to select TV or other external input sources such as DVD / Blu-ray players / cable box / STB satellite receiver
connected to the TV.
1. Press the SOURCE button on your remote.
2. Select a desired external input source.
■TV / HDMI1 / HDMI2/DVI / AV / Component
✎
In the Source, connected inputs will be highlighted.
✎
PC(D-Sub) input is not supported. If you want to connect PC to the TV, use HDMI2/DVI input.
How to use Edit Name
In the , press the button, and then you can set an external input sources name you want.Source TOOLS
■VCR / DVD / Cable STB / Satellite STB / PVR STB / AV Receiver / Game / Camcorder / PC / DVI PC / DVI Devices / TV / IPTV
/ Blu-ray / HD DVD / DMA: Name the device connected to the input jacks to make your input source selection easier.
✎
When connecting a PC to the port with HDMI cable, you should set the TV to HDMI IN 2(DVI) PC mode under Edit Name.
✎
When connecting a PC to the port with HDMI to DVI cable, you should set the TV to HDMI IN 2(DVI) DVI PC mode under
Edit Name.
✎
When connecting an AV devices to the port with HDMI to DVI cable, you should set the TV to HDMI IN 2(DVI) DVI Devices
mode under Edit Name.
Information
You can see detailed information about the connected external device.
English - 9
[UH5100-PAZL]BN68-06547K-LPRL02.indb 9 2014-07-22 �� 3:52:27
How to View the e-Manual
E-MANUAL
You can find instructions for your TV’s features in the e-Manual in your TV. To use, press the button on E-MANUAL
your remote. Move the cursor using the up/down/right/left buttons to highlight a category, then a topic, and then
press the ENTER
E
button. The e-Manual displays the page you want to see.
You can also access it through the menu:
O
MENU
m
→ Support → e-Manual → ENTER
E
✎
If you want to return to the e-Manual, press the E-MANUAL button on your remote.
✎
You can not use the function if the menu is not activated.Try Now
Screen Display
Basic Features
Changing the Preset Picture Mode
Adjusting Picture Settings
Changing the Picture Options
Changing the Preset Sound Modes
Adjusting Sound Settings
} Index E Enter
e Exit
TV Screen: Displays the program,
movie, video, etc. you are currently
watching.
The category list. Press
l
or
r
button to select the category you
want.
Displays the sub-menu list. Use the
arrow buttons on your remote to
move the cursor.
Press the ENTER
E
button to
select the sub-menu you want.
Operation Buttons:
}
Blue ( ): Displays index screen.Index
E
Enter: Select a category or sub-menu.
e
Exit: Exit the e-Manual.
How to toggle between an e-Manual topic and the corresponding OSD menu(s).
E-MANUAL
Try Now
a Try Now b
Home { Zoom }
Index L Page e Exit
Basic Features > Changing the Preset Picture Mode (1/1)
Picture Mode Standard
•Backlight 10
•Contrast 95
•Brightness 45
•Sharpness 50
•Color 50
•Tint (G/R) G50 R50
✎
This function is not enabled in some menus.
Method 1 Method 2
1. If you want to use the menu that corresponds to an
e-Manual topic, press the red button to select Try Now.
2. To return to the e-Manual screen, press the E-MANUAL
button.
1. Press the ENTER
E
button when a topic is displayed. “Do
you want to execute this?” appears. Select Yes, and then
press the ENTER
E
button. The OSD window appears.
2. To return to the e-Manual screen, press the E-MANUAL
button.
English - 10
[UH5100-PAZL]BN68-06547K-LPRL02.indb 10 2014-07-22 �� 3:52:30
Issues Solutions and Explanations
No Picture, No Video
The TV will not turn on. • Make sure the AC power cord is securely plugged into the wall outlet and the TV.
• Make sure the wall outlet is working.
• Try pressing the button on the TV to make sure the problem is not the remote control. If the TV POWER
turns on, refer to ‘Remote control does not work’ below.
The TV turns off automatically. • Ensure the is set to in the Sleep Timer Off System menu.
• If your PC is connected to the TV, check your PC power settings.
• Make sure the AC power cord is plugged in securely to the wall outlet and the TV.
• When watching TV from an antenna or cable connection, the TV will turn off after 10 - 15 minutes if there is
no signal.
There is no picture/video • Check cable connections. (remove and reconnect all cables connected to the TV and external devices).
• Set your external device’s (Cable/Set top box, DVD, Blu-ray etc) video outputs to match the connections to
the TV input. For example, if an external device’s output is HDMI, it should be connected to an HDMI input
on the TV.
• Make sure your connected devices are powered on.
• Be sure to select the TV’s correct source by pressing the button on the remote control.SOURCE
• Reboot the connected device by reconnecting the device’s power cable.
Antenna(Air / Cable) Connection
The TV is not receiving all channels. • Make sure the coaxial cable is connected securely.
• Please try Setup System Setup (Initial setup) to add available channels to the channel list. Go to MENU - -
(Initial setup) and wait for all available channels to be stored.
• Verify the Antenna is positioned correctly.
No Caption on digital channels. • Check Caption setup menu.
• Some channels may not have caption data.
The picture is distorted: macroblock,
error, small block, dots, pixelization.
• Compression of video contents may cause picture distortion, especially on fast moving pictures such as
sports and action movies.
• A low signal can cause picture distortion. This is not a TV problem.
Others
The picture will not display in full
screen.
• HD channels will have black bars on either side of the screen when displaying up scaled SD (4:3) contents.
• Black bars on Top & Bottom will be shown on movies that have aspect ratios different from your TV.
• Adjust picture size option on your external device or TV to full screen.
English - 13
[UH5100-PAZL]BN68-06547K-LPRL02.indb 13 2014-07-22 �� 3:52:31
Specifications
Environmental Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
50°F to 104°F (10°C to 40°C)
10% to 80%, non-condensing
-4°F to 113°F (-20°C to 45°C)
5% to 95%, non-condensing
Model Name UN40H5100
Display Resolution 1920 x 1080
Screen Size 101 cm
Sound (Output) 10W x 2
Dimensions (W x H x D)
Body
With stand
914.2 x 547.9 x 90.9 mm
914.2 x 586.4 x 196.4 mm
Weight
Without Stand
With Stand
7.0 kg
7.6 kg
✎
Design and specifications are subject to change without prior notice.
✎
The actual appearance of the TV may differ from the images in this manual, depending on the model.
✎
For information about the power supply, and more about power consumption, refer to the label attached to the product.
English - 18
[UH5100-PAZL]BN68-06547K-LPRL02.indb 18 2014-07-22 �� 3:52:32

Produkt Specifikationer

Mærke: Samsung
Kategori: televisión
Model: UN40H5100AH

Har du brug for hjælp?

Hvis du har brug for hjælp til Samsung UN40H5100AH stil et spørgsmål nedenfor, og andre brugere vil svare dig


televisión Samsung Manualer

Samsung

Samsung 75DU7100 Manual

30 Januar 2025
Samsung

Samsung UA55MU7351K Manual

14 Januar 2025
Samsung

Samsung UA50KU7001K Manual

14 Januar 2025
Samsung

Samsung UA65MU7351K Manual

14 Januar 2025
Samsung

Samsung GQ82Q800TGT Manual

12 Januar 2025
Samsung

Samsung GQ49Q87TGT Manual

12 Januar 2025
Samsung

Samsung UE55AU9002K Manual

12 Januar 2025
Samsung

Samsung GQ48S94DAE Manual

10 Januar 2025
Samsung

Samsung LS15S13C Manual

8 Januar 2025
Samsung

Samsung UA60F6100AR Manual

2 Januar 2025

televisión Manualer

Nyeste televisión Manualer

Thomson

Thomson 40FA2S13 Manual

20 Februar 2025
Continental Edison

Continental Edison CELED65SVQLD25B6 Manual

19 Februar 2025
Continental Edison

Continental Edison CELED32SVHD25B6 Manual

19 Februar 2025
TCL

TCL 55P8K Manual

10 Februar 2025
Thomson

Thomson 32FG2S14 Manual

5 Februar 2025
TCL

TCL 85C75B Manual

30 Januar 2025
Philips

Philips 32HFL2889T Manual

15 Januar 2025
Philips

Philips 25CE6270 Manual

15 Januar 2025
Grundig

Grundig st 84 899 dolby Manual

15 Januar 2025
Daewoo

Daewoo dtz 29u7 Manual

15 Januar 2025
