Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 28, 2020 8:24 AM
Product Diagram (USB2004EXT2NA)
Front
Rear
Component Function
1USB-A Ports Used to connect (mouse, keyboard, USB Devices
etc.) to the .Remote Extender
2LEDs (Local/Remote)
Power:
Solid Blue: Extenders The are receiving power.
Link:
Solid Green: Extenders The are linked.
O: Extenders The are not linked.
Host:
Solid: Extender Host Computer is linked to the .
Flashing: Extenders are in suspend mode.
Activity:
Flashing: Extenders Data is transmitted between .
O: Extenders are in a suspended mode.
4 Port USB 2.0 Extender over Cat5e, Cat6, or Cat7 | Up to 330 ft (100 m)
3Power Port 24V 1A
(Local/Remote)
Used to connect the to Remote Extender AC
Electrical Outlets, Power Adapter using the
(included).
4Cong Port Used for rmware management/updates.
5Mode Button Used for rmware management/updates.
6RJ45 Port - Link (Local/
Remote)
Used to connect the to the Local Extender Remote
Extender.
Max. data transfer rate = 480Mbps
7USB-B Host Port Used to connect the to a Local Extender Host
Computer USB Cable, using the (included).
Requirements
For the latest requirements, please visit www.startech.com/USB2004EXT2NA
USB Enabled Host Computer
Solid Core Cat5e unshielded twisted pair (UTP) or greater
Installation
1. Position the near the .Local Extender Host Computer
2. Position the near an .Remote Extender AC Electrical Outlet
3. Connect a (or better) to the on the and the Cat5e Cable RJ45 Port Local Extender
other end to the on the .RJ45 Port Remote Extender
Note: The cannot go through any networking equipment (router, Cat5e Cabling
switch, etc.).
4. Connect the (included) to the on the USB Cable USB-B Host Port Local Extender
and the other end to a USB port on the .Host Computer
5. Connect the (included) to the on the Power Adapter Power Port Remote Extender
and the other end to an .AC Electrical Outlet
6. Connect to the on the .USB Devices USB-A Ports Remote Extender
1 2
3 5 6 74
