Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 1, 2021 9:14 AM
Product Diagram (USB2004EXT100)
Local Transmitter
Remote Receiver
Component Function
1Status LED (Local) Green: Local Transmitter The is receiving power
2RJ45 Link Port (Local/
Remote)
Connect a (or better) between the Cat5e Cable
Local Transmitter Remote Receiverand
3USB Mini-B Host Port Connect the to the Local Extender Host Computer
using a USB-A to USB Mini-B Cable
4Status LED (Remote)
Red: Remote Receiver The is receiving power but
not linked to the Local Transmitter
Blue: Remote Receiver The is receiving power and
linked to the Local Transmitter
5USB Mini-B Power Port Connect the to the Remote Receiver USB Power
Adapter USB-A to USB Mini-B Cable using a
6USB-A Port Connect to the USB Peripheral Devices Remote
Receiver
4 Port 100m USB 2.0 Extender over CAT5e
Product Information
For the latest product information, technical specications, manuals, and Declarations
of Conformance please visit: www.StarTech.com/USB2004EXT100
Package Contents
Local Transmitter x 1
Remote Receiver x 1
USB-A to USB Mini-B Cables x 2
CAT5e Cable x 1
Universal Power Adapter (NA/JP, EU, UK, ANZ) x 1
Rubber Feet x 8
Quick-Start Guide x 1
Installation
1. Position the near the .Local Transmitter Host Computer
2. Position the near an .Remote Receiver AC Electrical Outlet
3. Connect a (or better) to the on the Cat5e Cable RJ45 Link Port Local Transmitter
and the other end to the on the .RJ45 Link Port Remote Receiver
Note: The cannot go through any networking equipment (router, Cat5e Cabling
switch, etc.).
4. Connect to the on the .USB Devices USB-A Ports Remote Receiver
5. Plug the into the Universal Power Adapter AC Electrical Outlet
6. Connect the to the on the Universal Power Adapter USB Mini-B Power Port
Remote Receiver USB-A to USB Mini-B Cable.using a
7. Connect the to the on the Host Computer USB Mini-B Host Port Local Transmitter
using a USB-A to USB Mini-B Cable.
2 3
1
56
4
2
