User’s Manual
VL62T/VL62TW HD-TVI IR Bullet Cameras
Model No. VL62T (VL62TW with White Color)
Video System NTSC
Sensor 1/2.7” Sony CMOS
Numbers of Pixel NTSC: 1928*1088
Resolution 1080P
Lens 3.6mm Lens
Day & Night Color/ B/W / Auto
Dynamic range 69dB
Sync. Internal
Scanning 2:1 Interlace
S/ N Ratio ≥54Db(Max 83.5dB)
Electronic Shutter 1/60(1/50)-1/100000S
White Balance Auto (Range 2200 10000K)
Backlight Compensation Auto/Manual
Gain control Auto/Manual
Gamma Correction 0.45/1.0
Video Output 1V p-p,75 Ω
IR LEDs 12pcs -efficiency LEDs Φ5 Hi
Min. Illumination 0.001Lux (IR LEDs OFF); 0Lux (IR LEDs ON)
IR Distance 49.2~66 ft (depend on scene reflection)
Waterproof IP67
Voltage Input DC12V± 10%
Power Current LED Off: 50mA (Max.); LED On: 120mA(Max.)
Operation Temp. -4°F~122°F
Storage Temp. -13°F~158°F
Humidity Range 20%~90% RH
Dimension 4.37L*2.46W*3.98H
Net Weight 8.8 oz
Technical Specifications:
Feature:
1/2.7” Sony CMOS Sensor
Ultra Hi Resolution 1080P
3.6mm Lens
12pcs -Power IR LEDs Φ5 Hi
DNR igital oise eduction), D-WDR (Digital ide ynamic ange) (D N R W D R
Full OSD Menu Operation optional.
Smart IR Design, sees clearly image from 0.16 ft to 66 ft away
Super Low Power Consumption
Constant Power Current Design ensures utmost lifespan of LEDs and high stability of camera
Color and B/W with IR switching time simultaneously, always make sure to have even and
smooth picture for both Day and Night.
12VDC power supply included
Removable and adjustable sunshield
3Axis Cable Managed Bracket easy for adjusting any direction of installation angle.
IP67 Waterproof for indoor or outdoor use
Available in white or black camera housing
Installation:
To prevent shock or damage to the waterproof body, tighten all screws and cover.
Adjust the sunshield to prevent the lens from direct sunlight.
Do not directly touch the front glass. To clean the dust, wipe with soft cloth with alcohol.
Do not install camera where vibration is present.
Do not install camera where temperature is above 122°F or below -4°F.
Do not expose power or video connection to moisture or water.
If camera is not functioning properly, please power off and contact the manufacturer.
Note: Non-regulated power supply may cause damage to camera.
