http://www.supermicro.com MNL-1703-QRG
Board Layout
SuperServer 1028R-MCT Quick Reference Guide
Rear View
CPU Installation
Beep Codes
Front View & Interface
Heatsink Installation
1. Place the heatsink on top of the installed CPU.
2. Align the four screws to the socket.
3. Holding the heatsink in place, screw down as shown
(cross pattern, in order: A, C, B, D).
4. Note: Only use 6-8 lb/f of torque; otherwise, hand-tighten
each screw to avoid damaging the CPU
Memory
Caution
Top iew of DDR4 Slo V t
Release Tab Release Tab
Note: Notch should align
with the receptive ke y
point on the slot.
Notch Notch
Front ie V w
Screw #D
Screw #C
Screw #A
SAFETY INFORMATION
IMPORTANT: See installation instructions and safety warning
before connecting system to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
WARNING:
To reduce risk of electric shock/damage to equipment,
disconnect power from server by disconnecting all power
cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap
CAUTION:
Always be sure all power supplies for this system have
the same power output. If mixed power supplies are
installed, the system will not operate.
For more information go to :
http://www.supermicro.com/support
!
!
!
Description
No.
sSocket Key
CPU Keys
Description
No.
I-SATA0 ~I-SATA5: SATA 3.0 Ports
JBT1: CMOS Clear
JS18: LSI SAS 3108 TFM Connector
CPU2 Slot4 PCI-E 3.0 x8
CPU1 Slot5 PCI-E 3.0 x16
CPU1 Slot6 PCI-E 3.0 x8
P2-DIMME1/P2-DIMMF1 slot
CPU2
P1-DIMMA1/P1-DIMMB1 slot
P2-DIMMG1/P2-DIMMH1 slot
CPU1 (Install CPU1 First)
P1-DIMMC1/P1-DIMMD1 slot
L-SAS 4~7 & L-SAS 0~3: SAS 3.0 Ports
JSD1: SATA DOM (Disk On Module) Power Connector
1
2
3
4
5
6
7
8
9
10
11
12
13
14
12
Beep Code/LED Message Description
1 beep Refresh Ready to boot
5 short beeps + 1 long beep Memory error No memory detected in the system
5 beeps No Con-In
or No Con-
Out devices
Con-In includes USB or PS/2 keyboard,
PCI or Serial Console Redirection, IPMI KVM or SOL.
Con-Out includes Video Controller, PCI or Serial
Console Redirection, IPMI SOL.
1 beep per device Refresh 1 beep or each USB device detected
Screw #B
1
2
3
4
5
6
7
8
FHHL PCI-E Expansion Slot (CPU1)
UID
10Gb LAN3/LAN4 Ports
1Gb LAN1/LAN2 Ports
USB Port 0/1 (3.0)
Dedicated LAN for IPMI
VGA Port
Single Power Supply Module
UID
LEDPWR
LEDBMC
FAN6
FAN5
FANB
FAN2
FAN3
FAN4
JIPMB1
JNVI2C1
JVRM2
JPTG1
JPB1
JPF1
JPF2
JPG1
JBR1
JPME2
JI2C1
JI2C2
JPS1
JPL2
JPL1
JVRM1
JWD1
J24
JS18
JF1
JPWR2
JL1
J21
JPI2C1
JPS7
SP1
BT1
JLAN3
JU DB1
JSD1
JS1
JSTBY1
I-SG PIO1
I-SG PIO2
J25
JTPM1
JBT1
PCI-E 3.0 X8
CPU2 SLOT4
CPU1 SLOT5 PCI-E 3.0 X16
CPU1 SLOT6 PCI-E 3.0 X8
JD1
CPU1
CPU2
1 2 3 4 5 6 7 8 109
14 1113
Pro o a their Co o M escess rs nd rresponding Mem ry odul
CPU# Corresponding DIMM Modules
CPU 1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1
CPU 2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1
Pro or a o M e for ti l P o ncecess nd Mem ry odul Popul ionat Op ma erf rma
Number of
CPUs+DIMMs (For memory to work properly, please follow the instructions below.)
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
Power Button
Reset Button
UID Button
Power LED
Device Activity LED
LAN1 LED & LAN2 LED
Information LED
Hard Drive Signal
Hard Drive Fail
DescriptionNo.
89
1
2
3
4
5
6
7
8
9
123
4567
HDD 1 HDD 3 HDD 5
HDD 0 HDD 2 HDD 4 HDD 6 HDD 7
18 7 46 25 3
Rev. 1.0a
Populating RDIMM/LRDIMM DDR4 Memory Modules
Type
Ranks
Per DIMM
and Data
Width
DIMM Capacity
(GB)
Speed (MT/s); Voltage (V); Slots per Channel (SPC) and
DIMMs per Channel (DPC)
1 Slot per Channel
1 DPC
E5-2600 V3 E5-2600 V4
4 GB 8 GB 1.2 V 1.2 V
RDIMM SRx4 8 GB 16 GB 2133 2400
RDIMM SRx8 4 GB 8 GB 2133 2400
RDIMM DRx8 8 GB 16 GB 2133 2400
RDIMM DRx4 16 GB 32 GB 2133 2400
LRDIMM QRx4 32 GB 64 GB 2133 2400
LRDIMM 3DS 8Rx4 64 GB 128 GB 2133 2400
