SNx4HCT273 Octal D-Type Flip-Flops With Clear

1 Features

• Operating voltage range of 4.5 V to 5.5 V

• Outputs can drive up to 10 LSTTL loads

• Low power consumption, 80 µA maximum ICC

• Typical tpd = 12 ns

• ±4 mA output drive at 5 V

• Low input current of 1 µA maximum

• Inputs are TTL-voltage compatible

• Contain eight D-type flip-flops

• Direct clear input

2 Applications

• Buffer or storage registers

• Shift registers

• Pattern generators

3 Description

These devices are positive-edge-triggered D-type flip-

flops with a common enable input. The ’HCT273

devices are similar to the ’HCT377 devices, but

feature a common clear enable (CLR) input instead

of a latched clock.

Device Information(1)

PART NUMBER PACKAGE BODY SIZE (NOM)

SN74HCT273DW SOIC (20) 12.80 mm × 7.50 mm

SN74HCT273DB SSOP (20) 7.20 mm × 5.30 mm

SN74HCT273N PDIP (20) 25.40 mm × 6.35 mm

SN74HCT273NS SO (20) 15.00 mm × 5.30 mm

SN74HCT273PW TSSOP (20) 6.50 mm × 4.40 mm

(1) For all available packages, see the orderable addendum at

the end of the data sheet.

Logic Diagram, (postive logic)

Logic Diagram, Each Flip Flop (positive logic)

SN54HCT273, SN74HCT273

SCLS068F – NOVEMBER 1988 – REVISED FEBRUARY 2022

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. PRODUCTION DATA.

Produkt Specifikationer

Mærke:	Texas Instruments
Kategori:	Ikke kategoriseret
Model:	SN74HCT273N
Type:	Logisk kredsløb
Bredde:	26.92 mm
Dybde:	6.6 mm
Højde:	4.57 mm
Antal pr. pakke:	20 stk
Pakkedybde:	506 mm
Pakkebredde:	13.97 mm
Pakkehøjde:	11.23 mm
Opbevaringstemperatur (T-T):	-65 - 150 °C
Driftstemperatur (T-T):	-40 - 85 °C
Pakketype:	PDIP
Antal stifter:	20
Bredde (med stifter):	26.92 mm
Højde (med stifter):	8.26 mm
Dybde (med stifter):	10.92 mm
