KD-65X7577H / 65X7500H / 55X7577H / 55X7500H / 49X7500H / 43X7500H
5-013-272-14(1)
Television
Reference Guide
Setting menus are subject to change without notice.
Note
• Before operating the TV, please read the “Safety Information”.
• Read the supplied safety documentation for additional safety
information.
• Instructions about “Installing the TV to the Wall” are included within this
TV’s instruction manual.
• Images and illustrations used in the Setup Guide and this manual are for
reference only and may differ from the actual product.
Location of the identification label
Labels for the TV Model No. and Power Supply rating are located on the
rear of the TV.
For models with supplied AC adapter:
Labels for AC adapter Model No. and Serial No. are located on the bottom
of AC adapter.
Safety Information
Installation/Set-up
Install and use the TV set in accordance with the instructions below in
order to avoid any risk of fire, electric shock or damage and/or injuries.
Installation
• The TV set should be installed near an easily accessible AC power outlet
(mains socket).
• Place the TV set on a stable, level surface to prevent it from falling over
and causing personal injury or property damage.
• Install the TV where it cannot be pulled, pushed, or knocked over.
• Install the TV so that the TV’s Table-Top Stand does not protrude out
from the TV stand (not supplied). If the Table-Top Stand protrudes out
from the TV stand, it may cause TV set to topple over, fall down, and
cause personal injury or damage to the TV.
Transporting
• Before transporting the TV set, disconnect all cables.
• Two or more people are needed to transport a large TV set.
• When transporting the TV set by hand, hold it as shown below. Do not
put stress on the LCD panel and the frame around the screen.
• When lifting or moving the TV set, hold it firmly from the bottom.
• When transporting the TV set, do not subject it to jolts or excessive
vibration.
• When transporting the TV set for repairs or when moving, pack it using
the original carton and packing material.
Topple prevention
(Models with supplied support belt kit)
Refer to the Setup Guide on top of the cushion.
The supplied wood screw is only for affixing to a solid object made of
wood.
About Manuals
This TV comes with the following manuals. Please retain the manuals for future reference.
Setup Guide
• TV installation and setup.
Reference Guide (this manual) / Safety Documentation
• Safety information, remote control, troubleshooting, wall-mount installation, specification,
etc.
Help Guide (On screen Manual)
• Settings, Android TV functions, Internet
connection, troubleshooting, etc.
• To open it, press the HELP button on the
remote control and select Help Guide.
• You can refer to the Help Guide with your
smartphone.
https://rd1.sony.net/help/
tv/ggar1/h_ga/
IMPORTANT – Read the End User Software Licence Agreement
before using your Sony product. Using your product indicates your
acceptance of the End User Software Licence Agreement. The software
licence agreement between you and Sony is available online at Sony
website (http://www.sony.net/tv-software-licenses2/) or on your
product screen. Go to [Settings] t [Device Preferences] t [About] t
[Legal information] t [Sony legal].
(Except models with supplied support belt kit)
KD-65X7577H / 65X7500H
KD-55X7577H / 55X7500H / 49X7500H / 43X7500H
Notice for customer in UAE
Remote Control and TV
The remote control shape, location, availability and
function of remote control buttons may vary
depending on your region/country/TV model.
(Microphone): Use the Google Assistant*1*2 or
voice search*2.
   / / / / : On screen menu navigation and
selection.
TV: Switch to a TV channel or input.
(TV standby)
Number buttons
(dot)
(Text): Display text information.
Google Play / NETFLIX*1*3 / Colour buttons
GUIDE/ : Display the digital programme guide
of TV or TV box*1.
APPS: Display a list of installed apps.
(Input select): Display and select the input
source, etc.
(Quick settings): Display Quick Settings.
BACK
HOME
+/– (Volume)
(Jump)
(Mute)
CH +/–/ / : Select the channel, or next () /
previous () page.
AUDIO*4: Select the sound of multilingual source
or dual sound (depend on programme source).
(Subtitle setting)
HELP: Display the Help menu.
   / / /
EXIT
/ (Info/Text reveal):
Display information.
KD-65X7577H / 65X7500H
KD-55X7577H / 55X7500H / 49X7500H / 43X7500H
(Power)/+/–
Remote Control sensor / LED
*1 Only on limited region/country/TV model/language.
*2 The Google Assistant or voice search requires an Internet
connection.
*3 Installation might be required depending on region/
country.
*4 Accessibility shortcut is available by pressing and holding
AUDIO.
Installing the TV to the Wall
Using the optional Wall-Mount Bracket
(SU-WL450)* (not supplied)
To Customers:
For product protection and safety reasons, Sony
strongly recommends that installation of your TV be
performed by Sony dealers or licensed contractors. Do
not attempt to install it yourself.
To Sony Dealers and Contractors:
Provide full attention to safety during the installation,
periodic maintenance and examination of this
product.
Wall-Mount Bracket Installation Information
This TV’s instruction manual only provides the steps to
prepare the TV for Wall-Mount installation before it is
installed on the wall. For instructions on Wall-Mount
Bracket installation, see the Installation Information
(Wall-Mount Bracket) on the product page for your TV
model.
https://www.sony-asia.com/support
Preparing for Wall-Mount Installation
• Prepare the TV for the Wall-Mount Bracket before
making cable connections.
• Follow the instruction guide provided with the
Wall-Mount Bracket for your model. Sufficient
expertise is required in installing this TV, especially
to determine the strength of the wall for
withstanding the TV’s weight.
• Be sure to entrust the attachment of this product to
the wall to Sony dealers or licensed contractors and
pay adequate attention to safety during the
installation. Sony is not liable for any damage or
injury caused by mishandling or improper
installation.
• The screws for Wall-Mount Bracket are not supplied.
• Only qualified service personnel should carry out
wall-mount installations.
• For safety reasons, it is strongly recommended that
you use Sony accessories, including:
Wall-Mount Bracket SU-WL450
• Be sure to use the screws supplied with the
Wall-Mount Bracket when attaching the Wall-Mount
Bracket to the TV set.
The supplied screws are designed as indicated by
illustration when measured from the attaching
surface of the Wall-Mount Bracket.
The diameter and length of the screws differ
depending on the Wall-Mount Bracket model.
Use of screws other than those supplied may result
in internal damage to the TV set or cause it to fall,
etc.
• Be sure to store the unused screws and Table-Top
Stand in a safe place until you are ready to attach the
Table-Top Stand. Keep the screws away from small
children.
* Only on limited region/country/TV model.
Note
• Place the TV with its screen facing down on a level and stable
surface covered with a thick and soft cloth when removing
the Table-Top Stand from the TV to prevent damaging the
surface of the LCD display. (KD-49X7500H / 43X7500H)
TRA
REGISTERED No: ER75237/19
DEALER No: DA0105422/13
8 mm – 12 mm
M6 screw (not
supplied)
Cord (not supplied)
1.5 N·m
{15 kgf·cm}
Screw (not
supplied)
1.5 N·m
{15 kgf·cm}
Screw (not
supplied)
Cord (not supplied)
M6 screw (not
supplied)
8 mm – 12 mm
MIC
Ȫ
ȫ
Ȭ
ȭ
Ȯ
ȩ
For more information, refer to the
Help Guide.
ȯ Ȱ
ȯȰ
8 mm - 12 mm
Screw (M6)
TV’s rear cover
Wall-Mount Bracket
