3-868-361-25(1)

TFT LCD Color

Computer Display

Operating Instructions

Mode d’emploi

Bedienungsanleitung

Manual de instrucciones

Istruzioni per l’uso

SDM-N50

Owner’s Record

The model and serial numbers are located at the rear of the unit.

Record these numbers in the spaces provided below. Refer to them

whenever you call upon your dealer regarding this product.

Model No. Serial No.

To prevent fire or shock hazard, do not expose the

unit to rain or moisture.

Dangerously high voltages are present inside the

unit. Do not open the cabinet. Refer servicing to

qualified personnel only.

FCC Notice

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

You are cautioned that any changes or modifications not expressly

approved in this manual could void your authority to operate this

equipment.

INFORMATION

This product complies with Swedish National Council for Metrology

(MPR) standards issued in December 1990 (MPR II) for very low

frequency (VLF) and extremely low frequency (ELF).

INFORMATION

Ce produit est conforme aux normes du Swedish National Council

for Metrology de décembre 1990 (MPR II) en ce qui concerne les

fréquences très basses (VLF) et extrêmement basses (ELF).

INFORMACIÓN

Este producto cumple las normas del Consejo Nacional Sueco para

Metrología (MPR) emitidas en diciembre de 1990 (MPR II) para

frecuencias muy bajas (VLF) y frecuencias extremadamente bajas (ELF).

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669)

or write to:

Sony Customer Information Center

1 Sony Drive, Mail Drop #T1-11, Park Ridge, NJ 07656

WARNING

NOTICE

This notice is applicable for USA/Canada only.

If shipped to USA/Canada, install only a UL LISTED/CSA

LABELLED power supply cord meeting the following

specifications:

SPECIFICATIONS

Plug Type Nema-Plug 5-15p

Cord Type SVT or SJT, minimum 3 × 18 AWG

Length Maximum 15 feet

Rating Minimum 7 A, 125 V

NOTICE

Cette notice s’applique aux Etats-Unis et au Canada

uniquement.

Si cet appareil est export* aux Etats-Unis ou au Canada, utiliser

le cordon d’alimentation portant la mention UL LISTED/CSA

LABELLED et remplissant les conditions suivantes:

SPECIFICATIONS

Type de fiche Fiche Nema 5-15 broches

Cordon Type SVT ou SJT, minimum 3 × 18 AWG

Longueur Maximum 15 pieds

Tension Minimum 7 A, 125 V

As an ENERGY STAR Partner, Sony

Corporation has determined that this

product meets the ENERGY STAR

guidelines for energy efficiency.

This monitor complies with the

TCO’95 guidelines.

Declaration of Conformity

Trade Name: SONY

Model No.: SDM-N50

Responsible Party: Sony Electronics Inc.

Address: 1 Sony Drive, Park Ridge, NJ 07656 USA

Telephone No.: 201-930-6972

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Table of Contents

• Macintosh is a trademark licensed to

Apple Computer, Inc., registered in the

U.S.A. and other countries.

• Windows and MS-DOS are registered

trademarks of Microsoft Corporation in

the United States and other countries.

• IBM PC/AT and VGA are registered

trademarks of IBM Corporation of the

U.S.A.

• VESA and DDC are trademarks of the

Video Electronics Standard

Association.

•ENERGY STAR is a U.S. registered

mark.

• All other product names mentioned

herein may be the trademarks or

registered trademarks of their respective

companies.

• Furthermore, “” and “” are not

mentioned in each case in this manual.

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

To enjoy clear sound from the built-in stereo speaker . . . . . . . . . . . 5

Identifying parts and controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Step 1: Connect the media engine to your computer . . . . . . . . . . . 8

Step 2: Connect the display and media engine . . . . . . . . . . . . . . . . 8

Step 3: Connect the power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Step 4: Turn on the monitor and computer . . . . . . . . . . . . . . . . . . . 9

Using the stereo speaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Selecting the input signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Customizing Your Monitor . . . . . . . . . . . . . . . . . . . . . . .11

Navigating the menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Adjusting the contrast (CONTRAST) . . . . . . . . . . . . . . . . . . . . . . . 12

Adjusting the black level of an image (BRIGHTNESS) . . . . . . . . . 12

Eliminating flicker or blurring (PHASE/PITCH) . . . . . . . . . . . . . . . 13

Adjusting the picture position (H CENTER/V CENTER) . . . . . . . . 13

Displaying a low-resolution signal at the actual resolution

(ZOOM). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Adjusting the color temperature (COLOR) . . . . . . . . . . . . . . . . . . . 14

Changing the menu’s position (MENU POSITION) . . . . . . . . . . . . 14

Resetting the adjustments (RESET) . . . . . . . . . . . . . . . . . . . . . . . 15

Additional settings (Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Technical Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Power saving function (user sensor/power saving mode) . . . . . . . 17

Automatic brightness adjustment function (light sensor) . . . . . . . . 18

Automatic picture quality adjustment function . . . . . . . . . . . . . . . . 18

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

On-screen messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Trouble symptoms and remedies . . . . . . . . . . . . . . . . . . . . . . . . . 20

Self-diagnosis function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i

Preset mode timing table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

TCO’95 Eco-document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .i

Precautions

Warning on power connections

• Use the supplied power cord. If you use a different power cord,

be sure that it is compatible with your local power supply.

For the customers in the U.S.A.

If you do not use the appropriate cord, this monitor will not

conform to mandatory FCC standards.

For the customers in the UK

If you use the monitor in the UK, please use the appropriate UK

power cord.

Installation

Do not install or leave the monitor:

• In places subject to extreme temperatures, for example near a

radiator, heating vent, or in direct sunlight. Subjecting the

monitor to extreme temperatures, such as in an automobile

parked in direct sunlight or near a heating vent, could cause

deformations of the casing or malfunctions.

• In places subject to mechanical vibration or shock.

• Near any equipment that generates a strong magnetic field,

such as a TV or various other household appliances.

• In places subject to inordinate amounts of dust, dirt, or sand, for

example near an open window or an outdoor exit. If setting up

temporarily in an outdoor environment, be sure to take

adequate precautions against airborne dust and dirt. Otherwise

irreparable malfunctions could occur.

Handling the LCD screen

• Do not leave the LCD screen facing the sun as it can damage

the LCD screen. Take care when you place the monitor by a

window.

• Do not push on or scratch the LCD screen. Do not place a heavy

object on the LCD screen. This may cause the screen to lose

uniformity or cause LCD panel malfunctions.

• If the monitor is used in a cold place, a residual image may

appear on the screen. This is not a malfunction. The screen

returns to normal as the temperature rises to a normal operating

level.

• If a still picture is displayed for a long time, a residual image

may appear for a while. The residual image will eventually

disappear.

• The LCD panel becomes warm during operation. This is not a

malfunction.

About the bright points of light or black dots

Bright points of light (red, blue or green) or black dots

may appear on the LCD screen. This is not a

malfunction. The LCD screen is made with high-

precision technology and more than 99.99 % of the

picture element is intact. However, some of the picture

element may not appear or some of the picture element

may appear constantly.

Maintenance

• Be sure to unplug the power cord from the power outlet before

cleaning your monitor.

• Clean the LCD screen with a soft cloth. If you use a glass

cleaning liquid, do not use any type of cleaner containing an

anti-static solution or similar additive as this may scratch the

LCD screen’s coating.

• Clean the cabinet, panel, and controls with a soft cloth lightly

moistened with a mild detergent solution. Do not use any type

of abrasive pad, scouring powder, or solvent, such as alcohol or

benzine.

• Do not rub, touch, or tap the surface of the screen with sharp or

abrasive items such as a ballpoint pen or screwdriver. This type

of contact may result in a scratched picture tube.

• Note that material deterioration or LCD screen coating

degradation may occur if the monitor is exposed to volatile

solvents such as insecticide, or if prolonged contact is

maintained with rubber or vinyl materials.

Transportation

• Disconnect all cables from the monitor when transporting.

When you transport this display, grasp the support and base

sections of the display stand firmly with both hands. Also use

both hands when carrying the media engine. If you drop the

monitor, you may be injured or the monitor may be damaged.

• When you transport this monitor for repair or shipment, use the

original carton and packing materials.

Replacement of the fluorescent tube

A specially designed fluorescent tube is installed as the lighting

apparatus for this monitor. If the screen becomes dark, unstable,

or does not turn on, replace the fluorescent tube with a new one.

Consult your Sony dealer when replacing the fluorescent tube.

Disposal of the monitor

•Do not dispose of this monitor with general

household waste.

•The fluorescent tube used in this monitor contains

mercury. Disposal of this monitor must be carried out

in accordance to the regulations of your local

sanitation authority.

The equipment should be installed near an easily accessible

outlet.

Example of plug types

for 100 to 120 V AC for 200 to 240 V AC for 240 V AC only

To adjust the tilt and height

This display can be adjusted within the angles shown below.

To adjust the angles, grasp the lower sides of the LCD panel with

both hands as shown below. Tilt the LCD panel adequately

backward, then lift the LCD panel upward to the desired screen

height, then adjust the screen tilt as desired. When adjusting the

screen height and tilt, proceed slowly and carefully, being sure not

to hit the LCD panel against the desk or the base of the display

stand.

To use the display comfortably

This display is designed so that you can set it up at a comfortable

viewing angle. Adjust the viewing angle of your display

according to the height of the desk and chair, and so that light is

not reflected from the screen to your eyes.

To enjoy clear sound from the built-

in stereo speaker

This monitor has a built-in stereo speaker in base of the display

stand.

We recommend that you position the LCD panel slightly away

from the display stand. High tones from the speaker may be

muffled if the LCD panel is positioned immediately on top of the

stand. Be careful not to drop any metal object into the speaker's

vents as the speakers generate a magnetic field. Also, this

magnetic field may affect data stored on magnetic tapes and discs.

Be sure to keep magnetic recording equipment, tapes, and floppy

discs away from the speaker’s opening.

A duct is provided on the rear part of the display stand to boost the

bass. Be sure not to block the duct with paper or other objects to

ensure clear sound.

90°

40°

50°

Ducts

Keep the LCD panel

slightly away from

the base.

Speaker

Identifying parts and controls

See the pages in parentheses for further details.

11 (Power) switch and indicator (pages 9, 17, 22)

This switch turns the display on and off.

The indicator lights up in green when the monitor is turned on.

The indicator flashes in green and orange when the monitor is

in low power consumption mode, and lights up in orange

when the monitor is in power saving mode.

2Light sensor and user sensor (pages 16, 17, 18)

These sensors measure the brightness of the surrounding area

and detect when a user becomes present in front of the screen.

Be sure not to cover the sensor with papers, etc.

3MENU button (page 12)

This button displays the main menu.

46 (contrast) button (page 12)

This button displays the CONTRAST menu.

58 (brightness) button (page 12)

This button displays the BRITGHTNESS menu.

62 (volume) +/– and M(+)/m(–) buttons

(pages 10, 12)

These buttons display the VOLUME menu and function as

the M(+)/m(–) buttons when selecting the menu items and

making adjustments.

7INPUT and OK button, and indicator (pages 10, 12)

This button selects the INPUT 1 or INPUT 2 (HD15 (RGB)

connectors) video input signal. The input signal and

corresponding input indicator change each time you press this

button.

This button also functions as the OK button when displaying

the menu on the screen.

8Stereo speaker (page 10)

This outputs the audio signals as sound.

9Ducts

These are used to boost the bass sound from the speaker.

0SYSTEM CONNECTOR (page 8)

This connector inputs signals from the media engine when the

display and the media engine are connected with a system

connecting cable.

qa Headphones jack (page 10)

This jack outputs audio signals to the headphones.

INPUT

SYSTEM CONNECTER

LCD display

Front Rear

Media engine

qs AUDIO IN jack (page 10)

This jack inputs audio signals when connecting to the audio

output jack of the computer or other audio equipment.

qd SYSTEM CONNECTOR (TO DISPLAY) (page 8)

This connector outputs signals to the display when the display

and the media engine are connected with a system connecting

cable.

qf HD15 (RGB) input 1 connector (INPUT1) (page 8)

This connector inputs RGB video signals (0.700 Vp-p,

positive) and SYNC signals.

* DDC (Display Data Channel) is a standard of VESA.

qg HD15 (RGB) input 2 connector (INPUT2) (page 8)

This connector inputs RGB video signals (0.700 Vp-p,

positive) and SYNC signals. The pin assignment is the same

as qf.

qh AC IN connector (page 9)

This connector provides AC power to the monitor.

qj AC power switch (page 9)

This switch turns the monitor on and off. When the AC power

switch is turned on, the display automatically turns on.

qk AC power indicator (page 17)

This indicator lights up in green when the media engine is

turned on. The indicator lights up in red when the display is

turned off with the media engine on. The indicator lights up in

orange when the monitor is in the power saving mode.

ql Media engine stand

This stand is used to install the media engine vertically.

Caution

Be sure to install the media engine vertically shown as left. Installing the

media engine lying flat may block ventilation, and may cause a

malfunction.

Pin No. Signal

1 Red

2 Green

(Sync on Green)

3 Blue

4 ID (Ground)

5 DDC Ground*

6 Red Ground

7 Green Ground

8 Blue Ground

9 DDC + 5V*

10 Ground

11 ID (Ground)

12 Bi-Directional Data (SDA)*

13 H. Sync

14 V. Sync

15 Data Clock (SCL)*

SYSTEM CONNECTER

(

TO DISPLAY )

INPUT 1

INPUT 2

AUDIO IN

5 4 3 2 1

678910

1112131415

Setup

Before using your monitor, check that the following accessories

are included in your carton:

• LCD display

• Media engine

• Media engine stand

• Power cord

• System connecting cable (2 m)

(applicable cable type: DP-2)

• HD15 (RGB) video signal cable

• Audio cord (stereo miniplug)

• Macintosh adapter

• Windows Monitor Information Disk/Utility Disk

• Macintosh Utility Disk

• Warranty card

• Notes for Macintosh users

• This instruction manual

Step 1: Connect the media engine

to your computer

Turn off the media engine and computer before connecting.

Note

Do not touch the pins of the video signal cable connector as this might

bend the pins.

xConnecting to an IBM PC/AT or compatible

computer

Connecting to a Macintosh or compatible

computer

* Refer to the supplied “Notes for Macintosh users” for further details.

Step 2: Connect the display and

media engine

Turn off the display and media engine before connecting.

Caution

Be sure to install the media engine vertically shown as above. Installing

the media engine lying flat may block ventilation, and may cause a

malfunction.

Note

Grasp the plug when connecting the cable.

to INPUT1 or

INPUT2 connector

HD15 (RGB) video

signal cable (supplied)

to video output

IBM PC/AT or

compatible computer

IBM PC/AT or

compatible computer

Use the supplied Macintosh adapter.

to INPUT1 or

INPUT2 connector

Macintosh adapter

(supplied)*

HD15 (RGB) video

signal cable (supplied)

to video output

Macintosh or

compatible computer

to SYSTEM

CONNECTOR

of the media

engine

system connecting

cable (2 m) (supplied)

to SYSTEM

CONNECTOR

of the display

Step 3:Connect the power cord

With the media engine, display, and computer switched off,

first connect the power cord to the media engine, then connect it

to a power outlet.

Step 4: Turn on the monitor and

computer

1Turn on the media engine.

The display automatically turns on. The indicators of the

media engine and display light up in green.

2Turn on the computer.

The installation of your monitor is complete. If necessary, use the

monitor’s controls to adjust the picture.

If no picture appears on your screen

• Check that the monitor is correctly connected to the computer.

• Check that the media engine is on.

• If NO INPUT SIGNAL appears on the screen, the computer is

in the power saving mode. Try pressing any key on the

keyboard or moving the mouse.

• If CABLE DISCONNECTED appears on the screen, try

changing the input signal (page 10), and check that the video

input cable is properly connected.

• If OUT OF SCAN RANGE appears on the screen, reconnect

the old monitor. Then adjust the computer’s graphic board so

that the horizontal frequency is between 30 – 61 kHz, and the

vertical frequency is between 48 – 85 Hz (only XGA mode at

75 Hz).

For more information about the on-screen messages, see “Trouble

symptoms and remedies” on page 20.

For customers using Windows 95/98

To maximize the potential of your monitor, install the new model

information ﬁle from the supplied Windows Monitor Information Disk

onto your PC.

This monitor complies with the “VESA DDC” Plug & Play standard. If

your PC/graphics board complies with DDC, select “Plug & Play Monitor

(VESA DDC)” or this monitor’s model name as the monitor type in the

“Control Panel” of Windows 95/98. If your PC/graphics board has

difficulty communicating with this monitor, load the Windows Monitor

Information Disk and select this monitor’s model name as the monitor

type.

For customers using Windows NT4.0

Monitor setup in Windows NT4.0 is diﬀerent from Windows 95/98 and

does not involve the selection of monitor type. Refer to the Windows

NT4.0 instruction manual for further details on adjusting the resolution,

refresh rate, and number of colors.

Adjusting the monitor’s resolution and color number

Adjust the monitor’s resolution and color number by referring to your

computer’s instruction manual. The color number may vary according to

your computer or video board. The color palette setting and the actual

number of colors are as follows:

• High Color (16 bit) t 65,536 colors

• True Color (24 bit) t about 16.77 million colors

In true color mode (24 bit), speed may be slower.

to a power outlet

power cord (supplied)

to AC IN

Using the stereo speaker

You can listen to music, sounds, and other audio files using the

stereo speaker of your monitor.

Connect the AUDIO IN jack to the audio output jack of your

computer or other audio equipment using the supplied audio cord

(stereo miniplug).

Adjusting the volume

Volume adjustments are made using a separate VOLUME menu

from the main menu (page 11).

1Press the +/– buttons.2

The VOLUME menu appears on the screen.

2Press the +/– button to adjust the volume.2

The menu automatically disappears after about 3 seconds.

Using the headphones jack

You can listen to the audio signals from your computer or other

audio equipment using headphones. Connect your headphones to

the headphones jack. The speaker turns off when headphones are

connected to the headphones jack. Adjust the volume of the

headphones using the VOLUME menu.

Notes

• You cannot adjust the volume when displaying the main menu on the

screen.

• When your monitor is in low power consumption mode or power

saving mode, no sound comes from the speaker.

Selecting the input signal

You can connect two computers to this monitor using the INPUT

1 and INPUT 2 connectors. To select one of the two computers,

use the INPUT button.

Press the INPUT button.

The input signal and corresponding input indicator, “1” (INPUT

1) or “2” (INPUT 2) change each time you press this button.

Notes

• You cannot select the input signal when displaying the main menu on

the screen.

• If no signal is input to the selected connector, NO INPUT SIGNAL or

CABLE DISCONNECTED appears on the screen. After a few seconds,

the monitor enters the power saving mode. If this happens, select the

other connector using the INPUT button.

VOL UME

4 0

INPUT

Customizing Your Monitor

You can make numerous adjustments to your monitor using the

on-screen menu.

Navigating the menu

Press the MENU button to display the main menu on your screen.

See page 12 for more information on using the MENU button.

Use the M(+)/m(–) and OK buttons to select one of the following

menus. See page 12 for more information on using the

M(+)/m(–) and OK buttons.

Before making adjustments

Connect the monitor and the computer, and turn them on.

Wait for at least 30 minutes before making adjustments for the

best result.

1PHASE (page 13)

Select the PHASE menu to

adjust the phase when the

characters or pictures appear

fuzzy throughout the entire

screen. Adjust the phase after

adjusting the pitch.

2PITCH (page 13)

Select the PITCH menu to

adjust the pitch when the

characters or pictures are

unclear in some areas of the

screen.

3H CENTER (page 13)

Select the H CENTER menu

to adjust the picture’s

horizontal centering.

PHASE

1 6

EX I T

PHA S E

EX I T

P I T C H

5 0

EX I T

H CENTER

4V CENTER (page 13)

Select the V CENTER menu

to adjust the picture’s vertical

centering.

5ZOOM (page 14)

Select the ZOOM menu to

adjust the picture’s sharpness

according to the input

signal’s aspect ratio or

resolution.

6COLOR (page 14)

Select the COLOR menu to

adjust the color temperature

of the picture. This adjusts

the tone of the screen.

7MENU POSITION

(page 14)

Select the MENU

POSITION to change the on-

screen menu position.

8RESET (page 15)

Select the RESET menu to

reset the adjustments.

9Option (page 15)

Select m (option) menu to

adjust the monitor’s options.

The options include:

• WIDE STEREO

• BASS BOOST

• BACKLIGHT

• LIGHT SENSOR

• POWER SAVE

• USER SENSOR

• LANGUAGE

• MENU LOCK

2 5

EX I T

V C ENT E R

OFF

ZOOM

EX I T

9 3 0 0 K

0 K6 5 0

5 0 0 0 K

USER

AL D J UST

CO LOR

EX I T

MEN NU POS I I OT

EX I T

S CREEN

A L L

R E S ET

EX I T

OF F

W I D E S T E R E O

EX I T

(continued)

Eliminating flicker or blurring

(PHASE/PITCH)

When the monitor receives an input signal, the automatic picture

quality adjustment function of this monitor automatically adjusts

the picture position, phase, and pitch, and ensures that a clear

picture appears on the screen. For more information about this

function, see “Automatic picture quality adjustment function” on

page 18.

For some input signals, this function may not completely adjust

the picture position, phase, and pitch. In this case, you can

manually set these adjustments according the following

instructions. If you manually set these adjustments, they are

stored in memory and automatically recalled whenever the

monitor receives the same input signals.

These settings may have to be repeated if you change the input

signal after reconnecting your computer.

1Set the resolution to 1024 ×

××

× 768 on the computer.

2Load the Utility Disk.

Use the appropriate disk for your computer.

For Windows 95/98

Windows Monitor Information Disk/Utility Disk

For Macintosh

Macintosh Utility Disk

3Start the Utility Disk and display the test pattern.

For Windows 95/98

Click [Utility Disk] t [Windows]/[Utility.exe].

For Macintosh

Click [Utility Disk] t [SONY-Utility].

4Press the MENU button.

The main menu appears on the screen.

5Press the M(+)/m(–) buttons to select (PITCH)

and press the OK button.

The PITCH menu appears on the screen.

6Press the M(+)/m(–) buttons until the screen color

becomes uniform.

Adjust so that the vertical stripes disappear.

7Press the OK button.

The main menu appears on the screen.

If horizontal stripes are observed over the entire screen, adjust

the phase as the next step.

8Press the M(+)/m(–) buttons to select (PHASE)

and press the OK button.

The PHASE menu appears on the screen.

9Press the M(+)/m(–) buttons until the screen color

becomes uniform.

Adjust so that the horizontal stripes are at a minimum.

10 Click [END] on the screen to turn off the test pattern.

To reset the automatic picture quality adjustment

Select SCREEN RESET and activate it using the RESET menu. See

page 15 for more information on using the RESET menu.

Adjusting the picture position

(H CENTER/V CENTER)

If the picture is not in the center of the screen, adjust the picture’s

centering as follows.

These settings may have to be repeated if you change the input

signal after reconnecting your computer.

1Start the Utility Disk and display the test pattern.

Repeat steps 2 and 3 of “Eliminating flicker or blurring

(PHASE/PITCH).”

2Press the MENU button.

The main menu appears on the screen.

3Press the M(+)/m(–) buttons to select (H

CENTER) or (V CENTER) and press the OK

button.

The H CENTER or V CENTER menu appears on the screen.

4Move the picture up, down, left, or right until the

frame at the perimeter of the test pattern

disappears.

Press the M(+)/m(–) buttons to adjust the picture’s

centering using the H CENTER menu for horizontal

adjustment, or the V CENTER menu for vertical

adjustment.

5Click [END] on the screen to turn off the test pattern.

Displaying a low-resolution signal

at the actual resolution (ZOOM)

This monitor is preset at the factory to display pictures on the

screen in full, irrespective of the picture’s mode or resolution.

You can also view the picture at its actual resolution.

1Press the MENU button.

The main menu appears on the screen.

2Press the M(+)/m(–) buttons to select (ZOOM)

and press the OK button.

The ZOOM menu appears on the screen.

3Press the m(–) button to select OFF.

The input signal is displayed on the screen at its actual

resolution.

To display the picture on the screen in full

Select ON in step 3.

Adjusting the color temperature

(COLOR)

The COLOR settings allow you to adjust the picture’s color

temperature by changing the color level of the white color field.

Colors appear reddish if the temperature is low, and bluish if the

temperature is high.

9300K is generally suitable for word processing and other text

oriented applications, and 6500K is generally suitable for video

images.

You can set the color temperature to 5000K, 6500K, 9300K or

user adjustment.

1Press the MENU button.

The main menu appears on the screen.

2Press the M(+)/m(–) buttons to select (COLOR)

and press the OK button.

The COLOR menu appears on the screen.

3Press the M(+)/m(–) buttons to select the desired

color temperature.

The preset color temperatures are 5000K, 6500K, and 9300K.

Since the default setting is 9300K, the whites will change

from a bluish hue to a reddish hue as the temperature is

lowered to 6500K and 5000K.

You can set separate color temperatures for each of the video

input signals.

4If necessary, fine tune the color temperature.

First press the M(+)/m(–) buttons to select ADJUST and

press the OK button. Then press the M(+)/m(–) buttons to

select R (Red) or B (Blue) and press the OK button, and then

press the M(+)/m(–) buttons to adjust the color temperature.

Since this adjustment changes the color temperature by

increasing or decreasing the R and B components with respect

to G (green), the G component is fixed.

If you fine tune the color temperature, the new color setting is

stored in memory for USER ADJUSTMENT and

automatically recalled whenever USER is selected.

The USER ADJUSTMENT setting is common to both the

input signals. If you change the user adjustment setting for

one input signal, the setting for the other input signal is also

changed.

Changing the menu’s position

(MENU POSITION)

You can change the menu position if it is blocking an image on

the screen.

1Press the MENU button.

The main menu appears on the screen.

2Press the M(+)/m(–) buttons to select (MENU

POSITION) and press the OK button.

The MENU POSITION menu appears on the screen.

3Press the M(+)/m(–) buttons to select the desired

position.

There are three positions each for the top of the screen and the

bottom of the screen, and one for the screen center.

R 1 6 8

G 1 7 0

B 1 7 5

EX I T

USE R AD JUST TMEN

Troubleshooting

Before contacting technical support, refer to this section.

On-screen messages

If there is something wrong with the input signal, one of the

following messages appears on the screen. To solve the problem,

see “Trouble symptoms and remedies” on page 20.

If OUT OF SCAN RANGE appears on the screen

This indicates that the input signal is not supported by the

monitor’s specifications. Check the following items.

If “xx.x kHz/xx Hz” is displayed

This indicates that either the horizontal or vertical frequency

is not supported by the monitor’s specifications.

The figures indicate the horizontal and vertical frequencies of

the current input signal. The horizontal frequencies above

100 kHz and the vertical frequencies above 100 Hz are

represented by 99.9 kHz and 99 Hz, respectively.

If “RESOLUTION > XGA” is displayed

This indicates that the resolution is not supported by the

monitor’s specifications.

If NO INPUT SIGNAL appears on the screen

This indicates that no signal is input, or that no signal is input

from the currently selected connector.

INPUT:

This indicates the currently selected connector (INPUT: 1 or

INPUT: 2).

GO TO POWER SAVE

The monitor will enter the power saving mode after about 4

seconds from the message is displayed.

If CABLE DISCONNECTED appears on the screen

This indicates that the video signal cable has been disconnected

from the currently selected connector.

INPUT:

This indicates the currently selected connector (INPUT: 1 or

INPUT: 2).

GO TO POWER SAVE

The monitor will enter the power saving mode after about 4

seconds from the message is displayed.

OUT OF SCAN RANGE

x x . x k H z / x x H z

I NF ORMA T I ON

NO I NP UT S I GNA L

I NPU T : 1

GO TO POWER S AVE

I NFORMAT I ON

CAB L E D I SCONNECT ED

I NPU T : 1

GO TO POWER S AVE

I NFORMAT I ON

Produkt Specifikationer

Mærke:	Sony
Kategori:	overvåge
Model:	SDM-N50

Har du brug for hjælp?

Hvis du har brug for hjælp til Sony SDM-N50 stil et spørgsmål nedenfor, og andre brugere vil svare dig

Dit navn*

Din email*

Skriv dit spørgsmål her

overvåge Sony Manualer

Sony ZRA-BH15D Manual

11 Januar 2025

Sony ZRK-CH15D Manual

3 September 2024

Sony LMD-1420 Manual

2 September 2024

Sony FW-75BZ35F Manual

2 September 2024

Sony PVM-2541A Manual

2 September 2024

2 September 2024

2 September 2024

2 September 2024

2 September 2024

2 September 2024

overvåge Manualer

Nyeste overvåge Manualer

Philips 230V8 Manual

5 Marts 2025

ProDVX UW-24 Manual

5 Marts 2025

Asus ZenScreen MB166CR Manual

27 Februar 2025

Xiaomi Monitor G Pro 27i Manual

21 Februar 2025

LG UltraFine 27UP850K Manual

18 Februar 2025

Hollyland Pyro 7 Manual

11 Februar 2025

Ikan VXF7-HB Manual

11 Februar 2025

ELO Collaboration Tray Manual

11 Februar 2025

Iiyama ProLite TF5039AS Manual

11 Februar 2025

HP E32k G5 Manual

11 Februar 2025
