Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 2, 2020 11:37 AM
Product Diagram (POEINJ1G90W)
Component Function
1Power LEDs • A is detected.Green: Power Source
• A is not detected.O: Power Source
2PoE LED
• Indicates that the is Amber: PoE Injector
providing power.
• Indicates that the is in idle O: PoE Injector
mode.
3PoE Out Port • Connect a (PD) to the Powered Device PoE
Injector.
4Data Port • Connect a to the Network Switch PoE
Injector.
54-Pin Terminal Block
V1 and V2
• Connect an external (48-56V DC Power Source
DC Input) to the .PoE Injector
6Ground Screw
• Connect a ground connection to the Ground
Screw DC Power Source when connecting a to
the .PoE Injector
Requirements
For the latest requirements, please visit www.startech.com/POEINJ1G90W
• Small Flat Head Screwdriver x 1
• (Optional) Phillips® Head Screwdriver x 1
• (Optional) Writing Utensil x 1
• PoE Powered Device (PD) x 1
• Network Switch x 1
• DC Power Source or Universal Power Adapter with Type N (OD: 5.5 mm, ID: 2.5 mm)
Barrel Connector x 1
90W Industrial Grade Hardened 802.3bt PoE Injector | 1G (1000 Mbps)
• RJ45 Terminated UTP/STP Cat 5e (or better) Network Cable x 2
Powering the PoE Injector
Terminal Block
Connecting and installing the , must be completed by a 4-Wire Terminal Connector
licensed Electrician.
Notes: Make sure that you turn o the power source before connecting the power wire
to the .PoE Injector
Do not exceed the recommend power source voltage as it may result in personal or
product damage.
1. Using a , loosen the two screws (V1 or V2) on the Small Flat Head Screwdriver
4-Wire Terminal Connector (included).
2. Connect the from a (48 - 56V DC), or the provided Power Wires DC Power Source
Barrel Power Connector Adapter, Terminal Block Connectorsto the proper to
the terminals are marked on the . Connect the positive wire to PoE Injector’s Casing
V+ and the negative wire to V-.
3. Tighten the two screws on the .4-Wire Terminal Connector
4. Insert the in the on the 4-Wire Terminal Connector 4-Wire Terminal Block PoE
Injector.
5. To connect a second to the , repeat steps 1 - 4.Power Source PoE Injector
6. Using a , loosen the on the .Phillips Head Screwdriver Ground Screw PoE Injector
7. Connect the from a to the on the Ground Wire DC Power Source Ground Screw
PoE Injector.
8. Using the , tighten the to secure thePhillips Head Screwdriver Ground Screw
Grounding Wire PoE Injectorto the .
(Optional) Barrel Connector
• Connect a from a Type N (OD: 5.5 mm, ID: 2.5 mm) Barrel Connector Universal
Power Adapter Terminal Block to Barrel Power Connector Adapter. to the
Connecting the PoE Injector
Notes: Make sure the total length of the connecting the CAT5e/6 Cable PD Device
to the and the connecting the to the PoE Injector CAT5e/6 Cable PoE Injector
Remote Switch does not exceed 100 meters in total length.
The is compatible with both Power over Ethernet (PoE) and 95W Power PoE Injector
over HDBaseT (PoH).
1 2 34 5 6
