For technical specificaons,
cerficates and declaraons,
refer to the product web site on:
www.simrad-yachng.com
211 mm (8.29")
197 mm (7.77")
185 mm (7.27") 60 mm
(2.36")
167 mm
(6.58")
80 mm
(3.15")
48 mm
(1.88")
Dimensions
Mounting
SD80
THRUSTER INTERFACE,
INSTALLATION GUIDE
*988-10474-001*
1
System wiring
T T
AD80/
SD80
OPTION
12/24V DC
12/24 V DC
12 V DC
AC70 SI80
1*
NMEA 0183
IN/OUT
COMPASS
GPS
SENSOR
4*
NMEA 0183
IN/OUT
THRUSTER
CONTROL
DRIVE UNIT
5
6
7
4
12/24 V DC
AP70/80
AUTOPILOT
CONTROL
HEAD
32
AP60
Parts included 1
1 * SD80 Computer
1 * Cable retainer
6 * Fixing screws, 3.5 * 19 mm (DIN7981B)
10 * Strips
9 * Connectors
4 * 10 Amp Fuse
1 * Micro-C Drop cable (male)
1 * Micro-C T-Joiner
1
2
3
4
5
6
7
8
5
678
Micro-C CAN bus backbone
SimNet to Micro-C (male) Drop cable
Micro-C Drop cable (female to male)
Micro-C Power cable with 120 Ohm
terminator, female
Micro-C Drop cable, male
Micro-C T-Joiners
Micro-C Terminator, 120 Ohm, male
1
2
3
4
5
6
7
2
4
3
