Side 1/17

Data sheet acquired from Harris Semiconductor

SCHS195C

Features

• Simultaneous and Independent Read and Write

Operations

• Expandable to 512 Words of n-Bits

• Three-State Outputs

• Organized as 4 Words x 4 Bits Wide

• Buered Inputs

• Typical Read Time = 16ns for ’HC670 V

CC = 5V, CL =

15pF, TA = 25oC

• Fanout (Over Temperature Range)

- Standard Outputs . . . . . . . . . . . . . . . 10 LSTTL Loads

- Bus Driver Outputs . . . . . . . . . . . . . 15 LSTTL Loads

• Wide Operating Temperature Range . . . -55oC to 125oC

• Balanced Propagation Delay and Transition Times

• Signiﬁcant Power Reduction Compared to LSTTL

Logic ICs

• HC Types

- 2V to 6V Operation

- High Noise Immunity: NIL = 30%, NIH = 30% of VCC

at VCC = 5V

• HCT Types

- 4.5V to 5.5V Operation

- Direct LSTTL Input Logic Compatibility,

VIL= 0.8V (Max), VIH = 2V (Min)

- CMOS Input Compatibility, Il ≤µ1 A at V

OL, VOH

Description

The ’HC670 and CD74HCT670 are 16-bit register files

organized as 4 words x 4 bits each. Read and write address

and enable inputs allow simultaneous writing into one location

while reading another. Four data inputs are provided to store

the 4-bit word. The write address inputs (WA0 and WA1)

determine the location of the stored word in the register.

When write enable ( WE) is low the word is entered into the

address location and it remains transparent to the data. The

outputs will reflect the true form of the input data. When (WE)

is high data and address inputs are inhibited. Data acquisition

from the four registers is made possible by the read address

inputs (RA1 and RA0). The addressed word appears at the

output when the read enable ( RE) is low. The output is in the

high impedance state when the ( RE) is high. Outputs can be

tied together to increase the word capacity to 512 x 4 bits.

Pinout

CD54HC670

(CERDIP)

CD74HC670, CD74HCT670

(PDIP, SOIC)

TOP VIEW

Ordering Information

PART NUMBER

TEMP. RANGE

(o C) PACKAGE

CD54HC670F3A -55 to 125 16 Ld CERDIP

CD74HC670E -55 to 125 16 Ld PDIP

CD74HC670M -55 to 125 16 Ld SOIC

CD74HC670MT -55 to 125 16 Ld SOIC

CD74HC670M96 -55 to 125 16 Ld SOIC

CD74HCT670E -55 to 125 16 Ld PDIP

CD74HCT670M -55 to 125 16 Ld SOIC

CD74HCT670MT -55 to 125 16 Ld SOIC

CD74HCT670M96 -55 to 125 16 Ld SOIC

NOTE: When ordering, use the entire part number. The sufﬁx 96

denotes tape and reel. The sufﬁx T denotes a small-quantity reel of

250.

RA1

RA0

GND

VCC

WA0

WA1

January 1998 - Revised October 2003

CAUTION: These devices are sensitive to electrostatic discharge. Users should follow proper IC Handling Procedures.

CD54HC670, CD74HC670,

CD74HCT670

High-Speed CMOS Logic

4x4 Register File

[ /Title

(CD74H

C670,

CD74H

CT670)

/Subject

(High-

Speed

CMOS

Logic

4 x4 Reg-

ister

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	CD74HCT670E
Type:	Logisk kredsløb
Bredde:	19.69 mm
Dybde:	6.6 mm
Højde:	4.57 mm
Antal pr. pakke:	25 stk
Pakkedybde:	506 mm
Pakkebredde:	13.97 mm
Pakkehøjde:	11.23 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-55 - 125 °C
Pakketype:	PDIP
Antal stifter:	16
Bredde (med stifter):	19.69 mm
Højde (med stifter):	8.26 mm
Dybde (med stifter):	10.92 mm
