The washer dryer was tested before leaving the factory.

To remove any water left over from testing procedures, the â

first cycle should be carried out without any laundry with

Flusenspülen  programme. aPage 6: Before using for

the first time

Programme selector for switching the

machine on and off and for selecting the

programme. Can be rotated in either

direction.

Detailed programme overview. a



Page 7/8

Sort and load the laundry (drying)

Only dry laundry that is labelled with the following care symbols:

( = tumble-dry at normal heat setting ( ).Trocknen 7

'c= tumble-dry at low heat setting ( ).Schontrocknen 8

The following textiles should not be tumble-dried:

) = do not tumble-dry care symbol.

 Woollens or items containing wool. Risk of shrinking!

 Delicate fabric (silk, synthetic net curtain). Risk of creasing!

 Items containing foam rubber or similar material.

 Items which have been treated with flammable solvents, such as stain

removers, petrol, paint thinners. Explosion hazard!

 Items still containing hair lacquer or similar substances.

Dangerous vapours!

Do not exceed the maximum drying load. aPage 7

Display panel/

Option buttons/

Additional functions

Sort and load the laundry

 Observe the care information provided by the manufacturer.

 Sort according to the information on the care labels.

 Sort according to type, colour, soiling and temperature.

 Remove any foreign objects  risk of rusting.

 Do not exceed the maximum load. aPage 7

 If drying programme selected. aPage 4: Sort and load the laundry (drying)

 Observe the instructions in the Important information section. aPage 6

 Load both large and small items of washing.

 Close the washer dryer door. Take care not to trap any items of clothing between the

loading door and rubber seal.

Add detergent and care product

 Add the appropriate dose according to: Amount of washing, soiling, water hardness

(ask your water supply company) and manufacturers instructions.

 Models without insert for liquid detergent: pour liquid detergent into an appropriate

compartment and place in the drum.

 Use commercially available low foam detergents for washer dryer only.

 During operation: close the detergent drawer!

Correct installation according to separate Installation

and maintenance instructions.

Check the machine

 Never switch on a damaged machine!

 Inform your customer service!

Insert mains plug

With dry hands only!

Take hold of the plug only!

Turn on the tap

 At the end of the drying programme there is an

automatic cleaning fluff process, turn on the water

tap even if a drying programme is selected.

Provide good ventilation

Good ventilation is required to extract air produced

during drying.

 Keep the installation room well ventilated.

 Clean the air inlet filter regularly.

 Do not block the air inlet and/or air outlet.

Compartment II: Detergent for the main wash, water softener,

bleacher, stain remover

Your washer dryer Preparation

Before using for the first time Page 6a

Set and adjust the programme

 Turn the programme selector to desired washing

programme. aPage 7: Programme overview

Use option buttons and additional functions. aPage 9/10

All buttons are sensitive and a gentle touch is adequate!

If you press and hold the °C (Temp.) (Spin) (Finish in),  or  option

buttons, the setting options automatically scroll through.

If washing and drying without interruption is desired (only possible for Koch/Bunt,

Bunt Eco Mix Pflegeleicht, , and ):Intensiv+Schnell

 Activate auto drying function by touching button twice and the 7( )Dry

indicator is on. aPage 9

 Do not exceed the maximum load for the drying function. aPage 7

 Select maximun selectable spin speed of washing programme to ensure the

drying result.

Select Start/Nachlegen

... Washing/Washing + drying

Compartment ~: Fabric softener

Compartment I: Detergent for pre-wash

Intended use

ʋFor domestic use only.

ʋFor the washing of machine-washable fabrics in a detergent

solution.

ʋTo be operated with cold mains water and commercially available

low foam detergents and care products which are suitable for use

in front loaded washer dryer.

 Do not leave children unattended near the washer dryer.

 Keep pets away from the washer dryer!

 The washer dryer is not to be used by children or persons

not familiar with the operating instructions.

 Install and operate the washer dryer in a room with a drain.

 In order to ensure your safety, you must plug the cable into

a socket which has a reliable earth connection.

Removing laundry

Open washer dryer door and remove laundry.

Leave the washer dryer door and detergent drawer open so that any residual

water can evaporate!

Turn off the tap

Not required for Aqua-Stop models. a



Installation maintenance instructions:

Page 9

Switch off

 Set programme selector to ( ).Aus Off

... Drying

Drying

Washing

Washing & Drying without interruption

Set and adjust the drying programme

 Turn the programme selector to or .Trocknen 7Schontrocknenc8

aPage 7: Programme overview



Programme selector

Programme ended when ...

... Start/Reload indicator light goes out and or (if was selected, 

no final spin/drain) appears on the display field, the buzzer sounds.

Set volume of buzzer. aPage 10

If was selected, and is displayed, touch the Start/Nachlegen button.

 The programme continues with draining the water and spinning the laundry

(the default spin speed can be changed in advance).

 If you only want to drain the water, touch the Start/ Nachlegen button again

when the spinning starts. The programme is paused and the door lock is

released. You can remove the laundry.

If appears and drying symbol flashes on the display field high drum 7a

temperature. Cool-down programme is running until drum is cooled down.

If and appears alternately. aPage 11: Information on the display

Change the programme ...

If you have selected the wrong programme by mistake:

 Reselect the washing/drying programme.

 If required, adjust the programme setting and/or select additional functions.

aPage 9/10

 Select Start/Nachlegen.

Pause the programme ...

 Touch the Start/ button.Nachlegen

 Follow the instructions in the display field: when  lights up and appears

in the display, the door can be opened. If required, add/remove a laundry â

item; If and are displayed alternately, the door cannot be opened

due to a high water level in drum or a high temperature.

 Touch /Nachlegen button to continue the programme.Start

 The pause function cannot be activated during drying phase.

... or terminate the programme

Washing programmes with high temperature:

 Cool down laundry: Select , touch Nachlegen.Spülen Start/

Washing programmes at lower temperature:

 Select Schleudern Start, touch/Nachlegen.

Drying programme:

 Select Trocknen Schontrocknen (Dry)7 or 8 7, touch option button,

set 15 minutes drying time, then touch /Nachlegen button.â â Start



Important information



Washing drying preparing/Protecting the laundry and the machine

 Empty pockets.

 Look out for metal items (paperclips, etc.).

 Trousers, knitwear and knitted textiles, e.g. Jersey garments, T-shirts or sweatshirts should

be turned inside out.

 Ensure that underwired bras are machine washable.

 Wash delicates in a net/bag (tights, curtains, underwired bras).

 Fasten zips, do up any buttons.

 Brush sand out of pockets and collars.

 Remove curtain hooks or place curtains in a net/bag.

 Use only tumble-dry textiles if you select drying.

 Before tumble-drying, handwash items should be spun using the appropriate spin speed.

 Remove as much water as possible before tumble-drying. Recommended spin speed for

cottons is more than 1000 rpm; for easy-care is more than 800 rpm.

 In order to ensure uniform drying, sort the items according to fabric type and degree

of drying required.â

 Items which require ironing do not have to be ironed immediately after being tumble-dried.

It is a good idea to fold or roll them together for a while, so that any remaining moisture

is evenly distributed.â

 To achieve good drying performance, dry quilt covers, terry towels or other large textile

items individually. Terry towels not more than 4 pieces (or 3 kg).

Before using for the first time

Do not put any laundry in the washer dryer. Turn on the tap, pour ½ measuring cup of

detergent into compartment II Flusens 40 °C Start. Set the pülen  programme and select/

Nachlegen. At the end of the programme, set the programme selector to Aus.

Laundry with different degrees of soiling

Wash new items separately.

Light Do not prewash.

If required, pretreat stains. Select programme orBunt Eco â

Intensive additional function.

Heavy Load less laundry. Prewash.

If required, pretreat stains. Select programme orBunt Eco â

Intensive additional function.

Soaking Load laundry of the same colour

Pour soaking agent/detergent into according to the manufacturer's compartment II

instructions. Set Koch/Bunt 30 °C programme and selectStart/Nachlegen. After approx. 10

minutes, select Start/ . After the required soaking time, reselect /Nachlegen if Nachlegen Start

the programme is to be continued or change the programme.

Starching Laundry must not be treated with fabric softener

Starching is possible in all wash programmes using liquid starch. Pour the starch into the fabric

softener compartment according to the manufacturer's instructions (if necessary clean it first).

Dyeing/bleaching

Dye should only be used in normal household quantities. Salt may damage stainless steel.

Always follow the dye manufacturer's instructions. bleach laundry in the washing Do not

machine.

Outdoor+Imprägnieren Laundry must not be treated with fabric softener.

Special detergents and impregnating agents suitable for machine washing are available in

sports shops. Dose according to manufacturer's instructions:

1. IIPlace the special detergent for outdoor clothing in compartment and

2. pour impregnating agent (max. 170 ml) into the compartment.~

Move the programme selector to Outdoor+Imprägnieren. Select temperature.

Touch /Start Nachlegen. Final treatment of laundry according to manufacturers instructions.



Start/

Nachlegen

Contents

 

ʋIntended use........................................................................................1

ʋPreparation.......................................................................................1/2

ʋPreparation Washing or Washing+Drying ..............................2/3/4

ʋPreparation Drying......................................................................2/3/4

ʋSet and adjust the programme ................................................3/4/5

ʋAfter washing/drying ..........................................................................5

ʋImportant information.........................................................................6

ʋProgramme overview .........................................................................7

ʋDrying table.......................................................................................... 8

ʋConsumption values ..........................................................................8

ʋDisplay and Option buttons ..............................................................9

ʋAdditional functions and Individual settings ............................... 10

ʋInformation on the display ............................................................. 11

ʋSafety instructions ........................................................................... 11

ʋWhat to do if ...............................................................................12/13

ʋEmergency release ......................................................................... 13

Detergent drawer with

compartments I, II, ~Control panel

Door handle

Service flap

Drum

Air inlet

Air outlet (rear side)

Protection of the environment/

Conservation tips

 Load the maximum amount of laundry to wash or dry for the

particular programme. aPage 7: Programme overview

 Wash normally soiled laundry without prewash.

 Select and additional function Bunt Eco 60°C

Intensive to obtain good cleaning results with significantly

lower energy consumption.

 Dose the detergent according to the manufacturers

instructions and water hardness.

 If the laundry is then to be dried in the appliance, select the

highest selectable spin speed  because the more water that

is spun out of the appliance, the less time and energy isâ

required to dry it.

 Keep the installation room well ventilated, clean the air inlet

filter regularly.

Installation and maintenance instructions. aPage 9

 Please do not dry dripping-wet laundry.

Waste of time and energy!

Congratulations  You have opted for a modern, high-quality

domestic appliance manufactured by SIEMENS. The washer dryer

is distinguished by its economical use of water and energy. â

Each appliance which leaves our factory is inspected thoroughly

to ensure that it functions properly and is in perfect condition.â

For further information about products, accessories, spare parts and

services visit our web site: www.siemens-home.com or contact our

after-sales service centres.

The default drying mode is , in this mode the drying time is â

automatically adjusted to the load amount to obtain cupboard dried

laundry ready to fold and stack in the cupboard. You can change

the drying mode to in order to obtain extra dry laundry, or

time dry and define the drying time by touching the 7 Dry button.

To estimate or select drying duration. aPage 8: Drying table

All buttons are sensitive and a gentle touch is adequate!

If you press and hold the option buttons, theFinish in â

setting options automatically scroll through.

Select Start/Nachlegen

Programme overview (see also the information on page 9,10)



Programmes C° max. load

(kg)â*Type of laundry Additional functions; information

Koch/Bunt :  90 7,0/ 4,0*** Hard-wearing textiles, heat-resistant textiles made of cotton or linen Quick , Less Iron, Water Plus, Rinse Plus, Intensive ,** **

Prewash

Bunt Eco :  60 Hard-wearing textiles made of cotton or linen Less Iron Water Plus Rinse Plus Intensive Prewash, , , ,

Intensiv+Schnell :  60 4,0/4,0*** Hard-wearing textiles made of cotton or blended fabric

Rinse Plus

Time-controlled programme, 60 minutes.

Short programme for normally soiled laundry.

Pflegeleicht :  60

3,5/2,5***

Easy-Care textiles made of cotton, linen, synthetic fibres or blended fabrics Quick Less Iron Water Plus Rinse Plus Prewash, , , ,

Mix :  60 Textiles made of cotton and easy-care textiles

Quick **, Less Iron, Water Plus, Rinse Plus,

Intensive **, Prewash

different types of textiles which can be washed together

Outdoor+

Imprägnieren :  40 2,0

Washing with subsequent waterproofing of all-weather, sportswear and

outdoor clothing, and clothing with a weatherproof membrane, waterproof fab-

rics

Water Plus, , Rinse Plus Intensive

further information on Impregnation; aPage 6

reduced final spin at intervals

Fein/Seide

:  40 2,0

For delicate, washable textiles, e.g.made of silk, satin, synthetic fibres or

blended fabrics

Quick Less Iron Water Plus Rinse Plus Prewash, , , ,

gentle spin between the rinse cycles only

ÿüWolle Hand or machine washable wool or rich-wool textiles

particularly gentle wash programme to prevent shrinkage

of laundry, longer breaks during the programme (fabrics

rest in the detergent solution)

Super 15 Easy-Care textiles made of cotton, linen, synthetic fibres or blended fabrics

Rinse Plus

short programme, approx. 15 minutes, suitable for lightly

soiled laundry

Flusenspülen : , 40, 90 0 Drum clean programme. 90° = antibacterial programme, pour no detergent; 40° = antibacterial programme for use with special

washing machine cleaning detergent; = fluff rinsing programme to remove fluff accumulated in the tub during tumble drying:

Spülen

7,0

Less Iron Water Plus Rinse Plus, ,

Schleudern Washable textiles Less Iron

Abpumpen

Trocknen 74,0 Cotton/coloureds textiles, dry at normal heat setting

Schontrocknen 82,5 Easy care textiles, dry at low heat setting

The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. .Intensive

* Max. load according to EN50229. Values in blue: Max load for drying; Values in black: Max load for washing.

** For Koch/Bunt programme, additional function Quick Intensive and cannot be selected in the same time.

*** If washing and drying without interruption is desired. The subsequent auto dry programme for , and is Intensive Dry, for Koch/Bunt Bunt Eco Intensiv+Schnell Pflegeleicht

and is Gentle Dry.Mix

For further information and a selection of our products

go to our web site: http://www.siemens-home.com

or contact our customer service centres

Siemens Electrogeräte GmbH

Carl -Wery-Str.34

D-81739 Munich/Germany

WD14H440 9000536280

0910

Produkt Specifikationer

Mærke:	Siemens
Kategori:	Vaskemaskine
Model:	WD14H440
Bredde:	590 mm
Dybde:	600 mm
Højde:	842 mm
Vægt:	85000 g
Produktfarve:	Hvid
Indbygget skærm:	Ja
Strøm:	10 A
Ledningslængde:	2.1 m
Energieffektivitetsklasse (gammel):	B
Placering af apparat:	Fritstående
Dørhængsel:	Venstre
Ilægningstype:	Front-læsning
Maksimal centrifugeringshastighed:	1400 rpm
Støjniveau (centrifugering):	73 dB
Støjniveau (vask):	54 dB
Forsinket start-timer:	Ja
Børnesikring:	Ja
Energiforbrug ved vask:	1.19 kWh
Årligt energiforbrug vask:	238 kWh
Døråbningsvinkel:	165 °
Tromle volumen:	56 L
Certificering:	CE, VDE
Vaskeklasse:	A
Årligt vandforbrug vask:	10200 L
Forsinket start (maks.):	24 t
Tørreevne:	4 kg
Vaske kapacitet:	7 kg
Årligt energiforbrug ved vask og tørring:	1134 kWh
Årligt vandforbrug ved vask og tørring:	11400 L
Energiforbrug pr. vask og tørring:	5.67 kWh
Vandforbrug pr. vask og tørring:	57 L
