Installation Guide

Connection

Unmanaged Desktop PoE+ Switch

PC Note:

1. PoE ports can also connect to non-PoE devices, but only transmit data.

2. DS106P can supply up to 30 W for each PoE port and 67 W for all PoE ports.

3. DS111P can supply up to 30 W for each PoE port and 65 W for all PoE ports.

4. DS111P has three uplink ports, which typically connect to uplink devices like routers.

Uplink 1 is an SFP slot and works with a 1000 Mbps SFP module. Uplink 2 and uplink 3

are RJ45 ports.

Link/Act

On: Link present but no activity

Flashing: Transmitting/receiving data

O: No link

PoE Status

On: Providing PoE power

Flashing: Current-overload/ Short-circuit

O: Not providing PoE power

Power

On: Power on

O: Power o

LED Explanation

DC Power Adapter

AC Power Cord

Switches Explanation

Note: Images may dier from your actual product. For simplicity, we will take DS111P for example throughout the Guide.

O: Ports run at 10/100 Mbps and support PoE power supply up to 100 m away.

On: Ports run at 10 Mbps and support PoE power supply up to 250 m away.

Extend (For DS106P/DS111P)

PoE MAX

DS106P

O: Total power supply < 60 W

On: 60 W ≤ Total power supply < 67 W

Flashing: Total power supply ≥ 67 W

DS111P

O: Total power supply < 58 W

On: 58 W ≤ Total power supply < 65 W

Flashing: Total power supply ≥ 65 W

O: The PoE Auto Recovery function is disabled.

On: The switch will constantly detect the working status of a PoE powered device (PD). When

the switch nds that the PD works abnormally, the switch will reboot it.

Recovery (For DS106P/DS111P)

O: Ports can transmit data with each other.

On: Specc ports cannot transmit data with other downlink ports. They can transmit data

only with the uplink ports.

Isolation (For DS111P)

O: All the ports transmit data with the same priority.

On: The specic ports transmit data with a higher priority than other ports. When congestion

occurs, packets which are transmitted by the ports with higher priority occupy the whole

bandwidth.

Priority (For DS106P)

Note: The numbers in brackets indicate the ports where the feature takes eect. For example, when Extend(1-4) is toggled to On, the Extend mode will be enabled for ports 1-4.

PoE Ports (1-8)

IP Camera AP IP Phone

Powered Device (PD)

Router

LAN Port WAN Port

Internet
