http://www.supermicro.com MNL-1713-QRG
Board Layout
SuperServer 6018R-TDTP Quick Reference Guide
Rear View
Power Button
Reset Button
Power LED
Device Activity LED
LAN1 LED & LAN2 LED
Information LED
Hard Drive Signal
Hard Drive Fail
Description
No.
CPU Installation
Beep Codes
Front View & Interface
Heatsink Installation
1. Place the heatsink on top of the installed CPU.
2. Align the four screws to the socket.
3. Holding the heatsink in place, screw down as shown
(cross pattern, in order: A, C, B, D).
4. Note: Only use 6-8 lb/f of torque; otherwise, hand-tighten
each screw to avoid damaging the CPU
Memory
Caution
HDD 0 HDD 1 HDD 2 HDD 3
78
1
2
3
4
5
6
7
8
SAFETY INFORMATION
IMPORTANT: See installation instructions and safety warning
before connecting system to power supply.
http://www.supermicro.com/about/policies/safety_information.cfm
WARNING:
To reduce risk of electric shock/damage to equipment,
disconnect power from server by disconnecting all power
cords from electrical outlets.
If any CPU socket empty, install protective plastic CPU cap
CAUTION:
Always be sure all power supplies for this system have
the same power output. If mixed power supplies are
installed, the system will not operate.
For more information go to :
http://www.supermicro.com/support
!
!
!
Description
No.
sSocket Key
CPU Keys
DescriptionNo.
123456
Beep Code/LED Message Description
1 beep Refresh Ready to boot
5 short beeps + 1 long beep Memory error No memory detected in the system
5 beeps No Con-In
or No Con-
Out devices
Con-In includes USB or PS/2 keyboard,
PCI or Serial Console Redirection, IPMI KVM or SOL.
Con-Out includes Video Controller, PCI or Serial
Console Redirection, IPMI SOL.
1 beep per device Refresh 1 beep or each USB device detected
1
2
3
4
5
6
7
8
9
FHHL PCI-E Expansion Slot (CPU1)
UID
VGA Port
10Gb SFP+ LAN Port 2
10Gb SFP+ LAN Port 1
USB 2.0 Ports
COM1 Port
Dedicated LAN for IPMI
Power Supply Module
Top iew of DDR4 Slo V t
Release Tab Release Tab
Note: Notch should align
with the receptive ke y
point on the slot.
Notch Notch
Front ie V w
Pro o a their Co o M escess rs nd rresponding Mem ry odul
CPU# Corresponding DIMM Modules
CPU 1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 P1-DIMMD1
CPU 2 P2-DIMME1 P2-DIMMF1 P2-DIMMG1 P2-DIMMH1
Pro or a o M e for ti l P o ncecess nd Mem ry odul Popul ionat Op ma erf rma
Number of
CPUs+DIMMs (For memory to work properly, please follow the instructions below.)
1 CPU &
2 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1
1 CPU &
4 DIMMs
CPU1
P1-DIMMA1/P1-DIMMB1, P1-DIMMC1/P1-DIMMD1
2 CPUs &
4 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1, P2-DIMME1/P2-DIMMF1
2 CPUs &
6 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1
2 CPUs &
8 DIMMs
CPU1 + CPU2
P1-DIMMA1/P1-DIMMB1/P1-DIMMC1/P1-DIMMD1, P2-DIMME1/P2-DIMMF1/P2-
DIMMG1/P2-DIMMH1
Screw #B
Screw #D
Screw #A
Screw #C
1
2
3
4
5
6
7
8
9
10
11
12
CPU1 Slot6 PCI-E 3.0 x8
P2-DIMMG1 slot
P2-DIMMH1 slot
CPU2
P2-DIMME1 slot
P2-DIMMF1 slot
P1-DIMMA1 slot
P1-DIMMB1 slot
CPU1 (Install CPU1 First)
P1-DIMMD1 slot
P1-DIMMC1 slot
I-SATA 0~5: SATA 3.0 Ports supported by Intel PCH (I-SATA 0~5)
139 6 48 27 5
CLOSE 1st
OPEN 1st
JBAT1
X10DRD-LTP
I-SATA5
I-SATA4I-SATA0
I-SATA1 I-SATA3
I-SATA2
JSTBY1
JL1
FAN3
FAN7
FAN8
FAN5
FAN6
I-SGPIO2
I-SGPIO1
JTPM1
JPWR1
JPWR3
JF1
JPI2C1
JPL1
JI2C2
JWD1JI2C1JPG1
LED3
LEDM1
LED1
LED4
LED5
LED6
JUIDB1
SP1
J1_SFP1
J1_SFP2
P2-DIMMG1
P2-DIMMH1
P1-DIMMC1
P1-DIMMB1
P1-DIMMD1
P1-DIMMA1
PMI_LAN
COM1
COM2
USB4/5
CPU1
CPU1 SLOT6 PCI-E 3.0 X8
VGA
USB2/3 USB0/1
USB6
JPWR2
FAN2
FAN1
FAN4
P2-DIMMF1
P2-DIMME1
JPB1
CPU2
PCH
BMC
AST2400
BIOS
(CPU1 required
)
CLOSE 1st
OPEN 1st
JIPMB1
SFP2
LAN2 LAN1
3
5
10 9 7
12
1
6
2
8
4
11
Rev. 1.0a
Populating RDIMM/LRDIMM DDR4 Memory Modules
Type
Ranks
Per DIMM
and Data
Width
DIMM Capacity
(GB)
Speed (MT/s); Voltage (V); Slots per Channel (SPC) and
DIMMs per Channel (DPC)
1 Slot per Channel
1 DPC
E5-2600 V3 E5-2600 V4
4 GB 8 GB 1.2 V 1.2 V
RDIMM SRx4 8 GB 16 GB 2133 2400
RDIMM SRx8 4 GB 8 GB 2133 2400
RDIMM DRx8 8 GB 16 GB 2133 2400
RDIMM DRx4 16 GB 32 GB 2133 2400
LRDIMM QRx4 32 GB 64 GB 2133 2400
LRDIMM 3DS 8Rx4 64 GB 128 GB 2133 2400
