Quick Start Set Up Guide

For information on using the TV’s features, please refer to the Operating Instructions.

Quick & easy guide for setting up your TV

What is included in the box

Using the remote control

Setting up the TV for the  rst time - including attaching the stand

Connecting other devices to the Television

Need help setting up or using your TV?

Please contact the UK & ROI Helpline*

Telephone UK 0330 024 0803 or ROI 01443 3323

Online support at: www.umc-uk.co.uk

Email support at: service@umc-uk.co.uk

*Calls to 0330 numbers are charged at standard call rates and are included as part of any bundled minutes with your

phone provider.

Calls to the ROI number are charged at the local call rate.

The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.

Bank Holidays - 10am to 4pm

Closed Christmas and New Years day

Model Numbers

32BC1IE

40BG1IE

Trademark Sharp

Model ID 32BC1IE 40BG1IE

Energy e ciency class A+

Visible screen size (diagonal) 81 cm / 32 inches 102 cm / 40 inches

On-mode power consumption 31.0 W 45.0 W

Annual energy consumption *1 45 kWh 66 kWh

Standby power consumption *2 <0.50 W

O mode power consumption n/a

Screen resolution 1366 (H) x 768 (V) 1920 (H) x 1080 (V)

*1: Energy consumption XYZ kWh per year, based on the power consumption of the television operating 4

hours per day for 365 days. The actual energy consumption will depend on how the television is used.

*2: When the TV is turned o with the remote control/standby button and no function is active.

Product  che

32BC1IE 40BG1IE

RF 75 ohm Antenna / Analog / DVB / Satellite

Inputs 3 x HDMI, 2 x USB,

1 x RJ45 LAN/Ethernet, 1 x Mini Component/YPbPr,

1 x Mini AV IN - Composite Video/CVBS and L/R Audio shared for Composite Video and

Component/YPbPr

Sound Outputs 1 x Digital Optical Audio output, 1 x 3.5mm Headphone

Speaker*/ Ampli er Watts

(RMS) 2 x 10 / 2 x 8

Voltage and power

consumption

AC 220V ~ 240V; 50Hz

31/45/70W (home mode/standard/max)

(<0.5W in Standby)

AC 220V ~ 240V; 50Hz

45/65/80W (home mode/standard/max)

(<0.5W in Standby)

Dimensions including stand

(mm) 732W x 472H x 179D 921W x 576H x 199D

Net weight (Kgs) 5.3 8.0

Wall Mounting VESA 200 x 200 (mm) VESA 200 x 300 (mm)

*Built-in Harman Kardon speaker systems (Full-range speaker and tweeter).

Win a

Soundbar

online within 14 days of purchase at

www.registertoday.co.uk/sharp

and enter into a prize draw to

SHA/QSW/0113

Harman Kardon is trademark of HARMAN International

Industries, Incorporated, registered in the United States

and/or other countries.

The terms HDMI, HDMI High-De nition Multimedia Interface,

and the HDMI Logo are trademarks or registered trademarks

of HDMI Licensing Administrator, Inc.

Technical Speci cation

Please save your box/packaging as you will need this in the event of warranty/service repair or support. We are

unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your

item in the event of warranty/service repair is in it’s original box/packaging.

Accessories

Included with this TV are the following accessories

What is included in the box

1 x Quick Start Guide

1 x Safety Leaﬂ et 1 x Remote Control

1 x Stand installation pack

2 x AAA Batteries

RF Cable

Additional Accessories

Should you wish to connect older/analogue devices to your television, you can purchase the necessary

cables either from your retailer or at www.umc-uk.co.uk/cables

USB Memory sticks for recording from Freeview TV

Your TV has a built in Personal Video Recording function, meaning you can set up recordings from the TV guide directly onto a

PVR ready USB memory stick. You can also pause live TV and rewind/fast forward through your recordings.

See our great range of tested and compatible PVR ready USB memory sticks at www.umc-uk.co.uk/usb

1 x TV

To receive Freeview channels, in particular Freeview HD channels, you will need a Digital TV aerial and be in a good Freeview

coverage area. You can check coverage for your postcode at www.freeview.co.uk.

Please note that any Freeview HD channels found during tuning will be placed in channel positions above 100. For

example, 101 (BBC1 HD) 102 (BBC2 HD) etc.

Sky Remote Code

If you wish to use your Sky remote to operate the TV’s basic

functions, you will need a Sky remote control (Revision 9 or later)

and you will need to program it with the code 2134. If you wish to

use your Sky Q remote to operate the TV’s basic functions, you will

need to program it with the code 4170.

Using the remote control

789

123

456

GUIDE

VOL CH

SOUR C E

SOUND

PI C TURE

ON /OFF

TEXT

SUBT ITLE

INFO

BACK

FAV

APPS

GO T O

A- B

ANGLE

REPEAT

LI ST

PV R/M E DIA

EXIT

M ENU

Freeview Play

STANDBY - Switch on the TV when in standby or vice versa.

FREEVIEW PLAY - Access the Freeview Play app.

NUMBER BUTTONS - 0–9 to select a TV channel directly.

MUTE - Mute the sound or vice versa.

TV GUIDE - Opens the 7 day TV guide (digital TV mode).

VOL (+/-) - To increase/decrease the sound level.

PICTURE - Scrolls through picture mode options.

SOUND- Scrolls through sound mode options.

SOURCE - To display the input/source menu.

CH (+/-) - To increase or decrease the channel being watched.

MENU - To display OSD menu.

EXIT - To exit all menus.

- Allows you to navigate the on-screen menus and adjust

the system settings to your preference.

BACK - To go back a previous step.

FAV - To display favourites menu.

INFO - Press once for now/next channel information.

- Press twice for information about the current programme.

TEXT - To enter/exit Text.

SUBTITLE - To switch the dialogue at the bottom of the screen (on/off).

TV - To switch to Digital Channels.

YOUTUBE - Access the Youtube App.

NETFLIX - Access the Netﬂ ix App.

APPS - Access the APPS menu.

RECORD - Access the USB record function.

REC LIST - Opens the list of previously recorded items.

GOTO - To go to a speciﬁ c chapter.

A-B - Press once to set point, press a second time to return to point.

ANGLE - Select different angle of DVD.

REPEAT - To repeat playback.

- To restart the current chapter

- To advance forward to the next chapter

- To stop the playback/Eject Disc

(To EJECT the disc press/hold the button for 4 seconds)

- To play in fast rewind mode

- To play in fast forward mode

- To play/pause

Key

For models with integrated DVD players.

For models with PVR Function.

For models with USB Playback.

For models with 3D functions.

1 x Power Cable

Mini Composite/AV Cable

Required if you wish to connect a device with

AV/Composite/CVBS output to the TV’s Mini AV Input

Mini YPbPr Cable

Required if you wish to connect a device with YPbPr/

Component output to the TV’s Mini YPbPr Input

Pr/

Connecting Component/YPbPr - you will need both the Mini YPbPr Cable and the Mini Composite/AV Cable.

The YPbPr cable will be used exclusively for video (red/green/blue) and the AV cable will be used for audio (Red/White while

Yellow stays unconnected).

Connecting Composite/AV - Mini Composite/AV Cable will be enough for both video and sound.

Microsoft PlayReady™

This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this

technology outside of this product is prohibited without the appropriate license(s) from Microsoft.

Content owners use Microsoft PlayReady™ content access technology to protect their intellectual property, including

copyrighted content. This device uses PlayReady technology to access PlayReady-protected content and/or WMDRM-protected

content. If the device fails to properly enforce restrictions on content usage, content owners may require Microsoft to revoke

the device’s ability to consume PlayReady-protected content. Revocation should not a ect unprotected content or content

protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their

content. If you decline an upgrade, you will not be able to access content that requires the upgrade.
